Chapter 2
Table 2-7. Tape Drive LED Codes
Left LED Right LED
Off Off
On Off
Flashing* Off
Pulsing** Off
Off On
Off Pulsing**
On Pulsing**
Flashing* Pulsing**
Pulsing** Pulsing**
* Flashing at 4 Hz rate
** Pulsing at 2 Hz rate
NOTE
For more information on the HP Tape Drive and its error
codes, refer to the documentation provided with the tape drive,
or refer to Hewlett-Packard's web site, at
Refer to Chapter 4, "Installing Mass Storage Devices" for
installation information.

Fan Indicators

The fan indicators are used to indicate which fan is defective and are only visible
when the fan cover is removed. If a fan is defective, the fan's indicator glows a
steady amber until it is replaced. Each indicator points to a particular fan as shown
in Figure 2-10.
Controls, Indicators, and Ports
Definition
No Power
Cartridge Loaded, but No activity
Cartridge Loaded and Active
Loading/Unloading/Ejecting/Power-On
Self Test Fail
No Cartridge, but Caution (cleaning required)
Cartridge Loaded, but Caution (cleaning required)
Cartridge Loaded, Drive Active, Caution (cleaning
required)
Cartridge Loading/Unloading, Caution (cleaning
required)
.
www.hp.com
15
