CAMSHAFT / CYLINDER HEAD / CYLINDER
ITEM
Valve Stem Diameter - Exhaust
Valve Stem Oil Clearance - Intake
Valve Stem Oil Clearance - Exhaust
Valve Stem Overall Length - Intake
Valve Stem Overall Length - Exhaust
Valve
Valve Guide Inner Diameter
Guide
Valve Seat - Contacting Width - Intake
Valve Seat - Contacting Width - Exhaust
Valve Seat Angles - Intake
Valve Seat
Valve Seat Angles - Exhaust
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
ENGINE / COOLING SYSTEM
STANDARD
0.2147 - 0.2153" (5.455 - 5.47 mm)
.0003 - .0015" (0.010 - 0.040 mm)
.0011 - .0023" (0.030 - 0.060 mm)
3.7704" (95.77 mm)
3.8023" (96.58 mm)
.1956 - .2019" (4.970 - 5.130 mm)
.0393 ± .0039" (1.0 ± 0.10 mm)
.0590 ± .0039" (1.5 ± 0.10 mm)
14.0° ± 1.5°
30.0° ± 1.5°
45.75° ± 0.25°
51.0° ± 1.5°
15.0° ± 1.5°
30.0° ± 1.5°
44.75° ± 0.25°
60.0° ± 1.5°
SERVICE LIMIT
-
-
-
-
-
3
-
.0551" (1.4 mm)
.0748" (1.9 mm)
-
-
3.5
