  • Page 1                                                                                                                                          PN: 040‐00044‐01   16‐ Jan  OPERATOR’S MANUAL...

  • Page 2: Product Specifications

    Operator’s Manual                                                                                                                          Product Specifications Electrical Power Domestic   120 VAC @ 60 Hz, 5 amps  International  240 VAC @ 50 Hz, 2.5 amps  Japan    100 VAC @ 50 Hz, 5 amps  DC Power Fuse Guide   ELECTICAL SAFETY NOTICE: REPLACE FUSE WITH SPECIFIED FUSE RATING ONLY. DO NOT REPLACE FUSE  WITH HIGHER THAN SPECIFIED RATING.     RIO PCB FUSE GUIDE:  +5 VDC ‐ 3 amp Slow Blow (RIO MCU, START BUTTON)    +12 VDC ‐ 5 amp Slow Blow (COIN DOOR, COOLING FANS, DASH LED)  *+12 VDC ‐ AUDIO POWER USES A THERMAL FUSE, RIO F3    CABINET FUSE GUIDE:  (NOTE: FUSES ARE MOUNTED TO THE LEFT OF THE RIO PCB. F1 IS LOCATED CLOSEST RIO PCB)    F1 ‐  PLAYER 1 GUN SOLENOID POWER , 5 amp Slow Blow  F2 ‐  PLAYER 2 GUN SOLENOID POWER , 5 amp Slow Blow  F3 ‐  DINO HEAD BACKLIGHT, 5 amp Slow Blow  F4 ‐  JURASSIC PARK GATE LOGO, 5 amp Slow Blow  F5 ‐  ROOF LED LED T‐MOLD, 5 amp Slow Blow  F6 ‐  BENCH LED T‐MOLD, 5 amp Slow Blow      Temperature 32° to 100° Fahrenheit (0° to 38° Celsius)   Humidity Must not exceed 95% relative humidity or where visible condensation is present.  Cabinet Dimensions Component  Height  Width ...

  • Page 3: Contact Information

    Operator’s Manual                                                                                                                          Contact Information For an authorized distributor near you, check the Raw Thrills website at www.rawthrills.com  Contact Betson Enterprise Headquarters or your local Betson office for sales, technical information,  warranty or repair. Betson can be reached at (800) 524‐2343   Fax (201) 438‐4837 www.betson.com  Betson Enterprises Headquarters    303 Paterson Plank Rd.  Carlstadt, NJ 07072  (800) 524‐2343  or  (201) 438‐1300  fax (201) 438‐4837                <JP environmental cabinet image>      Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 3  ...

  • Page 4: Operation

    Operator’s Manual                                                                                                                          Safety PERATION Before operating game, read this manual. Failure to properly install and operate this game could result in  malfunction or accident. Operate the game in accordance with the manual.  RANSPORTING   Cabinet is very heavy and contains fragile components. Use appropriate care when moving or transporting cabinet.   Avoid rough handling.    ANDLING OMPONENTS   Many components are extremely sensitive to handling, environmental and Electrostatic Discharge (ESD) events— especially the computer. Do not handle it roughly. Before servicing, call your distributor and inquire about the PC  warranty. Use proper ESD procedures when servicing. Protect components from harmful environmental  conditions, such as extreme temperatures, excessive moisture or other damaging effects.    ISCONNECT POWER   Always turn off power and unplug the unit before servicing or making adjustments, unless otherwise instructed.  Installing or repairing components while power is on can damage the components and void the warranty.    ROUNDING Avoid electrical shock. Do not plug in AC power until you have inspected and properly grounded the unit. Only plug  into a grounded, three‐wire outlet. Do not use a “cheater” plug or cut off the ground pin on the line cord.    LECTRICAL HOCKS   There is no isolation transformer in the cabinet. Disconnect AC power before servicing. However, be aware that  lethal voltages can remain in the electronic components even when AC power is disconnected. Use extreme  caution when servicing. Verify that there is a working ground connection. If the unit sustains water damage, cease  using it immediately and unplug AC power.    ONITOR Extremely high voltages exist in the monitor at all times. These high voltages exist even when the monitor is off  and the AC line cord is disconnected. These voltages are extremely lethal and will cause death. The monitor  contains no user serviceable parts. Do not attempt to service the monitor.  OWER ELECTOR Before installing game, ensure the voltage on the PC is set properly. There is a 115/230 VAC selector switch that ...

