ENGLISH
Fig. A
5. Charger
6. Charger plug
Assembly
Fitting and removing a drill bit or a screwdriver
bit (fi g. B)
This tool uses screwdriver bits and drill bits with
a 6.35 mm (1/4") hexagonal shank.
• To fi t a bit, insert the bit shaft into the bit holder
(3).
• To remove a bit, pull the bit shaft out of the bit
holder (3).
Use
Warning! Let the tool work at its own pace. Do not
overload.
• Before fi rst use, the battery must be charged for
at least 9 hours.
Charging the battery (fi g. C)
• Insert the charger plug (6) into the charger con-
nector (7).
• Plug in the charger (5).
• Leave the tool connected to the charger for
12 hours.
The charger may hum and become warm while
charging; this is normal and does not indicate
a problem.
Warning! Do not charge the battery at ambient
temperatures below 10 °C or above 40 °C.
Selecting the direction of rotation (fi g. D)
For drilling and for tightening screws, use forward ro-
tation. For loosening screws or removing a jammed
drill bit, use reverse rotation.
• To select forward rotation, push the forward/re-
verse slider (2) to the forward position.
• To select reverse rotation, push the forward/re-
verse slider (2) to the rearward position.
• To lock the tool, set the forward/reverse slider
into the centre position.
Drilling/screwdriving
• Select forward or reverse rotation using the
forward/ reverse slider (2).
• To switch the tool on, press the on/off switch
(1).
• To switch the tool off, release the on/off switch
(1).
LED light
The LED light (4) is activated automatically when the
trigger is depressed. The LED will also illuminate
6
when the trigger is depressed and the forward/re-
verse slider (2) is in the locked off position (central
position).
Hints for optimum use
Screwdriving
• Always use the correct type and size of screw-
driver bit.
• If screws are diffi cult to tighten, try applying
a small amount of washing liquid or soap as
a lubricant.
• Use the spindle lock to loosen very tight screws
or to fi rmly tighten screws.
• Always hold the tool and screwdriver bit in
a straight line with the screw.
• When screwing in wood, it is recommended to
drill a pilot hole with a depth equal to the length
of the screw. A pilot hole guides the screw and
prevents splintering or distortion of the wood.
For the optimum size of the pilot hole, refer to
the table below.
• When screwing in hardwood, also drill a clear-
ance hole with a depth equal to half the length of
the screw. For the optimum size of the clearance
hole, refer to the table below.
Screw size Pilot hole Ø
(softwood)
No. 6 (3.5 mm) 2.0 mm
No. 8 (4 mm) 2.5 mm
No. 10 (5 mm) 3.0 mm
Drilling
• Always apply a light pressure in a straight line
with the drill bit.
• Just before the drill tip breaks through the other
side of the workpiece, decrease pressure on the
tool.
• Use a block of wood to back up workpieces that
may splinter.
• Make an indentation using a centre punch at
the centre of the hole to be drilled in order to
improve accuracy.
Accessories
The performance of your tool depends on the ac-
cessory used. Black & Decker and Piranha acces-
sories are engineered to high quality standards and
designed to enhance the performance of your tool.
By using these accessories you will get the very
best from your tool.
This tool uses screwdriver bits with a 1/4" (6.35 mm)
hexagonal shank. Piranha Super-lok accessories
are designed for use with this tool.
Pilot hole Ø Clearance hole
(hardwood)
2.5 mm 3.6 mm
3.0 mm 4.5 mm
3.5 mm 5.0 mm
