  • Page 1 MAINTENANCE INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS D’INSTALLATION- D’UTILISATION-ET D’ENTRETIEN MANUAL DE INSTRUCCIONES INSTALACIÓN-USO-MANTENIMIENTO HANDBUCH FÜR INSTALLATION, GEBRAUCH UND WARTUNG serie FC CAN S.r.l. Via Nazionale 65, 25080 - Puegnago del Garda (BS) ITALY T. +39 0365 555909 F. +39 0365 651822 info@cansrl.com www.cansrl.com...
  • Page 2 GENERAL INFORMATION Additional information for installers and users. CAN S.r.l., as the manufacturer of the appliance, reserves the right to make changes to its products and to this manual considered appropriate, without being obliged to give prior notice. The drawings, installation diagrams and tables in the manual must be considered as guides and exclusively for explanatory purposes.
  • Page 3 EN 30-1-1: 2008 + A3 02/2013 • EN 30-2-1: 2015 We hereby declare that all the products of the FC SERIES are built according to the specifications of the appliances described in: TYPE TEST CERTIFICATE no. 51CO4387 issued by IMQ S.p.a.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TECHNICAL DATA SHEET: FC1336 TECHNICAL DATA SHEET: FC1337 TECHNICAL DATA SHEET: FC1343 TECHNICAL DATA SHEET: FC1344 TECHNICAL DATA SHEET: FC1345 TECHNICAL DATA SHEET: FC1347 TECHNICAL DATA SHEET: FC1348 TECHNICAL DATA SHEET: FC1349 TECHNICAL DATA SHEET: FC1350 TECHNICAL DATA SHEET: FC1352 GENERAL PRELIMINARY INFORMATION GENERAL SAFETY WARNINGS INTENDED USE...
  • Page 5 INSTRUCTIONS FOR THE INSTALLER INSTALLATION ROOM FEATURES OF INSTALLATION ROOM FLUE GAS EXHAUST INSTALLATION ON SUPPORT STRUCTURE RECESSED HOLE SAFETY DISTANCES POSITIONING THE APPLIANCE GAS CONNECTION GAS CATEGORIES CONNECTION PIPE REQUIREMENTS GAS CONNECTION PROCEDURE ELECTRICAL CONNECTION (ONLY FOR E VERSION) TROUBLESHOOTING AFTER INSTALLATION INSTRUCTIONS FOR USE DESCRIPTION...

  • Page 6: Technical Data Sheet: Fc1336

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1336 RECESSED HOLE FC1336 5 mm Detail C 8 mm 85 mm 128 mm...
  • Page 7 TECHNICAL DATA SHEET: FC1336 Dimensions Width 530 mm Depth 340 mm Height 48 mm (hob area) 105 mm (valves area) Weight 3.6 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX) Pn 1.00 kW – injector ø 0.50 mm – consumption 72.50 g/h (straight valves with bypass Ø...

  • Page 8: Technical Data Sheet: Fc1337

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1337 RECESSED HOLE FC1337 Detail C...
  • Page 9 TECHNICAL DATA SHEET: FC1337 Dimensions Width 340 mm Depth 530 mm Height 48 mm (hob area) 105 mm (valves area) Weight 3.8 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX) Pn 1.00 kW – injector ø 0.50 mm – consumption 72.50 g/h (straight valves with bypass Ø...

  • Page 10: Technical Data Sheet: Fc1343

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1343 RECESSED HOLE FC1343...
  • Page 11 TECHNICAL DATA SHEET: FC1343 Dimensions Width 480 mm Depth 480 mm Height 105 mm Weight 5.5 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX) Pn 1.00 kW – injector ø 0.50 mm – consumption 72.50 g/h (straight valves with bypass Ø...

  • Page 12: Technical Data Sheet: Fc1344

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1344 RECESSED HOLE FC1344...
  • Page 13 TECHNICAL DATA SHEET: FC1344 Dimensions Width 480 mm Depth 480 mm Height 105 mm Weight 5.5 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX) Pn 1.00 kW – injector ø 0.50 mm – consumption 72.50 g/h (straight valves with bypass Ø...

