Honeywell Excel 5000 Open System Installation Instructions page 4

W7762A,B HYDRONIC CONTROLLERS
1. STRIP 1/2 IN. (13 MM) FROM WIRES
TO BE ATTACHED AT ONE
TERMAINAL
OCCUPANCY SENSOR,
CHANGEOVER CONTACT,
AIRFLOW CONTACT,
WINDOW CONTACT,
MOTION SENSOR, etc.
6
5
T7560A,
T7460A, 4
T7460B, or
3
T7460E
2
1
WALL MODULE
Output type
Floating
1-stage
2-stage
3-stage
PWM
Thermal
Home and Building Control
Honeywell Inc.
Honeywell Plaza
P.O. Box 524
Minneapolis, MN 55408-0524
USA
http://www.honeywell.com
95-7563-3 Rev. 01-01 7157 351
2. TWIST WIRES TOGETHER WITH
PLIERS (A MINIMUM OF THREE
TURNS).
Fig. 7. Attaching two or more wires at terminal blocks.
W7762 HYDRONIC CONTROLLER
NOT USED
1
2 NOT USED
3 NOT USED
4 DIGITAL INPUT
5 DGND
6 LED
7
BYPASS
8 SETPT (for W7762B, only)
9 SENSOR
10 GND
Fig. 8. Hydronic Controller terminal assignments.
Table 1. Output assignments for various actuator types.
Out 1 Terminal
13 14
24 Vac open
24 Vac on/off
24 Vac stage 1
24 Vac stage 1
24 Vac PWM
24 Vac on/off
Home and Building Control
Honeywell Limited-Honeywell Limitee
155 Gordon Baker Road
North York, Ontario
M2H 3N7
Canada
http://www.honeywell.ca
printed in Germany
Проектирование. Монтаж. Продажа. - http://vskd.ru
3. CUT TWISTED END OF WIRES TO 3/16 IN. (5 MM) BEFORE
INSERTING INTO TERMINAL AND TIGHTENING SCREW. THEN
PULL ON EACH WIRE IN ALL TERMINALS TO CHECK FOR GOOD
MECHANICAL CONNECTION.
24 VAC
24 VAC
11
24 VAC COM
24 VAC COM
12
OUT 1 COM
13
OUT 1 OPEN
14
OUT 1 CLOSE
15
OUT 2 COM
16
OUT 2 OPEN
17
OUT 2 CLOSE
18
E-BUS (LON)
19
E-BUS (LON)
20
Out 2 Terminal
15 16
close 24 Vac
— 24 Vac
stage 2 24 Vac
stage 2 24 Vac
stage 3
— 24 Vac
— 24 Vac
Home and Building Control Products
Honeywell AG
Böblinger Straβe 17
D-71101 Schönaich
Germany
http://europe.hbc.honeywell.com
120/240 VAC
HEAT
COM
+
OPEN
CLOSE
COOL
COM
OPEN
CLOSE
LONWORKS NETWORK IN
LONWORKS NETWORK OUT
17 18
open close
on/off —
stage 1 stage 2
stage 1 stage 2
stage 3
PWM —
on/off —
