OWNER’S MANUAL ENGLISH ภาษาไทย AIR CONDITIONER (SPLIT TYPE) For general public use Indoor unit RAS-10, 13J2KCVRG-T Outdoor unit RAS-10, 13J2ACVRG-T 1122350201 1122350201_00_S03_182x257_64p_S_p70_190208.indd 1 2/23/2019 11:05:04 AM...
PRECAUTIONS FOR SAFETY Read the precautions in this This appliance is filled manual carefully before operating with R32. the unit. ● Keep this manual where the operator can easily find it. ● Read the precautions in this manual carefully before operating the unit. ● This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons.
Page 4
PRECAUTIONS FOR SAFETY (continued) ● Children should be supervised to ensure that they do not play with the appliance. ● Do not use any refrigerant different from the one specified (R32) for complement or replacement. Otherwise, abnormally high pressure may be generated in the refrigeration cycle, which may result in a failure or explosion of the product or an injury to your body.
DISPLAY Indoor unit display Temporary operation 1 Wi-Fi access (White) In case of the misplaced or discharged remote 2 ECO (White) control 3 PURE (White) Pressing the RESET button, the unit can start 4 Timer (White) or stop without using the remote control. 5 Operation Operation mode is set on AUTOMATIC OPERATION...
REMOTE CONTROLLER PREPARATION Kind of receiving tone Remote control When the indoor unit receives a signal from the remote control, the receiving tone sounds...Operation, change ..Stop PiPi ..Notice Transmitting part PiPi When the notice sounds, it means the operating setting returns to the datum point. (Example) When temperature setting.
Page 7
Remote control Insert the battery Setting the clock Remove the cover and insert Press the CLOCK button AAA alkaline dry batteries Press with tip of the pencil. Insert direction of (+) and (-) correctly ..........Adjust the “Day”...
Page 8
Indoor unit Turn on the main power supply ● A waiting period of 3 minutes is required after the power is turned on. During this period, the operation lamp will illuminate. However, the compressor will not start. Check transmitting and receiving Point the remote control at the remote control receiving module on the indoor unit.
AUTOMATIC OPERATION The air conditioner selects the cooling operation. When sounds, When starting automatic operation, select it notices that the operation setting returns to the datum point. Page 5 ● The air volume can be set as you prefer. TEMP. When changing the temperature, Press ●...
COOLING / FAN ONLY / DRY OPERATION Temperature and air volume for the cooling operation can be set as you prefer. When sounds, it notices the operation setting returns to the datum point. Page 5 Cooling operation Dry operation Fan only operation 1122350201_00_S03_182x257_64p_S_p70_190208.indd 8 2/23/2019 11:05:07 AM...
Page 11
For dehumidification, a moderate cooling performance is controlled automatically. operation TEMP. When changing the temperature, Press Down When at 24°C PiPi ● The temperature changes by 1°C when pressed. It changes continuously when pressed continuously. ● The available setting range is 17°C – 30°C. Notes ●...
AIR VOLUME When sounds, Changing the air volume, press it indicates the operation setting returns to the original setting. Page 5 ● Every time... When pressed during Auto, Cooling and Fan only. AIR FLOW DIRECTION Press : Move the louver in the desired vertical direction.
Hi-POWER OPERATION To automatically control room temperature and airflow for faster cooling operation (except in DRY and FAN ONLY mode) Hi-POWER OPERATION ● Hi-POWER appears on the remote control display. 1122350201_00_S03_182x257_64p_S_p70_190208.indd 11 2/23/2019 11:05:09 AM...
ECO OPERATION While Automatic, Cooling operation is activated, automatic control room temperature to save energy, except in DRY and FAN ONLY mode. ECO OPERATION ● appears on the remote control display. ● The set temperature will be automatically adjusted appropriately. However, the temperature is raised by no more than 2 degree Celsius.
PLASMA ION Capture efficiency of floating impurities in the air is accelerated by plasma ion contaminates such as bacteria, odor, smoke, dust and virus are caught and deactivated by Plasma Ion. To clean the air, Plasma Ion When stopping operation. ●...