  • Page 14: Technical Data Sheet: Fc1345

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1345 RECESSED HOLE FC1345 Please note: secured with adhesive.
  • Page 15 TECHNICAL DATA SHEET: FC1345 Dimensions External Diameter (Ø) 340 mm Height 80 mm Weight 2.1 kg Nominal values: Hob Unit (straight valves with 1 x SEMIRAPID burner (SR): bypass Ø 0.36 mm) Pn 2.00 kW – injector ø 0.70 mm – consumption 145.50 g/h Device Class CLASS 3 –...

  • Page 16: Technical Data Sheet: Fc1347

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1347 RECESSED HOLE FC1347...
  • Page 17 TECHNICAL DATA SHEET: FC1347 Dimensions Width 440 mm Depth 440 mm Height 80 mm Weight 5.3 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX): Pn 1.10 kW – injector ø 0.52 mm – consumption 80.00 g/h (straight valves with bypass Ø...

  • Page 18: Technical Data Sheet: Fc1348

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1348 RECESSED HOLE FC1348 Please note: secured with adhesive.
  • Page 19 TECHNICAL DATA SHEET: FC1348 Dimensions Width 510 mm (maximum overall dimension) Depth 390 mm (maximum overall dimension) Height 80 mm Weight 3.8 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX): Pn 1.10 kW – injector ø 0.52 mm – consumption 80.00 g/h (straight valves with bypass Ø...

  • Page 20: Technical Data Sheet: Fc1349

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1349 FC1349 RECESSED HOLE FC1349 5 mm Detail C 8 mm 85 mm 135 mm...
  • Page 21 TECHNICAL DATA SHEET: FC1349 Dimensions Width 716 mm Depth 340 mm Height 48 mm (hob area depth) 102 mm (gas circuit depth) Weight 5.6 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX): Pn 1.10 kW – injector ø 0.50 mm – consumption 72.50 g/h (straight valves with bypass Ø...

  • Page 22: Technical Data Sheet: Fc1350

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1350 RECESSED HOLE FC1350 5 mm Detail C 8 mm 85 mm 135 mm...
  • Page 23 TECHNICAL DATA SHEET: FC1350 Dimensions Width 716 mm Depth 340 mm Height 48 mm (hob area depth) 102 mm (gas circuit depth) Weight 5.6 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX): Pn 1.10 kW – injector ø 0.50 mm – consumption 72.50 g/h (straight valves with bypass Ø...

  • Page 24: Technical Data Sheet: Fc1352

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TECHNICAL DATA SHEET: FC1352 RECESSED HOLE FC1352 350 mm 350 mm Detail C 85 mm Detail D 85 mm...
  • Page 25 TECHNICAL DATA SHEET: FC1352 Dimensions Width 748 mm Depth 310 mm Height 54 mm (hob area depth) 110 mm (gas circuit depth) Weight 5.8 kg Nominal values: Hob Unit 1 x AUXILIARY burner (AUX): Pn 1.10 kW – injector ø 0.52 mm – consumption 80.00 g/h (straight valves with bypass Ø...

  • Page 26: General Preliminary Information

    GENERAL SAFETY WARNINGS ATTENTION! CAN S.r.l. will not be held liable for any use other than indicated. Do not use this appliance as a room heater. ATTENTION! Do not modify the appliance, unless the change is authorised and carried out by the Manufacturer or by his authorised technicians.

  • Page 27: Intended Use

    (e.g. extractor hood). ATTENTION! The appliance is equipped with a glass lid. Glass lids can shatter if overheated or struck by blunt objects. Always open the lid before lighting any burner, making sure to switch the burners off and let them cool for a few minutes before reclosing the glass lid at the end of each operating cycle.

  • Page 28: Identification Of The Appliance

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series ▪ Do not heat empty pans or without a sufficient amount of cooking fluid. ▪ Do not expose the appliance to air draughts. The burners could go out. ▪ Do not force the knobs if blocked. Contact the Technical Assistance Service.

