Dominion PX
User Guide
Release 1.2.5
Copyright © 2008 Raritan, Inc.
DPX-0I-E
October 2008
255-80-6080-00

Advertisement

Table of Contents
loading

Related Manuals for Raritan Dominion PX

Summary of Contents for Raritan Dominion PX

  • Page 1 Dominion PX User Guide Release 1.2.5 Copyright © 2008 Raritan, Inc. DPX-0I-E October 2008 255-80-6080-00...

  • Page 2: Safety Guidelines

    © Copyright 2008 Raritan, Inc., CommandCenter®, Dominion®, Paragon® and the Raritan company logo are trademarks or registered trademarks of Raritan, Inc. All rights reserved. Java® is a registered trademark of Sun Microsystems, Inc. Internet Explorer® is a registered trademark of Microsoft Corporation.
  • Page 3 Safety Guidelines WARNING: TO ISOLATE THIS EQUIPMENT DISCONNECT POWER SUPPLY PLUG. ATTENTION: AFIN D'ISOLER TOTALEMENT CET APPAREIL DEBRANCHER FICHE D'ALIMENTATION. CAUTION: USE ONLY IN DRY LOCATIONS. ATTENTION: UTILISER UNIQUEMENT DANS DES EMPLACEMENTS SECS. Do not use a 2-wire power cord in any product configuration. Test AC outlets at your computer and monitor for proper polarity and grounding.

  • Page 4: Table Of Contents

    Fill Out the Equipment Setup Worksheet ................12 Connecting the Dominion PX to a Computer................13 Connecting the Dominion PX to Your Network................14 Configuring the Dominion PX for Network Connectivity ..............15 Resetting to Factory Defaults ...................... 18 Chapter 4 Using the Dominion PX Front Panel ..........................
  • Page 5 Contents Back Panel........................... 21 Power Cord........................21 Outlets ..........................21 LED Display ........................22 Circuit Breaker ..........................24 Beeper ............................24 Measurement Accuracy ....................... 25 Chapter 5 Using the Web Interface Logging into the Web Interface....................26 Log In..........................26 Change Your Password.....................29 Using the Web Interface ......................
  • Page 6 View Internal Event Log.....................95 Configure NFS Logging .....................96 Configure SMTP Logging ....................97 Configure SNMP Logging....................98 Configure Syslog Forwarding ....................98 Managing the Dominion PX ......................99 Displaying Basic Device Information .................99 Displaying Model Configuration Information..............101 Displaying Connected Users ...................101 Naming the Dominion PX ....................102 Modifying the Network Settings ..................103...
  • Page 7 Add a Dominion PX Unit in Paragon II ................126 Associate Outlets with a Target..................127 Control a Target's Power ....................127 Control an Outlet's Power....................128 Dominion SX ..........................128 Configure a Dominion PX Power Unit on Dominion SX ..........128 Power Control ........................129 Check Power Strip Status....................130 Dominion KSX..........................130 CommandCenter Secure Gateway....................131 Direct Control from CC-SG 4.0..................131...
  • Page 8 Contents Appendix D Using the IPMI Tool Set Channel Commands ........................149 authcap <channel number> <max priv>................149 info [channel number] ......................150 getaccess <channel number> [userid] ................150 setaccess <channel number> <userid>[callin=on|off] [ipmi=on|off] [link=on|off] [privilege=level]........................150 getciphers <all | supported> <ipmi | sol> [channel] ............150 Event Commands ........................150 <predefined event number>...
  • Page 9 Contents IPMI Privilege Levels .........................161 Appendix E Event Types Appendix F Specifications Environmental Specifications.....................164 Dominion PX Serial RJ-45 Port Pinouts ..................164 Dominion PX Feature RJ-12 Port Pinouts .................164 Index...

  • Page 11: Chapter 1 Introduction

    Package Contents ..................4 Product Models The Dominion PX comes in several models that are built to stock and can be obtained almost immediately. Raritan also offers custom models that are built to order and can only be obtained on request.

  • Page 12: 1U Size

    Chapter 1: Introduction 1U Size 2U Size...

  • Page 13: Product Features

    Chapter 1: Introduction Product Features Dominion PX models and sizes vary. In general, Dominion PX features include: • The ability to control outlets collectively and individually • The ability to power on, power off, and reboot the devices connected to each outlet •...

  • Page 14: Package Contents

    • The ability to save one unit's configuration settings and then deploy those settings to other Dominion PX units • Fully shrouded local branch circuit breakers on products rated over 20A to protect connected equipment against overload and short circuits •...

  • Page 15: 1U Products

    Chapter 1: Introduction 1U Products • Dominion PX unit including power cord • 1U bracket pack and screws • Null-modem cable with RJ-45 and DB9F connectors on either end 2U Products • Dominion PX unit including power cord • 2U bracket pack and screws •...

  • Page 16: Chapter 2 Rack-Mounting The Dominion Px

    For Zero U Models Using L-Bracket............9 For Zero U Models Using Tool-less Button Mounting ......10 Rack Mount Safety Guidelines In Raritan products which require Rack Mounting, follow these precautions: Operation temperature in a closed rack environment may be greater than room temperature. Do not exceed the rated maximum ambient temperature of the appliances (see Appendix A: Specifications).
  • Page 17 Chapter 2: Rack-Mounting the Dominion PX Side Fixing End Fixing Blind Fixing...
  • Page 18 Chapter 2: Rack-Mounting the Dominion PX The Zero U units are provided with high grade engineering polycarbonate isolation hardware to allow fixing in a variety of positions within the rack. For panel/flush mount, pull out fixing brackets are available on each end cap to allow mounting on suitable rails.

  • Page 19: For Zero U Models Using L-Bracket

    Chapter 2: Rack-Mounting the Dominion PX Blind Fixing For Zero U Models Using L-Bracket...

  • Page 20: For Zero U Models Using Tool-Less Button Mounting

    These work by attaching to the back side of a Zero U Dominion PX (the side opposite of the outlets) and fitting the button into the mounting holes of the cabinet.
  • Page 21 Chapter 2: Rack-Mounting the Dominion PX 1. Slide the baseplates onto the rear of the Dominion PX unit. Leave at least 24 inches between the buttons for stability, and turn the thumbscrews until the plate grasps the Dominion PX lightly.

