- Page 1 YARIS HATCHBACK CUSTOMER EXPERIENCE CENTER 1-800-331-4331 2 0 1 7 QUICK REFERENCE GUIDE Printed in U.S.A. 8/16 00505QRG17YARHB 16-MKG-09536...
- Page 2 Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.
- Page 3 Pairing a Bluetooth Device ® Parking brake Power outlet Seat adjustments-Front Seat-Folding rear seat Seats-Head restraints Steering wheel switches Tilt steering wheel USB/AUX port Windows-Power Windshield wipers & washers * Visit your Toyota dealer for information on customizing this feature.
- Page 4 OVERVIEW Instrument panel Lane Departure Alert (LDA) switch Steering wheel audio controls Cruise control Steering wheel controls Wiper and washer controls Headlight, turn signal and front fog light controls Power outside rearview mirror control switches Instrument panel light control Hood release Tilt steering lock release lever...
- Page 5 Emergency flasher switch “AIR BAG ON” and “AIR BAG OFF” indicator Rear window defogger switch Air Conditioning controls USB port/AUX port If equipped. 12V DC power outlet...
-
Page 6: Instrument Cluster
WITHOUT TACHOMETER & FUEL GAUGE Speedometer Multi-Information Display Display change button Clock adjusting buttons Service indicators and reminders If indicator does not turn off within a few seconds of starting the engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. -
Page 7: Instrument Symbols
Instrument symbols For details, refer to “Indicators and warning lights,” Section 2-2, 2017 Owner’s Manual. Pre-Collision System (PCS) Brake system warning warning Pre-Collision System (PCS) Malfunction/Check Engine indicator activator indicator Lane Departure Alert (LDA) Maintenance required warning indicator Lane marker indicators Low Tire Pressure Warning Electric power steering system warning... -
Page 8: Keyless Entry (If Equipped)
OVERVIEW Keyless entry (if equipped)* LOCKING OPERATION Type A Type B Push UNLOCKING OPERATION Type A Type B Push ONCE: Driver door TWICE: All doors * Engine immobilizer feature if equipped. As an anti-theft feature, the vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on-board computer. -
Page 9: Hood Release
Hood release Pull Pull up latch and raise hood Engage support rod Engine maintenance Engine oil filler cap Engine coolant reservoir Engine oil level dipstick Windshield washer fluid tank and rear window washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will help Please refer to the extend the life of your vehicle and maintain performance. -
Page 10: Features & Operations
FEATURES & OPERATIONS Automatic transmission Park* Reverse Neutral Drive Third gear Second gear First gear * The ignition switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D”... -
Page 11: Lights & Turn Signals
Lights & turn signals HEADLIGHTS Type A Type B Headlights Headlights Parking lights Parking lights Type C High beam flasher Low beam Headlights Parking lights DRL ON High beam TURN SIGNALS Right turn Lane change Lane change Left turn FRONT FOG LIGHTS (IF EQUIPPED) Type A Type B Turn... -
Page 12: Windshield Wipers And Washers
FEATURES & OPERATIONS Windshield wipers & washers FRONT Type A Type B Single wipe Mist Interval wipe Interval wipe Slow Slow Fast Fast Pull to wash and wipe Pull to wash and wipe REAR Type A Type B Wash and wipe Wash and wipe Wipe Wipe... -
Page 13: Cruise Control
Cruise control (if equipped) TURNING SYSTEM ON/OFF FUNCTIONS Resume Increase speed Cancel Set/Decrease speed System ON/OFF The set speed may also be cancelled by depressing the brake pedal or the clutch pedal (manual transmission). Unless vehicle speed drops below 10 mph, the set speed may be resumed once vehicle exceeds 25 mph. -
Page 14: Seat-Folding Rear Seat
FEATURES & OPERATIONS Seat-Folding rear seat BEFORE FOLDING Push Push Store Store Store (5) Pull up (8) Pull up (7) Push (6) Fold down FOLD (SPLIT SEAT) Pull up Lower Push Fold down... -
Page 15: Air Conditioning/Heating
Air conditioning/heating WITH AIR CONDITIONING ON/OFF BUTTON Temperature Fan speed Airflow vent* selector Recirculate cabin air Air onditioning (outside air when OFF) ON/OFF Rear window defogger ON/ WITHOUT AIR CONDITIONING ON/OFF BUTTON Temperature Fan speed Airflow vent* selector Recirculate cabin air (outside air when OFF) Rear window defogger ON/OFF... -
