G
S
ETTING
TARTED
Catalyst 2960 Switch Getting Started Guide
(8-Port Switches)
INCLUDING LICENSE AND WARRANTY
1
About This Guide
2
Taking Out What You Need
3
Running Express Setup
4
Managing the Switch
5
Installing the Switch
6
Connecting to the Switch Ports
7
In Case of Difficulty
8
Obtaining Documentation and Submitting a Service Request
9
Cisco Limited Lifetime Hardware Terms
G
UIDE
Advertisement
Table of Contents
Related Manuals for Cisco Catalyst 2960-8TC
Summary of Contents for Cisco Catalyst 2960-8TC
- Page 1 INCLUDING LICENSE AND WARRANTY About This Guide Taking Out What You Need Running Express Setup Managing the Switch Installing the Switch Connecting to the Switch Ports In Case of Difficulty Obtaining Documentation and Submitting a Service Request Cisco Limited Lifetime Hardware Terms...
-
Page 2: About This Guide
Cisco.com. When you use the online publications, refer to the documents that match the Cisco IOS software version running on the switch. You can use the show version command to display software version information. - Page 3 Shipping Box Contents SY ST ST AT C O N S O DP LX SP D MO DE C a t a l y s t 2 9 6 er ie s Catalyst 2960 switch Four rubber mounting feet Mounting magnet Documentation Screw template AC power cord (AC-powered switches only)
-
Page 4: Running Express Setup
Power the switch as follows: Step 2 • Catalyst 2960-8TC and 2960G-8TC switches: Connect the AC power cord to the switch power connector and to a grounded AC outlet. • Catalyst 2960PD-8TT-L switches: Use the power adapter, or connect to a 10/100 or 10/100/1000 port from a Power-over-Ethernet (PoE) switch, such as a Catalyst 3560 PoE switch. - Page 5 Connect a Category 5 Ethernet cable Step 7 to any 10/100 or 10/100/1000 Ethernet port on the switch front panel. SYS T Connect the other end of the cable to STA T CO NS O DP LX MO DE the Ethernet port on your PC. C a t a l y s t 2 9 6 eri es...
- Page 6 Enter this information in the Network Settings fields: Step 10 • In the Management Interface (VLAN ID) field, the default is 1. Enter a new VLAN ID only if you want to change the management interface through which you manage the switch. The VLAN ID range is 1 to 1001.
-
Page 7: Refreshing The Pc Ip Address
For a statically assigned IP address, change it to the previously configured IP address. Managing the Switch After completing Express Setup and installing the switch in your network, use the device manager, Cisco Network Assistant, or another of the management options described in this section for further configuration. Using the Device Manager You can manage the switch by using the device manager that is in the switch memory. -
Page 8: Other Management Options
Downloading Cisco Network Assistant Cisco Network Assistant is a free software program that you download from Cisco.com and run on your PC. Network Assistant offers advanced options for configuring and monitoring multiple devices, including switches, switch clusters, switch stacks, routers, and access points. Network Assistant is free—there is no charge to download, install, or use it. -
Page 9: Installing The Switch
This section covers desk-, shelf-, and magnet-mounting. As an example, all the illustrations show the Catalyst 2960-8TC switch. For alternate mounting procedures, such as installing the switch in a rack or on a wall, see the Catalyst 2960 Switch Hardware Installation Guide on Cisco.com. -
Page 10: Before You Begin
Before You Begin When you determine where to install the switch, verify that these guidelines are met: • Airflow around the switch and through the • Do not stack switches or place switches vents is unrestricted. side-by-side, unless they are separated all around by at least 3 inches (7.6 cm) of clearance from each other. -
Page 11: Installation Warning Statements
Class 1 laser product. Statement 1008 Secure the Switch on a Desk or Shelf This section describes installation information specific to the Catalyst 2960-8TC and Catalyst 2960G-8TC switches. For information applicable to the other Catalyst 2960 switches, see the Catalyst 2960 Switch Hardware Installation Guide on Cisco.com. - Page 12 Figure 1 Positioning the Template and Inserting the Screws 4. Place the switch onto the mounting screws, and slide it forward until it locks in place (see Figure 2). Figure 2 Placing the Switch on the Mounting Screws SY ST ST AT C O N S O DP LX...
- Page 13 Mount the Switch with a Magnet Panel Follow these steps: 1. Position the mounting magnet on the mounting surface (see Figure 3). 2. Place the bottom of the switch on the mounting magnet (see Figure 3). Figure 3 Mounting the Switch with a Magnet Panel...
-
Page 14: Connecting To The Switch Ports
This section describes how to connect to the switch ports, the SFP module ports, and to the dual-purpose ports. For additional cabling information, see the Catalyst 2960 Switch Hardware Installation Guide on Cisco.com. Connect to the 10/100 and 10/100/1000 Ports... - Page 15 Insert the other cable end into the other device. Step 3 For a list of supported modules, see the release notes on Cisco.com. For detailed instructions on installing, removing, and connecting to SFP modules, see the documentation that came with the SFP module.
-
Page 16: Verify Port Connectivity
See the “In Case of Difficulty” section on page 16 for information about online assistance. In Case of Difficulty If you experience difficulty, help is available here and on Cisco.com. This section includes Express Setup troubleshooting, how to reset the switch, how to access help online, and where to find more... - Page 17 Troubleshooting Express Setup If Express Setup does not run, or if the Express Setup page does not appear in your browser: • Did you verify that POST successfully ran • If not, make sure that only the SYST and before starting Express Setup? STAT LEDs are green before pressing the Mode button to enter the Express Setup mode.
-
Page 18: Resetting The Switch
First look for a solution to your problem in the troubleshooting section of the Catalyst 2960 Switch Hardware Installation Guide or the Catalyst 2960 Switch Software Configuration Guide on Cisco.com. You can also access the Cisco Technical Support and Documentation website for a list of known hardware problems and extensive troubleshooting documentation, including: •... -
Page 19: For More Information
• Release Notes for the Catalyst 3750, 3560, 2970, and 2960 Switches. Before you install, configure, or upgrade the switch, refer to the release notes on Cisco.com for the latest information. • Catalyst 2960 Switch Hardware Installation Guide. This guide provides complete hardware descriptions and detailed installation procedures. - Page 20 Your formal Warranty Statement, including the warranties and license agreements applicable to Cisco software, is available on Cisco.com. Follow these steps to access and download the Cisco Information Packet and your warranty and license agreements from Cisco.com.
- Page 21 Duration of Hardware Warranty A Cisco product hardware warranty is supported for as long as the original end user continues to own or use the product, provided that the fan and power supply warranty is limited to five (5) years. In the event of a discontinuance of product manufacture, the Cisco warranty support is limited to five (5) years from the announcement of the discontinuance.
- Page 22 Cisco Website at www.cisco.com/go/offices. CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is a service mark of Cisco Systems, Inc.; and Access Registrar, Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS,...