  • Page 22: Chapter 3 Installation And Configuration

    Installation and Configuration Chapter 3 This chapter explains how to install a Dominion PX unit and configure it for network connectivity. In This Chapter Before You Begin ..................12 Connecting the Dominion PX to a Computer ..........13 Connecting the Dominion PX to Your Network ........14 Configuring the Dominion PX for Network Connectivity......15...

  • Page 23: Connecting The Dominion Px To A Computer

    Chapter 3: Installation and Configuration Connecting the Dominion PX to a Computer You must connect the Dominion PX to a computer to configure it, using a serial connection between the Dominion PX and the computer. If you plan to use this connection to log into the CLP command line interface, leave the cable connected after the configuration is complete.

  • Page 24: Connecting The Dominion Px To Your Network

    (COM) of the computer. Connecting the Dominion PX to Your Network To use the Web interface to administer the Dominion PX, you must connect the Dominion PX to your local area network (LAN). 1. Take a standard Category 5e UTP cable and connect one end to the LAN port on the front of the Dominion PX.

  • Page 25: Configuring The Dominion Px For Network Connectivity

    Chapter 3: Installation and Configuration Configuring the Dominion PX for Network Connectivity Once the Dominion PX is connected to your network, you must provide it with an IP address and some additional networking information. 1. Go to the computer that you connected to the Dominion PX and open a communications program such as HyperTerminal or PuTTY.
  • Page 26 Chapter 3: Installation and Configuration Static IP address - Select None and assign the Dominion PX a static IP address. You will be prompted for the address, network mask, and gateway. Note: The Dominion PX's IP address is automatically displayed in the system prompt.
  • Page 27 9. By default, the LAN interface duplex mode is set to Auto, which allows the system to pick the optimum mode. Half duplex allows data to be transmitted to and from the Dominion PX, but not at the same time. Full duplex allows data to be transmitted in both directions at the same time.

  • Page 28: Resetting To Factory Defaults

    For security reasons, the Dominion PX may be reset only to factory defaults at the local serial console. To do this: 1. Connect a computer to the serial port of the Dominion PX.
  • Page 29 Chapter 3: Installation and Configuration 2. Execute the defaults command to reset the DPX to its factory defaults. Note: Type "help" to show a list of available commands and a short description of each one. HyperTerminal is available on many Windows OS. But HyperTerminal is not available on Windows Vista.

  • Page 30: Chapter 4 Using The Dominion Px

    Measurement Accuracy................25 Front Panel The front panel of the 1U and 2U Dominion PX units features a blue LED to the right and three connection ports to the left, while the front panel of the Zero U model features power outlets to connect devices to Dominion PX, a display panel, and three connection ports.

  • Page 31: Blue Led

    Dominion PX unit is plugged in. Back Panel The back panel of the 1U and 2U Dominion PX units consists of, from left to right, a power cord, power outlets to connect devices to the Dominion PX, and a display panel; the Zero U models do not have a back panel.

  • Page 32: Led Display

    Yellow A firmware upgrade is being performed on the unit Note: When a Dominion PX unit is powered on, the power-on self-test and software loading takes a few moments. As the unit boots up, the outlet LEDs cycle through red, green and yellow. When the software has completed loading, the outlet LEDs display a steady color and the meter illuminates.
  • Page 33 Up and Down buttons Note: The small hole between the lower row and the Down button is the reset hole. The Dominion PX unit can be reset to its factory default values using this hole when connected to the serial port. See...

  • Page 34: Circuit Breaker

    On the Zero U product, access the breaker(s) by lifting the hinged cover over the breaker element. Beeper The Dominion PX includes a beeper. It will ring if any of the circuit breakers is tripped or if the control board temperature sensor exceeds 80 degrees Celsius (or 176 degrees Fahrenheit).

  • Page 35: Measurement Accuracy

    Chapter 4: Using the Dominion PX Measurement Accuracy • Voltage (per outlet): Range 0-255V, +/-5%, 3 digits, resolution 1V • Current (per outlet): Range 0-25A, +/-5%, 3 digits, resolution 0.1A...

  • Page 36: Chapter 5 Using The Web Interface

    To log into the Web interface, you must enter a user name and password. The first time you log in, use the default user name (admin) and password (raritan). You will then be prompted to change the password for security purposes.
  • Page 37 Chapter 5: Using the Web Interface where <ip address> is the IP address of the Dominion PX. A Login dialog appears. 2. Type your user name and password in the Username and Password fields. Both the user name and password are case sensitive, so make sure you capitalize the letters correctly.

  • Page 38: Dominion Px

    Chapter 5: Using the Web Interface Note: The Home window shown above shows 20 outlets. If your Dominion PX has eight outlets, the Home window will show eight. Elements may appear differently, depending on model type and setup. Java script must be enabled in the web browser for proper operation. If Java Script is not enabled, features such as the Status Panel on the left side of the interface will not display correctly.

  • Page 39: Change Your Password

    Chapter 5: Using the Web Interface Change Your Password To change your password: 1. Choose User Management > Change Password. The Change Password window opens. 2. Type your existing password in the Old Password field. 3. Type your new password in the New Password and Confirm New Password fields.

  • Page 40: Using The Web Interface

    Chapter 5: Using the Web Interface Using the Web Interface Every window in the Web interface provides menus and a navigation path across the top and a Status panel to the left. Menus There are several menus in the Web interface, each with their own set of menu options: Details Outlet Details...

  • Page 41: Navigation Path

    Note: The Home tab is not a menu. Clicking the Home tab will take you back to the Dominion PX home page. • Position the cursor on the menu name. A list of options drops down from the menu.

  • Page 42: Status Panel

    Information about the user, including: User name User's present state (active, idle, and so on) IP address of the user's computer Date and time of the user's last login • Information about the Dominion PX, including: Model name and number IP address Firmware version...
  • Page 43 A link to the User Guide on the Raritan Website. • A link to wiring diagrams for select Dominion PX models. The State field in the user information section considers a user to be "idle" 30 seconds after the last keyboard or mouse action. It then updates the idle time every 10 seconds until another keyboard or mouse action is detected.

  • Page 44: Status Messages

    Chapter 5: Using the Web Interface Status Messages When you perform an operation from the Web interface, such as creating a user profile or changing a network setting, a message appears at the top of the window indicating whether or not the operation was successful. Be sure to check this message to confirm that an operation was successful.

  • Page 45: Reset To Defaults

    All Outlets Control panel. The home window also contains an environmental sensors panel when environmental sensors are connected to Dominion PX. The Home window refreshes every 30 seconds to keep the data displayed up to date. You can return to the Home window from any other window in the Web interface by clicking: •...

