Replacing the status-light
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your
computer, follow the instructions in
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.

Procedure

1 Place the status-light board into the slot on the palm rest and keyboard
assembly.
2 Press down the status-light board until it snaps into place.
3 Adhere the status-light board cable to the palm rest and keyboard
assembly.
4 Slide the status-light board cable into the connector on the system board
and close the latch to secure the cable.

Post-requisites

1 Replace the battery.
2 Replace the hard
3 Replace the I/O
4 Replace the base
5 Replace the optical
computer. After working inside your
drive.
board.
cover.
drive.
After working inside your
51