COMFORT SLEEP The operation stops automatically at the Pre-set time. When 1, 3, 5 and 9 hours are selected, the comfort sleep operation begins. The set temperature will be automatically adjusted appropriately. However, the temperature is raised or decreased to no more than 2 degrees Celsius.
Page 17
Timer on, Timer off Start and stop of operation is selected with the time. Operate after setting the current time on the remote control Page 6 For timer on For timer off Example of setting (Selection of timer On/Off) To start at 6:00 AM and stop at 10:00 AM. ●...
WEEKLY TIMER OPERATION 4 programs for each day in the week can be set in WEEKLY TIMER. The following items can be set in WEEKLY TIMER operation. a. Operation time (ON timer for Start and OFF timer for Stop operation) b.
Page 19
How to set WEEKLY TIMER Press to enter WEEKLY TIMER setting. Blink ..................... . Press to select desired day in sequence.
Page 20
Press to select desired operation....................Press to select desired temperature.
Page 21
Edit Weekly timer program To edit the program after confirming the weekly timer setting on Page 18 , follow steps - 3 below. Press ● The day of the week and the program number of the current day will be displayed..................... . . Press to select the day of the week and press to select...
Page 22
To delete programs The individual program Press ● The day of the week and the program number is displayed. ● Select the day to delete the program..................... . . Press to select the program number to be deleted.
WEEKLY TIMER USAGE EXAMPLE Living room (Example#1) Wake up Return home 6:00, ON, Mode : Auto, 16:00, ON, Mode : Cool, 26°C, FAN : Low, ECO 25°C, FAN : Auto, Hi-POWER MO-FR 8:00, OFF 22:00, OFF Go out Go to bed No program set, control by user.
Page 24
WEEKLY TIMER USAGE EXAMPLE (continued) Bedroom (Example#2) More power save by Speed up adjustment to Release Hi-POWER More power save by ECO function with desired desired temperature with to normal operation ECO function with temperature. Hi-POWER function. for power save. desired temperature. 2:00, ON, 21:00, ON, Mode : Cool, 22:00, ON, 2:00, ON,...
PRESET OPERATION Set your preferred operation for future use. The setting will be stored in the memory and can be used for future requirements. PRESET OPERATION Select your preferred operation. Press and hold for 3 seconds to store the setting. mark displays.
POWER-SELECTION AND SILENT OPERATION (OUTDOOR UNIT) Power-Selection ( This function is used when the circuit breaker is shared with other electrical appliances. It limits the maximum current and power consumption to 100%, 75%, or 50% and can be implemented by POWER-SELECTION. The lower percentage, the higher saving and also longer compressor lifetime.
DISPLAY LAMP BRIGHTNESS ADJUSTMENT This function is used when it is necessary to decrease the display lamp brightness or turn it off. LAMP BRIGHTNESS ADJUSTMENT While operating (Auto, Cool or Dry), press and hold 5 seconds. Rise Press or Decrease to adjust brightness which can be set at 4 levels or to turn it off.
SELF CLEANING OPERATION (COOL AND DRY OPERATION ONLY) Self cleaning operation is started after operations of 10 minutes or longer. To stop the unit immediately press 2 more times within 30 seconds. After stopping the Self cleaning operation by remote control and starting the air conditioner, the next operation may be delayed.
WHEN INDOOR UNIT LAMP BLINKS Turn off the power supply. Wait 30 seconds. Turn on the power supply and check the operation of the unit. If the lamp blinks again, inspection and repair is required To repair quickly, check the status of the air conditioner according to the following procedure and inform (1) –...
AUTO RESTART SETTING This product is designed so that after a power failure, it can restart automatically in the same operating mode as before the power failure. The product was shipped with Auto Restart function in the OFF position. Turn it ON as required. How to set the Auto Restart How to set the Auto Restart Press and hold the Temporary switch on the indoor unit for 3 seconds to set the operation...
REMOTE CONTROL A-B SELECTION To separate using of remote control for each indoor unit in case of 2 air conditioners are installed nearly. Remote Control B Setup. 1. Press RESET button on the indoor unit to turn the air conditioner ON. 2.