  • Page 46: Line Loads Display

    Line Detail. Circuit Breaker Status For Dominion PX models with circuit breakers, a circuit breaker status display appears on the home page. This provides a quick view of each circuit breaker's status and the current handled by each circuit breaker.

  • Page 47: Outlets List

    Outlets List The Outlets List displays each outlet on the Dominion PX as a table row with a view of the power status, the RMS current, and the RMS Power through the individual outlet.

  • Page 48: All Outlets Control

    Chapter 5: Using the Web Interface Turn an Outlet On, Off, or Cycle the Power To turn an outlet ON, OFF, or cycle the power to it, click the On, Off, or Cycle in the outlet row. You will be asked to confirm your action, click OK and the outlet will then switch ON, OFF, or will cycle its power.

  • Page 49: Monitoring Line And Circuit Breaker Status

    To open the Line Details Page, choose Details > Line Details. The page opens and displays for each line the present current draw, the largest amount of current drawn since the Dominion PX's last boot, and the amount of available current that can be drawn.

  • Page 50: Circuit Breaker Details Page

    Dominion PX last booted, and the amount of available current that the circuit breaker can handle.

  • Page 51: Setting Up User Profiles

    Chapter 5: Using the Web Interface Setting Up User Profiles The Dominion PX is shipped with one built-in user profile: the admin profile, which is used for the original login. This profile has full system and outlet permissions, and should be reserved for the system administrator.
  • Page 52 Chapter 5: Using the Web Interface Note: Before entering any information in the user profile, make sure the User Group is created and available for selection. 2. In the User Management panel, type the following information about the user in the corresponding fields: Field Type this...

  • Page 53: Copy A User Profile

    Chapter 5: Using the Web Interface Note: New user name, Password, and Confirm Password are the only required fields. 3. Select a User Group from the drop-down list in the User Group field. The User Group determines the system functions and outlets this user can access.

  • Page 54: Modify A User Profile

    Chapter 5: Using the Web Interface Modify a User Profile Users with User/Group Management permissions can modify user profiles (see Setting the System Permissions (see "Set System Permissions" on page 46) for details on setting user permissions). To modify a user profile: 1.

  • Page 55: Setting Up User Groups

    Setting Up User Groups The Dominion PX is shipped with one User Group built in: the Admin User Group. This User Group provides full system and outlet permissions. It can be neither modified nor deleted.

  • Page 56: Create A User Group

    Chapter 5: Using the Web Interface Create a User Group To create a User Group: 1. Choose User Management > Users & Groups. The User/Group Management window opens. This window is divided into a User Management panel and a Group Management panel. 2.
  • Page 57 Chapter 5: Using the Web Interface 2. Select the User Group from the Group drop-down list. The permissions that apply to this group appear. If this is the first time you are setting the permissions for this group, all permissions are set to No.

  • Page 58: Set Outlet Permissions

    Chapter 5: Using the Web Interface 4. When you are finished, click Apply. The permissions are applied to the User Group. Note: The User (not in group) field on this window is used to set individual user permissions. If you are setting group permissions, you may ignore this field.

  • Page 59: Copy A User Group

    Chapter 5: Using the Web Interface 2. Select the User Group from the Group drop-down list. The permissions that apply to this group appear. If this is the first time you are setting the permissions for this group, all permissions are set to No.

  • Page 60: Delete A User Group

    3. Click Delete. The User Group is deleted. Setting Up Access Controls The Dominion PX provides tools to control unit access. You can require HTTPS encryption, enable the internal firewall and create firewall rules, and create login limitations.

  • Page 61: Configure The Firewall

    Chapter 5: Using the Web Interface Configure the Firewall The Dominion PX has a firewall that can be configured to prevent specific IP addresses and ranges of IP addresses from accessing the Dominion PX. When the Dominion PX was initially configured, you were prompted to enable or disable IP access control.
  • Page 62 Once enabled, the firewall has a built-in default policy that accepts traffic from all IP addresses. This means that any IP addresses not dropped by a specific rule will be permitted to access the Dominion PX. You can change the default policy to DROP, in which case traffic from all IP addresses will be dropped except traffic allowed by a specific ACCEPT rule.
  • Page 63 Chapter 5: Using the Web Interface Action Do this... • Type an IP address and subnet mask in the IP/Mask field. Add a rule to the end of the rules list • Select ACCEPT or DROP in the Policy field. •...

  • Page 64: Create Group Based Access Control Rules

    Chapter 5: Using the Web Interface Delete Firewall Rules To delete a firewall rule: 1. Choose Device Settings > Security. The Security Settings window opens. 2. Make sure the Enable IP Access Control checkbox is selected. 3. Type the number of the rule to be deleted in the Rule # field. 4.
  • Page 65 Create Group Based Access Control Rules Group based access control rules accept or drop traffic intended for the Dominion PX, based on the user's group membership. Like firewall rules, the order of the rule is important, since the rules are executed in numerical order.
  • Page 66 Chapter 5: Using the Web Interface Action Do this... • Type the higher of the two rule numbers in the Rule # Insert a rule between field. For example, to insert a rule between rules #5 and two existing rules #6, type 6.

  • Page 67: Set Up User Login Controls

    Set Up User Login Controls You can set up login controls to make it more difficult for hackers to access the Dominion PX and the devices connected to it. You can arrange to lock persons out after a specified number of failed logins, limit the number of persons who can log in at the same time using the same login, and force users to create strong passwords.
  • Page 68 4. To adjust how long users can remain idle before they are forcibly logged out by Dominion PX, enter a time in minutes in the Idle Timeout field. The default value is 15 minutes.
  • Page 69 Enable Strong Passwords Forcing users to create strong passwords makes it more difficult for intruders to crack user passwords and access the Dominion PX unit. Strong passwords should be at least eight characters long and should contain upper and lowercase letters, numbers, and special characters (such as @ or &).

  • Page 70: Setting Up A Digital Certificate

    Dominion PX, create a Certificate Signing Request (CSR) and submit it to a certificate authority (CA). Once the CA has processed the information in the CSR, it will provide you with a certificate, which you must install on the Dominion PX. Note: See Forcing HTTPS Encryption (see "Force HTTPS Encryption"...

