  • Page 1 XL-ICA-105M2 2.0 MegaPixel IP Camera User’s Guide...

  • Page 2: Safety Instruction

    Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may cause if any of the warnings is neglected. Cautions: Injury or equipment damage may cause if any of the cautions is neglected.
  • Page 3 2. Do not drop the camera or subject it to physical shock. 3. Do not touch CCD (Charge Coupled Device) modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an extended period, please turn on the lens cap to protect the CCD from dirt.

  • Page 4: Table Of Contents

    2.3.2 Alarm Output Connection..............................12 2.3.3 Pin Definition .................................13 2.4 Installati on of Client software 4.01 ...........................13 2.5 XL-ICA-105M2 camera Menu illustrate and E-PTZ operation ..................17 2.5.1 products e‐ptz function ..............................17 2.5.2 menu instruction ................................. 18 2.5.3 menu instruction ................................. 26 CHAPTER3 PARAMETERS CONFIGURATION .........................

  • Page 5: Chapter 1 Introduction

    15 separate users with different right levels, which highly improves the system security. （-E）illustration of support PoE (power over ethernet). Compression Functions XL-ICA-105M2 camera Support resolutions of UXGA (1600*1200),HD720p(1280*720), SVGA(800*600), VGA(640*480), 4CIF（PAL:704*576,NTSC:704*480）, DCIF (PAL:528*384,NTSC:528*320), 2CIF（PAL:704*288， NTSC:704*240） , CIF（PAL:352*288， NTSC： 352*240） to QCIF（PAL:176*144， NTSC：...

  • Page 6: Applications

    Remote Control - The product offers a 10M/100M self-adaptive Ethernet interface. - Support PPPoE and DHCP protocols. - You can set the parameters, browse real time videos or check the camera performance through software or IE, and get external alarming and store the compressed bit rate through network. - Support remote upgrades and maintenance.

  • Page 7: Chapter2 Installation

    Chapter2 Installation 2.1 Notice options 1. Please check if all the items on the package list have been inc luded with your camera. 2. Read the following contents carefully before the installation. 3. Make sure that all the related equipment is power-off during the installation. 4.

  • Page 8: Rear Panel Description

    series camera Fig 2.2.3 Side Elevation of XL-ICA-105M 2 【Notice】:The mark of illustrat ion of support automatic switching color to white&black、 e-PTZ 、progressive scan and 200 million Pixels. 【 Notice 】 :The mark of illustration of support automatic switching color to white&black、progressive scan and 130 million Pixels. 2.2.2 Rear Panel Description...
  • Page 9 （T＋ T-） 9. SD card slot (Support SDHC ). 10. Standard BNC for 1 channel video output. Fig. 2.2.6 Rear Panel of XL-ICA-105M2 camera 1. Standard Ethernet (UTP) RJ45 (10M/100M self-adaptive). 1 channel voice talk input,3.5mm audio interface, 2.0～2.4Vp-p, 1kΩ.
  • Page 10 Address& protocols dial switch, de fine for dial switch: , from 1 to 5 dial switch function as follows: switch function SHARP SOFT NAGC SAGC...

  • Page 12: Topological Graph Of Network

    2.3.1 Topological Graph of Network Fig.2.3.1 Topological Graph of Network camera for XL-ICA-105M2...

  • Page 13: Alarm Output Connection

    Physical Inte rface Connection Network Connect to network devices, such as switch , HUB, etc. Inte rface Please refer to Appe ndix B for pin Definition. Audio Input Connect to audio inp ut devices such as active tone (2.0～ （AIN） 2.4Vp-p, 1kΩ) Audio Output...

  • Page 14: Pin Definition

    2.3.3 Pin Definition （1）UTP between the network port of camera and HUB (Direct Cable) （2）UTP between the network port of camera and PC (Cross Cable): 2.4 Installation of Client software 4.01 【Notice】Your PC adaptor shall s upport colorspace conversion and zoo ming .Adaptors like Nvidia Tnt/Tnt2、Geforce Mx 200/400/420/440 Fx5200/5600, ATI Radeon 7000/7200/7500/8500 /9000/9200 /9500/9600, MatroxG450/550，...
  • Page 15 Fig.2.4.1 C lient Software Installation Fig.2.4.2 License Agreement Step2: Enable the option “I accept the terms of the license agreement” and click the “Next” button to go to the next step as Fig.2.4.3.
  • Page 16 Fig.2.4.3 Customer Information Step3: Input “User Name”, “Company Name” and click “Next” to go to the next step. Fig.2.4.4 Destination Folder Step4: Select the destination folder and click “Next” to go to the next step.
  • Page 17 Fig2.4.5 Ready to Install the Program Step5: Click “Install” to start installation shown as Fig2.4.6. Fig2.4.6 Install Process Step6: After finishing the installation, the installation completed dialog box will popup as Fig.2.4.7.

