- Page 1 Camera Network Mobile Camera Quick Start Guide UD01527B...
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
-
Page 4: Regulatory Information
Network Mobile Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 5 Network Mobile Camera·Quick Start Guide EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
-
Page 6: Safety Instruction
Network Mobile Camera·Quick Start Guide Warning This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. - Page 7 Network Mobile Camera·Quick Start Guide ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950-1 standard.
- Page 8 Network Mobile Camera·Quick Start Guide malfunction), and affect the endurance of sensor at the same time. ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.
- Page 9 Network Mobile Camera·Quick Start Guide responsibility for problems caused by unauthorized repair or maintenance.)
-
Page 10: Table Of Contents
Network Mobile Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 Overview ............... 10 Cable Description ............11 2 Installation ..................13 2.1 Camera Installation ............14 2.2 Network Cable Water-proof Accessory Installation ..18 3 Setting the Network Camera over the LAN ........21 Wiring ................ -
Page 11: Appearance Description
Network Mobile Camera·Quick Start Guide 1 Appearance Description Overview Figure 1-1 Overview of Mobile Network Camera Table 1-1 Description of Mobile Network Camera Description Cover Lens shield IR LED... -
Page 12: Cable Description
Network Mobile Camera·Quick Start Guide Description Mounting base 3-axis adjustable camera module Cable Description This camera series has several camera models, each of which may have different cable group. The following figures and tables show the description of all possible cables in this camera series. Figure 1-2 Overview of Cables Table 1-2... - Page 13 Network Mobile Camera·Quick Start Guide Description M12 Aviation Plug RJ45 Network Cable The relation between RJ45 wire and M12 wire is shown in the following figure and table. M12 Aviation Plug RJ45 Network Interface Figure 1-3 RJ45 Interface and M12 Aviation Plug Table 1-3 Wire Relation M12 Wire...
-
Page 14: Installation
Network Mobile Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera. -
Page 15: Camera Installation
Network Mobile Camera·Quick Start Guide Camera Installation Steps: 1. Paste the drill template to the desired mounting place. FRONT Drill Template Hole A: Route cables through the ceiling Hole 1: Fix the mounting base Code: 194101363 Figure 2-1 Drill Template 2. - Page 16 Network Mobile Camera·Quick Start Guide 3. Prepare the screws: Thread the provided bolt through the spring leaves and the flat gaskets in order. Bolt Spring Leaf Flat Gasket Figure 2-2 Preparing the Screws 4. Disassemble the camera: Loosen and take off the four screws on the camera cover, and separate the cover from the mounting base.
- Page 17 Network Mobile Camera·Quick Start Guide Figure 2-4 Insert Screws 6. Tighten the four nuts on the back of the surface to secure the mounting base. Tighten Nuts Figure 2-5 Tighten Nuts 7. Adjust the surveillance angle. 1). Get the live view image of the camera via Ethernet interface or the aviation plug.
- Page 18 Network Mobile Camera·Quick Start Guide P Direction: -15° to 15° Adjustment Screw R Direction: -90° to 90° T Direction: 0° to 30° Figure 2-6 Surveillance Angle Adjustment Tighten the adjustment screw and finish adjusting. 8. Align the cover to camera and fix it by tightening the screws which are embedded together with the cover.
-
Page 19: Network Cable Water-Proof Accessory Installation
Network Mobile Camera·Quick Start Guide Network Cable Water-proof Accessory Installation Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface. ① ② ③ ④ ⑤... - Page 20 Network Mobile Camera·Quick Start Guide Steps: Align the snap and notch. i. Insert into ⑤ ④ ii. Secure with ⑥ ④ Camera Switch/Router Figure 2-9 Water-proof Accessory Installation Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤ (rubber gasket inset ridge must face waterproof endcap), and the water-proof endcap ④...
- Page 21 Network Mobile Camera·Quick Start Guide Insert the water-proof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥ with the water-proof endcap ④. Align the snap on the water-proof endcap ④ with the notch on the camera’s network interface socket ①, and then secure the water-proof endcap ④...
-
Page 22: Setting The Network Camera Over The Lan
Network Mobile Camera·Quick Start Guide 3 Setting the Network Camera over the Note You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. -
Page 23: Activating The Camera
Network Mobile Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation. -
Page 24: Activation Via Sadp Software
Network Mobile Camera·Quick Start Guide 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. - Page 25 Network Mobile Camera·Quick Start Guide Figure 3-4 SADP Interface Note: The SADP software supports activating the camera in batch. Please refer to the user manual of SADP software for details. 3. Create a password and input the password in the password field, and confirm the password.
-
Page 26: Modifying The Ip Address
Network Mobile Camera·Quick Start Guide 4. Click OK to save the password. You can check whether the activation is completed on the popup window. If activation failed, please make sure that the password meets the requirement and try again. Modifying the IP Address Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your... - Page 27 Network Mobile Camera·Quick Start Guide Figure 3-5 Modify the IP Address 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details.
-
Page 28: Accessing Via Web Browser
Network Mobile Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:... - Page 29 Network Mobile Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the plug-in installation.
