JVC MX-KC45E Service Manual

Compact component system
Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
COMPACT COMPONENT SYSTEM
7
2006
MB550
MX-KC45E,MX-KC45EN,
MX-KC45A,MX-KC45UW,
MX-KC45UY,MX-KC45UJ
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
SP-MXKC45

TABLE OF CONTENTS

COPYRIGHT © 2006 Victor Company of Japan, Limited
CA-MXKC45
SP-MXKC45
No.MB550
2006/7

Advertisement

Table of Contents
loading

Related Manuals for JVC MX-KC45E

Summary of Contents for JVC MX-KC45E

  • Page 1: Table Of Contents

    SERVICE MANUAL COMPACT COMPONENT SYSTEM MB550 2006 MX-KC45E,MX-KC45EN, MX-KC45A,MX-KC45UW, MX-KC45UY,MX-KC45UJ SP-MXKC45 CA-MXKC45 SP-MXKC45 Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) TABLE OF CONTENTS PRECAUTION............... . . 1-3 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION 155 W per channel, min. RMS, driven into 6 Ω at 1kHz, with no Amplifier Output Power (IEC 268-3) more than 10% total harmonic distortion 125 W per channel, min. RMS, driven into 6 Ω at 1kHz, with no (DIN-3) more than 0.9% total harmonic distortion Input Sensitivity/...

  • Page 3: Precaution

    SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and voltmeter. many circuits and components specially for safety purpos- Move the resistor connection to each exposed metal es. For continued protection, no changes should be made part, particularly any exposed metal part having a return to the original design unless authorized in writing by the path to the chassis, and measure the AC voltage across...
  • Page 4 Important for laser products 1.CLASS 1 LASER PRODUCT 5.CAUTION : If safety switches malfunction, the laser is able to function. 2.CAUTION : (For U.S.A.) Visible and/or invisible class II laser radiation 6.CAUTION : Use of controls, adjustments or performance of when open.

  • Page 5: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. (No.MB550)1-5...

  • Page 6: Disassembly

    SECTION 3 DISASSEMBLY Main Body 3.1.1 Removing the metal cover (See Fig.1, 2) (1) Remove the two screws A and four screws B attaching the metal cover from both side of the main body. (See Fig.1) (2) Remove the six screws C attaching the metal cover from back side of main body.

  • Page 7: See Fig.

    3.1.4 Removing the 3CD changer mechanism (See Fig.3 to 7) (1) Disconnect the card wire from amp board connected to the connector CN601 of the main board. (See Fig.3) CN303 CN201 (2) Disconnect the card wire from the tuner pack connected to the connector CN306 of the main board.

  • Page 8: See Fig.

    3.1.5 Removing the main board (See Fig.6, 8, 9) (1) Remove the six screws H attaching the main board. (See Fig.6) connector wire traverse mechanism (2) Disconnect the connector wire connected to the connector of the motor board. (See Fig.8) (3) Disconnect the connector wire connected to the connector of the traverse mechanism.
  • Page 9 3.1.6 Removing the tuner pack (See Fig.11) (1) Remove the two screws J attaching the tuner pack. CN902 CN202 CN903 3.1.7 Removing the amp board (See Fig.10, 11) (1) Disconnect the connector wire from the front board con- nected to the connector CN202 of the amp board.
  • Page 10 3.1.10 Removing the front panel assembly (See Fig.3, 4, 12, 13) (1) Disconnect the two earth wires from the bottom plate. (See Fig.12) (2) Remove the one screw P attaching the front panel assem- bly from bottom side. (See Fig.13) (3) Remove the two screws Q attaching the front panel assem- bly from both side of the main body.

  • Page 11: No.mb550)1

    3.1.11 Removing the cassette mechanism assembly (See Fig.14) (1) Remove the six screws R attaching the cassette mecha- nism assembly. 3.1.12 Removing the front board (See Fig.14, 15) (1) Remove the seven screws S attaching the front board. (See Fig.14) (2) Disconnect the connector wire from the connector CN201 of the front board.

