GE D90 Plus Communications Manual

Line distance protection system
Hide thumbs Also See for D90 Plus:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
GE
Grid Solutions
Plus
D90
Line Distance Protection System
Communications Guide
Product version: 1.9x
GE publication code: 1601-9070-F4 (GEK-113469D)
1601-9070-F4

Advertisement

Table of Contents
loading

Related Manuals for GE D90 Plus

Summary of Contents for GE D90 Plus

  • Page 1 Grid Solutions Plus Line Distance Protection System Communications Guide Product version: 1.9x GE publication code: 1601-9070-F4 (GEK-113469D) 1601-9070-F4...
  • Page 2 The contents of this manual are the property of GE Multilin Inc. This documentation is furnished on license and may not be reproduced in whole or in part without the permission of GE Multilin. The content of this manual is for informational use only and is subject to change without notice.

  • Page 3: Table Of Contents

    Plus Line Distance Protection System Table of contents 1 INTRODUCTION Safety symbols and definitions..................1 For further assistance ....................1 2 MODBUS Modbus protocol overview ...................3 COMMUNICATION Physical layer..............................3 Data link layer ..............................4 CRC-16 algorithm ............................4 Modbus function codes ....................5 Read actual values ............................5 Execute command............................6 Exception responses.............................7 Modbus settings ......................8...
  • Page 4 TABLE OF CONTENTS PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...

  • Page 5: Introduction

    Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. Indicates practices not related to personal injury. For further assistance For product support, contact the information and call center as follows: GE Grid Solutions 650 Markland Street Markham, Ontario Canada L6C 0M1 PLUS...
  • Page 6 CHAPTER 1: INTRODUCTION Worldwide telephone: +1 905 927 7070 Europe/Middle East/Africa telephone: +34 94 485 88 54 North America toll-free: 1 800 547 8629 Fax: +1 905 927 5098 Worldwide e-mail: multilin.tech@ge.com Europe e-mail: multilin.tech.euro@ge.com Website: http://www.gegridsolutions.com/multilin PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...

  • Page 7: Modbus Modbus Protocol Overview

    Plus Line Distance Protection System Chapter 2: Modbus communication Modbus communication This chapter outlines the Modbus protocol. Use the memory map at the end of the chapter Plus when designing a client to access the D90 device using Modbus. Modbus protocol overview Modbus is a standard protocol for communication among devices.

  • Page 8: Data Link Layer

    MODBUS PROTOCOL OVERVIEW CHAPTER 2: MODBUS COMMUNICATION Data link layer Communication takes place in packets that are groups of asynchronously framed byte data. The master transmits a packet to the slave and the slave responds with a packet. The end of a packet is marked by dead-time on the communications line. The table shows the general format for both transmit and receive packets.

  • Page 9: Modbus Function Codes

    While the Modbus protocol defines function codes from 1 to 127, only a small subset Plus generally is needed. The table outlines the functions supported by the D90 Table 2: Modbus function codes supported Function code Modbus definition GE Grid Solutions definition Decimal Read holding registers Read settings Read input registers Read actual values...

  • Page 10: Execute Command

    MODBUS FUNCTION CODES CHAPTER 2: MODBUS COMMUNICATION The following tables show the format of the master and slave packets. The example shows a master device requesting three register values starting at address 4050h from slave device 11h (17 decimal); the slave device responds with the values 40, 300, and 0 from registers 4050h, 4051h, and 4052h, respectively.

  • Page 11: Exception Responses

    CHAPTER 2: MODBUS COMMUNICATION MODBUS FUNCTION CODES Table 6: Master transmission packet example, function code 05h Packet format Example (hex) Slave address Function code Operation code - high order byte Operation code - low order byte Code value - high order byte Code value - low order byte CRC - low order byte CRC - high order byte...

  • Page 12: Modbus Settings

    MODBUS SETTINGS CHAPTER 2: MODBUS COMMUNICATION Modbus settings This section outlines configuration settings from the instruction manual. Modbus protocol The Modbus server can simultaneously support one client over serial RS485 and four clients over Ethernet. The server is capable of reporting any indication or measurement and operating any output present in the device.

