  • Page 1 Installation and Operation Manual GX2-PSDC10D-R Power Supply...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Caution These servicing instructions are for use by qualified personnel only. To reduce the risk of electrical shock, do not perform any servicing other than that contained in the Installation and Troubleshooting Instructions unless you are qualified to do so.
  • Page 3 Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 4: Table Of Contents

    Installation ......................................3-1 Powering ......................................3-2 Operation ......................................3-2 Fault Reporting....................................3-3 Appendix A Specifications Input Power.......................................A-1 Output Power....................................A-1 Physical Properties..................................A-1 Environmental ....................................A-1 Appendix B Menus Module Status Menu ..................................B-1 Module Info Menu.....................................B-2 Alarms .......................................B-2 GX2-PSDC10D-R Installation and Operation Manual...
  • Page 5 Figures Figure 1-1 GX2-PSDC10D-R................................1-1 Figure 2-1 GX2-HSG* fully populated .............................2-1 Figure 2-2 GX2-PSDC10D-R front view............................2-2 Figure 2-3 GX2-PSDC10D-R top view ............................2-2 Figure 2-4 GX2-PSDC10D-R rear view ............................2-3 Figure 3-1 GX2-PSDC10D-R................................3-1 Figure 3-2 DC input connector ...............................3-2 Figure 3-3 GX2-PSDC10D-R block diagram ..........................3-2 Tables Table 3-1 LED fault indication ................................3-3...
  • Page 6 The wide operational bandwidth of the platform enables you to offer more revenue-generating services. This manual describes the GX2-PSDC10D-R power supply that provides power for the equipment shelf (GX2-HSG*) and all application modules. The GX2-PSDC10D-R replaces the GX2-PSDC10-C.

  • Page 7: Introduction

    Toll-free: 1-888-944-HELP (1-888-944-4357) Outside the U.S.: 1-215-323-0044 Direct: 1-847-725-4011 Motorola Online: http://businessonline.motorola.com The TRC is on call 24 hours a day, 7 days a week. In addition, Motorola Online offers a searchable solutions database, technical documentation, and low-priority issue creation and GX2-PSDC10D-R Installation and Operation Manual...

  • Page 8: Calling For Repairs

    Web page. Calling for Repairs If repair is necessary, call Motorola’s Repair Facility at 1-800-642-0442 for a Return for Service Authorization (RSA) number before sending the unit. The RSA number must be prominently displayed on all equipment cartons. The Repair Facility is open from 8:00 AM to 5:00 PM Central Time, Monday through Friday.
  • Page 9 Automated escalation management, both technical and issue related, if necessary through to the high-level development teams or senior account management. The e-mail address for the Call Management System is: BCS.Helpdesk@motorola.com. Or, you may call the following toll-free individual country phone numbers:...

  • Page 10: Overview

    Figure 2-1 GX2-HSG* fully populated The GX2-PSDC10D-R provides +5.1, +12, and +3.7 VDC power to the GX2-HSG* and all application modules. The DC input voltage can range from –36 VDC to – 75 VDC. Surge protection for the input plus overcurrent protection for the output provide the necessary safeguards for the power supply and the application modules served by it.

  • Page 11: Figure 2-2 Gx2-Psdc10D-R Front View

    Overview Figure 2-2 illustrates a front view of the GX2-PSDC10D-R: Figure 2-2 GX2-PSDC10D-R front view Figure 2-3 illustrates a top view of the GX2-PSDC10D-R: Figure 2-3 GX2-PSDC10D-R top view CAUTION Surface may be hot. Disconnect power and allow surface to cool before touching.

  • Page 12: Redundancy

    GX2-PSDC10D-Rs (as shown in Figure 3-1), two GX2-PSAC10D-Rs, or any combination of GX2-PS*10C or GX2-PS*10D-R power supplies. It is not possible to use one GX2-PSDC10B and one GX2-PSDC10D-R power supply together for redundancy. If one power supply fails, the other assumes the entire load.

  • Page 14: Installation And Operation

    This section provides instructions to install the GX2-PSDC10D-R power supply in the GX2-HSG* and verify its operation. Unpacking Unpack the GX2-PSDC10D-R and inspect it for damage. If damage is visible, set it aside in the original packing material and contact the Motorola Customer Service Department for further instructions.

  • Page 15: Operation

    +5.1, +12, and +3.7 VDC respectively. Short circuit protection is provided by each of the DC/DC converters to limit the output current until the fault is cleared. Figure 3-3 illustrates a block diagram of the GX2-PSDC10D-R: Figure 3-3 GX2-PSDC10D-R block diagram...

  • Page 16: Fault Reporting

    Ethernet ports on the front and rear panels. Using the GX2-SDU, or an element management system, you can identify the cause of a fault in the GX2-PSDC10D-R. Refer to Appendix B, Menus, for information regarding the SDU menu structure.

  • Page 18: Specifications

    S p e c i f i c a t i o n s Specifications for the GX2-PSDC10D-R are valid over the given operating temperature range. Refer to the current Motorola BCS product catalog for additional information not provided in this section. I n p u t P o w e r...

  • Page 20: Menus

    This appendix provides information about: Using the optional SDU with display to access GX2-PSDC10D-R menus The menu structure Alarms Table B-1 identifies the procedure for navigating through the GX2-PSDC10D-R menus using the optional SDU with display: Table B-1 GX2-PSDC10D-R menus Scroll to the top-level Press the up or down arrows to scroll to the PS1 or PS2 menu.

  • Page 21: Module Info Menu

    FAN CURRENT ALARM +12V BACKPLANE ALARM +5.1V BACKPLANE ALARM +3.7V BACKPLANE ALARM AMBIENT TEMPERATURE ALARM HEATSINK TEMPERATURE ALARM BANK 0 BOOT ALARM BANK 1 BOOT ALARM FLASH ALARM FACTORY CRC ALARM ALARM CRC ALARM POWER SUPPLY FAIL GX2-PSDC10D-R Installation and Operation Manual...
  • Page 22 A b b r e v i a t i o n s a n d A c r o n y m s The abbreviations and acronyms list contains the full spelling of the short forms used in this manual: Community Antenna Television CATV decibels...
  • Page 24 Visit our website at: www.motorola.com 512823-001-a 9/07...