  • Page 12: Adjustment

    SECTION 4 ADJUSTMENT This service manual does not describe ADJUSTMENT. 1-12 (No.MB550)

  • Page 13: Troubleshooting

    SECTION 5 TROUBLESHOOTING This service manual does not describe TROUBLESHOOTING. (No.MB550)1-13...
  • Page 14 Victor Company of Japan, Limited Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.MB550) Printed in Japan...
  • Page 15 SCHEMATIC DIAGRAMS COMPACT COMPONENT SYSTEM MX-KC45E,MX-KC45EN,MX-KC45A MX-KC45UW,MX-KC45UY,MX-KC45UJ CD-ROM No.SML200607 SP-MXKC45 CA-MXKC45 SP-MXKC45 Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Contents Block diagrams Standard schematic diagrams Printed circuit boards 2-17 to 21 No.MB550SCH COPYRIGHT 2006 Victor Company of Japan, Limited.
  • Page 16 In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " " mark nearby are critical for safety.

  • Page 17: Block Diagram

    Block diagram TUNER PARK CON1 AUX IN CN306 CN205 ANT IN AUX L AUX R HEADPHONE TUNER L CW202 TUNER R Q401 to Q410 DECK-A Q438 Q611 PB-HEAD A/B DECK MUTE EXCHANGE PRE-AMP L CLK,CE IC601 PRE-AMP R DAT IN/OUT SPEAKER TAPE L Q434,Q435...
  • Page 18 Standard schematic diagrams For E,EN version Amplifier section D631 1SS133 D601 CN603 RF601 1N4003 R672 CON - 2.5 - 3P 33(1 / 2W)-FR 33(1 / 4W) Q604 FAN+ KTB1366Y Q101 FAN- Q607 D602 2SC3052 KTA1273Y 1N4003 Q605 D610 R608 FAN+ 2SC3052 Q114 100(A)
  • Page 19 Main section TO TUNER UNIT E VERSION: CN306 12P R515 R418 OTHER VERSION: CN306 10P R420 R514 CN301 Q401 100(A) HEAD-PLAY R416 C418 CON - 2.0 - 3P 2SJ460 R403 2.2 / 50V L.CH R415 C407 Q521 2.2 / 50V 560(A) D405 DTA114TK...
  • Page 20 Micon section TO TUNER PART R346 100(A) R387 10K(A) R347 100(A) RDS-ON 1K(A) R345 TU-CE R356 R344 220(A) TU-DATA R357 100(A) R343 220(A) TU-CLK R358 100(A) 220(A) R342 TU-DIN R359 100(A) R341 1K(A) TU-ON R340 470(A) RDS-DA R339 RDS-CK TO DECK PART R338 R337 AVREF(3.3V)
  • Page 21 Front section IC201 RMC(RPM1740-V4) CN201 CON - ASSY2.0 - 3P FL201 R205 FLT(HNA-17LMO3) DGND REMOTE 58 57 56 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 CON - 2.0 - 3P CN202...
  • Page 22 CD section C816 R811 [ TO FUNCTION PART ] ASP00 ASP01 4.7 / 50 CD-LCH L501 BEAD(A) CD-AGND CD-RCH C817 R810 C732 0.1U 4.7 / 50 RM[01:50] C733 ASP02 0.1U C832 ASP03 L801 10UH(A) Q701 KTA1266 ADDR6 R815 RM07 R723 R722 R721 LOCK...
  • Page 23 For A version Amplifier section D631 1SS133 D601 RF601 1N4003 CN603 R672 CON - 2.5 - 3P 33(1 / 2W)-FR 33(1 / 4W) Q604 FAN+ KTB1366Y Q101 FAN- Q607 D602 2SC3052 KTA1273Y 1N4003 Q605 D610 R608 FAN+ 2SC3052 Q114 100(A) KTA1273Y UZ6.2BSB 1N4003...
  • Page 24 Main section TO TUNER UNIT E VERSION: CN306 12P R515 R418 OTHER VERSION: CN306 10P R420 R514 CN301 HEAD-PLAY Q401 100(A) R416 C418 CON - 2.0 - 3P 2SJ460 R403 2.2 / 50V L.CH RDS OPTION R415 C407 Q521 2.2 / 50V 560(A) D405 R582...