  • Page 13: Modbus Memory Map

    CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP values for the previous Address lines incremented by 1. An address value of “0” in the initial register means "none" and values of “0” displays for all registers. Different address values can be entered as required in any of the register positions. Select the Settings >...
  • Page 14 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Table 10: Modbus memory map Address Description Range Units Step Format Default Product Information (Read Only) 0000 UR Product Type 0 to 65535 F001 0002 Product Version 0 to 655.35 0.01 F001 Product Information (Read Only - Written by Factory) 0010 Serial Number F203...
  • Page 15 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 014F IEC Protocol Function 0 to 1 F126 0 (No) 0150 IEC 61850 Available 0 to 1 F126 0 (No) Settings Notification (Read/Write) 0150 Settings Notification Function 0 to 3 F010 3 (N_IDLE)
  • Page 16 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 0424 Virtual Input 37 Commands 0 to 1 F108 0 (Off) 0425 Virtual Input 38 Commands 0 to 1 F108 0 (Off) 0426 Virtual Input 39 Commands 0 to 1 F108 0 (Off)
  • Page 17 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 06CC Breaker 4 Operations B 0 to 4294967295 F003 06CE Breaker 4 Operations C 0 to 4294967295 F003 06D2 Breaker 5 Operations A 0 to 4294967295 F003 06D4 Breaker 5 Operations B...
  • Page 18 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 0764 ...Repeated for Disconnect 30 Disconnect Operations Actual Values (Read Only Non-Volatile States) (30 Modules) 06F2 Disconnect 1 Operations 0 to 4294967295 F003 06F6 Disconnect 2 Operations 0 to 4294967295 F003 06FA...
  • Page 19 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 078A ...Repeated for Disconnect 14 0 to 15 F107 0 (None) 078C ...Repeated for Disconnect 15 0 to 15 F107 0 (None) 078E ...Repeated for Disconnect 16 0 to 15 F107 0 (None)
  • Page 20 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 07AA ...Repeated for Disconnect 30 0 to 15 F107 0 (None) Inter Relay Transceiver Actual Values (Read Only) (4 Modules) 07B0 Channel 1 Transmit Bias Current 0 to 65535 µA F001...
  • Page 21 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 07B6 ...Repeated for Channel 3 07B7 ...Repeated for Channel 3 07B9 ...Repeated for Channel 4 07BB ...Repeated for Channel 4 Direct I/O (Read/Write Setting) 07C0 Direct Device ID 1 to 16 F001 Direct I/O (Read/Write Command)
  • Page 22 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 080A Digital Counter 2 Frozen -2147483647 to F004 2147483647 080C Digital Counter 2 Frozen Time Stamp 0 to 4294967295 F050 080E Digital Counter 2 Frozen Time Stamp (US) 0 to 4294967295 F003 0810...
  • Page 23 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 090A FlexState bits 161 through 176 0 to 65535 F001 090B FlexState bits 177 through 192 0 to 65535 F001 090C FlexState bits 193 through 208 0 to 65535 F001 090D...
  • Page 24 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default Element State Actual Values (Read Only) (64 Modules); see format code F124 for element enumeration 1000 Operate states for elements 0 to 15 0 to 65535 F502 1001 Operate states for elements 16 to 32...
  • Page 25 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 102E Operate states for elements 736 to 797 0 to 65535 F502 102F Operate states for elements 752 to 814 0 to 65535 F502 1030 Operate states for elements 768 to 831 0 to 65535 F502 1031...
  • Page 26 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1060 Automation Virtual Analog 17 Actual Value –9999999999 to 0.00000 F060 9999999999 1062 Automation Virtual Analog 18 Actual Value –9999999999 to 0.00000 F060 9999999999 1064 Automation Virtual Analog 19 Actual Value –9999999999 to 0.00000 F060...
  • Page 27 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1098 Automation Virtual Analog 45 Actual Value –9999999999 to 0.00000 F060 9999999999 109A Automation Virtual Analog 46 Actual Value –9999999999 to 0.00000 F060 9999999999 109C Automation Virtual Analog 47 Actual Value –9999999999 to 0.00000 F060...
  • Page 28 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 10D0 Automation Virtual Analog 73 Actual Value –9999999999 to 0.00000 F060 9999999999 10D2 Automation Virtual Analog 74 Actual Value –9999999999 to 0.00000 F060 9999999999 10D4 Automation Virtual Analog 75 Actual Value –9999999999 to 0.00000 F060...
  • Page 29 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1108 Automation Virtual Analog 101 Actual Value –9999999999 to 0.00000 F060 9999999999 110A Automation Virtual Analog 102 Actual Value –9999999999 to 0.00000 F060 9999999999 110C Automation Virtual Analog 103 Actual Value –9999999999 to 0.00000 F060...
  • Page 30 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default Automation Virtual Input State Actual Values (Read Only Non-Volatile) 1140 States for Virtual Inputs 0 to 15 0 to 65535 F500 1141 States for Virtual Inputs 16 to 32 0 to 65535 F500 1142...
  • Page 31 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1174 Automation Virtual Input 21 Command 0 to 1 F108 0 (Off) 1175 Automation Virtual Input 22 Command 0 to 1 F108 0 (Off) 1176 Automation Virtual Input 23 Command 0 to 1 F108 0 (Off)
  • Page 32 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 11A3 Automation Virtual Input 68 Command 0 to 1 F108 0 (Off) 11A4 Automation Virtual Input 69 Command 0 to 1 F108 0 (Off) 11A5 Automation Virtual Input 70 Command 0 to 1 F108 0 (Off)
  • Page 33 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 11D2 Automation Virtual Input 115 Command 0 to 1 F108 0 (Off) 11D3 Automation Virtual Input 116 Command 0 to 1 F108 0 (Off) 11D4 Automation Virtual Input 117 Command 0 to 1 F108 0 (Off)
  • Page 34 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1217 Modbus User Map 24 Value 0 to 65535 F001 1218 Modbus User Map 25 Value 0 to 65535 F001 1219 Modbus User Map 26 Value 0 to 65535 F001 121A...
  • Page 35 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1246 Modbus User Map 71 Value 0 to 65535 F001 1247 Modbus User Map 72 Value 0 to 65535 F001 1248 Modbus User Map 73 Value 0 to 65535 F001 1249...
  • Page 36 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1275 Modbus User Map 118 Value 0 to 65535 F001 1276 Modbus User Map 119 Value 0 to 65535 F001 1277 Modbus User Map 120 Value 0 to 65535 F001 1278...
  • Page 37 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 12A4 Modbus User Map 165 Value 0 to 65535 F001 12A5 Modbus User Map 166 Value 0 to 65535 F001 12A6 Modbus User Map 167 Value 0 to 65535 F001 12A7...
  • Page 38 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 12D3 Modbus User Map 212 Value 0 to 65535 F001 12D4 Modbus User Map 213 Value 0 to 65535 F001 12D5 Modbus User Map 214 Value 0 to 65535 F001 12D6...
  • Page 39 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default Data Logger Channel Statistics Actual Values (Read Only) (16 Modules) 1300 Data Logger Channel 1 Maximum -9999999999.999 to 0.001 F060 9999999999.999 1302 Data Logger Channel 1 Maximum Date 0 to 4294967295 F050 1304...
  • Page 40 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1350 Data Logger Channel 5 Minimum Date 0 to 4294967295 F050 1352 Data Logger Channel 5 Minimum Time 0 to 4294967295 F050 1354 Data Logger Channel 5 Average -9999999999.999 to 0.001 F060...
  • Page 41 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 13A4 Data Logger Channel 10 Maximum Date 0 to 4294967295 F050 13A6 Data Logger Channel 10 Maximum Time 0 to 4294967295 F050 13A8 Data Logger Channel 10 Minimum -9999999999.999 to 0.001 F060...
  • Page 42 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 13F6 Data Logger Channel 14 Average -9999999999.999 to 0.001 F060 9999999999.999 13F8 Data Logger Channel 14 Unit F215 (None) 13FC Data Logger Channel 15 Maximum -9999999999.999 to 0.001 F060 9999999999.999...
  • Page 43 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 143F Contact Outputs 113 through 115 Current States 0 to 65535 F500 1440 Contact Outputs 1 to 16 Voltage States 0 to 65535 F500 1441 Contact Outputs 17 to 32 Voltage States 0 to 65535 F500 1442...
  • Page 44 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1552 Remote Double-Point Status Inputs 193 to 208 States 0 to 4 F087 3 (Bad) 1553 Remote Double-Point Status Inputs 209 to 224 States 0 to 4 F087 3 (Bad) 1554...
  • Page 45 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1731 Autoreclose HMI AddCause 0 to 65535 F500 Autoreclose 1P 3P Commands (Read/Write Command) 1740 Autoreclose SCADA Command 0 to 15 F107 0 (None) 1741 Autoreclose HMI Command 0 to 15 F107 0 (None)
  • Page 46 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1858 Source 2 Ground Current Angle -359.9 to 0 ° F002 1859 Source 2 Zero-Sequence Current Magnitude 0 to 999999.999 0.001 F060 185B Source 2 Zero-Sequence Current Angle -359.9 to 0 °...
  • Page 47 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 18D6 Source 4 Ground Current Magnitude 0 to 999999.999 0.001 F060 18D8 Source 4 Ground Current Angle -359.9 to 0 ° F002 18D9 Source 4 Zero-Sequence Current Magnitude 0 to 999999.999 0.001 F060...
  • Page 48 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1954 Source 6 Ground Current RMS 0 to 999999.999 0.001 F060 1956 Source 6 Ground Current Magnitude 0 to 999999.999 0.001 F060 1958 Source 6 Ground Current Angle -359.9 to 0 °...
  • Page 49 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1A4C Source 2 phase CG voltage magnitude 0 to 999999.999 0.001 F060 1A4E Source 2 phase CG voltage angle -359.9 to 0 ° F002 1A4F Source 2 phase AB or AC voltage RMS 0 to 999999.999 0.001 F060...
  • Page 50 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1AC0 Source 4 phase AG voltage RMS 0 to 999999.999 0.001 F060 1AC2 Source 4 phase BG voltage RMS 0 to 999999.999 0.001 F060 1AC4 Source 4 phase CG voltage RMS 0 to 999999.999 0.001 F060...
  • Page 51 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1B22 Source 5 auxiliary voltage angle -359.9 to 0 ° F002 1B23 Source 5 zero-sequence voltage magnitude 0 to 999999.999 0.001 F060 1B25 Source 5 zero-sequence voltage angle -359.9 to 0 °...
