iPF6400S
Cause
The White/Black Backing Plate is soiled.

Spectrophotometer Sensor Cover open.

Spectrophotometer Sensor Cover open.
The Spectrophotometer Sensor Cover of the Spectrophotometer Unit is
open.

Spectrophotometer Unit cover open.

Spectrophotometer Unit cover open.
The Spectrophotometer Unit Cover of the Spectrophotometer Unit is open.

Spectrophotometer read error.

Spectrophotometer read error.
Cause
The Spectrophotometer Sensor to
be loaded into the Spectropho-
tometer Carriage is not installed
correctly.
The color measurement pattern
was not printed correctly.
The color measurement pattern is
out of alignment.
The performance of part of the
Spectrophotometer Unit may be
impaired.

Clean calibration white tile because it may be dirty.

Clean calibration white tile because it may be dirty.
Cause
The White Cali- Remove, clean, and reinstall the White Calibration Tile.
bration Tile
(See "Cleaning the Spectrophotometer Unit (option) Parts.")
may be dirty.
If this message is still displayed after cleaning the White Calibration Tile, we recommend adjusting the Spectrophotometer
Sensor.
Contact your Canon dealer for more information on adjustment services.
(See "Replacing the Spectrophotometer Sensor of the Spectrophotometer Unit (option).")
User's Guide
Clean the White/Black Backing Plate and then press the OK button.
(See "Cleaning the Spectrophotometer Unit (option) Parts.")
Cause
Cause
Turn off the power, and reinstall by pushing the two connectors all the way into the Spectrophotometer
Sensor.
(See "Replacing the Spectrophotometer Sensor of the Spectrophotometer Unit (option).")
Check the color measurement pattern. If the printing is faint, clean the printhead and perform the operation
again.
(See "Cleaning the Printhead.")
Pulling or lifting a printed color measurement pattern may cause the pattern to come out of alignment.
Perform the operation again taking care not to touch the color measurement pattern.
Execute Feed Priority to improve the printing position of the pattern for color measurement.
(See "Automatic Banding Adjustment.")
If the same message is displayed again after performing the above operation, set Pattern Size to Large
on the Control Panel menu and perform the operation again.
(See "Menu Structure.")
P.628
➔
Alternately, it may be resolved by selecting Air Drying in Drying Method in the Color Measurement
Preferences dialog box in the Color Calibration Management Console and selecting the Dry Separated
Chart check box if it is off.
(See "Acquiring Color Measurement Data For Any Color Chart (Windows).")
(See "Acquiring Color Measurement Data For Any Color Chart (Mac OS).")
Turn off the printer and wait a while before restoring power, and then perform the operation again.
If the same message is displayed again, contact your Canon dealer for assistance.
Corrective Action
Corrective Action
Close the Spectrophotometer Sensor Cover and press the OK button.
Corrective Action
Close the Spectrophotometer Unit Cover and press the OK button.
Corrective Action
P.891
➔
P.771
➔
Corrective Action
P.911
➔
Spectrophotometer Sensor Cover open.
P.911
➔
P.928
➔
P.830
➔
P.866
➔
P.928
➔
987