  • Page 25 Micon section TO TUNER PART R346 100(A) R387 10K(A) R347 100(A) RDS-ON 1K(A) R345 TU-CE R356 R344 220(A) TU-DATA R357 100(A) R343 220(A) TU-CLK R358 100(A) R342 220(A) TU-DIN R359 100(A) R341 1K(A) TU-ON R340 470(A) RDS-DA R339 RDS-CK TO DECK PART R338 R337 AVREF(3.3V)
  • Page 26 Front section IC201 RMC(RPM1740-V4) CN201 CON - ASSY2.0 - 3P FL201 R205 FLT(HNA-17LMO3) DGND REMOTE 58 57 56 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 CON - 2.0 - 3P CN202...
  • Page 27 CD section C816 R811 [ TO FUNCTION PART ] ASP00 ASP01 4.7 / 50 CD-LCH L501 BEAD(A) CD-AGND CD-RCH C817 R810 C732 0.1U 4.7 / 50 RM[01:50] C733 ASP02 0.1U C832 ASP03 L801 10UH(A) Q701 KTA1266 ADDR6 R815 RM07 R723 LOCK R722 R721...
  • Page 28 For UW, UY, UJ version Amplifier section D631 1SS133 D601 CN603 RF601 1N4003 R672 CON - 2.5 - 3P 33(1 / 4W) 33(1 / 2W)-FR Q604 FAN+ KTB1366Y Q101 FAN- Q607 D602 2SC3052 1N4003 Q605 KTA1273Y D610 R608 FAN+ 2SC3052 [ 1 ] Q114 100(A)
  • Page 29 Main section TO TUNER UNIT E VERSION: CN306 12P R515 R418 OTHER VERSION: CN306 10P R420 R514 CN301 HEAD-PLAY Q401 100(A) R416 C418 CON - 2.0 - 3P 2SJ460 R403 2.2 / 50V L.CH RDS OPTION R415 C407 Q521 2.2 / 50V 560(A) D405 DTA114TK...
  • Page 30 Micon section [ TO TUNER PART ] R346 100(A) R387 10K(A) 100(A) R347 RDS-ON [ 2 ] 1K(A) R345 [ 2 ] TU-CE R356 220(A) R344 [ 2 ] TU-DATA R357 100(A) R343 220(A) [ 2 ] TU-CLK R358 100(A) R342 220(A) TU-DIN...
  • Page 31 Front section IC201 RMC(RPM1740-V4) CN201 CON - ASSY2.0 - 3P FL201 R205 FLT(HNA-17LMO3) DGND REMOTE 58 57 56 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 23 22 21 20 19 18 17 16 15 14 13 12 11 10 8 7 6 CON - 2.0 - 3P CN202...
  • Page 32 CD section C816 R811 [ TO FUNCTION PART ] ASP00 ASP01 4.7 / 50 CD-LCH [ 2 ] L501 BEAD(A) CD-AGND [ 2 ] CD-RCH [ 2 ] C817 R810 C732 0.1U 4.7 / 50 RM[01:50] C733 ASP02 0.1U C832 ASP03 L801 10UH(A)
  • Page 33 Printed circuit boards Main board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) forward side reverse side R711 C771 R710 R709 R708 C711 C714 C705 JR701 R706 C503 Q405 L509 R705 Q434 C464 C706 R704 R701...
  • Page 34 Amplifier board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) forward side reverse side CN903 JW648 CN08P / 2.54 D614 D615 RS402M G5SBA60L C659 682(M) C660 C627 JW605 JW606 JW631 1000 / 25 C628 C603 R101...
  • Page 35 Trans board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) C902 D903 JW908 D902 JW901 C901 D901 C903 R901 Q901 C905 D904 C907 C904 D906 D905 R902 2-19...
  • Page 36 Front board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) forward side (Front board) (FL board) (Headphone board) D208 JK201 D207 R285 R286 L202 L201 C219 C211 C203 (Remocon board) IC201 JW10 JW214 JW17 JW207 JW20...
  • Page 37 Front board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) reverse side (Front board) (FL board) (AUX IN board) R221 C221 R220 R219 C224 R234 R235 R233 C236 C206 R208 R247 R238 R284 R283 R203 R282...
  • Page 38 Victor Company of Japan, Limited Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.MB550SCH)