  • Page 5: Specifications

    Operator’s Manual                                                                                                                          OMPUTER   The computer contains sensitive components, including a hard drive. Do not handle it roughly. Call your distributor  before servicing its internal components. Ask about warranty information as it relates to the PC.   Do not turn the PC power switch on or off. It should remain permanently in the ON position.   Cycle AC power on or off with the cabinet power switch.  A dongle has been inserted into one of the USB ports. This is required for game play.   Do not remove the dongle except for troubleshooting purposes.    OWER If the power cord is damaged or lost, replace it with an identical cord as supplied by the manufacturer or an  authorized service agent.  ATER Do not install or operate game within operating perimeter of a water jet. Do not clean equipment using water jet.  AZARD TO PILEPTICS A small portion of the population has an epileptic condition that may cause seizures. Affected persons experience  seizure while watching some television pictures or playing certain video games. People who have not had seizures  may still have an undetected epileptic condition. If anyone in your family has experienced epilepsy symptoms  (seizures or loss of awareness), consult your physical before using video games. While children play video games, a  parent should observe. Be alert to the following symptoms: dizziness, altered vision, eye or muscle twitching,  involuntary movements, loss of awareness, disorientation or convulsions. If you or your child experiences these  symptoms, discontinue use immediately and consult your physician.    ANUAL Keep this manual available and ready for use. If the game fails to function properly, turn off the machine and  unplug the AC line cord. Contact your local distributor. Your warranty, when applicable, lasts 60 days from your  purchase date. You may not reproduce this document or any of its contents without written authorization from  Raw Thrills™, Inc.     PECIFICATIONS For reasons such as performance, this product’s specifications may change without notice. Federal patent,  copyright and other intellectual property laws protect the content, devices and design of the game and its  equipment.         Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 5  ...

  • Page 6: Cabinet Setup

    Operator’s Manual                                                                                                                          Cabinet Setup SAFETY NOTICE: Installing this product requires two individuals able to lift heavy objects safely. You will also be required to climb a  ladder as part of the installation process.  Make sure that you are familiar with the manual contents and game set  up and operation before you begin the installation process.  Do not push or pull the on the guns or decorative  items such as the marquee or bench log to move the game. Doing so can damage the gun mechanism or  decorative items. Be aware of your surrounding and individuals around you during the installation process for your    safety and others. Work only in area with sufficient lighting and a clean and level surface.  Unpack Cartons 1. Place the shipping crates on a flat stable surface.   2. Cut the banding straps and remove the cardboard lids.  3. Lift off the large cardboard container surrounding the cabinet and any shipping cleats.  4. With at least two people and a dolly, remove the cabinet from the shipping pallet. See model  specific assembly diagram.   5. Remove the coin door key from the coin return chute.  6. Open the top coin door.  7. Locate the key for the top and bottom back doors and the cash box.   8. Remove the items inside cash box: AC power cable, a bag of screws and tools, marquee power  cable, this manual.  Check Electrical Settings (For Units Shipped From Different Location) 1. Verify the voltage in the nearest AC outlet.  2. Verify the AC outlet ground connection is present and working.  3. Open the lower back door of the monitor assembly.  4. Verify the voltage selector switch is set to correct AC voltage for all power supplies. This step is  recommended if the unit has been moved or shipped from another locality.  ...
  • Page 7 Operator’s Manual                                                                                                                          Cabinet Setup 55” ENVIRONMENTAL MODEL ASSEMBLY ILLUSTRATION  NOTE: ALL FASTENERS ARE T27‐ 1/4‐20 EXCEPT FOR STEP 1 AND 5  WHICH USE PHILIPS HEAD    SCREWS NOTE: DO NOT FULLY TIGHTEN  SCREWS FOR STEP3 UNTIL ALL  SCREWS FOR STEP 4 ARE IN      PLACE. NOTE: MAKE ELECTRICAL  CONNECTIONS FOR SEAT AND LCD  CABINET TO THE INTERFACE  HARNESS FOUND INSIDE THE    FLOOR ASSEMBLY.     Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 7  ...
  • Page 8 Operator’s Manual                                                                                                                              NOTE: CONNECTION FOR DINO  TOPPER IS BEHIND THE LCD.  CONNECTION FOR THE ROOF LED  IS ON THE TOP RIGHT OF LCD  CABINET   Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 8  ...

