SPECIFICATIONS

Power supply specifications

Communications specifications

Testing and certification

1–10
OUTPUT RELAY BREAK CAPACITY (FORM-A RELAY)
AC resistive, 120 V AC: ...................................... 5 A
AC resistive, 250 V AC: ...................................... 5 A
AC inductive, PF = 0.4:....................................... 240 VA pilot duty
DC resistive, 30 V DC: ........................................ 5 A
OUTPUT RELAY BREAK CAPACITY (FORM-C RELAY)
AC resistive, 120 V AC: ...................................... 5 A normally-open, 5 A normally-closed
AC resistive, 240 V AC: ...................................... 5 A normally-open, 5 A normally-closed
AC inductive, PF = 0.4:....................................... 240 VA pilot duty
DC resistive, 30 V DC: ........................................ 5 A
POWER SUPPLY (LO RANGE)
Nominal:.................................................................. 24 V DC
Range:...................................................................... 18 to 36 V DC
Power Consumption:......................................... 10 W typical
POWER SUPPLY (HI RANGE)
Nominal:.................................................................. 120 to 240 V AC
Range:...................................................................... 60 to 300 V AC (50 and 60 Hz)
Power consumption: ......................................... 10 W typical
Voltage withstand: ............................................. 2 × highest nominal voltage for 10 ms
DEVICENET (COPPER)
Modes: ..................................................................... slave (125, 250, and 500 kbps)
Connector: ............................................................. 5-pin terminal
Current Draw:....................................................... 80 mA at 24 VDC
PROFIBUS (COPPER)
Modes: ..................................................................... DP V0 slave, up to 1.5 Mbps
Connector: ............................................................. 5-pin terminal
RS485 PORT
Port:........................................................................... opto-isolated
Baud rates: ............................................................ up to 115 kbps
Protocol:.................................................................. Modbus RTU, half-duplex
Maximum distance: ........................................... 1200 m
Isolation: ................................................................. 2 kV
TYPE TESTS
Test
Dielectric voltage withstand
Impulse voltage withstand
Damped Oscillatory
Electrostatic Discharge
RF immunity
Fast Transient Disturbance
Surge Immunity
Conducted RF Immunity
Reference Standard
EN60255-5
IEC61000-4-18IEC60255-22-1
EN61000-4-2/IEC60255-22-2
EN61000-4-3/IEC60255-22-3
EN61000-4-4/IEC60255-22-4
EN61000-4-5/IEC60255-22-5
EN61000-4-6/IEC60255-22-6
MM200 MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
CHAPTER 1: INTRODUCTION
Test Level
2.3KV
5KV
2.5KV CM, 1KV DM
Level 4
Level 3
Class A
Level 3
Level 3