  • Page 39: Parts List

    PARTS LIST MX-KC45E,MX-KC45EN,MX-KC45A MX-KC45UW,MX-KC45UY.MX-KC45UJ * All printed circuit boards and its assemblies are not available as service parts. - Contents - Exploded view of general assembly and parts list (Block No.M1) Electrical parts list (Block No.01~13) 3-30 Packing materials and accessories parts list (Block No.M3)
  • Page 40 Exploded view of general assembly and parts list Block No. Main board Front board Front board...
  • Page 41 55 55 only UW,UY,UJ only UW,UY,UJ board Power board Amp board...
  • Page 42 General Assembly Block No. [M][1][M][M]  Symbol No. Part No. Part Name Description Local BI1084430101X1 MAIN VOLUM KNOB BI1084440101X1 V RING ORNAMENT VOLUME BI1084350101X1 DISP ORNAMENT BI1084360101X1 DISP ORNAMENT BI1084370101X1 CAS DOOR WINDOW BI1084380101X1 CAS DOOR WINDOW BI1084300101X1 CASS DOOR HLDR BI1084310101X1 CASS DOOR HLDR BI1084320101X1...
  • Page 43  Symbol No. Part No. Part Name Description Local BI403361X FUSE F901 T4AL 250V UW,UY,UJ   BI403021X FUSE F902 T2AL 250V UW,UY,UJ...

