Chapter 5
No.
010
011
013
028
No.010
Use it to set the length of time for line connection identification.
If an error occurs often because of the line condition at time of a communication, increase the parameter.
Memo
The line connection recognition time means the period from transmission of dial signal to detection of significant signal for the transmission end, and the
period from transmission of DIS signal to detection of significant signal for the receiving end.
No.011
Set the T1 timer for the receiver (wait time after DIS transmission starts until a significant signal is received).
If frequent errors occur during reception because of line connection conditions, increase the value of this parameter.
No.013
Set the maximum receivable time per line of image data when receiving image data. If the other party is a computer fax and the like, and the image data
reception time per line is longer, increase the value of this parameter to lengthen the maximum receivable time.
No.028
Use it to set the length of time during which the menu select screen is indicated on the LCD.
In the meantime, the length of time during which the registration and setting screen is indicated is fixed.

5.5.6 Counter Indication (COUNTER)

5.5.6.1 #9 COUNTER

/ / FAX-L390 / / / FAX-L380S
Display the counter readings of scanning, printing, communication, and copy.

5.5.7 Report Output (REPORT)

5.5.7.1 #10 SERVICE REPORT

/ FAX-L390 / / / FAX-L380S
This fax outputs the service data setting status, past communications history reports, detailed error information reports, etc. in service mode.
List of service reports
This fax outputs the service reports shown below.
Report type
System data list
System dump list
Key history report
Counter report
Print spec report
Service Tx/RX report
(with service error code and dump list)
System data list
This list shows service data setting statuses of service soft switches and service parameters.
5-22
Function
Line connection identification time length
T.30 T1 timer (for reception)
Maximum time to receive one line of image data
Menu select screen display time length
Operations
In the service mode, select #10 SERVICE
REPORT menu, and press OK button.
Then select the report type, and press
OK button.
If you set bits 0 and 1 of #1 SSSW SW01 in the service mode, the
service error code and dump list are indicated on the TX/Rx report.
T-5-21
Selecting range
0 to 9999 (10ms)
0 to 9999 (10ms)
500 to 3000 (10ms)
1 to 60 sec
T-5-22
Default
setting
5500
3500
1300
3
0011-5270
0011-9446