  • Page 29: Receiving The Appliance

    MANUEL D’INSTRUCTIONS D’INSTALLATION- D’UTILISATION-ET D’ENTRETIEN MANUAL DE INSTRUCCIONES INSTALACIÓN-USO-MANTENIMIENTO HANDBUCH FÜR INSTALLATION, GEBRAUCH UND WARTUNG serie FC CAN S.r.l. Via Nazionale 65, 25080 - Puegnago del Garda (BS) ITALY T. +39 0365 555909 F. +39 0365 651822 info@cansrl.com www.cansrl.com CONTROL AND HANDLING Upon receiving the appliance, proceed to unpack it.

  • Page 30: Instructions For The Installer

    INSTRUCTIONS FOR THE INSTALLER ATTENTION! Installation and all the interventions on the appliance described in this instruction manual must be carried out by qualified technical personnel and in compliance with standards in force. ATTENTION! The gas connection systems and the installation rooms must be suitable and meet the safety standards in force in the Country of use.

  • Page 31: Installation On Support Structure

    ATTENTION! The appliance must be installed in a room without air draughts which can have a negative effect on combustion. The chosen installation position must also prevent the accumulation of unburnt gases.

  • Page 32: Safety Distances

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series SAFETY DISTANCES The appliance must be kept a certain distance away from side and upper walls. Consult the following table: dimensions and minimum safety distances for installation [mm] [mm] [mm]...

  • Page 33: Positioning The Appliance

    POSITIONING THE APPLIANCE Proceed as follows to position the appliance on the support structure: step action Position the gasket (sold separately) on the edges of the metal moulding or sealant paste (if present). Position the appliance on the recessed hole and push it onto the support structure. Secure the appliance by the fixing screws provided in the specific kit and screw them into the holes made at the four corners of the metal moulding.

  • Page 34: Gas Connection

    (Please note: this valve must always be shut during installation and maintenance on the appliance).

  • Page 35: Gas Connection Procedure

    12V and in direct current (DC) is strictly prohibited. 1 Power cable positive pole Any other connection can pose a severe 2 Power cable negative pole 3 Connection cable generator danger for the user of the appliance and...

  • Page 36: Troubleshooting After Installation

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TROUBLESHOOTING AFTER INSTALLATION If the appliance does not work properly after installation, perform the controls in the table. problem possible solutions Check that the gas cock is completely open. Check that the fuel supply circuit has a suitable flow rate.

  • Page 37: Instructions For Use

    INSTRUCTIONS FOR USE DESCRIPTION See the exploded drawings on the following pages for the position of the components listed in the table. component Wire pan support Ring for glass lid Glass lid Hinge for glass lid Plastic cap Silent block for resting lid Fixing screws cap Hob unit fixing screw CE label...
  • Page 38 GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TYPE FC1336 detail A detail B detail C Fixing kit detail A detail B detail C...
  • Page 39 TYPE FC1337 detail A detail B detail C detail A detail B detail C Fixing kit ▪ Installation, use and maintenance instruction manual Ed. 07/2018 Rev. 00...
  • Page 40 GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TYPE FC1343 detail A detail B detail C detail C detail A detail B Fixing kit...
  • Page 41 TYPE FC1344 detail A detail B detail C detail A detail B detail C Fixing kit ▪ Installation, use and maintenance instruction manual Ed. 07/2018 Rev. 00...
  • Page 42 GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TYPE FC1345 detail A detail B detail A detail B...
  • Page 43 TYPE FC1347 detail A detail B detail A detail B Fixing kit ▪ Installation, use and maintenance instruction manual Ed. 07/2018 Rev. 00...
  • Page 44 GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TYPE FC1348 detail A detail B detail A detail B...
  • Page 45 TYPE FC1349 detail A detail B detail C detail C detail A detail B Fixing kit ▪ Installation, use and maintenance instruction manual Ed. 07/2018 Rev. 00...
  • Page 46 GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series TYPE FC1350 detail A detail B detail C detail A detail C detail B Fixing kit...
  • Page 47 TYPE FC1352 detail A detail B detail B detail A ▪ Installation, use and maintenance instruction manual Ed. 07/2018 Rev. 00...

  • Page 48: Safety Warnings During Use

    ▪ Switch the burner off after each use. ▪ Do not set or keep flammable liquids or materials or objects which can easily catch fire on the appliance or in its immediate vicinity. ▪ Do not place hot pans on the controls.