  • Page 18: Xl-Ica-105M2 Camera Menu Illustrate And E-Ptz Operation

    After the client software being installed, you can find the remote client software through “Start” -> “Program” on your PC 2.5 XL-ICA-105M2 camera M enu illustrate and E-PTZ operation 2.5.1 XL-ICA-105M2 products e-ptz function Under the resolution of QCIF/CIF/DCIF/2CIF/VGA/D1/SVGA, support pan\tilt\zoom operation, pan and tilt operation can be carried out only after zoo ming in，Support 127 preset pos itions（95...

  • Page 19: Menu Instruction

    Main code rate：rtsp://admin:12345@192.0.0.64 Sub code rate：rtsp://admin:12345@192.0.0.64/mpeg-4/ch1/sub/av_stream Attention: 852F/752F will force to reboot when change the resolution to UXGA or HD720p. 2.5.2 XL-ICA-105M2 menu instruction 1、Display menu Invoke Pre-set pos ition95；Double click presetting po ints of “95 ”,main menu display on screen .
  • Page 20 Select OSD menu by PTZ control key, as follows: ※ U P ↑: Means select OSD menu item ※ DOWN↓: Means select OSD menu item ※ LEFT ← : Means select parameter on OSD ※ RIGHT→: Means select parameter on OSD Attention：...
  • Page 21 ◆Resolution This option is used for displaying the current resolution, can’t be controlled by “left” “right” buttons. ◆Frame This option is used for displaying the output frame rate, can’t be controlled by “left” “right” buttons. ◆Shutter AUTO×2 AUTO×5 “OFF” The regulation of shutter exposure time is default. “AUTO×2”...
  • Page 22 XL-ICA-105M2 50Hz 60Hz Resolutio Auto×2 Auto×5 Auto×2 Auto×5 DCIF QCIF 4CIF 25fps 12.5fps 5fps 30fps 15fps 5fps 2CIF SVGA UXGA 12.5fps 12.5fps 5fps 10fps 10fps 5fps HD720p 25fps 12.5fps 5fps 15fps 15fps 5fps...
  • Page 23 ◆AUTO GAIN MEDIUM HIGH You can set up different auto gain values separately in the condition of low illumination, and increase the picture brightness. This function may not only be independent employment, but also coordinate with option selections in shutter establishment, in order to achieve better low light illumination mode effect.
  • Page 24 In the condition of low illumination, the auto mode has a better noise cut-down effect compared with color mode. ◆WHITE BALANCE Auto...
  • Page 25 “Auto” Enable the auto W&B of the current screen “OFF” Based on the current W&B state，no more auto adjustment. ◆EFFECTS MODE OFF SEPIA NEGA TIVE SOLARIZE1 SOLARIZE2 If B&W is switched to color mode，this function is compelled to be “OFF”。 ◆MIRROR LEFT RIGHT UP BOTTOM...
  • Page 27 ◆EPTZ “OFF” Means support mechanical PTZ only “ON” Means support EPTZ function only ◆EXIT SAVE CANCEL DEFAULT This mode is employed after clicking “enter” buttons. “SAVE” Save the current configuration “CANCEL” Cancel with the current operations，restore to the configuration before carrying out the operations. “DEFAULT”...

  • Page 28: Menu Instruction

    2.5.3 762/862 series menu instruction 1、Display menu Invoke Pre-set position95；Double click presetting points of “95 ”,main menu display on screen . <MAIN MENU> LANGUAGE ENGLISH RESOLUTION HD(1208*720) FRAME 25fps LENS SHUTTER 1/25s AUTO GAIN DAY/NIGHT WHITE BALANCE A TC BACKLIGHT COMP. MANUAL …...
  • Page 29 ※ RIGHT→: Means select parameter on OSD 2、Exit menu “Iris＋”means『enter』 ，you can select “save”、“cancel” or “preset” according to the exit options. 3、Menu details operations The menu selection is implemented through “up” “down” “left” “right” buttons, you can select the menu function by “up”...
  • Page 30 ◆ Shutter Auto When select “ Auto Iris”(AI) , Shutter can be selected by as list: Support “auto” and “---” two mode. 1/25s,1/50s,1/100s,1/250s,1/500s,1/1ks,1/2ks,1/4ks,1/10ks,1/100ks. When select “AES”, and it support “Auto ” electron shutter. ◆ Auto gain High Middle When select “ Day” or “Night” mode at “DAY/NIGHT” option, Auto Gain support High、 Middle、 Low 、 Off option. When select “Auto ”...
  • Page 31 ◆ White balance A TW1 A TW2 A TC … When select “Night” mode , white balance option will display “---”, means not support setting by manual. When select “Auto” or “Day” mode ,white balance support setting by manual; A TW 1 A TW 2 A TC MWB SETTING...
  • Page 32 ◆Backlight Comp Manual… Support “Off” and “Manual…” two mode; . option, the pos ition and size of . can be setting When select “Manual…” at Backl ight Comp Backlight Comp by manual. BACKLIGHT COMP MANUAL… POSITION… SIZE… click Iris[+],entry DOWN BACK M anual…( LEFT...
  • Page 33 ◆Mirror Left Right Up Bottom Center Support “Off”、”Left Right”、”Up Bot tom”、”Center” mode, and set by “left” “right” buttons ◆Exit Save Cancel Default This mode is employed after clicking “enter” buttons “SAVE” Save the current configuration “CANCEL” Cancel with the current operations，restore to the configuration before carrying out the operations. “DEFAULT”...

