Panasonic BB-HCS301A Getting Started Manual

Getting Started

Network Camera Server
BB-HCS301A
Model No.
Trademarks
Adobe, Acrobat and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
•
Microsoft, Windows and ActiveX are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
•
• Screen shots reprinted with permission from Microsoft Corporation.
• All other trademarks identified herein are the property of their respective owners.
• This software is based in part on the work of the Independent JPEG Group.
Abbreviations
• UPnP is the abbreviation for "Universal Plug and Play".
"Network Camera" or the "Analog Camera connected to this product" is called "Camera" in this manual.
•
1.
Connect the video cable (BNC terminal) to this product's video input terminal, and
turn the camera on.
2.
Connect this product to your router, and turn this product on.
Connect the Ethernet cable (customer-provided)
to this product.
This product will be connected to your router using a "straight" Cat5
network cable (customer-provided).
Ethernet (LAN) port
Ethernet cable
(customer-provided)
Note
In advance, make your PC connected to the Internet. See the
router's manual for the Internet access.
Connect the Ethernet cable (customer-provided)
to your router.
To the supply
To this product
Ethernet cable
(Straight Cat5 cable)
(Customer-provided)
PSQX3859ZB
KK0605YT2056
To your camera
To your router
To LAN jack
To your modem
To your PC
Please read the Installation manual before using.
•
This Getting Started explains how to connect and set up this product.
•
See the Operating Instructions on the Setup CD-ROM for details about
the features.
If you cannot complete the setup, see the Troubleshooting manual on the
•
Setup CD-ROM.
Fit the plug's groove to this product's video input terminal.
Connect the power cord
Turn the grip right.
Note
In advance, adjust the image display on the monitor
such as a position, etc.
Connect the AC adaptor to this product.
• If the indicator does not light green, see page 3 and page 4 of the
Troubleshooting on the Setup CD-ROM.
Use only specified Panasonic AC adaptor PQLV202 (Order No.
•
PQLV202Y).
Put an AC adaptor cord through an AC adaptor hook.
2005 Panasonic Communications Co., Ltd. All Rights Reserved.
Connect the plug to the DC IN jack.
AC adaptor
Plug the AC cord
into the outlet.
To your camera
To
your router
Hook
To your camera
To your router
To the supply