  • Page 44: Electrical Parts List

    Electrical parts list Main board (MX-KC45E,MX-KC45EN) Symbol Part No. Part Name Description Local  Block No. [0][1] D306 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000 Symbol  Part No. Part Name Description Local BI31SS133M000V D307 1SS133 FR DIODE BI31SS133M000V D308 1SS133 FR DIODE...
  • Page 45  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local C407 BICE225500MP01 E CAPACITOR 2.2uF 50V C704 BICE476160MP01 E CAPACITOR 47uF 16V C408 BICC471500KA04 C CAPACITOR 470pF 50V C705 BICC102500KA04 C CAPACITOR 1000pF 50V C409 BICC103500KA04 C CAPACITOR...
  • Page 46  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R302 BIRC1010105A00 C RESISTOR 100Ω 1/10W R387 BIRC1030085M00 C RESISTOR 10KΩ 1/8W J R303 BIRC1010105A00 C RESISTOR 100Ω 1/10W R388 BIRC2220085N00 C RESISTOR 2.2KΩ 1/8W R304 BIRC1010105A00 C RESISTOR...
  • Page 47  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R472 BIRC5630105A00 C RESISTOR 56KΩ 1/10W R714 BIRC1030105A00 C RESISTOR 10KΩ 1/10W R479 BIRC1200045M00 C RESISTOR 12Ω 1/4W R715 BIRC1830105A00 C RESISTOR 18KΩ 1/10W R480 BIRC2720105A00 C RESISTOR...
  • Page 48 R236 BIRC3020105A00 C RESISTOR 3KΩ 1/10W R237 BIRC3920105A00 C RESISTOR 3.9KΩ 1/10W R238 BIRC6220105A00 C RESISTOR 6.2KΩ 1/10W Front board (MX-KC45E,MX-KC45EN) R241 BIRC1030105A00 C RESISTOR 10KΩ 1/10W R247 BIRC1020105A00 C RESISTOR 1KΩ 1/10W Block No. [0][2] R248 BIRC1020085M00 C RESISTOR 1KΩ...
  • Page 49 BI1206721X FLAT CABLE D606 1N4003 DIODE BI31N4003LEM000 CW203 BI3UZ12BSCM000 D607 UZ12BSC Z DIODE BI3UZ30BSDM000 D609 UZ30BSD Z DIODE Amp board (MX-KC45E,MX-KC45EN) D610 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000 D611 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000 Block No. [0][3] D613 1N4003 DIODE BI31N4003LEM000 D614 RS402M...
  • Page 50  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local C603 BICC104250ZA04 C CAPACITOR 0.1uF 25V R608 BIRC1010085N00 C RESISTOR 100Ω 1/8W C604 BICC104250ZA04 C CAPACITOR 0.1uF 25V R609 BIRC1010085N00 C RESISTOR 100Ω 1/8W C605 BICE47825M0 E CAPACITOR...
  • Page 51 Q408 2SK2541 TRNSISTOR BI2SK2541P0001 Q409 2SK2541 TRNSISTOR BI2SK2541P0001 Power trans board Q410 SR2202S TRNSISTOR BI2SR2202S00 Q411 KT1267GR TRNSISTOR BI2KT1BI267GP (MX-KC45E,MX-KC45EN) Q412 DTC114YK DIGI TRNSISTOR BI2DTC114YK018 Q413 DTC114YK DIGI TRNSISTOR BI2DTC114YK018 Block No. [0][4] Q414 2SC3052 TRNSISTOR BI2SC3052F013H Q415 KT1273 TRNSISTOR BI2KT1273P0008 ...
  • Page 52  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local BI31SS133M000V C435 BICC103500K04 C CPCITOR 0.01uF 50V D505 1SS133 FR DIODE C436 BICC103500K04 C CPCITOR 0.01uF 50V BI31SS133M000V C437 BICC682500K04 C CPCITOR 6800pF 50V D508 1SS133 FR DIODE...
  • Page 53  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local C732 BICC104500K04 C CPCITOR 0.1uF 50V R330 BIRC2220085M00 C RESISTOR 2.2KΩ 1/8W C733 BICC104500K04 C CPCITOR 0.1uF 50V R331 BIRC2220085M00 C RESISTOR 2.2KΩ 1/8W C759 BICC104500K04 C CPCITOR...
  • Page 54  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R422 BIRC823010500 C RESISTOR 82KΩ 1/10W R523 BIRC222010500 C RESISTOR 2.2KΩ 1/10W R423 BIRC224010500 C RESISTOR 220KΩ 1/10W R525 BIRC104010500 C RESISTOR 100KΩ 1/10W R424 BIRC223010500 C RESISTOR...
  • Page 55 Front board (MX-KC45A)  Symbol Part No. Part Name Description Local Block No. [0][6] R755 BIRC133010500 C RESISTOR 13KΩ 1/10W Symbol Part No. Part Name Description Local  R756 BIRC1020085N00 C RESISTOR 1KΩ 1/8W R757 BIRC1020085N00 C RESISTOR 1KΩ 1/8W R758 BIRC181010500 C RESISTOR...
  • Page 56  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R250 BIRC1020085M00 C RESISTOR 1KΩ 1/8W J S225 BI8SKRGED0P0 TCT SWITCH SKRGED010 R251 BIRC473010500 C RESISTOR 47KΩ 1/10W S226 BI8SKRGED0P0 TCT SWITCH SKRGED010 R252 BIRC473010500 C RESISTOR 47KΩ...
  • Page 57  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local D601 1N4003 DIODE BI31N4003LEM000 C635 BICE107100MP01 E CAPACITOR 100uF 10V D602 1N4003 DIODE BI31N4003LEM000 C636 BICE107100MP01 E CAPACITOR 100uF 10V D603 1N4003 DIODE BI31N4003LEM000 C637 BICC030500CA04 C CAPACITOR...