  • Page 71: Create A Certificate Signing Request

    Chapter 5: Using the Web Interface Create a Certificate Signing Request To create a CSR: 1. Choose Device Setting > Certificate. The first page of the SSL Server Certificate Management window appears. 2. Provide the information requested. Type the following in the appropriate fields: Field Type this...
  • Page 72 An email address where you or another administrative user can be reached Challenge Password The password that will be required to access the Dominion PX. Type it first in the Challenge Password field and then again in the Confirm Confirm Challenge Challenge password field.

  • Page 73: Install A Certificate

    Protocol (LDAP) or the Remote Access Dial-In User Service (RADIUS) protocol. By default, the Dominion PX is configured for local authentication. If you stay with this method, you do not have to do anything other than create user profiles for each authorized user. If you prefer to use an external LDAP or RADIUS server, you must provide the system with information about the server.

  • Page 74: Gather Information For Ldap Configuration

    Chapter 5: Using the Web Interface Gather Information for LDAP Configuration. Configuring Dominion PX to use LDAP authentication requires knowledge of your LDAP server and directory settings. Below is a list of settings you will need values for to configure LDAP authentication. If you are not familliar with these settings, ask your LDAP administrator to help you prepare this list.

  • Page 75: Setup Ldap Authentication

    Chapter 5: Using the Web Interface Setup LDAP Authentication To set up LDAP authentication: 1. Choose Device Settings > Authentication. The Authentication Settings window opens. The LDAP parameters appear on the left side of the window. 2. Click the radio button labeled LDAP to enable the LDAP fields on the page.
  • Page 76 5. To encrypt traffic to and from the LDAP server, select the SSL Enabled checkbox. 6. By default, the Dominion PX uses the standard port 389 for LDAP or port 636 for secure LDAP (SSL). If you prefer to use non-standard ports, specify another port.

  • Page 77: Setting Up Radius Authentication

    4. Type the shared secret in Shared Secret field. The shared secret is necessary to protect communication with the RADIUS server. 5. By default, the Dominion PX uses the standard RADIUS port 1812 (authentication) and 1813 (accounting). If you prefer to use non- standard ports, change the ports.

  • Page 78: Setting Up Outlets And Power Thresholds

    Chapter 5: Using the Web Interface Setting Up Outlets and Power Thresholds The Dominion PX is shipped with certain Dominion PX and outlet power thresholds already defined. You can change the default Dominion PX thresholds, and you can give each outlet a name and change its default thresholds.

  • Page 79: Set Default Outlet State

    Chapter 5: Using the Web Interface Set Default Outlet State Set a global default for the power state of the outlets when the Dominion PX unit is powered on. Setting an individual outlet's startup state to something other than Device Default (see Naming the Outlets) will override this default state for that outlet.

  • Page 80: Set Dominion Px Thresholds

    2. Type a number in the field labeled PDU Power Cycling Delay. When power to the Dominion PX is cycled (either manually or because of a temporary power loss), this number determines how many seconds Dominion PX will wait before it provides power to the outlets. This is useful in cases where power may not initially be stable after being restored, or when UPS batteries may be charging.

  • Page 81: Set Outlet Power-Up Sequence

    Chapter 5: Using the Web Interface Note: When there are a large number of outlets, especially when dealing with outlets grouped from other Dominion PX Units, you may want to set both the Power off period and the Sequence Delays to lower numbers in order to avoid a long wait before all the outlets are available again.

  • Page 82: Name Outlets

    Chapter 5: Using the Web Interface Note: If you use Outlet Grouping to group outlets together, you should adjust the Outlet Sequencing to ensure that all outlets from this Dominion PX that are part of the same group, power up consecutively. Name Outlets You can give each outlet a name to help you identify the device connected to it.

  • Page 83: Set Outlet Thresholds

    4. Select an outlet state from the drop-down list in the Outlet state on device startup. This will determine if the outlet is ON or OFF when the Dominion PX powers up. If set to Device Default, the state for this outlet will be determined by the Default Outlet State in the PDU Setup page.

  • Page 84: View Outlet Details

    Chapter 5: Using the Web Interface View Outlet Details To display details about a particular outlet: 1. Choose Details > Outlet Details. The Outlet Details window opens. 2. Select an outlet from the Show details of outlet drop-down list. The window shows these details about the outlet: Outlet name Outlet status...

  • Page 85: Power Cycle An Outlet

    Note: You can also power cycle an outlet from the Home window. The length of time between the off and on states in a power cycle can be set on the Dominion PX as a whole, and for individual outlets. Setting the Dominion PX Thresholds (see "Set Dominion PX...

  • Page 86: Connect Environmental Sensors

    OUT ports of the hub. Map Environmental Sensors Once the sensors have been physically connected to the Dominion PX, they must be mapped to the unit's logical sensors before Dominion PX will recognize (and display) the readings from them. To map the environmental sensors: 1.
  • Page 87 3. For each physical sensor (shown as a row) in the table, click a radio button under the logical sensor (shown as columns) you want to map it to. Dominion PX will now track this sensor's readings and display it on the home page when configuration is finished.
  • Page 88 Chapter 5: Using the Web Interface The serial number for each sensor also appears listed with each physical sensor detected by Dominion PX. Match the serial number from the tag to the ones in the Environmental Sensor table in order to identify and differentiate sensors, then map the physical sensor to the logical sensors and configure the thresholds appropriately.

  • Page 89: Configure Environmental Sensors And Thresholds

    To make sensors more useful, rename the logical sensors that are in use and configure their threshold settings. Configuring thresholds for these sensors allows Dominion PX to generate an alert whenever environmental factors at those sensors move outside of your idea values.

  • Page 90: View Sensor Readings

    Configuring and Using Alert Notifications A benefit of Dominion PX's intelligence is its ability to notify you of (and react to) a change in conditions. This notification is called an Alert.