  • Page 52 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1A15 Source 1 Phase AB or AC Voltage Magnitude 0 to 999999.999 0.001 F060 1A17 Source 1 Phase AB or AC Voltage Angle -359.9 to 0 °...
  • Page 53 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1A89 Source 3 Phase BG Voltage Magnitude 0 to 999999.999 0.001 F060 1A8B Source 3 Phase BG Voltage Angle -359.9 to 0 ° F002 1A8C Source 3 Phase CG Voltage Magnitude 0 to 999999.999 0.001 F060...
  • Page 54 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1AE9 Source 4 Negative-Sequence Voltage Magnitude 0 to 999999.999 0.001 F060 1BEB Source 4 Negative-Sequence Voltage Angle -359.9 to 0 ° F002 1B00 Source 5 Phase AG Voltage RMS 0 to 999999.999 0.001 F060...
  • Page 55 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1B5E Source 6 Auxiliary Voltage RMS 0 to 999999.999 0.001 F060 1B60 Source 6 Auxiliary Voltage Magnitude 0 to 999999.999 0.001 F060 1B62 Source 6 Auxiliary Voltage Angle -359.9 to 0 °...
  • Page 56 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1C2E Source 2 Phase C Reactive Power -1000000000000 to 0.001 F060 1000000000000 1C30 Source 2 Three-Phase Apparent Power -1000000000000 to 0.001 F060 1000000000000 1C32 Source 2 Phase A Apparent Power -1000000000000 to 0.001 F060...
  • Page 57 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 1C6C Source 4 Phase B Reactive Power -1000000000000 to 0.001 F060 1000000000000 1C6E Source 4 Phase C Reactive Power -1000000000000 to 0.001 F060 1000000000000 1C70 Source 4 Three-Phase Apparent Power -1000000000000 to 0.001 F060...
  • Page 58 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 1CAA Source 6 Phase A Reactive Power -1000000000000 to 0.001 F060 1000000000000 1CAC Source 6 Phase B Reactive Power -1000000000000 to 0.001 F060 1000000000000 1CAE Source 6 Phase C Reactive Power -1000000000000 to 0.001 F060...
  • Page 59 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default Frequency Metering Actual Values (Read Only) (6 Modules) 1D80 Source 1 Frequency 2 to 90 0.001 F003 1D82 Source 2 Frequency 2 to 90 0.001 F003 1D84 Source 3 Frequency 2 to 90...
  • Page 60 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 21FA Breaker 2 Arcing Accumulated Arcing Current Phase 0 to 99999999 -cyc 1 F060 21FC Breaker 2 Arcing Clearing Time Phase A 0 to 65535 F001 21FD Breaker 2 Arcing Clearing Time Phase B 0 to 65535...
  • Page 61 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 234F Fault 1 Prefault Phase C Voltage Magnitude 0 to 999999.999 0.001 F060 2351 Fault 1 Prefault Phase C Voltage Angle -359.9 to 0 ° F002 2352 Fault 1 Fault Phase A Current Magnitude 0 to 999999.999...
  • Page 62 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2545 Breaker 1 Block Open Cmd 0 to 65535 F300 2546 Breaker 1 Ext Close Cmd 0 to 65535 F300 2547 Breaker 1 AR Close Supv 0 to 65535 F300 2548...
  • Page 63 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2667 Breaker 1 Interlock Open Interlock 1 0 to 65535 F300 2668 Breaker 1 Interlock Open Interlock 2 0 to 65535 F300 2669 Breaker 1 Interlock Open Interlock 3 0 to 65535 F300 266A...
  • Page 64 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2B25 FlexState 38 Actual Value 0 to 1 F108 0 (Off) 2B26 FlexState 39 Actual Value 0 to 1 F108 0 (Off) 2B27 FlexState 40 Actual Value 0 to 1 F108 0 (Off)
  • Page 65 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2B54 FlexState 85 Actual Value 0 to 1 F108 0 (Off) 2B55 FlexState 86 Actual Value 0 to 1 F108 0 (Off) 2B56 FlexState 87 Actual Value 0 to 1 F108 0 (Off)
  • Page 66 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2B83 FlexState 132 Actual Value 0 to 1 F108 0 (Off) 2B84 FlexState 133 Actual Value 0 to 1 F108 0 (Off) 2B85 FlexState 134 Actual Value 0 to 1 F108 0 (Off)
  • Page 67 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2BB2 FlexState 179 Actual Value 0 to 1 F108 0 (Off) 2BB3 FlexState 180 Actual Value 0 to 1 F108 0 (Off) 2BB4 FlexState 181 Actual Value 0 to 1 F108 0 (Off)
  • Page 68 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2BE1 FlexState 226 Actual Value 0 to 1 F108 0 (Off) 2BE2 FlexState 227 Actual Value 0 to 1 F108 0 (Off) 2BE3 FlexState 228 Actual Value 0 to 1 F108 0 (Off)
  • Page 69 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2C0F Contact Input 16 Actual Value 0 to 1 F108 0 (Off) 2C10 Contact Input 17 Actual Value 0 to 1 F108 0 (Off) 2C11 Contact Input 18 Actual Value 0 to 1 F108 0 (Off)
  • Page 70 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2C3E Contact Input 63 Actual Value 0 to 1 F108 0 (Off) 2C3F Contact Input 64 Actual Value 0 to 1 F108 0 (Off) 2C40 Contact Input 65 Actual Value 0 to 1 F108 0 (Off)
  • Page 71 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2C6D Contact Input 110 Actual Value 0 to 1 F108 0 (Off) 2C6E Contact Input 111 Actual Value 0 to 1 F108 0 (Off) 2C6F Contact Input 112 Actual Value 0 to 1 F108 0 (Off)
  • Page 72 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2D28 Contact Output 41 Actual Value 0 to 1 F108 0 (Off) 2D29 Contact Output 42 Actual Value 0 to 1 F108 0 (Off) 2D2A Contact Output 43 Actual Value 0 to 1 F108 0 (Off)
  • Page 73 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2D57 Contact Output 88 Actual Value 0 to 1 F108 0 (Off) 2D58 Contact Output 89 Actual Value 0 to 1 F108 0 (Off) 2D59 Contact Output 90 Actual Value 0 to 1 F108 0 (Off)
  • Page 74 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 2D12 Virtual Output 19 Actual Value 0 to 1 F108 0 (Off) 2D13 Virtual Output 20 Actual Value 0 to 1 F108 0 (Off) 2D14 Virtual Output 21 Actual Value 0 to 1 F108 0 (Off)
  • Page 75 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 2F00 Remote Device State (32 items) 0 to 1 F155 0 (Offline) 2F80 Remote Input State (64 items) 0 to 1 F108 0 (Off) Transient Recorder Commands (Read/Write Command) 3005 Transient Record Force Trigger 0 to 1...
  • Page 76 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 3350 Modbus File Transfer Filename 2 F204 (none) 3378 Modbus File Transfer State 2 0 to 7 F095 0 (IDLE) 3379 Modbus File Transfer Position 2 0 to 4294967295 F003 337B...
  • Page 77 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 3741 Disturbance Record Available Files 0 to 65535 F001 3742 Disturbance Record Last Cleared Date 0 to 400000000 F050 3744 Disturbance Record Number of Cycles per Record 0 to 65535 F001 3745...
  • Page 78 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 3A7C ...Repeated for User Pushbutton 30 Disconnect (Read/Write Setting) (30 Modules) 3AA0 Disconnect 1 Function 0 to 1 F102 0 (Disabled) 3AA1 Disconnect 1 Long Name F202 "Disconnect 1"...
  • Page 79 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 3DAF ...Repeated for Disconnect 28 3DCC ...Repeated for Disconnect 29 3DE9 ...Repeated for Disconnect 30 Disconnect Control (Read/Write Setting) (30 Modules) 3E10 Disconnect 1 Control Function 0 to 1 F102 0 (Disabled)
  • Page 80 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default Passwords (Read/Write Setting) 4008 Modbus Local Setting Password Setting (4 items) 0 to 4294967295 F003 Passwords (Read/Write Command) 4010 Modbus Remote Command Password Setting (4 0 to 4294967295 F003 items) Passwords (Read/Write Setting)
  • Page 81 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 408C Network Address NSAP F074 4096 Configure IP Network 0 to 1 F126 0 (No) 4097 TFTP Main IP Port Number 1 to 65535 F001 4098 TFTP Data IP Port Number (4 items) 0 to 65535 F001...
  • Page 82 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default Communications (Read/Write Setting) 410F IEC IP Port Number 1 to 65535 F001 2404 4110 IEC Sector Address 0 to 65535 F001 4111 IEC Cyclic Data Transmission Period 1 to 65535 F001 4112...
  • Page 83 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 41C3 Transient Record Trigger Position 1 to 100 F001 41C4 Transient Record Sample Rate 0 to 5 F183 2 (32 samples/ cycle) 41C5 Transient Record Analog Channel (16 items) 0 to 4294967295 F600 41E5...
  • Page 84 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 448E ...Repeated for CT Bank 8 Aux CT Settings (Read/Write Setting) (6 Modules) 4490 Ground CT 1 Ratio 1 to 65000 F001 4491 Ground CT 1 Secondary 0 to 1 F123 0 (1 A)
  • Page 85 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 4786 Synchrocheck 1 Maximum Frequency Difference 0 to 2 0.01 F001 1000 4787 Synchrocheck 1 Dead Source Select 0 to 5 F176 1 (LV1 and DV2) 4788 Synchrocheck 1 Dead V1 Maximum Voltage 0 to 1.25...
  • Page 86 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default Data Logger (Read/Write Setting) 4B00 Data Logger Function 0 to 1 F102 0 (Disabled) 4B01 Data Logger Block 0 to 65535 F300 4B02 Data Logger Rate 1 to 3600 F001 4B03...
  • Page 87 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 4C64 ...Repeated for Disconnect 3 4C6E ...Repeated for Disconnect 4 4C78 ...Repeated for Disconnect 5 4C82 ...Repeated for Disconnect 6 4C8C ...Repeated for Disconnect 7 4C96 ...Repeated for Disconnect 8 4CA0 ...Repeated for Disconnect 9...
  • Page 88 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 51D4 ...Repeated for module number 13 51FB ...Repeated for module number 14 5222 ...Repeated for module number 15 5249 ...Repeated for module number 16 5270 ...Repeated for module number 17 5297 ...Repeated for module number 18 52BE...
  • Page 89 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 587C ...Repeated for FlexLogic Timer 32 Phase Time Overcurrent (TOC) (Read/Write Grouped Setting) (6 Modules) 5900 Phase Time Overcurrent 1 Function 0 to 1 F102 0 (Disabled) 5901 Phase Time Overcurrent 1 Signal Source 0 to 5...
  • Page 90 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 5B04 Neutral Time Overcurrent 1 Curve 0 to 16 F103 0 (IEEE Mod Inv) 5B05 Neutral Time Overcurrent 1 Multiplier 0 to 600 0.01 F001 5B06 Neutral Time Overcurrent 1 Reset 0 to 1 F104...
