- Page 1 HU-20 Water Purifier Product Installation & Operation Manual Honeywell Environmental & Combustion Controls (Tianjin) Co., Ltd.
-
Page 2: Table Of Contents
Catalog Important Notes Safety Precautions Product Functions Product Features Installation Instructions P6-P7 Operation Instructions Care & Maintenance Warranty Provisions Packing List... -
Page 3: Important Notes
3. For the water purifier maintenance and filter cartridge replacement, use the replacement parts authorized by Honeywell Environmental & Combustion Controls (Tianjin) Co., Ltd..Quality problems, degradation of operational performance or property damage caused by using una- uthorized parts or accessories are not covered in the guarantee. -
Page 4: Safety Precautions
Safety Precautions At the inlet of the water purifier, the water quality must be the municipal tap water quality which meets local standard. Do not install the water purifier in the water supply pipe, whose press- ure exceeds 0.6MPa. If the water inlet pressure exceeds 0.6 MPa, the pressure reduce valve (purchased separately) must be installed. -
Page 5: Product Functions
Product Functions Exterior Features 330mm 122mm Figure 1 Figure 1 Technical Parameters Model HU-20 Water inlet pressure 0 .2MPa～0.6MPa Water inlet temperature 5–38°C Purified water flow rate 1.5 L / Min Rated maximum capacity *2500L Water inlet requirement Municipal tap water, conforming to local standard * The rated maximum capacity is the effective treatment capacity after adding the standard solution in the whole process according to the inspection rules required by Ministry of Health. -
Page 6: Product Features
Product Features Brief Introduction The water purifier is designed to work under the table near the sink in the kitchen. The supply pipe connects to your existing water connection pipe with a tee joint. This water purifier is designed to purify the drinking water. The water purifier filter cartridges need to be changed regularly. -
Page 7: Installation Instructions
Installation Instructions Input Outlet Filter adapte PP dense cotton filter cartridge MS composite molecular sieve filter cartridge (sterilization) UF membrane Figure 2 Preparations before Installation 1. Confirm the location before installing the water purifier. (It depends on the actual ins- tallation) 2. - Page 8 Installation Instructions Installation Steps Plug Ring Cold water pipe Ball Valve connection nut Ball Valve nut Sealing gasket 1/4" PE pipe Tee joint Sealing gasket MS composite Cold water valve molecular sieve filter Wrapped cartridge (sterilization) PP dense cotton with PTFE filter cartridge UF membrane tape...
-
Page 9: Operation Instructions
Operation Instructions 1. Check water purifier and components regularly to avoid leakage, which may cause damage to property. 2. When you go out or do not use the water purifier for a long time, pl- ease shut off the water inlet of the purifier (turn off the water inlet b- all valve). -
Page 10: Care & Maintenance
Care & Maintenance The set of capacity and replacement time recommended for filter cartridges at various stages Recommended Filter cartridge name Recommended replacement time handling capacity 3-9 months PP dense cotton filter 1-2 tons MS composite molecular 6-12 months 1.5-3 tons sieve (sterilization) 12-18 months UF membrane... -
Page 11: Warranty Provisions
● Users should keep the invoice and the manual in a safe place. ● The product should be installed by service teams authorized by Honeywell ● or qualified installation teams authorized by the State authority. The supplied manual must be strictly followed when using the product. -
Page 12: Packing List
Packing List Item Quantity Filter adapter 1 set 1 set PP dense cotton filter cartridge MS composite molecular sieve filter 1 set cartridge (sterilization) UF membrane filter cartridge 1 set 1/4”PE white pipe 2.0 m 1/4” tee joint 1 pcs Accessories 1/2”... - Page 13 Honeywell Environmental & Combustion Controls (Tianjin) Co., Ltd. No. 158, NanHai Road Tianjin Economic-Technological Development Area Tianjin, 300457, P.R.C. Phone: +86-22-66287000 Subject to change without notice 50085497-001...
