Cisco IronPort S670 Quick Start Manual

Hide thumbs

page of 2

/ 2
Bookmarks

Quick Links

Download this manual

Enlarged version

Networking Worksheet

Cisco IronPort Web Security Appliance

Deployment Options

Web Proxy

Transparent with L4 Switch

L4 Traffic Monitor

Simplex Tap

Network Context

Is there another proxy on the network?

YES:

Other Proxy in Forward Mode

IP address and Port:

Network Settings

Default System Hostname:

DNS Servers

Use the Internet's root DNS servers

Network Time Protocol (NTP) server

IP address and host name:

Time Zone Region

Region:

Interface Settings

Management Interface M1 Ethernet port only

IP address:

Network mask:

Host name:

NOTE: The Web Proxy can share the Management interface. If configured separately, the Data interface IP address and the Management

interface IP address cannot share the same subnet.

Data Interface

IP address:

Network mask:

Host name:

Routes

Internal Routes for Management

Default Gateway:

Static Route Name:

Static Route Destination Network:

Static Route Gateway:

Internal Routes for Data

Default Gateway:

Static Route Name:

Static Route Destination Network:

Static Route Gateway:

Tranparent Routing Device

Device type:

Layer 4 switch

WCCP router

NOTE: When you connect the appliance to a WCCP router, you must configure the Web Security appliance to create WCCP services after

you run the System Setup Wizard.

Administrative Settings

Administrative Password:

Send Email System Alerts to:

Security Services

IP Spoofing

L4 Traffic Monitor:

Monitor Only

Block

IronPort URL Filtering

Web Reputation Filters

Malware and Spyware Scanning:

Enable Webroot

Enable McAfee

© 2009 Cisco Systems, Inc. All rights reserved. Cisco, the Cisco logo, Cisco Systems, Cisco IronPort, IronPort, SenderBase and AsyncOS are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the United States

and certain other countries. All other trademarks mentioned in the document or website are the property of their respective owners. The use of the word partner does not imply a partnership between Cisco and any other company. (0903R)

P/N 421-0542

Technical Support:

1-877-641-IRON (4766)

Transparent with WCCP Router

Explicit Forward Proxy

Duplex Tap

In Transparent Mode

In Forward Mode

Use these DNS servers (maximum 3):

1. ........................................................................................................................

2. .......................................................................................................................

3. ........................................................................................................................

Country:

GMT Offset:

.............................................................................................................................

Auto Support

Action for Detected Malware:

Monitor Only

Action for Unscannable Transactions:

Monitor Only

SenderBase Network Participation

Participation Level:

Limited

Block

Standard

QUICKSTART GUIDE

Cisco IronPort S670
