Programming the panels for networking 5.1.1 By keypad 5.1.2 By browser 5.1.3 By off-line tool Programming the network 5.2.1 By keypad 5.2.2 By browser 5.2.3 By off-line tool Technical data Bosch Security Systems, Inc. Installation manual 2017.11 | 2.0 | F.01U.214.374...
Install, test and maintain the device according to these instructions, NFPA codes, local codes, and the authority having jurisdiction (AHJ). Failure to follow these instructions can result in failure of the device to operate properly. Bosch Security Systems, Inc. is not responsible for improperly installed, tested or maintained devices.
Page 5
One Ethernet port CAT 5 minimum 328 ft. (100 m) Two wired ports 14 AWG to 18 AWG 3280 ft. (1000 m) (ISO 2.5 mm 0.75 mm plain or twisted pair wire (shielded or unshielded) Tab. 1.1: Network card types Bosch Security Systems, Inc. Installation manual 2017.11 | 2.0 | F.01U.214.374...
Ethernet IN port (Port 3 on the wired card and Port 1 on the fiber optic card). This jumper allows Ground Fault Detection to be disabled for 2017.11 | 2.0 | F.01U.214.374 Installation manual Bosch Security Systems, Inc.
For programming information, follow the panel programming instructions in the FPA-1000Network Quick Installation Guide, or see Menu Structure (6‑PROGRAMMING, 8‑NETWORKING) or Overview of the web user interface (Networking) in the FPA-1000 Installation and Operation Guide. Bosch Security Systems, Inc. Installation manual 2017.11 | 2.0 | F.01U.214.374...
Press down softly until the snap-fit hook locks into place ensuring that the connections seat into the slot properly Figure 3.1: Mounting a Network Card 1 Network card 2 Connectors and slot 3 Snap-fit hook 2017.11 | 2.0 | F.01U.214.374 Installation manual Bosch Security Systems, Inc.
Plug one end of the chosen interconnection cable into an appropriate port on the networking card installed in one of the two panels to be interconnected. Make a note of the port that is used for this connection. 2017.11 | 2.0 | F.01U.214.374 Installation manual Bosch Security Systems, Inc.
LED yellow = data transmission right LED yellow = data transmission 3 Port 3 LEDS, left LED green = link 4 Power LED (green) right LED yellow = data transmission Bosch Security Systems, Inc. Installation manual 2017.11 | 2.0 | F.01U.214.374...
2‑NO if that port is empty. Press the ESC key five times to escape from keypad programming. 17. Repeat steps 1 through 17 for each panel to be added to the network. 2017.11 | 2.0 | F.01U.214.374 Installation manual Bosch Security Systems, Inc.
If you have already saved new configuration files, you can browse to any of the saved files and open it for editing. To access the off-line configuration tool: Download the Off-line tool ZIP file from the Bosch website (www.boschsecurity.com) Under the FPA-1000 software downloads. Bosch Security Systems, Inc.
By browser Notice! If the computer is not auto-negotiating capable, use a crossover cable. Otherwise, use a straight CAT 5 cable or better. Connect a computer to the panel’s Ethernet port. 2017.11 | 2.0 | F.01U.214.374 Installation manual Bosch Security Systems, Inc.
When the path displays in the textbox next to Browse, click Upload. When the display indicates, the upload is completed, disconnect your computer from the panel. Repeat the process for each panel on the network. Bosch Security Systems, Inc. Installation manual 2017.11 | 2.0 | F.01U.214.374...
Green LED, one per board * Applies to all three network card types Trademarks All hardware/software product names used in this document are likely to be registered trademarks and must be treated accordingly. 2017.11 | 2.0 | F.01U.214.374 Installation manual Bosch Security Systems, Inc.