  • Page 91 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 5D10 ...Repeated for Ground Time Overcurrent 2 5D20 ...Repeated for Ground Time Overcurrent 3 5D30 ...Repeated for Ground Time Overcurrent 4 5D40 ...Repeated for Ground Time Overcurrent 5 5D50 ...Repeated for Ground Time Overcurrent 6 Ground Instantaneous Overcurrent (IOC) (Read/Write Grouped Setting) (12 Modules)
  • Page 92 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 605A Wattmetric Ground Fault 1 Curve 0 to 5 F236 0 (Definite Time) 605B Wattmetric Ground Fault 1 Multiplier 0.01 to 2 0.01 F001 605C Wattmetric Ground Fault 1 Block 0 to 65535 F300 605D...
  • Page 93 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 64D0 Overfrequency 1 Function 0 to 1 F102 0 (Disabled) 64D1 Overfrequency 1 Block 0 to 65535 F300 64D2 Overfrequency 1 Source 0 to 5 F167 0 (SRC 1) 64D3 Overfrequency 1 Pickup...
  • Page 94 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 6703 Load Encroachment Reach 0.02 to 250 ohms 0.01 F001 6704 Load Encroachment Angle 5 to 50 degrees 1 F001 6705 Load Encroachment Pickup Delay 0 to 65.535 0.001 F001 6706...
  • Page 95 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 6830 DUTT Function 0 to 1 F102 0 (Disabled) 6831 DUTT Seal In Delay 0 to 65.535 0.001 F001 6832 DUTT 1P Number of Communication Bits 0 to 2 F198 0 (1)
  • Page 96 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 686C Hybrid POTT 1P Trans Block Reset Delay 0 to 65.535 0.001 F001 686D Hybrid POTT 1P Echo Duration 0 to 65.535 0.001 F001 686E Hybrid POTT 1P Echo Lockout 0 to 65.535 0.001 F001...
  • Page 97 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 689C Autoreclose Breaker 3 Pole Open 0 to 65535 F300 689D Autoreclose 3-Pole Dead Time 1 0 to 655.35 0.01 F001 689E Autoreclose 3-Pole Dead Time 2 0 to 655.35 0.01 F001...
  • Page 98 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 68D0 Directional Comparison Unblocking Rx1 0 to 65535 F300 68D1 Directional Comparison Unblocking LOG1 0 to 65535 F300 68D2 Directional Comparison Unblocking Rx2 0 to 65535 F300 68D3 Directional Comparison Unblocking LOG2...
  • Page 99 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 7073 Phase Distance Zone 1 Direction 0 to 2 F154 0 (Forward) 7074 Phase Distance Zone 1 Comparator Limit 30 to 90 degrees 1 F001 7075 Phase Distance Zone 1 Delay 0 to 65.535 0.001...
  • Page 100 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 7145 Ground Distance Zone 1 Non-Homogeneous Angle -40 to 40 degrees 0.1 F002 7146 Ground Distance Zone 1 POL Current 0 to 1 F521 0 (Zero-seq) 7147 Ground Distance Zone 1 Reverse Reach 0.02 to 500...
  • Page 101 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 721B Breaker Failure 1 Neutral Amp Loset Pickup 0.001 to 30 0.001 F001 1050 721C Breaker Failure 1 Loset Time 0 to 65.535 0.001 F001 721D Breaker Failure 1 Trip Dropout Delay 0 to 65.535 0.001...
  • Page 102 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 72A3 Neg Sequence Directional Overcurrent 1 Forward 0 to 90 ° Lag F002 72A4 Neg Seq Directional Overcurrent 1 Forward Limit 40 to 90 degrees 1 F001 Angle 72A5...
  • Page 103 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 7362 ...Repeated for IEC 61850 GOOSE Analog Input 15 7369 ...Repeated for IEC 61850 GOOSE Analog Input 16 7370 ...Repeated for IEC 61850 GOOSE Analog Input 17 7377 ...Repeated for IEC 61850 GOOSE Analog Input 18 737E...
  • Page 104 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 74AB ...Repeated for IEC 61850 GOOSE Analog Input 62 74B2 ...Repeated for IEC 61850 GOOSE Analog Input 63 74B9 ...Repeated for IEC 61850 GOOSE Analog Input 64 74C0 ...Repeated for IEC 61850 GOOSE Analog Input 65 74C7...
  • Page 105 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 75F4 ...Repeated for IEC 61850 GOOSE Analog Input 109 76FB ...Repeated for IEC 61850 GOOSE Analog Input 110 7602 ...Repeated for IEC 61850 GOOSE Analog Input 111 7609 ...Repeated for IEC 61850 GOOSE Analog Input 112 7610...
  • Page 106 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 7F20 ...Repeated for Neutral Overvoltage 3 Auxiliary Overvoltage (Read/Write Grouped Setting) (3 Modules) 7F30 Auxiliary Overvoltage 1 Function 0 to 1 F102 0 (Disabled) 7F31 Auxiliary Overvoltage 1 Signal Source 0 to 5 F167 0 (SRC 1)
  • Page 107 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 934C ...Repeated for Automation Virtual Input 13 9355 ...Repeated for Automation Virtual Input 14 935E ...Repeated for Automation Virtual Input 15 9367 ...Repeated for Automation Virtual Input 16 9370 ...Repeated for Automation Virtual Input 17 9379...
  • Page 108 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 94EA ...Repeated for Automation Virtual Input 59 94F3 ...Repeated for Automation Virtual Input 60 94FC ...Repeated for Automation Virtual Input 61 9505 ...Repeated for Automation Virtual Input 62 950E ...Repeated for Automation Virtual Input 63 9517...
  • Page 109 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 9691 ...Repeated for Automation Virtual Input 106 969A ...Repeated for Automation Virtual Input 107 96A3 ...Repeated for Automation Virtual Input 108 96AC ...Repeated for Automation Virtual Input 109 96B5 ...Repeated for Automation Virtual Input 110 96BE...
  • Page 110 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 97FA ...Repeated for Automation Virtual Output 23 9801 ...Repeated for Automation Virtual Output 24 9808 ...Repeated for Automation Virtual Output 25 980F ...Repeated for Automation Virtual Output 26 9816 ...Repeated for Automation Virtual Output 27 981D...
  • Page 111 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 9943 ...Repeated for Automation Virtual Output 70 994A ...Repeated for Automation Virtual Output 71 9951 ...Repeated for Automation Virtual Output 72 9958 ...Repeated for Automation Virtual Output 73 995F ...Repeated for Automation Virtual Output 74 9966...
  • Page 112 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 9A8C ...Repeated for Automation Virtual Output 117 9A93 ...Repeated for Automation Virtual Output 118 9A9A ...Repeated for Automation Virtual Output 119 9AA1 ...Repeated for Automation Virtual Output 120 9AA8 ...Repeated for Automation Virtual Output 121 9AAF...
  • Page 113 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default 9BD5 ...Repeated for Automation Virtual Output 164 9BDC ...Repeated for Automation Virtual Output 165 9BE3 ...Repeated for Automation Virtual Output 166 9BEA ...Repeated for Automation Virtual Output 167 9BF1 ...Repeated for Automation Virtual Output 168 9BF8...
  • Page 114 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default 9D1E ...Repeated for Automation Virtual Output 211 9D25 ...Repeated for Automation Virtual Output 212 9D2C ...Repeated for Automation Virtual Output 213 9D33 ...Repeated for Automation Virtual Output 214 9D3A ...Repeated for Automation Virtual Output 215 9D41...
  • Page 115 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default FlexElement (Read/Write Setting) (16 Modules) A0B0 FlexElement 1 Function 0 to 1 F102 0 (Disabled) A0B1 FlexElement 1 Name F206 “FxE 1” A0B4 FlexElement 1 InputP 0 to 4294967295 F600 A0B6...
  • Page 116 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default A2E0 FlexElement 9 Actual -2147483.647 to 0.001 F004 2147483.647 A2E2 FlexElement 10 Actual -2147483.647 to 0.001 F004 2147483.647 A2E4 FlexElement 11 Actual -2147483.647 to 0.001 F004 2147483.647 A2E6 FlexElement12 Actual...
  • Page 117 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default A409 Selector 10 Position 1 to 7 F001 Selector Switch Settings (Read/Write Setting) (10 Modules) A410 Selector 1 Function 0 to 1 F102 0 (Disabled) A411 Selector 1 Range 1 to 7 F001...
  • Page 118 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default AA64 ...Repeated for Non-Volatile Latch 11 AA6E ...Repeated for Non-Volatile Latch 12 AA78 ...Repeated for Non-Volatile Latch 13 AA82 ...Repeated for Non-Volatile Latch 14 AA8C ...Repeated for Non-Volatile Latch 15 AA96 ...Repeated for Non-Volatile Latch 16 Digital Counter (Read/Write Setting) (8 Modules)
  • Page 119 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default AF4D IEC 61850 Config GOOSE ConfRev 1 to 4294967295 F003 AF4F IEC 61850 Config GOOSE Tx Dataset Item (64 items) 0 to 516 F232 0 (NONE) AF8F ...Repeated for module number 2 AFF9...
  • Page 120 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default DFD6 PMU one-shot negative-sequence current angle -180 to 180 ° 0.01 F002 DFD7 PMU one-shot zero-sequence current magnitude 0 to 999999.999 0.001 F060 DFD9 PMU one-shot zero-sequence current angle -180 to 180 °...
  • Page 121 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default B32A ...Repeated for IEC 61850 GGIO2 SPCSO 53 B32B ...Repeated for IEC 61850 GGIO2 SPCSO 54 B32C ...Repeated for IEC 61850 GGIO2 SPCSO 55 B32D ...Repeated for IEC 61850 GGIO2 SPCSO 56 B32E ...Repeated for IEC 61850 GGIO2 SPCSO 57 B32F...
  • Page 122 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default B40F ...Repeated for IEC 61850 GGIO4 Analog 28 B417 ...Repeated for IEC 61850 GGIO4 Analog 29 B41F ...Repeated for IEC 61850 GGIO4 Analog 30 B427 ...Repeated for IEC 61850 GGIO4 Analog 31 B42F ...Repeated for IEC 61850 GGIO4 Analog 32 IEC 61850 GSE Configuration (Read/Write Settings)
  • Page 123 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default B8C2 IEC 61850 MMXU Hz Deadband 1 0.001 to 100 0.001 F003 10000 B8C4 IEC 61850 MMXU PPV.phsAB Deadband 1 0.001 to 100 0.001 F003 10000 B8C6 IEC 61850 MMXU PPV.phsBC Deadband 1 0.001 to 100...
  • Page 124 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default IEC 61850 GSSE Hold Time (Read/Write Setting) BCB8 GSSE Minimum Hold Time 50 to 4000 F001 BCBA GOOSE Minimum Time to Live 50 to 4000 F001 IEC 61850 GOOSE Retrans Profiles (Read/Write Setting) (8 Modules) BCBC Config GOOSE 1 Minimum Time to Live...
  • Page 125 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default BCED ...Repeated for IEC 61850 GGIO5 SPCSO 34 ctlModel BCEE ...Repeated for IEC 61850 GGIO5 SPCSO 35 ctlModel BCEF ...Repeated for IEC 61850 GGIO5 SPCSO 36 ctlModel BCF0 ...Repeated for IEC 61850 GGIO5 SPCSO 37 ctlModel BCF1...