  • Page 34: Chapter3 Parameters Configuration

    Chapter3 Parameters Configuration There are several network parameters of the camera those need to be set after the hardware installation. Those parameters including IP address, subnet mask and port number, etc. which can be set through various kinds of methods, 2 of them are introduced as below. 1.
  • Page 35 Fig. 3.3 Login Interface Fig. 3.4 Previewing Interface It supports the “Playback” and “Log” functions are as Fig. 3.4. To set the camera parameters through IE browser, click “Config” and wait for the “Remote Parameters Config” dialog box to pop up, and then set the parameters like IP address, etc.

  • Page 36: Parameter Configuration Through Client Software

    Fig. 3.5 Remote Parameters Config 【Notice】 Security level settings are necessary for browsing equipments by IE. Please open the IE browser and set the security level to “Low” in “Tools/ Internet Options/ Security/ Customize” or enable the “ActiveX Controls and Plug-Ins” directly. 3.2 Parameter Configuration through Client Software After the installation of client software 4.01, click the “client software 4.01 ”in “Start”→...
  • Page 37 Fig.3.6 Register Administrator Enter the registered user name and password as Fig. 3.7. Click “Login” to enter the “Preview” menu as Fig. 3.8. Fig. 3.7 User Login Fig. 3.8 Preview Menu Click the “Configure” button in Fig. 3.8, and then right click the blank spaces in the middle. Click the “Create Root Node ”...
  • Page 38 Fig. 3.9 Create Root Node Fig. 3.10 Area Properties Input the area name (you can create whatever name you like) and click “OK” as Fig. 3.11. Then right click the area name you have just created as Fig. 3.12.
  • Page 39 Fig. 3.11Area Name Adding Completed Fig. 3.12 Right Click the Area Name Click “Add Device”, and the “Server Properties” dialog box will pop up as Fig. 3.13. Input your “Server Name” and select “HC” from the “Server Type ” option. Select “Normal” from “Register” option. Input your camera IP in “Server IP”, e.g.
  • Page 40 Fig. 3.13 Add Device Fig.3.14 DVR Adding Completed Click the “Preview” button in Fig. 3.14 to enter the “Preview” menu as Fig. 3.15. Double click the channel name in the left tree to preview the pictures.
  • Page 41 Double click the channel Fig.3.15 Preview Menu Please refer to “Network Video Surveillance Software Operation Instruction (4.01)” for more detailed parameters configuration. You can find the document in PC Operating System after the installation of client software 4.01 by selecting “Start”-> “Program”-> “client software 4.01”.

  • Page 42: Chapter4 Wan Access

    After that you can use the client software to control it. Turn to ch3.2 to find the client software operations. Attention: XL-ICA-105M2 network camera need to open RTSP port 554, other than open 80 & 8000 ports.
  • Page 43 When network camera is connected to WAN with PPPoE, it will get an IP address, and send its name and the IP to the DNS server. The client software will immediately connect to the PC that used as the DNS server to tell it that network camera is waiting for access.

  • Page 44: Q&A

    Q&A 1、Time showing incorrectness: Use client 4.01 to correct the time by selecting “configure”Æ“local configure”Æ“Hard disk recorder timing” 2、IP unknowing： Connect the camera and PC with the same hub，turn on the camera and run the “SADP Search Software” on PC to get the IP of the connected camera. You can get the SADP from your dealer. 3、Administrator password missing: Please contact your dealer.

  • Page 45: Appendix Technology Specification

    Appendix Technology Specification Parameter M odel XL-ICA-105M 2 Camera Image Sensor 1/3 inch CM OS Effective Pixels 1600(H)×1200(V) 0.5Lux/F1.2 M in. Illumination 0.1Lux/F1.2, sensitization X5 Electronic Shutter Auto Auto Iris Lens Day&Night Electronic (ICR option) Lens Option Lens M ount C/CS mount Video Output 1Vp-p Composite Output(75Ω/BNC)
  • Page 46 1 channel 3.5mm audio interface(2.0～2.4Vp-p,1kΩ) Voice Talk Input Voice Out put 1 channel 3.5mm audio interface(Line level, 600Ω) Communication 1 RJ45 10M /100M self-adaptive Ethernet port and 1 RS-485 interface Alarm Input 1 channel signal input Alarm Output 1 channel signal relay output Others Working Temperature -10℃~60℃...
