- Page 1 Fuj i t su 3. 2 TB Fl a s h Acc e l e r at o r Card User ' s Gui d e For Pr o duct Model s 7119601 and 7119603 Fujitsu 3.2 TB Flash Accelerator Card...
-
Page 2: Preface
Keep this manual in a safe and convenient location for quick reference. Fujitsu makes every effort to prevent injury to users and bystanders as well as property damage. Be sure to use the product in accordance with the instructions in this manual. - Page 3 Trademark indications (TM, (R)) are omitted for some system and product names in this document. This document shall not be reproduced or copied without the permission of Fujitsu Limited. All Rights Reserved, Copyright (C) Fujitsu Limited 2018, 2019 Organization and Contents of This Manual This document consists of the following chapters and appendixes.
- Page 4 This chapter describes how to configure the Fujitsu 3.2 TB Flash Accelerator Card. Appendix A Precautions and Restrictions This appendix describes precautions and restrictions on the Fujitsu 3.2 TB Flash Accelerator Card. Appendix B Specifications This appendix shows the specifications of the Fujitsu 3.2 TB Flash Accelerator Card.
- Page 5 Ask a certified service engineer or our sales representative to perform the following tasks for this product and the optional products provided by Fujitsu. The work must not be done by the customer under any circumstances. Otherwise, electric shock, injury, or fire may result.
-
Page 6: Product Handling Precautions
Ask a certified service engineer or our sales representative to perform the following tasks for this product and the optional products provided by Fujitsu. The work must not be done by the customer under any circumstances. Otherwise, electric shock, injury, or fire may result. -
Page 7: Table Of Contents
A.4 LBA Format Precaution …………………………………………………………………… …………………………………………………… A.5 Precaution on OS Boot From FCode A.5.1 Workaround A.5.2 Corrective Action After Occurrence A.6 Precaution on Installing an OS on the Fujitsu 3.2 TB Flash Accelerator Card ……… A.6.1 Workaround A.6.2 Corrective Action After Occurrence ……………………………… A.7 Precaution on the nvmeadm namespace -v Command A.8 Restriction on the -n Option of the nvmeadm Command ………………………………... - Page 8 Contents A.11 fwupdate Command Precaution ………………………………………………………… ……………………………………………… 13 Appendix B Specifications …………………………………………………………………… B.1 Product Specifications B.2 Physical Specifications …………………………………………………………………… …………………………………………………………… B.3 Environmental Specifications B.4 Electrical Specifications …………………………………………………………………… B.5 Performance Specifications ……………………………………………………………… ………………………………………………………………… B.6 Reliability Specifications ……………………………… 16 Appendix C Environmental Information ……………………………………………………………… C.1 Taiwan RoHS Declarations ……………………………………………………………… C.2 China RoHS Declarations C.3 For Indian e-waste Rules …………………………………………………………………...
- Page 9 Contents Figure Table Contents Figure Contents …………………… Figure 1-1 Appearance of the Fujitsu 3.2 TB Flash Accelerator Card …………………………………………………………… Figure 1-2 Status Indicator LEDs viii C120-0067-02EN...
- Page 10 Contents Table Contents Table 1-1 Product and Model Names ………………………………………………………… Table 1-2 Components ………………………………………………………………………… …………………………………………………………… Table 1-3 Operating Environment Table 1-4 Fujitsu 3.2 TB Flash Accelerator Card Status Indicated by the Indicator LEDs ………………………………………………………………………………………… …………………………………………………………… Table B-1 Product Specifications …………………………………………………………… Table B-2 Physical Specifications ……………………………………………………...
-
Page 11: Chapter 1 Overview
This chapter provides an overview of the Fujitsu 3.2 TB Flash Accelerator Card. Product and Model Names Table 1-1 lists the product and model names of the Fujitsu 3.2 TB Flash Accelerator Card. Table 1-1 Product and Model Names Item Description Product name Fujitsu 3.2 TB Flash Accelerator Card... -
Page 12: Functions
The card is a suitable product for enterprises since a life of 5 DWPD x 5 years is guaranteed. ■ Control Driver The nvme driver is bundled with the Oracle Solaris. Operating Environment Table 1-3 shows the operating environment of the Fujitsu 3.2 TB Flash Accelerator Card. C120-0067-02EN... -
Page 13: Status Indicator Leds
GPNA5B3Q or GPJA0B3Q Status Indicator LEDs Figure 1-2 shows the indicator LEDs that indicate the status of the Fujitsu 3.2 TB Flash Accelerator Card. Figure 1-2 Status Indicator LEDs Table 1-4 lists the status of the Fujitsu 3.2 TB Flash Accelerator Card as shown by the indicators. - Page 14 Chapter 1 Overview 1.7 Status Indicator LEDs Table 1-4 Fujitsu 3.2 TB Flash Accelerator Card Status Indicated by the Indicator LEDs Indicator LED Icon Color State Meaning Transfer Rate Green Linked up at PCIe x8 The status is either of the following: - Linked up at PCIe x4...
