T
ECHNICAL INFORMATION
Model No.
Description
C
ONCEPT AND MAIN APPLICATIONS
Models UB1102, UB1103 Blowers are successors of UB1100, UB1101.
Their output air volume is 4.1m³/min. over the predecessors 2.8m³/min.
The other features are as follows:
• Ergonomic designed handle with elastomer for more comfortable
and controlled operation
• Self-standing design enables stationary use, easy storage and upside-down
standing
The specification difference between UB1102 and UB1103 is;
UB1102: Single speed
UB1103: Variable speed control by dial and trigger
S
pecification
Voltage (V)
110
120
220
230
240
Model No.
No load speed: min.
Max. air volume*
1
Max. sealed suction: kPa
Variable speed control
Protection against electric shock
Power supply cord: m (ft)
Weight according to
EPTA-Procedure 01/2003*
*1 Without Nozzle, Joint
*2 With Nozzle, Joint
S
tandard equipment
Nozzle .....................................1
Joint .........................................1
Dust bag (capacity of 2L) .......1 (for some countries)
Note: The standard equipment for the tool shown above may vary by country.
O
ptional accessories
Dust bag assembly
Nozzle assembly
Long nozzle assembly
UB1102, UB1103
Blower
Current (A)
5.7
6.8
2.9
2.8
2.7
¹=rpm
ˉ
: m³/min.
: kg (lbs)
2
Flexible hose set
Anchor nozzle set (for vacuum function only)
Bending long nozzle set
Continuous Rating (W)
Cycle (Hz)
Input
50/60
600
50/60
---
50/60
600
50/60
600
50/60
600
UB1102
16,000
4.1
5.7
No
Australia: 0.5 (1.64), Others: 2.5 (8.2)
L
Dimensions: mm (")
Length (L)
Width (W)
Height (H)
Output
---
---
---
---
---
UB1103
0 - 16,000
0 - 4.1
0 - 5.7
Double insulation
2.0 (4.3)
PRODUCT
P 1/ 8
H
W
479 (18-7/8)
185 (7-1/4)
178 (7)
Max. Output (W)
---
---
---
---
---
Yes

Advertisement

Table of Contents
loading

Related Manuals for Makita UB1102

Summary of Contents for Makita UB1102

  • Page 1 Description Blower ONCEPT AND MAIN APPLICATIONS Models UB1102, UB1103 Blowers are successors of UB1100, UB1101. Their output air volume is 4.1m³/min. over the predecessors 2.8m³/min. The other features are as follows: • Ergonomic designed handle with elastomer for more comfortable and controlled operation Dimensions: mm (")

  • Page 2: Necessary Repairing Tools

    P 2/ 8 epair CAUTION: Repair the machine in accordance with “Instruction manual” or “Safety instructions”. [1] NECESSARY REPAIRING TOOLS Code No. Description Use for 1R370 Ring Terminal Setting Jig connecting Ring terminals to Brush holder 1R063 Guide Bar for fitting Field assembling Field to Motor housing complete [2] LUBRICATION It is not required to lubricate, because the product has no gear mechanism to be lubricated.

  • Page 3: Fan Section

    P 3/ 8 epair [3] DISASSEMBLY/ASSEMBLY [3] -2. Fan Section DISASSEMBLING Disassemble Fan 110 as drawn in Fig. 2. Fig. 2 Nozzle 1. Remove Nozzle. 2. Remove Set plate by prying it off with a small slotted screwdriver. Set plate Fan cover 4.

  • Page 4: Motor Section

    P 4/ 8 epair [3] DISASSEMBLY/ASSEMBLY [3] -3. Motor Section DISASSEMBLING (1) Remove Carbon brush as drawn in Fig. 3. Fig. 3 Carbon brush (2) Disassemble Fan section as drawn in Fig. 2. (3) Disassemble Armature as drawn in Fig. 4. Fig.
  • Page 5 P 5/ 8 epair [3] DISASSEMBLY/ASSEMBLY [3] -3. Motor Section (cont.) DISASSEMBLING (4) Disassemble Field as drawn in Fig. 5. Fig. 5 2. Disconnect Field lead wires from Switch. 1. Unscrew four 4x18 Tapping screws and remove Handle cover. Switch Handle cover Field lead wire 3.
  • Page 6 P 6/ 8 epair [3] DISASSEMBLY/ASSEMBLY [3] -3. Motor Section (cont.) ASSEMBLING (1) Assemble Field to Motor housing. Refer to the drawing on the middle right in Fig. 5. Also see Fig. D-2 about the wiring of Field lead wires. Note: Using 1R063 enables Field to be assembled easily than by hand.

  • Page 7: Circuit Diagram

    P 7/ 8 ircuit diagram Fig. D-1 Color index of lead wires' sheath Black Blue White Brown Lead wire (white or blue) of Power supply cord connected to P2 terminal Lead wire (black or brown) of Power supply cord connected to P1 terminal Switch Note: Noise suppressor and Line filter are not used for some countries.

  • Page 8: Wiring Diagram

    P 8/ 8 iring diagram Fig. D-3 Switch Motor housing complete Noise suppressor Field (if used) Lead wire holder Power supply cord See the drawing on the right in Fig. D-2. Line filter (if used) Set Line filter with Field lead wires between Lead wire holders.