  • Page 58: Main Board

     Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R639 BIRC1530105A00 C RESISTOR 15KΩ 1/10W C903 BICH223250ZM01 C CPCITOR 0.022uF 25V R640 BIRC0470045N00 C RESISTOR 4.7Ω 1/4W C904 BICH223250ZM01 C CPCITOR 0.022uF 25V R641 BIRC0470045N00 C RESISTOR...
  • Page 59  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local Q438 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011 C312 BICC240500JA04 C CAPACITOR 24pF Q504 KTA1267GR TRANSISTOR BI2KTA1267GP00 C313 BICC330500JA04 C CAPACITOR 33pF 50V Q505 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011 C314 BICC102500KA04...
  • Page 60  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local C526 BICE105500MP01 E CAPACITOR 1uF 50V C818 BICC102500KA04 C CAPACITOR 1000pF 50V C527 BICE226250MP01 E CAPACITOR 22uF 25V C819 BICC102500KA04 C CAPACITOR 1000pF 50V C528 BICE476160MP01 E CAPACITOR...
  • Page 61  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R363 BIRC4710085M00 C RESISTOR 470Ω 1/8W R450 BIRC3320105A00 C RESISTOR 3.3KΩ 1/10W R365 BIRC1010105A00 C RESISTOR 100Ω 1/10W R451 BIRC1020105A00 C RESISTOR 1KΩ 1/10W R366 BIRC1010085M00 C RESISTOR...
  • Page 62  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local R572 BIRC4720085M00 C RESISTOR 4.7KΩ 1/8W R821 BIRC1020085M00 C RESISTOR 1KΩ 1/8W J R573 BIRC2210085M00 C RESISTOR 220Ω 1/8W R850 BIRC1020105A00 C RESISTOR 1KΩ 1/10W R574 BIRC1030105A00 C RESISTOR...
  • Page 63  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local C207 BICE226500MP01 E CAPACITOR 22uF 50V R272 BIRC4730105A00 C RESISTOR 47KΩ 1/10W C209 BICC104500KA04 C CAPACITOR 0.1uF 50V R273 BIRC4730105A00 C RESISTOR 47KΩ 1/10W C211 BICE107500MP01 E CAPACITOR...
  • Page 64 Amp board  Symbol Part No. Part Name Description Local (MX-KC45UW,MX-KC45UY.MX-KC45UJ) Block No. [1][1] D613 1N4003 DIODE BI31N4003LEM000 D614 RS402M SELEN RECTIFIER BI3RS402M1 D615 GBU6J DIODE BI3GBU6J1V  Symbol Part No. Part Name Description Local BI3UZ12BSCM000 D616 UZ12BSC Z DIODE BI3UZ12BSCM000 D617 UZ12BSC...
  • Page 65  Symbol  Symbol Part No. Part Name Description Local Part No. Part Name Description Local C646 BICM104101KP01 M CAPACITOR 0.1uF 100V R650 BIRC1040105A00 C RESISTOR 100KΩ 1/10W C647 BICM104101KP01 M CAPACITOR 0.1uF 100V R651 BIRC1040105A00 C RESISTOR 100KΩ 1/10W C648 BICM104101KP01 M CAPACITOR...
  • Page 66  Symbol Part No. Part Name Description Local CW902 BI12P60176X CONNECTOR WIRE 6P to AMP CN902 CW903 BI12P80121X CONNECTOR WIRE 8P to AMP CN903  PT902 BI211011151001 POWER TRANS EI28SI  RY901 BI8RL00331X RELAY RELAYDC9V  S901 BI805220X POWER SWITCH SDKPA40700 XXXXX BI11W080H2Y...
