T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPT AND MAIN APPLICATIONS
Models HP1640, HP1640F, HP1641, HP1641F have been developed
as the successor models to the current HP1620 series models, featuring
renewed external appearance.
Listed below are the differences among the four models.
Model No.
Drill chuck type
HP1640
HP1640F
HP1641
Keyless
HP1641F
Keyless
These models are also available with plastic carrying case as "K" models;
HP1640K, HP1640FK, HP1641K, HP1641FK
S
pecification
Voltage (V)
110
110/ Taiwan
120
220
230
240
Specifications
No load speed: min
Impacts per min: min
Chuck type
Chuck capacity: mm (")
Capacities: mm (")
Variable speed control by trigger
Reversing switch
LED job light
Protection against electric shock
Power supply cord: m (ft)
Net weight: kg (lbs)
S
tandard equipment
Chuck key S-13 ........................ 1 (HP1640/ HP1640F only)
Key holder ................................. 1 (HP1640/ HP1640F only)
Side grip .................................... 1
Depth gauge .............................. 1
Plastic carrying case ................. 1 ("K" models only)
Note: The standard equipment for the tool shown above may differ by country.
O
ptional accessories
Drill bits
Keyless drill chuck set
Drill chuck set
Side handle set
HP1640, HP1640F, HP1641, HP1641F
Hammer Drill 16 mm (5/8")
LED job light
Keyed
No
Keyed
Yes
No
Yes
Cycle (Hz)
Current (A)
6.5
50/60
5.6
50/60
6.0
50/60
50/60
3.3
50/60
3.1
50/60
3.0
Model No.
HP1640/ HP1640F
= rpm
-1
= ipm
-1
Keyed chuck
Concrete
Steel
Wood
Type 43 drill stand
Chuck key S-13 (HP1640/ HP1640F only)
Depth gauge
Blow-out bulb
Continuous Rating (W)
Input
680
590
---
680
680
680
HP1641/ HP1641F
0 - 2,800
0 - 44,800
Keyless chuck
1.5 - 13 (1/16 - 1/2)
16 (5/8)
13 (1/2)
30 (1-3/16)
Yes
Yes
No/ Yes
No/ Yes
Double insulation
2.0 (6.6)*
1.8 (4.0)
L
W
H
HP1640/ HP1640F
Dimensions: mm (")
Length (L)
Width (W)
Height (H)
Max. Output (W)
Output
380
340
380
400
400
400
*Taiwan: 5m, Argentine: 2.5m
PRODUCT
P 1/ 7
HP1641/ HP1641F
303 (11-7/8)
72 (2-13/16)
222 (8-3/4)
500
500
500
600
600
600