  • Page 126 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default BD1C ...Repeated for IEC 61850 GGIO5 SPCSO 81 ctlModel BD1D ...Repeated for IEC 61850 GGIO5 SPCSO 82 ctlModel BD1E ...Repeated for IEC 61850 GGIO5 SPCSO 83 ctlModel BD1F ...Repeated for IEC 61850 GGIO5 SPCSO 84 ctlModel BD20...
  • Page 127 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default BD4B ...Repeated for IEC 61850 GGIO5 SPCSO 128 ctlModel IEC 61850 Received Analogs (Read Only) (128 Modules) BD28 IEC 61850 GOOSE Analog Input 1 -1000000000000 to 0.001 F060 1000000000000...
  • Page 128 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default BD80 ...Repeated for IEC 61850 GOOSE Analog Input 45 BD82 ...Repeated for IEC 61850 GOOSE Analog Input 46 BD84 ...Repeated for IEC 61850 GOOSE Analog Input 47 BD86 ...Repeated for IEC 61850 GOOSE Analog Input 48 BD88...
  • Page 129 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default BDDE ...Repeated for IEC 61850 GOOSE Analog Input 92 BDE0 ...Repeated for IEC 61850 GOOSE Analog Input 93 BDE2 ...Repeated for IEC 61850 GOOSE Analog Input 94 BDE4 ...Repeated for IEC 61850 GOOSE Analog Input 95 BDE6...
  • Page 130 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default BD86 ...Repeated for Contact Input 7 BD8F ...Repeated for Contact Input 8 BD98 ...Repeated for Contact Input 9 BDA1 ...Repeated for Contact Input 10 BDAA ...Repeated for Contact Input 11 BDB3 ...Repeated for Contact Input 12 BDBC...
  • Page 131 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default BF2D ...Repeated for Contact Input 54 BF36 ...Repeated for Contact Input 55 BF3F ...Repeated for Contact Input 56 BF48 ...Repeated for Contact Input 57 BF51 ...Repeated for Contact Input 58 BF5A ...Repeated for Contact Input 59 BF63...
  • Page 132 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default C0D4 ...Repeated for Contact Input 101 C0DD ...Repeated for Contact Input 102 C0E6 ...Repeated for Contact Input 103 C0EF ...Repeated for Contact Input 104 C0F8 ...Repeated for Contact Input 105 C101 ...Repeated for Contact Input 106 C10A...
  • Page 133 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default C27B ...Repeated for Contact Input 148 C284 ...Repeated for Contact Input 149 C28D ...Repeated for Contact Input 150 C296 ...Repeated for Contact Input 151 C29F ...Repeated for Contact Input 152 C2A8 ...Repeated for Contact Input 153 C2B1...
  • Page 134 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default C422 ...Repeated for Contact Input 195 C42B ...Repeated for Contact Input 196 C434 ...Repeated for Contact Input 197 C43D ...Repeated for Contact Input 198 C446 ...Repeated for Contact Input 199 C44F ...Repeated for Contact Input 200 C458...
  • Page 135 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default C5C9 ...Repeated for Contact Input 242 C5D2 ...Repeated for Contact Input 243 C5DB ...Repeated for Contact Input 244 C5E4 ...Repeated for Contact Input 245 C5ED ...Repeated for Contact Input 246 C5F6 ...Repeated for Contact Input 247 C5FF...
  • Page 136 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default C7D1 ...Repeated for Virtual Input 26 C7DA ...Repeated for Virtual Input 27 C7E3 ...Repeated for Virtual Input 28 C7EC ...Repeated for Virtual Input 29 C7F5 ...Repeated for Virtual Input 30 C7FE ...Repeated for Virtual Input 31 C807...
  • Page 137 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default C95A ...Repeated for Virtual Output 7 C961 ...Repeated for Virtual Output 8 C968 ...Repeated for Virtual Output 9 C96F ...Repeated for Virtual Output 10 C976 ...Repeated for Virtual Output 11 C97D ...Repeated for Virtual Output 12 C984...
  • Page 138 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default CAA3 ...Repeated for Virtual Output 54 CAAA ...Repeated for Virtual Output 55 CAB1 ...Repeated for Virtual Output 56 CAB8 ...Repeated for Virtual Output 57 CABF ...Repeated for Virtual Output 58 CAC6 ...Repeated for Virtual Output 59 CACD...
  • Page 139 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default CD53 Remote Input 1 Events 0 to 1 F102 0 (Disabled) CD54 Remote Input 1 Name F205 “Rem I/P 1” CD5A ...Repeated for Remote Input 2 CD64 ...Repeated for Remote Input 3 CD6E...
  • Page 140 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default CF1C ...Repeated for Remote Input 47 CF26 ...Repeated for Remote Input 48 CF30 ...Repeated for Remote Input 49 CF3A ...Repeated for Remote Input 50 CF44 ...Repeated for Remote Input 51 CF4E ...Repeated for Remote Input 52 CF58...
  • Page 141 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default D038 ...Repeated for Remote Output 27 D03C ...Repeated for Remote Output 28 D040 ...Repeated for Remote Output 29 D044 ...Repeated for Remote Output 30 D048 ...Repeated for Remote Output 31 D04C ...Repeated for Remote Output 32 Remote Output UserSt Pairs (Read/Write Setting) (32 Modules)
  • Page 142 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default D0D4 Remote DPS Input 1 Name F205 "RemDPS Ip 1" D0DA ...Repeated for Remote DPS Input 2 D0E4 ...Repeated for Remote DPS Input 3 D0EE ...Repeated for Remote DPS Input 4 D0F8 ...Repeated for Remote DPS Input 5 D102...
  • Page 143 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default D314 ...Repeated for Contact Output 13 D31F ...Repeated for Contact Output 14 D32A ...Repeated for Contact Output 15 D335 ...Repeated for Contact Output 16 D340 ...Repeated for Contact Output 17 D34B ...Repeated for Contact Output 18 D356...
  • Page 144 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default D519 ...Repeated for Contact Output 60 D524 ...Repeated for Contact Output 61 D52F ...Repeated for Contact Output 62 D53A ...Repeated for Contact Output 63 D545 ...Repeated for Contact Output 64 D550 ...Repeated for Contact Output 65 D55B...
  • Page 145 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default D71E ...Repeated for Contact Output 107 D729 ...Repeated for Contact Output 108 D734 ...Repeated for Contact Output 109 D73F ...Repeated for Contact Output 110 D74A ...Repeated for Contact Output 111 D755 ...Repeated for Contact Output 112 D760...
  • Page 146 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default Clear Disturbance Recorder (Read/Write Setting) D842 Clear Disturbance Recorder 0 to 65535 F300 Force Contacts Inputs (Read/Write Setting) (255 Modules) DA40 Force Contact Input 1 State 0 to 2 F144 0 (Normal)
  • Page 147 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default DA6C ...Repeated for Force Contact Input 45 DA6D ...Repeated for Force Contact Input 46 DA6E ...Repeated for Force Contact Input 47 DA6F ...Repeated for Force Contact Input 48 DA70 ...Repeated for Force Contact Input 49 DA71...
  • Page 148 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default DA9B ...Repeated for Force Contact Input 92 DA9C ...Repeated for Force Contact Input 93 DA9D ...Repeated for Force Contact Input 94 DA9E ...Repeated for Force Contact Input 95 DA9F ...Repeated for Force Contact Input 96 DAA0...
  • Page 149 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default DACA ...Repeated for Force Contact Input 139 DACB ...Repeated for Force Contact Input 140 DACC ...Repeated for Force Contact Input 141 DACD ...Repeated for Force Contact Input 142 DACE ...Repeated for Force Contact Input 143 DACF...
  • Page 150 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default DAF9 ...Repeated for Force Contact Input 186 DAFA ...Repeated for Force Contact Input 187 DAFB ...Repeated for Force Contact Input 188 DAFC ...Repeated for Force Contact Input 189 DAFD ...Repeated for Force Contact Input 190 DAFE...
  • Page 151 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default DB28 ...Repeated for Force Contact Input 233 DB29 ...Repeated for Force Contact Input 234 DB2A ...Repeated for Force Contact Input 235 DB2B ...Repeated for Force Contact Input 236 DB2C ...Repeated for Force Contact Input 237 DB2D...
  • Page 152 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default DC6C ...Repeated for Automation Virtual Analog 19 DC72 ...Repeated for Automation Virtual Analog 20 DC78 ...Repeated for Automation Virtual Analog 21 DC7E ...Repeated for Automation Virtual Analog 22 DC84 ...Repeated for Automation Virtual Analog 23 DC8A...
  • Page 153 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default DD86 ...Repeated for Automation Virtual Analog 66 DD8C ...Repeated for Automation Virtual Analog 67 DD92 ...Repeated for Automation Virtual Analog 68 DD98 ...Repeated for Automation Virtual Analog 69 DD9E ...Repeated for Automation Virtual Analog 70 DDA4...
  • Page 154 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default DEA0 ...Repeated for Automation Virtual Analog 113 DEA6 ...Repeated for Automation Virtual Analog 114 DEAC ...Repeated for Automation Virtual Analog 115 DEB2 ...Repeated for Automation Virtual Analog 116 DEB8 ...Repeated for Automation Virtual Analog 117 DEBE...
  • Page 155 PMU Function 0 to 1 F102 0 (Disabled) E033 PMU IDcode 1 to 65534 F001 E034 PMU STN F203 "GE-UR+PMU" E03C PMU Source 0 to 5 F167 0 (SRC 1) E03D PMU Post-Filter 0 to 3 F540 1 (Symm 3-...
  • Page 156 1 (None) E04B PMU PHS-x (14 items) 0 to 14 F543 0 (Off) E075 PMU PHS-x Name (14 items) F203 "GE-UR+PMU- PHS x" E1C5 PMU A-CH-x (8 items) 0 to 4294967295 F600 E1F5 PMU D-CH-x Name (8 items) F203 "AnalogChan nel x"...
  • Page 157 E4D0 PMU Rec PHS-x (14 items) 0 to 14 F543 0 (Off) E4DE PMU Rec PHS-x Name (14 items) F203 "GE-UR+PMU- PHS x" E54E PMU Rec A-CH-x (8 items) 0 to 4294967295 F600 E55E PMU Rec D-CH-x Name (8 items) F203 "AnalogChan...
  • Page 158 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default E640 PMU Auxiliary Voltage Test Magnitude 0 to 700 0.01 F003 50000 E642 PMU Auxiliary Voltage Test Angle -180 to 180 ° 0.05 F002 E643 PMU Phase A Current Test Magnitude 0 to 9.999 0.001 F004...
  • Page 159 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Address Description Range Units Step Format Default E7F5 ...Repeated for Remote Device 8 E816 ...Repeated for Remote Device 8 E817 ...Repeated for Remote Device 8 E818 ...Repeated for Remote Device 9 E839 ...Repeated for Remote Device 9 E83A ...Repeated for Remote Device 9 E83B...

