Management Plane Protection Commands
Usage Guidelines
If you permit or allow a specific protocol to an interface, traffic is allowed only for that protocol, and all other
management traffic is dropped.
After you configure the interface as inband or out-of-band, the specified protocol's traffic, or all protocol
traffic, is allowed on the interface. Interfaces that are not configured as inband or out-of-band interfaces, drop
the protocol traffic.
The IOS XR XML API provides a programmatic interface to the router for use by external management
applications. This interface provides a mechanism for router configuration and monitoring utilizing XML
formatted request and response streams. As one of the management services, XML should be capable of
applying MPP. To secure XML MPP data, XML keyword has been added to the command.
Task ID
Task ID
system
Examples
The following example shows how to configure all management protocols for all inband interfaces:
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:router(config)# control-plane
RP/0/RP0/CPU0:router(config-ctrl)# management-plane
RP/0/RP0/CPU0:router(config-mpp)# inband
RP/0/RP0/CPU0:router(config-mpp-inband)# interface all
RP/0/RP0/CPU0:router(config-mpp-inband-all)# allow all
The following example shows how to configure peer interface for the TFTP protocol for out-of-band interfaces:
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:router(config)# control-plane
RP/0/RP0/CPU0:router(config-ctrl)# management-plane
RP/0/RP0/CPU0:router(config-mpp)# out-of-band
RP/0/RP0/CPU0:router(config-mpp-outband)# interface GigabitEthernet 0/1/1/2
RP/0/RP0/CPU0:router(config-mpp-outband-GigabitEthernet0_1_1_2)# allow TFTP peer
RP/0/RP0/CPU0:router(config-tftp-peer)#
The following example shows how to configure MPP support on an XML peer in-band interface:
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:router(config)# control-plane
RP/0/RP0/CPU0:router(config-ctrl)# management-plane
RP/0/RP0/CPU0:router(config-ctrl-mpp)# inband interface all allow xml peer address ipv4
172.10.10.1
Related Commands
Command
control-plane, on page 169
inband, on page 170
OL-24740-01
Operations
read, write
Cisco IOS XR System Security Command Reference for the Cisco CRS Router, Release 4.1
Description
Configures the control plane.
Configures an inband interface or protocol.
allow
