Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or minor)
and the occurrence of injury (definitely occurs or has the potential to occur) when the warning is
ignored:
DANGER! Indicates a situation which, when not avoided, results in death or severe injury.
WARNING! Indicates a situation which, when not avoided, has the potential to result in death
or severe injury; and/or severe property damage.
CAUTION! Indicates a situation which, when not avoided, results or has the potential to result
in minor injury; and/or minor property damage.
Basic safety precautions should be followed, including the following:
Ensure all local, state, and federal laws and codes including health and safety guidelines are met when
installing Waterlogic Equipment. Only qualified service technicians should attempt installation and
service of Waterlogic Equipment. Always read the entire operating instructions before using the
appliance and save these instructions for future use.
DANGER! This product can cause death or severe injury if incorrectly operated, installed or
maintained. The installation, maintenance, sanitizing and any repair must be performed by qualified
persons trained by Waterlogic International or their approved distributors only. Do not remove any
panel or cover to protect against electrical shock and exposure to UV radiation.
DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly grounded outlet. Unit
should be protected by ground‐fault circuit interrupter (GFCI) or residual current device (RCD) having a
rated residual operating current not exceeding 30mA. Use only Waterlogic supplied power cord. Never
use extension cords or power strips to connect unit. Do not use if the power supply cord is damaged.
Always unplug from power supply prior to servicing.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual, and untrained individuals who use this manual assume the risk of any resulting
property damage or personal injury. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
WARNING! SUPERVISE CHILDREN. Keep appliance and cord out of reach of children under the age of
8years. Children under the age of 8 years must not use or play with the appliance.
WARNING! UV‐C EMITTER (UV LAMP). This appliance contains a UV‐C emitter (UV Lamp).
UV‐C radiation may, even in little doses, cause harm to the eyes and skin. Unintended use or damage to
the housing may result in the escape of dangerous UV‐C radiation. Never operate the UV‐C emitter if
damaged or removed from enclosure. Do not touch or look directly into the faucet.
WL380 User Manual
SAFETY ALERT SYMBOLS
SAFETY PRECAUTIONS
Page 4 ‐ Revision: 6‐9‐2016