  • Page 9: Diagnostic Menu System

    Operator’s Manual                                                                                                                          Diagnostic Menu System Diagnostic Menu Interface The Service Panel has two rocker type momentary ON buttons. Press the switch UP/DOWN toward the  direction of the function you wish to perform. Pressing the TEST button at any point while the game is  running will enter the diagnostic menu.  This menu can be navigated with the service panel or the gun.    An on‐screen message acknowledges changes or when you exit a selection without making a change.  At the bottom of each screen, there is a brief description of the highlighted menu option.   Navigating with Service Panel Switches          Volume    TEST        SERVICE  Volume    DOWN         TEST     enters diagnostic system or select highlighted menu option   SERVICE      exit current menu   VOLUME DOWN   moves down through menu or setting choices  ...
  • Page 10 Operator’s Manual                                                                                                                          Menu Screens and Descriptions Main Menu  Diagnostics  ‐ verify game inputs and outputs are functional     Pricing    ‐ view various tracking statistics   Game Adj          ‐ setup and manage game parameters   System Adj  ‐ setup and manage system parameters   Audits                ‐ view various hardware and software information ie. collection and play data   Gun Cal                 ‐ calibrate and verify gun functionality   Game Vol  ‐ adjust game and attract volume  This document will be updated periodically to improve accuracy and usability. Please visit: rawthrills.com to get the latest version of this manual.   Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 10  ...
  • Page 11 Operator’s Manual                                                                                                                          Main Menu Diagnostics Switch Tests Periodic checks of all game inputs are key to maximizing earnings, customer enjoyment and safety.   Main Menu Diagnostics Sound Test       Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 11  ...
  • Page 12 Operator’s Manual                                                                                                                          Main Menu Diagnostics Light Tests Increase your game’s curb appeal while also offering the best visual experience for players and  prospective customers by making sure that all controlled lighting effects are working.     Main Menu Diagnostics Gun Vibration Tests The gun mechanical feedback system is designed with unique features that enhance the player’s  experience. Verify that gun vibration special effects are functional.      Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 12  ...
  • Page 13 Operator’s Manual                                                                                                                          Main Menu Diagnostics Color Bar LCD Display Test   Main Menu Diagnostics Motion Tests (Jurassic Park Arcade Motion Models Only)         Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 13  ...
  • Page 14 Operator’s Manual                                                                                                                          Main Menu Diagnostics Watchdog Tests The watchdog function is a critical part of making sure that the game is able to recover from a lock‐up  condition automatically. This is especially critical in unattended locations.     Main Menu Diagnostics Motion Self Tests (Jurassic Park Arcade Motion Models Only)       Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 14  ...
  • Page 15 Operator’s Manual                                                                                                                          Main Menu Diagnostics Motion Calibration (Jurassic Park Arcade Motion Models Only)     Main Menu Diagnostics Coin Meter Tests This unit has a common meter for coin and DBV accounting. Replace with 5VDC meter only.      Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 15  ...
  • Page 16 Operator’s Manual                                                                                                                          Main Menu Pricing Adjust game pricing and crediting parameters. Customize pricing for best location earnings.      Main Menu Game Adjustments Adjust in‐game parameters. Customize in‐game features to suit customer base and location.        Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 16  ...
  • Page 17 Operator’s Manual                                                                                                                          Main Menu System Adjustments     Main Menu Audits Monitor game audits to make informed decisions in determining key game settings. ie. pricing, game  length.      Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 17  ...
  • Page 18 Operator’s Manual                                                                                                                            Main Menu Utilities Resetting Audit information is recommended whenever you change a game parameter in order to  accurately track changes in earnings.    Main Menu Gun Calibration Maximize your games earning potential by making sure that the guns are periodically calibrated and all  switch inputs are functional.     Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 18  ...

