UHF FM REPEATER
TKR-850
SERVICE MANUAL
SUPPLEMENT
This supplement to the Service Manual is available for products with serial number 50500011 or later.
This Service Manual contains a parts list, schematic diagrams and PC boards of a new final unit for the TKR-850.
Since the adjustment procedure is the same as before, refer to the Service Manual (K,E : B51-8557-10 , C : B51-8568-10) for
the TKR-850 for items not provided in this Service Manual.
Panel (Outer)
(A62-0840-03)
Panel assy
(A62-0934-03)
PARTS LIST .............................................................................................. 2
PC BOARD
FINAL UNIT (X45-3740-10) .................................................................. 4
SCHEMATIC DIAGRAM ........................................................................... 8
EXPLODED VIEW ................................................................................... 10
SPECIFICATIONS ................................................................................... 11
Key top
(K29-5460-02)
CONTENTS
© 2003-7 PRINTED IN JAPAN
B51-8662-00 ( N ) 1927
Knob (DC source)
(K29-9106-04)
Knob (VOL)
(K29-5389-03)
Modular jack
(E08-0877-05)

Advertisement

loading

Related Manuals for Kenwood TKR-850

Summary of Contents for Kenwood TKR-850

  • Page 1: Table Of Contents

    This supplement to the Service Manual is available for products with serial number 50500011 or later. This Service Manual contains a parts list, schematic diagrams and PC boards of a new final unit for the TKR-850. Since the adjustment procedure is the same as before, refer to the Service Manual (K,E : B51-8557-10 , C : B51-8568-10) for the TKR-850 for items not provided in this Service Manual.

  • Page 2: Parts List

    Les articles non mentionnes dans le Parts No. ne sont pas fournis. Y : AAFES (Europe) X : Australia M : Other Areas Teile ohne Parts No. werden nicht geliefert. C : China TKR-850 (Y54-319X-XX) FINAL UNIT (X45-3740-10) Desti- Desti- Ref. No. Address Parts No.
  • Page 3 TKR-850 PARTS LIST FINAL UNIT (X45-3740-10) Desti- Desti- Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description parts nation parts nation RK73FB2A470J CHIP R 1/10W 2SC4116(Y) TRANSISTOR R92-2571-05 CHIP R 1/2W DTD123EK DIGITAL TRANSISTOR R92-1259-05 CHIP R...
  • Page 4 TKR-850 PC BOARD FINAL UNIT (X45-3740-10) Component side view (J72-0911-09) CN8 GND CN6 MAIN DC (BLACK) (RED) CN7 BACKUP (ORANGE) Back up battery Main DC CHARGE C120 FAB 1 TX IN J72-0911-09 (B/2) Ref. No. Address Ref. No. Address Ref. No. Address...
  • Page 5 TKR-850 PC BOARD FINAL UNIT (X45-3740-10) Component side view (J72-0911-09) C118 C120 J72-0911-09 (A/2) Component side Layer 1 Layer 2 Layer 3 Layer 4 Foil side...
  • Page 6 TKR-850 TKR-850 PC BOARD PC BOARD FINAL UNIT (X45-3740-10) Component side view (J72-0911-09) FINAL UNIT (X45-3740-10) Component side view (J72-0911-09) CN8 GND CN6 MAIN DC (BLACK) (RED) CN7 BACKUP (ORANGE) Back up battery Main DC CHARGE C118 C120 FAB 1...
  • Page 7 TKR-850 PC BOARD FINAL UNIT (X45-3740-10) Foil side view (J72-0911-09) J72-0911-09 (A/2) Ref. No. Address...
  • Page 8 TKR-850 PC BOARD FINAL UNIT (X45-3740-10) Foil side view (J72-0911-09) C115 C114 Back up battery Main DC C105 C101 C103 C102 J72-0911-09 (B/2) Component side Layer 1 Layer 2 Layer 3 Layer 4 Foil side...
  • Page 9 TKR-850 TKR-850 PC BOARD PC BOARD FINAL UNIT (X45-3740-10) Foil side view (J72-0911-09) FINAL UNIT (X45-3740-10) Foil side view (J72-0911-09) C115 C114 Back up battery Main DC C105 C101 C103 C102 J72-0911-09 (A/2) J72-0911-09 (B/2) Component side Ref. No. Address...

  • Page 10: Schematic Diagram

    TKR-850 SCHEMATIC DIAGRAM FINAL UNIT (X45-3740-10)(A/2) T:7.57V T:7.61V T:7.91V R:0V R:0V R:0V 2SC3356(R24) 470p 470p 6.8n 470p 2SC5110(O) 2SK2596 T:0.70V T:0.69V R:0V R:0V Q1-3 RF AMP 100k 2SC4116(Y) DC SWITCH SURGE VOLTAGE PROTECTOR REGULATOR T:13.03V R:13.54V NJM78L05UA 100k TK11050M Comp.out...
  • Page 11 TKR-850 SCHEMATIC DIAGRAM DRIVE FINAL AMP PD55008S RD60HUF1-01 C160 470p 470p 470p D4,5 RF DETECTOR T:4.26V R:0V DC AMP VOLTAGE REFERENCE C120 TA75W01FU 0.022u IN2+ IN2- IN1+ 470k OUT-B IN1- OUT1 (X45-3740-10)(B/2) CN51 MAIN DC MAIN DC T:13.05V R:13.56V REVERSE...
  • Page 12 FINAL UNIT (X45-3740-10)(A/2) T:7.57V T:7.61V T:7.91V R:0V R:0V R:0V DRIVE FINAL AMP PD55008S RD60HUF1-01 2SC3356(R24) C160 470p 470p 6.8n 470p 470p 470p 470p 2SC5110(O) 2SK2596 T:0.70V T:0.69V R:0V R:0V D4,5 RF DETECTOR Q1-3 T:4.26V RF AMP R:0V DC AMP VOLTAGE REFERENCE C120 TA75W01FU...

  • Page 13: Exploded View

    TKR-850 EXPLODED VIEW M4 x 14 : N30-4014-46 N M3 x 8 : N67-3008-46 O M2.6 x 6 (Br-Tap) : N87-2606-46 Q M3 x 6 (Br-Tap) : N87-3006-46 Hardware fixture (J21-8467-04) Earth spring (G02-0894-04) Qx11 Final (A/2) Final (B/2) Parts with the exploded numbers larger than 700 are not supplied.

  • Page 14: Specifications

    TKR-850 SPECIFICATIONS (K,C TYPE) GENERAL Frequency Range ........ 450 to 480MHz Number of Channels ......16 channel Channel Spacing ......... Wide : 25kHz Narrow : 12.5kHz (PLL channel stepping 5kHz/6.25kHz) Operating Voltage ....... 13.6V DC± 15% Current Drain Standby .......... 0.8A Standby w/power save ....