  • Page 91: Components Of An Alert

    Environmental Sensors page. Destinations are configured as part of the Alert creation process. E-mail alert destinations require that the Dominion PX be set up for SMTP communication (see the Configuring the SMTP Settings section). How to Configure an Alert The best way to create a new set of alerts, in sequence, is: •...
  • Page 92 Chapter 5: Using the Web Interface Creating Alert Destinations To set up new Alerts, first create the necessary destinations in the Alert Destinations page. Choose Alerts > Alert Destinations to open the page.
  • Page 93 • Event Log: One of the system default destinations. Adding the event log destination to a policy causes the Dominion PX to record alert notifications in the system log. This destination cannot be deleted and additional ones of this type cannot be created.
  • Page 94 SNMP is configured in the Event Logging page. For SNMP alert destinations, Dominion PX sends IPMI-PET (platform event traps) traps to the SNMP manager. The traps are generated in the alert configuration and sent out in IPMI-specific formats containing raw data.
  • Page 95 On this page, you can select an existing policy to modify, or can create a new policy. The table on this page lists all the configured alert destinations available on the Dominion PX. To create an Alert Policy: 1. Choose Alerts > Alert Policy Editor.
  • Page 96 4. Click Create to create the new policy, or click Modify if modifying an existing one. Note: In Dominion PX models without outlet switching, the Current Outlet and Switch Outlet destinations have no effect. These policies will now be available as a response when creating an Alert.
  • Page 97 Chapter 5: Using the Web Interface Creating Alerts The Alert Configuration Page is where you specify how Dominion PX responds to certain events. First describe an event that triggers an alert and then select the policy Dominion PX should take in response.
  • Page 98 Alert Policy Editor. 7. Click Add. Added alerts will now be tracked by Dominion PX. When an alert's event conditions are met, the associated policy will be executed. Note: If Environmental Temperature or Environmental Humidity is selected as part of the Event, an alert event will be created for each logical Temperature or Humidity sensor.

  • Page 99: Sample Alerts

    Chapter 5: Using the Web Interface Sample Alerts Sample Outlet-Level Alert In this example, we want Dominion PX to notify us when the current draw on a specific outlet (Outlet 6) approaches the critical limit. To do that we would setup an alert like this: •...
  • Page 100 Chapter 5: Using the Web Interface Sample Unit Level Alert In this example, we want Dominion PX to shut down most of its outlets if the Dominion PX becomes too hot. However, since mission-critical servers are plugged in to Outlets 1 and 2, we want to leave them running.
  • Page 101 Switch Outlets, with all outlets set to OFF; e-mail for the system administrator and e-mail for the facilities manager. This way, all equipment powered through the Dominion PX would power OFF to avoid damage and prevent from adding more heat to the room. The sysadmin and the facilities manager would both receive notification that the room temperature was too high.

  • Page 102: Setting Up Event Logging

    This way, when the temperature returns to normal (for example, if the ventilation system works properly again), Dominion PX will power on all of its outlets. Additionally, the system administrator and the facilities manager will receive e-mail notification stating that the room temperature dropped below the warning level.

  • Page 103: Configure Local Event Log

    Chapter 5: Using the Web Interface Configure Local Event Log To configure the local event log: 1. Choose Device Settings > Event Log. The Event Log Settings window opens. The Local Logging panel appears first. This panel controls the local event log. 2.
  • Page 104 Chapter 5: Using the Web Interface 5. By default, when the local event log is enabled, seven event types appear in the Event Log Assignments panel to the right. All are enabled by default. To disable any of these event types, deselect the appropriate checkboxes.

  • Page 105: View Internal Event Log

    Chapter 5: Using the Web Interface View Internal Event Log To display the internal event log, choose Maintenance > View Event Log. Entries For each entry, the event log shows: • The date and time of the event • The type of event (board message, security, host control, or authentication) •...

  • Page 106: Configure Nfs Logging

    Chapter 5: Using the Web Interface Configure NFS Logging To configure Network File System (NFS) logging: 1. Choose Device Settings > Event Log. The Event Log Settings window opens. The NFS Logging panel controls NFS logging. 2. Select the NFS Logging Enabled checkbox. 3.

  • Page 107: Configure Smtp Logging

    To enable any of these event types, select the appropriate checkboxes. 5. Click Apply. SMTP logging is configured. Important: If you have not configured the Dominion PX's SMTP settings, you must do so for SMTP logging to work. Click the here Configuring the SMTP Settings link at the bottom of the panel.

  • Page 108: Configure Snmp Logging

    Event logging can be performed by sending SNMP traps to a third-party SNMP manager. See the Using SNMP appendix for instructions on enabling SNMP Event Logging on Dominion PX. Configure Syslog Forwarding Note: If you enable Syslog forwarding a "--MARK--" message may appear in the Syslog record every 20 minutes.

  • Page 109: Managing The Dominion Px

    Managing the Dominion PX You can display basic device information about the Dominion PX, give the Dominion PX a new device name, and modify any of the network settings that were entered during the initial configuration process. You can also set the unit's date and time and configure its SMTP settings so it can send email messages when alerts are issued.
  • Page 110 Chapter 5: Using the Web Interface 2. The Device Information panel displays the product name, serial number, and IP and MAC addresses of the Dominion PX, as well as detailed information about the firmware running in the unit. 3. To open or save an XML file providing details for Raritan Technical...

  • Page 111: Displaying Model Configuration Information

    Chapter 5: Using the Web Interface Displaying Model Configuration Information To display information about the specific model of the Dominion PX that you are using, choose Maintenance > Device Information. The Device Information window opens. Information about your model is shown in the Model Configuration Panel below the Device Information panel.

  • Page 112: Naming The Dominion Px

    Chapter 5: Using the Web Interface Naming the Dominion PX By default, the Dominion PX has a device name of pdu. You may want to give the Dominion PX a more easily recognizable name to help identify it. To name the Dominion PX: 1.

  • Page 113: Modifying The Network Settings

    Chapter 5: Using the Web Interface Modifying the Network Settings The Dominion PX was configured for network connectivity during the installation and configuration process (see Installation and Configuration (on page 12)). If necessary, you can modify any of these settings. To do this: 1.

  • Page 114: Modifying The Communications, Port And Bandwidth Settings

    Chapter 5: Using the Web Interface Modifying the Communications, Port and Bandwidth Settings You can use Telnet or SSH to log into the Dominion PX's CLP interface. However, by default, SSH is enabled and Telnet is not (because it communicates openly and is not secure). You can change this and enable or disable either application.

  • Page 115: Modifying The Lan Interface Settings

    Chapter 5: Using the Web Interface 6. When you are finished, click Apply. The settings are modified. Modifying the LAN Interface Settings The LAN interface speed and duplex mode were set during the installation and configuration process (see Configuring the Dominion PX for Network Connectivity (on page 15)).

  • Page 116: Setting The Date And Time

    Chapter 5: Using the Web Interface Setting the Date and Time You can set the internal clock on the Dominion PX manually, or you can link to a Network Time Protocol (NTP) server and let it set the date and time.

