Chapter 4
1. At the front of the HP NetServer, open the bezel.
Refer to Chapter 3, "Opening and Closing the HP NetServer" for details.
2. To unlock the drive, push the locking latch in and then pull the ejector
handle toward you. See Figure 4-3.
Figure 4-3. Pulling Open the Latch of a Hot Swap Drive
3. Gently pull the drive out about an inch to disengage the power connection.
4. Wait 30 seconds for the drive to stop spinning and the drive heads to park.
5. Use your hand to support the bottom of the drive, while you slowly pull the
drive straight out and do not allow the drive to fall.
6. Place drive in an electrostatically protected container and do not stack
drives.

Installing the Optional Tape Backup (DAT) Drive

If you require the optional tape backup (DAT) drive and it did not come installed
in the HP NetServer, you will have to remove the Peripheral bay to install it and
connect both cables to the rear of the DAT tape drive. This procedure could also
be used to install a different CD-ROM or Flexible Disk drive.
Installing Mass Storage Devices
Pull locking latch completely open
before pulling out the drive.
43