  • Page 49: Lighting The Burners

    Before use, make sure that the burner spreaders, caps and pan holders are positioned properly. burner spreader positioning The matching burner is indicated on each knob. The burner can be lit: ▪ manually using the external igniter (on S versions), ▪...

  • Page 50: Adjusting The Flame

    To adjust the flame, turn the knob to the desired position (MIN or MAX). The knob can also be set in the middle, between the maximum and minimum position. Do not place the knob between the maximum and “off” position.

  • Page 51: Switching Off The Burner

    Do not try to repair or modify the appliance. CAN S.r.l. will provide maximum collaboration and assistance should any technical or other type of problem arise on any of its products.

  • Page 52: Maintenance And Cleaning

    Remove the components from their housing and wash them with warm water and dishwashing soap. Stubborn filth on the enamelled components can be removed using a slightly abrasive sponge and a degreaser, taking BURNER SPREADER/CAPS care not to damage the surfaces.

  • Page 53: Long Idle Periods

    After cleaning, make sure that the pan holders have been put back in place correctly, paying attention not to invert them or couple them to different burners. The pan holders must always be stable and sit without rocking on the hob unit or be set firmly inside the specific fixing seats. LONG IDLE PERIODS If you do not expect to use the appliance for a long period of time (beyond 2-3 weeks) proceed as follows: ▪...

  • Page 54: Spare Parts

    SPARE PARTS ATTENTION! Use only original spare parts. The use of components other than those supplied by the Manufacturer terminates the Warranty and could cause personal harm or damage the appliance. ATTENTION! Parts must be replaced safely by authorised and qualified personnel. To make it easier to recognise the spare parts, read the tables below together with the exploded drawings shown in paragraph "Description".

  • Page 55: Spare Parts - Fc1337

    E VERSION - ELECTRONIC LIGHTING code component component 4000319 Single-pole button 3A red key 2000147 12V generator kit + assembly bracket 4000168 Universal lighting cable (-) 4000169 IGN lighting cable L320 4000297 IGN lighting cable 2 (+) 4000232 Burner lighting glow plug L350 4000321 Burner lighting glow plug L410 4000137...

  • Page 56: Spare Parts - Fc1343

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series 4000321 Burner lighting glow plug L 410 4000137 Clip for glow plug SPARE PARTS - FC1343 The column "Pos." refers to the exploded drawing "TYPE FC1343" on page 40. VERSION S - MANUAL LIGHTING...

  • Page 57: Spare Parts - Fc1345

    3000083 Tall rubber bushing for pan holders 3000073 Wire pan holder for AUX burner 3000074 Wire pan holder for SR burner 3000453 Silentblock Ø 11 4000026 2nd series lid stud bolt 4000170 Glass lid cable gland 4000224 Intense black screw cap 4000008 Standard black knob 4000031...

  • Page 58: Spare Parts - Fc1347

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series E VERSION - ELECTRONIC LIGHTING code component component 4000015 Single-pole button 3A red key 2000147 12V generator kit + assembly bracket 4000168 Universal lighting cable (-) 4000169 IGN lighting cable L320...

  • Page 59: Spare Parts - Fc1348

    SPARE PARTS - FC1348 The column "Pos." refers to the exploded drawing "TYPE FC1348" on page 44. VERSION S - MANUAL LIGHTING code component component 2000008 Hinge for glass lids 3000002 Glass FC1348 3000072 Rubber bushing for pan holders 2000096 SR stainless steel pan support for steel hob units 2000095 AUX stainless steel pan support for steel hob units...

  • Page 60: Spare Parts - Fc1350

    GAS HOB UNITS WITH GLASS RECESSED LID ▪ FC series 4000224 Intense black screw cap Black/chrome knob Ø 34 4000260 4000031 Universal nut for thermocouple 4000069 Thermocouple for fast-on magnet cock 4000025 Burner spreader for 2nd series AUX burner 4000021 Ø...

  • Page 61: Spare Parts - Fc1352

    7000138 Glass lid flame label 4000229 5 x 6 CH screw to secure the hinge and silentblock E VERSION - ELECTRONIC LIGHTING code component component 4000319 Single-pole button 3A red key 2000147 12V generator kit + assembly bracket 4000168 Universal lighting cable (-) 4000169 IGN lighting cable L320 4000297...