  • Page 117: Configuring The Smtp Settings

    Chapter 5: Using the Web Interface Configuring the SMTP Settings The Dominion PX allows you to configure alerts to send an email message to a specific administrator. To do this, you have to configure the Dominion PX's SMTP settings and enter an IP address for your SMTP server and a sender's email address.

  • Page 118: Configuring The Snmp Settings

    1. Choose Device Settings > SNMP Settings. The SNMP Settings window opens. Enable 2. Select the Enable SNMP Agent checkbox to enable the Dominion PX to communicate with external SNMP managers. A number of options will become available. 3. Check SNMP v1 / v2c Protocol to enable communication with an SNMP manager using SNMP v2c protocol.

  • Page 119: Enabling Data Retrieval

    8. Click Apply. The SNMP configuration is set. Enabling Data Retrieval This feature allows the retrieval of Dominion PX data (such as unit, outlet, line, and circuit breaker data, etc.) by an SNMP manager. When enabled, Dominion PX will measure all sensor data at regular intervals and store these samples for access over SNMP.

  • Page 120: Resetting The Dominion Px

    For each Line Line identifier Line Voltage Resetting the Dominion PX You can use Unit Reset function to reboot the Dominion PX from the Web interface. To reset the Dominion PX: 1. Choose Maintenance > Unit Reset. The Reset Operations window...
  • Page 121 Chapter 5: Using the Web Interface 2. Click Reset. A Reset Confirmation window opens. 3. When you click Really Reset, the Dominion PX will reboot. If you change your mind, click Cancel to terminate the reset operation. If you choose to proceed with the reset, the window shown below opens and the reset takes place.

  • Page 122: Updating The Firmware

    Discard. The update may take several minutes. The Status panel on the left tracks the progress of the upgrade. Note: Do NOT power the Dominion PX off during the update. To indicate at the rack that an update is in progress, the outlet LEDs will...

  • Page 123: Copying Configurations With Bulk Configuration

    Copying Configurations with Bulk Configuration The Bulk Configuration feature lets you save the settings of a configured Dominion PX unit to your PC. This file can be used to copy that configuration to other PX units of the same model type. Users saving Dominion PX configurations require the Bulk Configuration system permission.
  • Page 124 Chapter 5: Using the Web Interface Saving a Dominion PX Configuration A source unit is an already configured Dominion PX that is used to create a configuration file. This configuration file contains the settings that can be shared between Dominion PX units, such as user and group configurations, thresholds, alert policies, the access control list, etc.
  • Page 125 Chapter 5: Using the Web Interface Copying a Dominion PX Configuration A target unit is a Dominion PX that loads another unit's configuration file. Copying a Dominion PX configuration to a target unit will adjust that Dominion PX's settings to match those of the source unit. In order to successfully restore a Dominion PX configuration: •...

  • Page 126: Outlet Grouping

    1. Chose Outlet Groups > Outlet Group Devices. The Outlet Group Devices window opens. 2. Type a name to identify the Dominion PX unit you want to add in the Name field. 3. Type the IP Address of the Dominion PX unit you want to add in the IP Address field.

  • Page 127: Grouping Outlets Together

    Dominion PX, retype the information for the same Dominion PX unit and click Add/Modify again. Note: You can re-add the Dominion PX unit you are accessing (if you deleted it from the list) or modify its details by using the IP address 127.0.0.1.

  • Page 128: Viewing And Controlling Outlet Groups

    4. Under the Capabilities field, check the boxes of the Power Control abilities you want available for this outlet. 5. A list of available Dominion PX units and their outlets appears under Collection of Real Outlets. Check the box representing the desired physical outlet to make it part of the outlet group.

  • Page 129: Editing Or Deleting Outlet Groups

    1. Choose Outlet Groups > Outlet Group Devices. The Outlet Group Devices window opens, displaying a list of known Dominion PX units. 2. Click Delete for the Dominion PX you want to remove from outlet grouping.
  • Page 130 Chapter 5: Using the Web Interface Note: If you delete a Dominion PX that still has outlets in a group, it will remove the associated outlets from that group, but the group will still exist. Remove the group itself using the Outlet Group Editor.

  • Page 131: Chapter 6 Integration

    Integration Chapter 6 Product Direct Access Access Through CC- Connectivity Max # of PX Interfaces SG Interfaces Units Supported Association Control Association Control Dominion SX >= 3.1: SX RSC into CC GUI CC GUI CSCSPCS-1 Max = number GUI; PX serial or CSCSPCS- of serial ports port...

  • Page 132: Dominion Kx

    NOTE: Connecting any power CIM except the for the D2CIM-PWR (e.g. P2CIM-PWR) to the serial port of the Dominion PX will switch all the outlets to the ON state, even if they were previously OFF. In This Chapter Dominion KX..................122...

  • Page 133: Associate Outlets With A Target

    6. See the KX User Guide for details. Associate Outlets with a Target 1. Select target, then select Properties from pop-up menu. 2. Select up to eight Dominion PX units from drop-down list. 3. Select up to a total of four outlets from the PX units.

  • Page 134: Control A Target's Power

    Chapter 6: Integration 4. Notice the target icon change to indicate power. 5. Notice the outlet icon change to indicate association. 6. Notice the outlet name automatically changes to the target's name. Control a Target's Power 1. Select the target associated with outlets.

  • Page 135: Dominion Kx-Ii

    1. Connect the Dominion PX to your target server. 2. Name the Dominion PX unit. 3. Associate outlet(s) in the Dominion PX to the target server. 4. Use remote power management of the target server from the Port Access Page.

  • Page 136: Paragon Manager Application

    Add a Dominion PX Unit in Paragon II Add a Dominion PX unit exactly as you would add any second-tier device. Your Paragon II unit auto-detects the Dominion PX and changes the device type to PCR8, PCS12, or PCS20. On the OSD screen, press F5 to enter the Channel Configuration page.

  • Page 137: Associate Outlets With A Target

    Chapter 6: Integration Associate Outlets with a Target On the OSD screen, press the F5 key to enter the Channel Configuration page and select the channel. Press G to enter the special second-tier screen (Outlet Configuration page). Control a Target's Power To control a target's power: 1.

  • Page 138: Control An Outlet's Power

    Chapter 6: Integration Control an Outlet's Power Use the Channel Selection menus, except for Channel Selection by Name, to navigate to individual Dominion PX ports and control power. Select an outlet and press X, O, or R: • If there is no permission to the outlet, the message Permission denied appears.