  • Page 19: General Troubleshooting

    Operator’s Manual                                                                                                                          Troubleshooting Warning:  Review safety chapter before making any adjustments to game.  General Troubleshooting Problem  Possible Cause Solution  Game will not power up  Game not plugged in.  Plug game into outlet.    Game not turned on.  Turn on main power switch.     Game fuse is blown.  Check and replace fuse.      No power to receptacle.  Test outlet and plug game into  powered outlet.     PC not turned on.  Turn PC power switch on. Ensure    IEC cable tightly plugged in. Trace  cable back to source to ensure  continuity.    PC BIOS set incorrectly.  See BIOS Settings chapter.   Screen not powering on with game  No AC power or bad video cable Check loose or bad AC or video  connection    NO VIDEO message  Video cables not plugged in properly Reattach and/or tighten video cable ...
  • Page 20 Operator’s Manual                                                                                                                                        Game resets  Bad file or bad 5V RIO fuse. Run File Test. Restore hard drive. Replace 5V fuse on RIO pcb.    Problem  Possible Cause Solution  Guns won’t register or function  Bad calibration Calibrate guns.  poorly    Dirty/damaged potentiometers Inspect and or replace potentiomer   Gun/pot. disconnected Check gun/pot connections.   Coin meter does not click during  No pulse to meter Check all wiring from meter to I/O  Test  board    Faulty meter Replace coin meter    Exits Test Mode every 3 seconds  Test button stuck in ON position Slide or toggle button off after Test  Menu appears    Dongle Not Present  Dongle missing or disconnected Find dongle USB connection and  reseat in USB port   ...
  • Page 21 Operator’s Manual                                                                                                                                                     MECHANICAL AND ELECTRICAL DIAGRAMS                                        Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 21  ...
  • Page 22 Operator’s Manual                                                                                                                                Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 22  ...
  • Page 23 Operator’s Manual                                                                                                                                Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 23  ...
  • Page 24 Operator’s Manual                                                                                                                                Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 24  ...
  • Page 25 Operator’s Manual                                                                                                                                Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 25  ...
  • Page 26 Operator’s Manual                                                                                                                                Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 26  ...
  • Page 27 Operator’s Manual                                                                                                                              Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 27  ...
  • Page 28 Operator’s Manual                                                                                                                              Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 28  ...
  • Page 29 Operator’s Manual                                                                                                                              Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 29  ...
  • Page 30 Operator’s Manual                                                                                                                              Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 30  ...
  • Page 31 Operator’s Manual                                                                                                                                Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 31  ...
  • Page 32 Operator’s Manual                                                                                                                              Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 32  ...
  • Page 33 Operator’s Manual                                                                                                                              Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 33  ...
  • Page 34 Operator’s Manual                                                                                                                                  Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 34  ...
  • Page 35 Operator’s Manual                                                                                                                            NOTES:                                        Jurassic Park ™© is a trademark and copyright of Universal Studios and Amblin Entertainment, Inc. Licensed by Universal Studios Licensing LLC. All rights reserved. Jurassic Park Arcade Game Software Copyright 2014 Raw Thrills, Inc. All rights reserved. Page | 35  ...
  • Page 36                                                                                                                                          PN: 040‐00044‐01   16‐ Jan                                                                                        ...