  • Page 160: Modbus Data Formats

    MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Address Description Range Units Step Format Default EA25 ...Repeated for Remote Device 24 EA46 ...Repeated for Remote Device 24 EA48 ...Repeated for Remote Device 25 EA69 ...Repeated for Remote Device 25 EA6B ...Repeated for Remote Device 26 EA8C ...Repeated for Remote Device 26 EA8E...
  • Page 161 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F004: UR_SINT32 (signed 32-bit integer, 2 registers) The high order word is stored in the first register. The low order word is stored in the second register. F010: Settings notification (16-bit enumeration) This format code indicates the values for the settings notification command. Enumeration Value N_Clear N_Loading...
  • Page 162 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F072: HEX6 (six bytes - 12 ASCII digits) F074: HEX20 (20 bytes - 40 ASCII digits) F075: Recorder memory available (16-bit enumeration) This format code indicates memory availability for reports. Enumeration Value Green Yellow PLUS LINE DISTANCE PROTECTION SYSTEM –...
  • Page 163 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F076: Metering source (16-bit enumeration) Enumeration Value SRC 1 SRC 2 SRC 3 SRC 4 F079: GGIO6 master device (16-bit enumeration) Enumeration Value None Remote Device 1 ↓ ↓ Remote Device 32 F080: Autoreclose 1P 3P mode (16-bit enumeration) Enumeration Value 1 &...
  • Page 164 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F084: Selector power up (16-bit enumeration) Enumeration Value Restore Synchronize Sync/Restore F085: Power swing shape (16-bit enumeration) Enumeration Value Mho Shape Quad Shape F086: SPS input default state (16-bit enumeration) This format code indicates channel input state. Enumeration Value Latest/Off Latest/On...
  • Page 165 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F088: Inter-relay application (16-bit enumeration) Enumeration Value None Direct I/O Teleprotection Direct I/O redundant F091: Data logger mode (16-bit enumeration) Enumeration Value Mean F094: Trigger mode (16-bit enumeration) Enumeration Value Trigger Only Retrigger Only Trigger/Retrigger F095: Modbus file transfer state (16-bit enumeration) Enumeration Value...
  • Page 166 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F100: VT connection type (16-bit enumeration) Enumeration Value Delta F102: Enabled/disabled choice (16-bit enumeration) This format code indicates the enabled or disabled value for relevant registers. Enumeration Value Disabled Enabled F103: Curve shapes (16-bit enumeration) Enumeration Value IEEE Mod Inv IEEE Very Inv...
  • Page 167 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F107: Select-before operate command (16-bit enumeration) This format code indicates the values for the breaker and disconnect configuration commands. Enumeration Value None Select Cancel Bypass Close Open Untag Substitution on Substitution off Substitution closed Substitution opened Local Remote...
  • Page 168 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F111: Undervoltage curves (16-bit enumeration) Enumeration Value Definite Time Inverse Time F112: RS485 baud rate (16-bit enumeration) Enumeration Value 1200 2400 4800 9600 19200 38400 57600 115200 F113: Parity (16-bit enumeration) This format code indicates parity of the serial interface. Enumeration Value None Even...
  • Page 169 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value 0.40 0.45 0.48 0.50 0.52 0.54 0.56 0.58 0.60 0.62 0.64 0.66 0.68 0.70 0.72 0.74 0.76 0.78 0.80 0.82 0.84 0.86 0.88 0.90 0.91 0.92 0.93 0.94 0.95 0.96 0.97 0.98 1.03 1.05...
  • Page 170 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Enumeration Value 2.40 2.50 2.60 2.70 2.80 2.90 3.00 3.10 3.20 3.30 3.40 3.50 3.60 3.70 3.80 3.90 4.00 4.10 4.20 4.30 4.40 4.50 4.60 4.70 4.80 4.90 5.00 5.10 5.20 5.30 5.40 5.50 5.60 5.70...
  • Page 171 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value 11.50 12.00 12.50 13.00 13.50 14.00 14.50 15.00 15.50 16.00 16.50 17.00 17.50 18.00 18.50 19.00 19.50 20.00 F120: Distance shape (16-bit enumeration) Enumeration Value Quad F122: Element input signal type (16-bit enumeration) Enumeration Value Phasor F123: CT secondary (16-bit enumeration)
  • Page 172 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Enumeration Element Phase directional overcurrent 2 Neutral instantaneous overcurrent 1 Neutral instantaneous overcurrent 2 Neutral instantaneous overcurrent 3 Neutral instantaneous overcurrent 4 Neutral time overcurrent 1 Neutral time overcurrent 2 Neutral time overcurrent 3 Neutral time overcurrent 4 Neutral directional overcurrent 1 Neutral directional overcurrent 2...
  • Page 173 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Element Load encroachment Power swing detect Battery monitor Voltage transformer fuse failure (VTFF) 1 Voltage transformer fuse failure (VTFF) 2 Voltage transformer fuse failure (VTFF) 3 Source 1 disturbance detection (50DD) Source 2 disturbance detection (50DD) Source 3 disturbance detection (50DD) Breaker control 1 Breaker control 2...
  • Page 174 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Enumeration Element FlexElement 8 FlexElement 9 FlexElement 10 FlexElement 11 FlexElement 12 FlexElement 13 FlexElement 14 FlexElement 15 FlexElement 16 Non-volatile latch 1 Non-volatile latch 2 Non-volatile latch 3 Non-volatile latch 4 Non-volatile latch 5 Non-volatile latch 6 Non-volatile latch 7 Non-volatile latch 8...
  • Page 175 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Element User-programmable pushbutton 6 User-programmable pushbutton 7 User-programmable pushbutton 8 User-programmable pushbutton 9 User-programmable pushbutton 10 User-programmable pushbutton 11 User-programmable pushbutton 12 User-programmable pushbutton 13 User-programmable pushbutton 14 User-programmable pushbutton 15 User-programmable pushbutton 16 User-programmable pushbutton 17 User-programmable pushbutton 18 User-programmable pushbutton 19...
  • Page 176 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F127: Latched or self-resetting (16-bit enumeration) Enumeration Value Latched Self-Reset F131: Forced contact output state (16-bit enumeration) Enumeration Value Normal Energized De-energized Freeze F133: Program state (16-bit enumeration) This format code indicates if the device in online or offline. The device needs to be in the Programmed state to function, else error messages display.
  • Page 177 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value Phase B to C to ground fault (B-C-G) Phase C to A to ground fault (C-A-G) Phase A to B to C fault (A-B-C) Phase A to B to C to ground fault (A-B-C-G) F150: Inter-relay protocol encoding (16-bit enumeration) This format code indicates the clock.
  • Page 178 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F153: Distance transformer connection (16-bit enumeration) Enumeration Value None Dy11 Yd11 F154: Distance direction (16-bit enumeration) Enumeration Value Forward Reverse Non-directional F155: Ethernet link status (16-bit enumeration) Enumeration Value Offline Online F156: Remote input dataset items (16-bit enumeration) Enumeration Value None DNA-1...
  • Page 179 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value UserSt-15 UserSt-16 UserSt-17 UserSt-18 UserSt-19 UserSt-20 UserSt-21 UserSt-22 UserSt-23 UserSt-24 UserSt-25 UserSt-26 UserSt-27 UserSt-28 UserSt-29 UserSt-30 UserSt-31 UserSt-32 Dataset Item 1 ↓ ↓ Dataset Item 64 PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...
  • Page 180 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F157: Pole indication mode (16-bit enumeration) Enumeration Value 3-Pole 1-Pole F158: Remote DPS input dataset items (16-bit enumeration) Enumeration Value None Dataset Item 1 ↓ ↓ Dataset Item 64 F166: Auxiliary VT connect type (16-bit enumeration) Enumeration Value F167: Signal source (16-bit enumeration) Enumeration Value...
  • Page 181 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F173: Network IP update status (16-bit enumeration) This format code indicates port status. Enumeration Value PORT 1 NETMASK ERROR PORT 2 NETMASK ERROR PORT 3 NETMASK ERROR PORT 1 IP ADDR RSVD PORT 2 IP ADDR RSVD PORT 3 IP ADDR RSVD PORT 1 IP ADDR LPBK PORT 2 IP ADDR LPBK...
  • Page 182 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F174: Communication port without UDP (16-bit enumeration) Enumeration Value None COM1 - RS485 Network - TCP F176: Synchrocheck dead source select (16-bit enumeration) Enumeration Value None LV1 and DV2 DV1 and LV2 DV1 or DV2 DV1 Xor DV2 DV1 and DV2 F177: Communication port with UDP (16-bit enumeration)
  • Page 183 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F186: Measurement mode (16-bit enumeration) This format code indicates undervoltage measurement mode. Enumeration Value Phase to Ground Phase to Phase PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...
  • Page 184 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F192: Ethernet operation mode (16-bit enumeration) Enumeration Value 10/100 BASE-TX 100 BASE-FX Auto F194: DNP scale factor (16-bit enumeration) Enumeration Value 0.01 1000 10000 100000 0.001 F195: Singe pole trip mode (16-bit enumeration) Enumeration Value Disabled 3 Pole Only...
