Summary of Contents for Grizzly PSJ-VZ58 gen3 OEM
-
Page 2: Table Of Contents
Content: 1. GEN.3 updates overview 2. General information 3. Functions overview 4. Technical parameters 5. PSJ installation 6. Fire modes and programming 7. Troubleshooting 8. Package contents OEM version Products with OEM indicate is determined for experts. The lower price is compensated by absence of packaging, extensive manual and some universal accessories. -
Page 3: Technical Parameters
3.2. Rate of fire • allows you to set delay between the two following shots • allows smooth rate of fire setting • programmable by trigger (see figure 6.2.) 3.3. Special functions • default settings reset: You can simply reset all settings to their default values by trigger (see figure 6.2.) •... -
Page 4: Psj Installation
5. PSJ-VZ58 installation ! PSJ-VZ58 gen.2 should be installed by specialists only ! Advanced knowledge of AEG replicas is. Also basics in electronics and soldering skills are needed. Never use soldering gun! Manufacturer takes no responsibility for damaged caused by unprofessional installation! 5.1. - Page 5 5.3. Recommended soldering wiring Pict.3: Example of soldering for OEM version. 5.4. Preparation For PSJ-VZ58 installation take gearbox out of your replica and remove original processor unit. To remove the unit must be removed also the selector plate. Pict.4: Removed gearbox from the replica without original processor unit...
- Page 6 5.5. Heat-conductive foil On both transistors stick enclosed heat-conducting foils. Foils are self-adhesive, is necessary to remove protective foil from them - from both sides. Pict. 5: Removing the protective foils from the heat-conducting foils and their placing, gearbox check 5.6.
- Page 7 Everything was tested on more guns but may happen that the ARES manufacturer changes gearbox or dimensions of plate without notice. This situation will be necessary to deal with the GRIZZLY manufacturer. Pict. 8: Checking the settings of magnets for „cut-of lever“ and hall probe...
- Page 8 „auto“. Everything was tested on more guns but may happen that that the ARES manufacturer changes gearbox or dimensions of plate without notice. This situation will be necessary to deal with the GRIZZLY manufacturer. Pict. 9: Checking the settings of selector plate’s magnet with the probe hall 5.10.1 Magnet installation on the trigger...
- Page 9 5.10.2 Magnet installation on the trigger The checking is very simple: LED must flash when you push the trigger Exact notification of trigger: Free trigger - LED doesn’t light Pushed trigger (firing) - LED lights Pict. 11: Notifications of the trigger by using LED 5.11.
-
Page 10: Fire Modes And Programming
6. Fire modes and programming 6.1. Preset modes Selector on semi: Selector on auto: Semi Burst / Auto Semi Auto Semi Semi Semi Burst only Burst only Auto Burst only Burst / Auto 6.2. Unit programming For programming, connect a battery and within 5 seconds pull and hold the trigger for another 5 seconds. Entering is confirmed by the motor vibrating twice. -
Page 11: Troubleshooting
If your installation is unsuccessful, you can opt to send your replica to our installation and repair center. Please notify us by email to shop@grizzlyairsoft.com Address to ship your replica to: Grizzly Airsoft, Zizkova 84/7, 682 01 Vyskov, Czech Republic... -
Page 12: Package Contents
8. Package content • processor unit PSJ gen.3 • pre-installed insulation foil • heat conducting foil • magnets WARNING: PSJ should be installed by qualified AEG professionals only! Manufacturer is not liable for any damage on the replica caused by unprofessional installation. Do not use soldering gun!
