Radial Lead Type
NHG
Series:
Type:
■
Features
● Endurance : 105 °C 1000 h to 2000 h
● RoHS directive compliant
■
Specifi cations
Category Temp. Range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Cur rent
tan δ
Endurance
Shelf Life
■
Frequency correction factor for ripple current
W.V.(V.DC)
6.3 to 100
160 to 450
■
Di men sions in mm (not to scale)
Pressure relief
φ6.3<
Body Dia. φD
Lead Dia. φd
Lead space F
Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
A
–55 °C to +105 °C
6.3 V.DC to 100 V.DC
0.1 µF to 22000 µF
I < 0.01 CV or 3 (µA) After 2 minutes
(Which is greater)
Please see the attached standard products list
After following life test with DC voltage and +105 °C±2 °C ripple current value applied (The sum
of DC and ripple peak voltage shall not exceed the rated working voltage), When the capacitors
are restored to 20 °C, the capacitors shall meet the limits specifi ed below.
Duration : 6.3 V.DC to 100 V.DC : (φ5 to φ8)=1000 hours, (φ10 to φ18)=2000 hours
160 V.DC to 450 V.DC : 2000 hours
Capacitance change ±20 % of initial measured value
tan δ
< 200 % of initial specifi ed value
< initial specifi ed value
DC leakage current
After storage for 1000 hours at +105 °C±2 °C with no voltage applied and then being stabilized
at +20 °C, capacitors shall meet the limits specifi ed in Endurance. (With voltage treatment)
Cap. (µF)
0.1 to
33
47
to
470
1000
to 22000
1
to
330
Sleeve
φd±0.05
✽
L
14 min.
✽ L<16 : L±1.0
L>20 : L±2.0
5
6.3
0.5
0.5
2.0
2.5
Aluminum Electrolytic Capacitors/ NHG
±20 % (120 Hz/+20 °C)
Frequency (Hz)
60
120
0.75
1.00
0.80
1.00
0.85
1.00
0.80
1.00
φ5 to φ8
+
–
φD±0.5
3 min.
8
10
0.6
0.6
3.5
5.0
–25 °C to +105 °C
160 V.DC to 450 V.DC
1.0 µF to 330 µF
I < 0.06 CV +10 (µA) After 2 minutes
1 k
10 k
1.55
1.80
1.35
1.50
1.10
1.15
1.35
1.50
[mm]
φ10<
φD±0.5
12.5
16
0.6
0.8
5.0
7.5
100 k
2.00
1.50
1.15
1.50
(mm)
18
0.8
7.5
Apr. 2008
