Advanced image processing
with color handling capability.
AX40 MICRO-IMAGECHECKER image processing device
ARCT1B229E '04.1
10/2004
Image Processing Device
New

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Micro-Imagechecker AX40

Summary of Contents for Panasonic Micro-Imagechecker AX40

  • Page 1 Advanced image processing with color handling capability. AX40 MICRO-IMAGECHECKER image processing device ARCT1B229E ’04.1 10/2004 Image Processing Device...
  • Page 2 Image processing with advanced functions that’s easy to use. The AX40 inherits image processing technology built up over many years and know-how derived from hands-on experience in the field. Even more important, it is designed for the kind of performance requirements demanded by our customers.
  • Page 3 Color images are displayed at high accuracy during inspection and both color and gradation are processed. The AX40 offers easy-to-grasp visual comprehension. [Functions] Fully featured with basic functions such as 360° contour matching, smart matching, and versatile rotation and positional adjustment. [Setting and Operation] Maintenance and initial setup support functions included and an easy-to-use operation menu.
  • Page 4 Features Versatile image processing that enables gray scale and color processing. Differentiation processing is possible in addition to color and gray scale processing and binarization. High precision image processing means you can use it in a wide range of applications. Full color Color extraction Verify images on a beautiful color monitor.
  • Page 5 360° contour matching A world first! By calculating contour lines and judging, stable positional detection is possible even for hidden, overlapped objects that have been difficult to detect up to now. Thanks to this, better yields are achieved. Previous AX40 Versatile rotational and positional adjustment Highly accurate and reliable inspection is realized by automatically adjusting object...
  • Page 6 Settings, operation, and applications Easy operation Setting is easy using the operation menus which are designed to be easy to understand. Basic keypad operation, too, only requires you to align the cursor with the menu and press the Enter key. Setting help This function sets the focus and adjusts the aperture, tasks that used to rely on human...

  • Page 7: Data Monitor

    Data monitor Original function Up to 50 inspection results are displayed on the monitor in chart form for operator verification. Also, threshold adjustment (upper and lower limit values) can be changed on the data monitor without entering them in the setting menu. AXTOOL Vision Support Tool fills out peripheral lineup! The new AXTOOL Vision Support Tool is packed with handier functions than ever.

  • Page 8: System Configuration

    System configuration CompactFlash and Ethernet Ethernet AX40s can be connected to a LAN using high- speed Ethernet (100BASE-TX) to meet various application requirements. Measurement data during operation can be transmitted at high speed to a PC. Also, the inspection status of multiple AX40s can be monitored from a single PC.
  • Page 9 Dimensions (Unit: mm inch) G Main unit (Controller) ANMX400 2.323 POWER ERROR READY COM.1 TOOL COM.2 KEYPAD COM.1 CAMERA1 COM.2 FCT1 FCT2 MONITOR CAMERA2 .197 ø4.6 ø.181 G Dedicated color camera: C mount ANMX8310 54.5 2.146 1.220 (46.5) .315 (1.831) 1.142 24.5±0.6 .965±.024...

  • Page 10: Functional Specification

    Product Numbers and Specifications Table of Product Numbers Product name Specification AX40 Series Controller NPN output; English/Japanese switchover (No manual) NPN output; English/Japanese switchover (English manual) PhotoMOS output; English/Japanese switchover (No manual) PhotoMOS output; English/Japanese switchover (English manual) Color camera Random color camera Color camera cable Camera cable: 3 m...
  • Page 11 Product name Specification Gray scale Max. 99/product type Inspection window function *Only when gray scale and differential processing are selected. Shape: rectangle/polygon (3 to 16 points)/ellipse; mask shape: rectangle/polygon/ellipse; 16 Upper and lower brightness levels can be set. Judgment: average gray scale value Output: average gray scale value Gray scale Max 99/product type...

  • Page 12: Internet Homepage

    Internet Homepage North America : http://www.aromat.com/ Europe : http://www.mew-europe.com/ These materials are printed on ECF pulp. These materials are printed with earth-friendly vegetable-based (soybean oil) ink. Please contact ... ARCT1B229E 200311-3YT Asia & others : http://www.nais-e.com/ • (Japanese) : http://www.mac-j.co.jp/ •...