  • Page 139: Power Control

    Chapter 6: Integration 4. Select the number of outlets from the Number of Outlets drop-down menu. 5. Type the port number in the Port field. 6. Click OK. Power Control 1. Choose Power Control --> Power Strip Power Control. The Outlet Control screen appears.

  • Page 140: Check Power Strip Status

    PX, including power state of each outlet on the unit. Dominion KSX Support of KSX for Dominion PX is not currently available. However, Dominion PX can be managed as a serial target on one of KSX's serial ports, interacting through CLP interface.

  • Page 141: Commandcenter Secure Gateway

    Paragon II See the CC-SG Administrators Guide for more details. Note: If you have to reboot or power OFF the Dominion PX while it is integrated with a Raritan product under CC-SG management you should PAUSE MANAGEMENT of the integrated product until the Dominion PX fully powers ON again.

  • Page 142: Appendix A Equipment Setup Worksheet

    Appendix A Equipment Setup Worksheet Dominion PX Series Unit Model ____________ Dominion PX Series Unit Serial Number ____________...
  • Page 143 Appendix A: Equipment Setup Worksheet OUTLET 1 OUTLET 2 OUTLET3 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 4 OUTLET 5 OUTLET 6 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 7 OUTLET 8 OUTLET 9 MODEL MODEL MODEL...
  • Page 144 Appendix A: Equipment Setup Worksheet SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 13 OUTLET 14 OUTLET 15 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 16 OUTLET 17 OUTLET 18 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 19 OUTLET 20 OUTLET 21...
  • Page 145 Appendix A: Equipment Setup Worksheet OUTLET 22 OUTLET 23 OUTLET 24 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER Types of adapters __________________________________________________________ Types of cables __________________________________________________________ ______ Name of software program ______________________________________________________...

  • Page 146: Appendix B Using The Clp Interface

    HyperTerminal, or via a Telnet or SSH client such as PuTTY. Note: Telnet access to the Dominion PX is disabled by default because Telnet transmits in the clear and is insecure. To enable Telnet, choose Device Settings > Network and select the click Enable CLP-Telnet Access checkbox.

  • Page 147: With Hyperterminal

    Appendix B: Using the CLP Interface With HyperTerminal To log in using HyperTerminal: 1. Connect your PC to the Dominion PX serial port via a serial cable, launch HyperTerminal and open a console window. When the window first opens, it is blank.

  • Page 148: With Ssh Or Telnet

    Appendix B: Using the CLP Interface 6. You are now logged into the CLP interface and can begin using the interface to administer the Dominion PX. With SSH or Telnet To log in using SSH or Telnet: 1. Launch an SSH or Telnet client such as PuTTY and open a console window.

  • Page 149: Showing Outlet Information

    Appendix B: Using the CLP Interface Showing Outlet Information The show command displays the name, power state (on or off), and associated sensors for one outlet or for all outlets. Note: When displaying outlet information, the outlet names will be returned as OUTLET1, OUTLET2, and so on.

  • Page 150: Examples

    Appendix B: Using the CLP Interface Examples The following are examples of the show command. Example 1 - No Attributes The following shows the output of the show command with no attributes entered. Example 2 - Name Attribute The following shows the output of the show command with the name attribute.

  • Page 151: Syntax

    Appendix B: Using the CLP Interface Syntax The following is the syntax for the set command: clp:/-> set /system1/<outlet number> powerState=on|off where the keyword on turns the outlet on and the keyword off turns the outlet off. Querying an Outlet Sensor The show command with the Antecedent key word queries an outlet's sensors clp:/->...

  • Page 152: Appendix C Using Snmp

    Appendix C Using SNMP This Appendix will help you set up Dominion PX for use with an SNMP manager. The Dominion PX can be configured to send traps to an SNMP manager, as well as receive GET and SET commands in order to retrieve status and configure some basic settings.
  • Page 153 Appendix C: Using SNMP 2. Select the Enable SNMP Agent checkbox to enable the Dominion PX to communicate with external SNMP managers. A number of options will become available. 3. Select the Enable SNMP v1 / v2c Protocol checkbox to enable communication with an SNMP manager using SNMP v1 or v2c protocol.

  • Page 154: Configure Users For Encrypted Snmp V3

    The SNMP v3 protocol allows for encrypted communication. To take advantage of this, users will need to have a Encryption Phrase,which acts as a shared secret between them and the Dominion PX. This encryption phrase can be set in the User Management page.

  • Page 155: Configuring Snmp Traps

    Configuring SNMP Traps Dominion PX automatically keeps an internal log of events that occur (see Setting Up Event Logging under the Using the Web interface chapter). These events can also be used to send SNMP traps to a third party manager.

  • Page 156: Snmp Gets And Sets

    MIB for the release you are using. SNMP Gets and Sets In addition to sending traps, Dominion PX is able to receive SNMP get and set requests from third-party SNMP managers. Get requests can be used to retrieve information about the Dominion PX (such as the system location, or the current on a specific outlet).

  • Page 157: The Dominion Px Mib

    Layout Opening the MIB will reveal the custom objects that describe the Dominion PX system at the unit-level as well as at the individual-outlet- level. As standard, these objects are first presented at the beginning of the file, listed under their parent group. The objects then appear again...

  • Page 158: Disabling Switching

    Appendix C: Using SNMP For example, the unitSensorsGroup group contains objects for sensor readings of the Dominion PX as a whole. One object listed under this group, unitCurrent, is described later in the MIB as "The value for the unit's current sensor in millamps"--the measure of the current drawn by Dominion PX.

  • Page 159: Appendix D Using The Ipmi Tool Set

    Appendix D Using the IPMI Tool Set The IPMI tool set is command-line that allows users to display channel information, print sensor data, and set LAN configuration parameters. The following explains the available IPMI commands. Note: The open source IPMI tool can be downloaded from sourceforge, and compiled on Linux system .Then users can interact with Dominion PX via IPMI protocol through this tool.

  • Page 160: Info [Channel Number]

    Appendix D: Using the IPMI Tool Set info [channel number] Displays information about the selected channel. If no channel is given it will display information about the currently used channel: Example $ ipmitool -I lan -H 192.168.51.58 -U admin -a channel info getaccess <channel number>...

