INSTRUCTION MANUAL
Cordless Cleaner
CL070D
CL100D
010013
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading

Related Manuals for Makita CL070D

Summary of Contents for Makita CL070D

  • Page 1 INSTRUCTION MANUAL Cordless Cleaner CL070D CL100D 010013 WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    ENGLISH SPECIFICATIONS Model CL070D CL100D Capacity 600 mL Continuous use Approx. 8 min. Approx. 12 min. Overall length 966 mm Net weight 0.77 kg 0.86 kg Rated voltage D.C. 7.2 V D.C. 10.8 V • Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

  • Page 3: Functional Description

    If you drop or strike the cleaner, check it power. carefully cracks damage before Never recharge a fully charged battery operation. cartridge. Do not bring close to stoves or other heat Overcharging shortens the battery service life. sources. Charge the battery cartridge with room temperature at 10 ﾟ...
  • Page 4 Switch action 1. Capsule 2. Suction inlet 1. Switch trigger 010023 010016 Now point suction inlet downwards, turn capsule in direction of arrow in diagram, and disconnect capsule CAUTION: slowly and straight. Before inserting the battery cartridge into the tool, •...
  • Page 5 Clean out fine dust from prefilter. Next, remove filter, and Connect capsule. Align projection on capsule with lightly tap to dislodge dust. projection on handle and then firmly twist capsule in direction of arrow until it is secured. Reassembly 1. Filter 010031 010027 1.

  • Page 6: Operation

    Example 2: Only filter has been loaded (no prefilter) 1. Capsule 1. Filter 010017 010034 Cleaning (Suction) Example 3: Filter has been loaded in a peeled back state Nozzle Attach the nozzle to clean off tables, desks, furniture, etc. 1. Filter Nozzle slips on easily.

  • Page 7: Maintenance

    Corner nozzle +Extension wand (Straight pipe) Cleaning In tight quarters where the cleaner itself cannot squeeze in, or in high places hard to reach, use this arrangement. 1. Corner nozzle 2. Extension wand 3. Cleaner body 010038 010021 From time to time wipe off the outside (cleaner body) of the cleaner using a cloth dampened in soapy water.
  • Page 8 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Extension wand (Straight pipe) • Nozzle • Nozzle for carpet •...
  • Page 12 Makita Corporation Anjo, Aichi, Japan 884898-227...
