Raise and Lower Monitor Screen

The monitor may be raised or lowered in either Portrait or Landscape mode.
To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1).
NOTE: Handle with care when raising or lowering the monitor screen.

Screen Rotation

Before rotating, the screen must be raised to the highest level to avoid knocking the screen on the desk or pinching with your
fingers.
To raise the screen, place hands on each side of the monitor and lift up to the highest position (Figure RL.1).
To rotate screen, place hands on each side of the monitor screen and turn clockwise from Landscape to Portrait or counter-
clockwise from Portrait to Landscape (Figure R.1).
To rotate OSD menu between landscape and portrait, refer to "Controls" section.
NOTE: After screen rotation, please execute "Self Calibration" and "Gamma Adjust".
Tilt
Grasp both sides of the monitor screen with your hands and
adjust the tilt as desired (Figure TS.1).
NOTE: Handle with care when tilting the monitor screen.
Figure TS.1
Figure RL.1
Figure R.1
Swivel
Grasp both sides of the monitor screen with your hands and
adjust the swivel as desired (Figure TS.2).
English-8
Figure TS.2