  • Page 161: Predefined Event Number

    Appendix D: Using the IPMI Tool Set <predefined event number> Sends a pre-defined event to the System Event Log. The Currently supported values for are: • Temperature: Upper Critical: Going High • Voltage Threshold: Lower Critical: Going Low • Memory: Correctable ECC Error Detected Note: These pre-defined events will likely not produce "accurate"...

  • Page 162: Set

    Appendix D: Using the IPMI Tool Set set <channel> <parameter> Sets the given parameter on the given channel. Valid parameters are: • ipaddr <x.x.x.x> Sets the IP address for this channel. • netmask <x.x.x.x> Sets the netmask for this channel. •...

  • Page 163: Sensor Commands

    Appendix D: Using the IPMI Tool Set Characters used in privlist and their associated privilege levels are: • Cipher Suite Unused • CALLBACK • USER • O OPERATOR • ADMIN • O OEM Sensor Commands The Sensor commands allow you to display detailed sensor information. list Lists sensors and thresholds in a wide table format.

  • Page 164: Thresh

    $ ipmitool -I lan -H allen-dpxpcr20-20 -U admin -P raritan1 sensor thresh "R.14 Current" unr 10.5 OEM Commands You can use the OEM commands to manage and control the operation of the Dominion PX. OEM Net-Fn is as defined below: #define IPMI_NETFN_OEM_PP 0x3C The table lists each OEM command and gives its ID.

  • Page 165: A Note About Group Commands

    For example, sending the following is incorrect: #ipmitool -H 192.168.80.43 -U admin -P pass raw 0x3c 0x14 grp2 0 Dominion PX will ignore this command. Set Power Set Delay Command The global power on delay defines how much time has to pass between two power on actions.

  • Page 166: Get Receptacle State Command

    Appendix D: Using the IPMI Tool Set Request Data # of receptacle [7 - 5] reserved [4 - 0] # of receptacle, 0 based, highest valid # depends on device model new state [7 - 2] reserved [1] 1b = recycle, ignoring [0], 0b = get new state from [0] [0] 1b = power on, 0b = power off Response Data Completion Code...

  • Page 167: Set Group Membership Command

    Appendix D: Using the IPMI Tool Set Request Data # of group [7 - 5] reserved [4 - 0] group #, valid numbers: 0 - 23, 255 new state [7 - 1] reserved [0] 1b = power on, 0b = power off Response Data Completion Code Set Group Membership Command...

  • Page 168: Set Group Power On Delay Command

    Appendix D: Using the IPMI Tool Set Request Data # of group [7 - 5] reserved [4 - 0] group #, valid numbers: 0 - 23, 255 [7 - 1] reserved [0] 1b = group is enabled, 0b = group is disabled [7] 1b = receptacle 7 belongs to group [0] 1b = receptacle 0 belongs to group [7] 1b = receptacle 15 belongs to group...

  • Page 169: Set Receptacle Acl

    Appendix D: Using the IPMI Tool Set Set Receptacle ACL ACLs define who is authorized to change the state of a receptacle. ACLs will be stored for each individual outlet. A single ACL entry defines whether a certain user id or privilege level is allowed or denied to issue control commands for the outlet.

  • Page 170: Test Actors

    Appendix D: Using the IPMI Tool Set Request Data Sensor number (ffh = reserved) Response Data Completion Code 00h - If calibration ok CDh - if sensor can't be calibrated Test Actors Used for hardware testing during production Request Data [7 - 2] reserved [1] Beeper test, 0b - disable, 1b - enable [0] 7 segment display test, 0b - disable, 1b - enable...

  • Page 171: Ipmi Privilege Levels

    Appendix D: Using the IPMI Tool Set Note: Values greater than 255 cannot be sent to the Dominion PX via IPMI. To set the Power Cycle Delay to longer than 255 seconds, use the web interface. IPMI Privilege Levels The IPMI privilege level that you select determines:...
  • Page 172 Appendix D: Using the IPMI Tool Set User/Group Management User Group Yes/No Yes/No Yes/No Yes/No Yes/No Permissions...

  • Page 173: Appendix E Event Types

    Appendix E Event Types Event Type Examples Outlet Control Outlet(#) switched on by user Outlet(#) switched off by user Outlet(#) cycled by user Outlet/Unit/Environmental Assertion: Environmental Temperature (#) above upper non- Sensors critical threshold Deassertion: Environmental Temperature (#) above upper critical threshold User/Group Administration User added successfully...

  • Page 174: Appendix F Specifications

    Appendix F Specifications In This Chapter Environmental Specifications ..............164 Dominion PX Serial RJ-45 Port Pinouts ..........164 Dominion PX Feature RJ-12 Port Pinouts..........164 Environmental Specifications Environmental Factor Threshold Max Ambient Temperature 40 degrees Celsius Dominion PX Serial RJ-45 Port Pinouts RJ-45 Pin/signal definition Pin No.
  • Page 175 Appendix F: Specifications ― Signal Ground RS485 Data Line + (Data +) directional RS485 Data Line - directional (Data -) ― Signal Ground 1-wire...

  • Page 177: Index

    Control an Outlet's Power • 128 About the CLP Interface • 136 Copy a User Group • 49 Add a Dominion PX Unit in Paragon II • 126 Copy a User Profile • 43 All Outlets Control • 38 Copying a Dominion PX Configuration • 115 Associate Outlets with a Target •...
  • Page 178 Get Receptacle ACL • 159 Get Receptacle State Command • 156 Name Outlets • 72, 75 getaccess <channel number> [userid] • 150 Naming the Dominion PX • 102, 103 getciphers <all | supported> <ipmi | sol> Navigation Path • 31 [channel] • 150 Grouping Outlets Together •...
  • Page 179 Turn Outlet On or Off • 75 Sample Outlet-Level Alert • 89 Turning an Outlet On or Off • 140 Sample Unit Level Alert • 90 Saving a Dominion PX Configuration • 114 Sensor Commands • 153 Unavailable Options • 34 set <channel> <parameter> • 152 Unpack the Dominion PX and Components •...
  • Page 180 For CommandCenter Secure Gateway: Press 6, then Press 2 Phone: +31-10-2844040 Fax: 732-764-8887 Email: tech.europe@raritan.com Email for CommandCenter NOC: tech-ccnoc@raritan.com Email for all other products: tech@raritan.com United Kingdom Monday - Friday 8:30 a.m. to 5 p.m. GMT China Phone +44(0)20-7090-1390...

Table of Contents