  • Page 185 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value Contact Outs 49-64 Remote Ins 1-16 Remote Ins 17-32 Remote Devs 1-16 Elements 1-16 Elements 17-32 Elements 33-48 Elements 49-64 Elements 65-80 Elements 81-96 Elements 97-112 Elements 113-128 Elements 129-144 Elements 145-160 Elements 161-176 Elements 177-192 Elements 193-208...
  • Page 186 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F198: Pilot scheme communication bits (16-bit enumeration) Enumeration Value F199: Disabled/enabled custom (16-bit enumeration) This format code applies to pilot POTT and Pilot Directional Comparison Unblocking (DCUB). Enumeration Value Disabled Enabled Custom F202: TEXT20 (20-character ASCII text) 10 registers, 16 bits, first character most significant bit (MSB), second character least significant bit (LSB).
  • Page 187 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F213: TEXT32 (32-character ASCII text) F215: TEXT8 (eight-character ASCII text) F221: IEC 61850 GOOSE retransmission profiles (16-bit enumeration) Enumeration Value NONE AGGRESSIVE STANDARD RELAXED F223: Setting control access type (16-bit enumeration) This format code indicates local or remote connection. Enumeration Value Local Remote...
  • Page 188 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Enumeration Value MMXU1.MX.PPV.phsAB.cVal.ang.f MMXU1.MX.PPV.phsBC.cVal.mag.f MMXU1.MX.PPV.phsBC.cVal.ang.f MMXU1.MX.PPV.phsCA.cVal.mag.f MMXU1.MX.PPV.phsCA.cVal.ang.f MMXU1.MX.PhV.phsA.cVal.mag.f MMXU1.MX.PhV.phsA.cVal.ang.f MMXU1.MX.PhV.phsB.cVal.mag.f MMXU1.MX.PhV.phsB.cVal.ang.f MMXU1.MX.PhV.phsC.cVal.mag.f MMXU1.MX.PhV.phsC.cVal.ang.f MMXU1.MX.A.phsA.cVal.mag.f MMXU1.MX.A.phsA.cVal.ang.f MMXU1.MX.A.phsB.cVal.mag.f MMXU1.MX.A.phsB.cVal.ang.f MMXU1.MX.A.phsC.cVal.mag.f MMXU1.MX.A.phsC.cVal.ang.f MMXU1.MX.A.neut.cVal.mag.f MMXU1.MX.A.neut.cVal.ang.f MMXU1.MX.W.phsA.cVal.mag.f MMXU1.MX.W.phsB.cVal.mag.f MMXU1.MX.W.phsC.cVal.mag.f MMXU1.MX.VAr.phsA.cVal.mag.f MMXU1.MX.VAr.phsB.cVal.mag.f MMXU1.MX.VAr.phsC.cVal.mag.f MMXU1.MX.VA.phsA.cVal.mag.f MMXU1.MX.VA.phsB.cVal.mag.f MMXU1.MX.VA.phsC.cVal.mag.f MMXU1.MX.PF.phsA.cVal.mag.f MMXU1.MX.PF.phsB.cVal.mag.f MMXU1.MX.PF.phsC.cVal.mag.f MMXU2.MX.TotW.mag.f MMXU2.MX.TotVAr.mag.f MMXU2.MX.TotVA.mag.f...
  • Page 189 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value MMXU2.MX.PhV.phsC.cVal.ang.f MMXU2.MX.A.phsA.cVal.mag.f MMXU2.MX.A.phsA.cVal.ang.f MMXU2.MX.A.phsB.cVal.mag.f MMXU2.MX.A.phsB.cVal.ang.f MMXU2.MX.A.phsC.cVal.mag.f MMXU2.MX.A.phsC.cVal.ang.f MMXU2.MX.A.neut.cVal.mag.f MMXU2.MX.A.neut.cVal.ang.f MMXU2.MX.W.phsA.cVal.mag.f MMXU2.MX.W.phsB.cVal.mag.f MMXU2.MX.W.phsC.cVal.mag.f MMXU2.MX.VAr.phsA.cVal.mag.f MMXU2.MX.VAr.phsB.cVal.mag.f MMXU2.MX.VAr.phsC.cVal.mag.f MMXU2.MX.VA.phsA.cVal.mag.f MMXU2.MX.VA.phsB.cVal.mag.f MMXU2.MX.VA.phsC.cVal.mag.f MMXU2.MX.PF.phsA.cVal.mag.f MMXU2.MX.PF.phsB.cVal.mag.f MMXU2.MX.PF.phsC.cVal.mag.f MMXU3.MX.TotW.mag.f MMXU3.MX.TotVAr.mag.f MMXU3.MX.TotVA.mag.f MMXU3.MX.TotPF.mag.f MMXU3.MX.Hz.mag.f MMXU3.MX.PPV.phsAB.cVal.mag.f MMXU3.MX.PPV.phsAB.cVal.ang.f MMXU3.MX.PPV.phsBC.cVal.mag.f MMXU3.MX.PPV.phsBC.cVal.ang.f MMXU3.MX.PPV.phsCA.cVal.mag.f MMXU3.MX.PPV.phsCA.cVal.ang.f MMXU3.MX.PhV.phsA.cVal.mag.f MMXU3.MX.PhV.phsA.cVal.ang.f...
  • Page 190 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Enumeration Value MMXU3.MX.W.phsB.cVal.mag.f MMXU3.MX.W.phsC.cVal.mag.f MMXU3.MX.VAr.phsA.cVal.mag.f MMXU3.MX.VAr.phsB.cVal.mag.f MMXU3.MX.VAr.phsC.cVal.mag.f MMXU3.MX.VA.phsA.cVal.mag.f MMXU3.MX.VA.phsB.cVal.mag.f MMXU3.MX.VA.phsC.cVal.mag.f MMXU3.MX.PF.phsA.cVal.mag.f MMXU3.MX.PF.phsB.cVal.mag.f MMXU3.MX.PF.phsC.cVal.mag.f MMXU4.MX.TotW.mag.f MMXU4.MX.TotVAr.mag.f MMXU4.MX.TotVA.mag.f MMXU4.MX.TotPF.mag.f MMXU4.MX.Hz.mag.f MMXU4.MX.PPV.phsAB.cVal.mag.f MMXU4.MX.PPV.phsAB.cVal.ang.f MMXU4.MX.PPV.phsBC.cVal.mag.f MMXU4.MX.PPV.phsBC.cVal.ang.f MMXU4.MX.PPV.phsCA.cVal.mag.f MMXU4.MX.PPV.phsCA.cVal.ang.f MMXU4.MX.PhV.phsA.cVal.mag.f MMXU4.MX.PhV.phsA.cVal.ang.f MMXU4.MX.PhV.phsB.cVal.mag.f MMXU4.MX.PhV.phsB.cVal.ang.f MMXU4.MX.PhV.phsC.cVal.mag.f MMXU4.MX.PhV.phsC.cVal.ang.f MMXU4.MX.A.phsA.cVal.mag.f MMXU4.MX.A.phsA.cVal.ang.f MMXU4.MX.A.phsB.cVal.mag.f MMXU4.MX.A.phsB.cVal.ang.f MMXU4.MX.A.phsC.cVal.mag.f MMXU4.MX.A.phsC.cVal.ang.f...
  • Page 191 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value MMXU4.MX.PF.phsC.cVal.mag.f MMXU5.MX.TotW.mag.f MMXU5.MX.TotVAr.mag.f MMXU5.MX.TotVA.mag.f MMXU5.MX.TotPF.mag.f MMXU5.MX.Hz.mag.f MMXU5.MX.PPV.phsAB.cVal.mag.f MMXU5.MX.PPV.phsAB.cVal.ang.f MMXU5.MX.PPV.phsBC.cVal.mag.f MMXU5.MX.PPV.phsBC.cVal.ang.f MMXU5.MX.PPV.phsCA.cVal.mag.f MMXU5.MX.PPV.phsCA.cVal.ang.f MMXU5.MX.PhV.phsA.cVal.mag.f MMXU5.MX.PhV.phsA.cVal.ang.f MMXU5.MX.PhV.phsB.cVal.mag.f MMXU5.MX.PhV.phsB.cVal.ang.f MMXU5.MX.PhV.phsC.cVal.mag.f MMXU5.MX.PhV.phsC.cVal.ang.f MMXU5.MX.A.phsA.cVal.mag.f MMXU5.MX.A.phsA.cVal.ang.f MMXU5.MX.A.phsB.cVal.mag.f MMXU5.MX.A.phsB.cVal.ang.f MMXU5.MX.A.phsC.cVal.mag.f MMXU5.MX.A.phsC.cVal.ang.f MMXU5.MX.A.neut.cVal.mag.f MMXU5.MX.A.neut.cVal.ang.f MMXU5.MX.W.phsA.cVal.mag.f MMXU5.MX.W.phsB.cVal.mag.f MMXU5.MX.W.phsC.cVal.mag.f MMXU5.MX.VAr.phsA.cVal.mag.f MMXU5.MX.VAr.phsB.cVal.mag.f MMXU5.MX.VAr.phsC.cVal.mag.f MMXU5.MX.VA.phsA.cVal.mag.f MMXU5.MX.VA.phsB.cVal.mag.f...
  • Page 192 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION Enumeration Value MMXU6.MX.PPV.phsCA.cVal.mag.f MMXU6.MX.PPV.phsCA.cVal.ang.f MMXU6.MX.PhV.phsA.cVal.mag.f MMXU6.MX.PhV.phsA.cVal.ang.f MMXU6.MX.PhV.phsB.cVal.mag.f MMXU6.MX.PhV.phsB.cVal.ang.f MMXU6.MX.PhV.phsC.cVal.mag.f MMXU6.MX.PhV.phsC.cVal.ang.f MMXU6.MX.A.phsA.cVal.mag.f MMXU6.MX.A.phsA.cVal.ang.f MMXU6.MX.A.phsB.cVal.mag.f MMXU6.MX.A.phsB.cVal.ang.f MMXU6.MX.A.phsC.cVal.mag.f MMXU6.MX.A.phsC.cVal.ang.f MMXU6.MX.A.neut.cVal.mag.f MMXU6.MX.A.neut.cVal.ang.f MMXU6.MX.W.phsA.cVal.mag.f MMXU6.MX.W.phsB.cVal.mag.f MMXU6.MX.W.phsC.cVal.mag.f MMXU6.MX.VAr.phsA.cVal.mag.f MMXU6.MX.VAr.phsB.cVal.mag.f MMXU6.MX.VAr.phsC.cVal.mag.f MMXU6.MX.VA.phsA.cVal.mag.f MMXU6.MX.VA.phsB.cVal.mag.f MMXU6.MX.VA.phsC.cVal.mag.f MMXU6.MX.PF.phsA.cVal.mag.f MMXU6.MX.PF.phsB.cVal.mag.f MMXU6.MX.PF.phsC.cVal.mag.f GGIO4.MX.AnIn1.mag.f GGIO4.MX.AnIn2.mag.f GGIO4.MX.AnIn3.mag.f GGIO4.MX.AnIn4.mag.f GGIO4.MX.AnIn5.mag.f GGIO4.MX.AnIn6.mag.f...
  • Page 193 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP Enumeration Value GGIO4.MX.AnIn20.mag.f GGIO4.MX.AnIn21.mag.f GGIO4.MX.AnIn22.mag.f GGIO4.MX.AnIn23.mag.f GGIO4.MX.AnIn24.mag.f GGIO4.MX.AnIn25.mag.f GGIO4.MX.AnIn26.mag.f GGIO4.MX.AnIn27.mag.f GGIO4.MX.AnIn28.mag.f GGIO4.MX.AnIn29.mag.f GGIO4.MX.AnIn30.mag.f GGIO4.MX.AnIn31.mag.f GGIO4.MX.AnIn32.mag.f GGIO6.MX.AnIn1.mag.f GGIO6.MX.AnIn2.mag.f GGIO6.MX.AnIn3.mag.f GGIO6.MX.AnIn4.mag.f GGIO6.ST.Ind1.stVal GGIO6.ST.Ind2.stVal F233: IEC 61850 GOOSE Rx Dataset items (16-bit enumeration) This format code indicates the IEC 68150 Rx items. Enumeration Value None GGIO3.ST.Ind1.q...
  • Page 194 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F234: Wattmetric ground fault voltage selection (16-bit enumeration) Enumeration Value Calculated VN Measured VX F235: Wattmetric ground fault current selection (16-bit enumeration) Enumeration Value Calculated IN Measured IG F236: Wattmetric ground fault curve (16-bit enumeration) Enumeration Value Definite Time Inverse...
  • Page 195 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F239: Daylight savings time day instance (16-bit enumeration) This format code indicates the week for the day to start and stop daylight savings time. Enumeration Value First Second Third Fourth Last F270: Fault report VT substitution (16-bit enumeration) Enumeration Value None F300: FlexLogic BASE type (6-bit type)
  • Page 196 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F513: Power swing mode (16-bit enumeration) Enumeration Value Two Step Three Step F514: Power swing trip mode (16-bit enumeration) Enumeration Value Delayed Early F515: Element input mode (16-bit enumeration) This format code indicates FlexElement input mode. Enumeration Value Signed Absolute...
  • Page 197 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F521: Ground distance polarizing current (16-bit enumeration) Enumeration Value Zero-seq Neg-seq F523: DNP object 20, 22, 23 default variation (16-bit enumeration) Enumeration Value F524: DNP object 21 default variation (16-bit enumeration) Enumeration Value F525: DNP object 32 default variation (16-bit enumeration) Enumeration Value 531: Language (16-bit enumeration)
  • Page 198 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION F540: PMU post-filter (16-bit enumeration) Enumeration Value None Symm-3-point Symm-5-point Symm-7-point F542: PMU trigger mode (16-bit enumeration) Enumeration Value Automatic Overwrite Protected F543: PMU phasors (16-bit enumeration) Enumeration Value F544: PMU recording/reporting rate (16-bit enumeration) Enumeration Value 1/sec 2/sec...
  • Page 199 CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP F545: PMU communications port type (16-bit enumeration) Enumeration Value Network None F546: PMU reporting style (16-bit enumeration) Enumeration Value Polar Rectangular F547: PMU reporting format(16-bit enumeration) Enumeration Value Integer Floating F600: FlexAnalog parameter (UR_UINT32) The 32-bit value corresponds to the Modbus address (comprised of an 8-bit function code and 16-bit address) of the value to be used when this parameter is selected.
  • Page 200 MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...