-
Page 15: Chapter 2 Fujitsu 3.2 Tb Flash Accelerator Card Installation
Chapter 2 Fujitsu 3.2 TB Flash Accelerator Card Installation For details on how to install the Fujitsu 3.2 TB Flash Accelerator Card, see "Maintaining the PCI Express Cards" or "Maintaining PCIe Cards" in the following service manuals for the respective models of the... -
Page 16: Chapter 3 Fujitsu 3.2 Tb Flash Accelerator Card Settings
Checking the Fujitsu 3.2 TB Flash Accelerator Card You can check the Fujitsu 3.2 TB Flash Accelerator Card in the same way as detecting a hard disk drive. The command shown below is an example. # /usr/sbin/format Searching for disks...done AVAILABLE DISK SELECTIONS: 2. -
Page 17: 3.3 Checking Various Information On The Fujitsu 3.2 Tb Flash Accelerator Card
128 KB. Checking Various Information on the Fujitsu 3.2 TB Flash Accelerator Card You can check various information on the Fujitsu 3.2 TB Flash Accelerator Card with the nvmeadm command. Checking the firmware version ■... - Page 18 Chapter 3 Fujitsu 3.2 TB Flash Accelerator Card Settings 3.3 Checking Various Information on the Fujitsu 3.2 TB Flash Accelerator Card Number of Media Errors: 0x0 Number of Error Info Log Entries: 0x0 C120-0067-02EN...
-
Page 19: Appendix A Precautions And Restrictions
Active replacement and active addition/removal with the PCI Hot Plug (PHP) and physical partition dynamic reconfiguration (PPAR DR) functions cannot be used. Disk Label Precaution Only the EFI disk label is supported because the size of the Fujitsu 3.2 TB Flash Accelerator Card is a disk volume exceeding 2 TB. LBA Format Precaution The Fujitsu 3.2 TB Flash Accelerator Card supports only LBA formats with a block size of 512 bytes. -
Page 20: A.5.1 Workaround
Precaution on Installing an OS on the Fujitsu 3.2 TB Flash Accelerator Card Installation of an OS on the Fujitsu 3.2 TB Flash Accelerator Card may cause the following message to be output, and the card may not appear as an OS possible installation destination. -
Page 21: A.7 Precaution On The Nvmeadm Namespace -V Command
Appendix A Precautions and Restrictions A.9 Precaution on the nvmeadm list -s Command Precaution on the nvmeadm namespace -v Command Not "1" but rather "32" appears as the namespace ID. # nvmeadm namespace -v SUNW-NVME-1-NAMESPACE-1 Namespace: 32 Block Size: 512 Capacity: 3200631791616 Metadata Size: 0 Block Device Name: /dev/rdsk/c11t1d0s2 Status: online... -
Page 22: A.10 Restriction On Probe-Nvme-All
0xa814 A.10 Restriction on probe-nvme-all The probe-nvme-all command cannot be used. To confirm that the Fujitsu 3.2 TB Flash Accelerator Card is recognized on the OpenBoot PROM environment, use the show-devs command. A.11 fwupdate Command Precaution The fwupdate list controller command does not display "NVMe" but rather "SAS" for Type. The command shown below is an example. -
Page 23: Appendix B Specifications
Appendix B Specifications B.2 Physical Specifications Appendix B Specifications Product Specifications Table B-1 Product Specifications Item Specifications Capacity 3.2 TB, LBA: 6,251,233,967 Form factor Half-height half-length standard connector Interface PCI Express Gen3 x8 NAND type SAMSUNG TLC V-NAND (V3 and V4) Safety/Radio wave standards cUL, CE, KCC, VCCI, TUV-GS, CB, FCC, RCM, ICES Environmental standard RoHS Compliance... -
Page 24: B.3 Environmental Specifications
Appendix B Specifications B.5 Performance Specifications Environmental Specifications Table B-3 Environmental Specifications Item Specifications Temperature Operating: 0 to 55ºC Non-operating: -40 to 85ºC Relative humidity Operating: 8 to 80% (no condensation) Non-operating: 5 to 95% (no condensation) Impact 1,500 G/0.5 msec Vibration 20 G RMS (10 to 2,000 Hz) Airflow 300 LFM@55ºC Electrical Specifications... -
Page 25: B.6 Reliability Specifications
Appendix B Specifications B.6 Reliability Specifications Table B-5 Performance Specifications (continued) Item Specifications Quality of service Read/Write (99%): 160/100 µs Performance consistency Read/Write (99.9%): 98/84% Reliability Specifications Table B-6 Reliability Specifications Item Specifications Uncorrectable bit error rate 1 sector per 10 bits read MTBF 2,000,000 hours Life 5 years... -
Page 26: Appendix C Environmental Information
Appendix C Environmental Information C.1 Taiwan RoHS Declarations Appendix C Environmental Information Taiwan RoHS Declarations Table C-1 Taiwan RoHS Declarations 3.2TB Flash Accelerator Card Equipment name Type designation (Type) Restricted substances and its chemical symbols 醚 Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Unit chromium biphenyls... -
Page 27: C.2 China Rohs Declarations
Appendix C Environmental Information C.3 For Indian e-waste Rules China RoHS Declarations 该标 际惯 2016 报 1 报 21 报 [ 电 电 产 质财 办 办 ] SJ/T11364[ 电 电 产 质 标识 销 电 电 产 环 标识 该产 项 , 该... - Page 28 Appendix C Environmental Information C.3 For Indian e-waste Rules C120-0067-02EN...
