Technical Specifications - Huawei HG659 User Manual

8
Appendix

Technical Specifications

Item
Power supply
Power consumption
Ambient operating
temperature
Ambient humidity
Dimensions (H x W x D)
Weight
DSL standard
Wireless transmission rate
12 V DC, 2 A
< 24 W
0°C to 40°C
5% to 95% RH (non-condensing)
185 mm x 37 mm x 240 mm, exclude the installer
< 350 g
VDSL standard
ADSL standard
ADSL2 standard
ADSL2+ standard
WLAN standard
802.11b
802.11g
802.11n (2T2R
technology)
802.11ac (3T3R
antenna
technology)
Specifications
ITU G.993.2 (G.dmt) Annex B
8a, 8b, 8c, 8d, 12a, 12b, 17a
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.994.1 (G.hs)
ANSI T1.413 Issue 2
ITU G.992.3 (G.dmt.bis) Annex L
ITU G.992.5 (G.dmt.bitplus) Annex M
802.11b, 802.11g, 802.11n (2.4 GHz) and
802.11ac (5 GHz)
Up to 11 Mbit/s
Up to 54 Mbit/s
Up to 300 Mbit/s
Up to 1.3 Gbit/s