  • Page 201: Dnp Dnp Device Profile

    Plus Line Distance Protection System Chapter 3: DNP communication DNP communication This chapter outlines the Distributed Network Protocol (DNP). DNP device profile DNP allows for the optimization of control and data acquisition between the equipment in the substation and the central control center. It improves upon many master-slave protocols by improving overall communication performance requirements and provides time-stamping with millisecond accuracy.
  • Page 202 DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION – Analog input changes (object 32) – Analog deadbands (object 34) – Time and date (object 50) – Time delay fine (object 52) – Class 0, 1, 2, and 3 data (object 60) –...

  • Page 203: Dnp V3.00 Implementation Document

    CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE Plus Explanation of sometimes — Object 12 points are mapped to the D90 virtual inputs. The persistence of virtual inputs is determined by the virtual input Type settings. The Plus “Pulse on” and “Latch on” operations perform the same function in the D90 ;...
  • Page 204 DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION • Qualifier codes for requests, object 1, variation 0: – 00, 01 (start-stop) – 06 (no range, or all) – 07, 08 (limited quantity) – 17, 28 (index) There are no codes used for responses. Object 1, Variation 1: Binary input Object 1, Variation 2: Binary input with status The following codes are used for requests.
  • Page 205 CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE – 130 (unsolicited response) • Qualifier codes for responses, object 2, variations 1 and 2: – 17, 28 (index) Object 2, Variation 3: Binary input change with relative time The following codes are used for requests. •...
  • Page 206 DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION – 3 (select) – 4 (operate) – 5 (direct operate) – 6 (direct operate, no acknowledge) • Qualifier codes for requests, object 12, variation 1: – 00, 01 (start-stop) – 07, 08 (limited quantity) –...
  • Page 207 CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE – 06 (no range, or all) – 07, 08 (limited quantity) – 17, 28 (index) The following codes are used for responses. • Function codes for responses, object 20, variations 1, 2, 5, and 6: –...
  • Page 208 DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION Variation 0 is used to request the default variation. The following codes are used for requests. • Function codes for requests, object 22, variation 0: – 1 (read) • Qualifier codes for requests, object 22, variation 0: –...
  • Page 209 CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE • Function codes for responses, object 23, variations 1, 2, 5, and 6: – 129 (response) – 130 (unsolicited response) • Qualifier codes for responses, object 23, variations 1, 2, 5, and 6: –...
  • Page 210 DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION • Qualifier codes for requests, object 32, variation 0: – 06 (no range, or all) – 07, 08 (limited quantity) There are no codes used for responses. Object 32, variation 1: 32-bit analog input change events without time Object 32, variation 2: 16-bit analog input change events without time Object 32, variation 3: 32-bit analog input change events with time Object 32, variation 4: 16-bit analog input change events with time...
  • Page 211 CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE – 06 (no range, or all) – 07, 08 (limited quantity) – 17, 28 (index) The following codes are used for responses. • Function codes for responses, object 34, variations 1, 2, and 3: –...

  • Page 212: Dnp Protocol Settings

    DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION – 21 (disable unsolicited response) – 22 (assign class) • Qualifier codes for requests, object 60, variation 0: – 06 (no range, or all) There are no codes used for responses. Object 60, variation 1: class 0 data The following codes are used for requests.
  • Page 213 CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE operating any output present in the device. Both direct-operate and select-before-operate modes of control are supported. Two user-configurable input and output maps are implemented. Select the Settings > Communications > DNP > Protocol menu to open the DNP protocol configuration window.
  • Page 214 DNP DEVICE PROFILE CHAPTER 3: DNP COMMUNICATION DNP Channel Address Range: 0 to 65519 in steps of 1 Default: 1 Plus This setting specifies the DNP slave address. This number identifies the D90 on a DNP communications link. Assign a unique address to each DNP slave. DNP Client Address 1 through DNP Client Address 5 Range: any standard IP address Default: 0.0.0.0...
  • Page 215 CHAPTER 3: DNP COMMUNICATION DNP DEVICE PROFILE DNP Current Default Deadband, DNP Voltage Default Deadband, DNP Power Default Deadband, DNP Energy Default Deadband, DNP Other Default Deadband Range: 0 to 100000000 in steps of 1 Default: 30000 These settings determine when to trigger unsolicited responses containing analog input Plus data.

  • Page 216: Dnp Points

    DNP POINTS CHAPTER 3: DNP COMMUNICATION DNP TCP Connection Timeout Range: 10 to 300 seconds in steps of 1 Default: 120 seconds This setting specifies a time delay for the detection of dead network TCP connections. If there is no data traffic on a DNP TCP connection for greater than the time specified by Plus this setting, the connection is aborted by the D90 .

  • Page 217: Binary And Frozen Counter Points

    CHAPTER 3: DNP COMMUNICATION DNP POINTS Point 64 → automation virtual input 1 Point 65 → automation virtual input 2 Point 66 → automation virtual input 3 Point 191 → automation virtual input 128 Binary and frozen counter points The following description applies to binary counters (object 20) and frozen counters (object 21).

  • Page 218: Analog Input Points

    DNP POINTS CHAPTER 3: DNP COMMUNICATION Plus A counter freeze command has no meaning for counters 8 and 9. The D90 digital counter values are represented as 32-bit integers. The DNP 3.0 protocol defines counters to be unsigned integers. Take care when interpreting negative counter values. Analog input points The DNP analog input data points are configured through the Settings >...
  • Page 219 CHAPTER 3: DNP COMMUNICATION DNP POINTS Figure 4: DNP user point list configuration settings The following settings are available for points 0 through 255. DNP Binary Input Point 0...DNP Binary Input Point 255 Range: any FlexLogic operand Default: Off These settings represent DNP binary input points and are configured by assigning an appropriate FlexLogic operand to each.
  • Page 220 DNP POINTS CHAPTER 3: DNP COMMUNICATION PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...
  • Page 221 Plus Line Distance Protection System Index Index Auxiliary overvoltage, Modbus ............102 Help, getting ....................1 Auxiliary undervoltage, Modbus ..........102 IEC 61850 protocol, Modbus ..............98 Breaker arcing current, Modbus ............. 98 Breaker failure, Modbus ............... 96 Memory map ....................9 Modbus Communications execute operation ...................
  • Page 222 INDEX Phase undervoltage, Modbus ............94 Repair .........................1 Settings ....................8, 9, 208 Support, technical ..................1 Technical support ..................1 User map ......................9 User point list ..................214 VT fuse failure, Modbus ..............112 PLUS LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE...

Table of Contents