Page 16: Multi-Information Display (Mid)
FEATURES & OPERATIONS Multi-Information Display (MID) Type A Type B Type C Push button to change information in the following succession (shown in box indicated above): (1) Odometer (2) Trip meters (3) Miles left on remaining fuel (RANGE/MI) (4) Average gas mileage (AVG/MPG) (5) Current gas mileage (MPG) (6) Average vehicle speed from engine start (AVG/MPH) Clock... -
Page 17: Light Control-Instrument Cluster
Light control-Instrument cluster Brightness control USB/AUX port (if equipped) USB port By connecting a USB-compatible portable audio device or USB memory to the USB port, you can listen to music from the portable audio device or USB memory through the vehicle’s speaker system. AUX port By inserting a mini plug into the AUX port, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. -
Page 18: Pairing A Bluetooth
FEATURES & OPERATIONS Audio YARIS ENTUNE™ AUDIO Eject CD Turn to tune radio stations manually or Push to turn select tracks ON/OFF SETUP Button Push to display audio screen Push to display ® Bluetooth hands-free Seek station/ system CD track select APPS button NOTE: Concentrating on the road should always be your first priority while driving. -
Page 19: Toyota Safety Sense
TOYOTA SAFETY SENSE Quick overview-Toyota Safety Sense C Toyota Safety Sense (TSS) C is a set of active safety technologies designed to help prevent or mitigate collisions across a wide range of traffic situations. TSS-C is designed to help support the driver’s awareness, decision making and vehicle operation contributing to a safe and comfortable driving experience. -
Page 20: Pre-Collision System (Pcs)
TOYOTA SAFETY SENSE Pre-Collision System (PCS) The Pre-Collision System uses a laser sensor and camera sensor to help detect vehicles in front of your vehicle. Note: PCS is enabled each time the engine switch is turned to Ignition On. The system can be disabled/enabled and the warning timing of the system can be changed. - Page 21 CHANGING THE PRE-COLLISION WARNING TIMING Middle (default) Near Each time the Pre-Collision System switch is pressed, the response to the warning distance changes. DISABLING THE PRE-COLLISION SYSTEM (PCS) To disable the system Press the PCS switch for 3 seconds or more. The PCS warning light will turn on and a message will be displayed on the Multi- Information Display (MID).
-
Page 22: Lane Departure Alert (Lda)
TOYOTA SAFETY SENSE Lane Departure Alert (LDA) The Lane Departure Alert system is designed to recognize visible white or yellow lane markers via a front sensor. The system alerts the driver with a warning buzzer sound and message in the Multi-Information Display (MID) when it detects the vehicle deviating from its lane. - Page 23 FUNCTIONS LDA function display Lane Lane Departure Alert (LDA) indicators turn green when operating. The LDA function displays when the Multi-Information Display (MID) is switched to the driving assist system information screen. (1) The system displays solid white lines on the LDA indicator when visible lane markers on the road are detected.
-
Page 24: Auto High Beams (Ahb)
TOYOTA SAFETY SENSE Auto High Beams (AHB) The AHB uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and is designed to automatically turn high beams on or off as necessary. -
Page 25: Safety & Emergency Features
SAFETY & EMERGENCY FEATURES Doors-Child safety locks Rear door (5-door models only) Moving the lever to downward will allow the door to be opened only from the outside. Seat belts Take up slack Too high Keep as low on hips as possible NOTE: If a passenger’s seat belt is fully extended, then retracted even slightly, the Automatic locking retractor (ALR) will prevent it from being re-extended beyond that point, unless fully retracted again. -
Page 26: Tool Location
” indicator will illuminate. Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details. -
Page 27: Star Safety System
Traction Control helps maintain traction on loose gravel and wet, icy, or uneven surfaces by applying brake force to the spinning wheel(s). Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip. TRAC limits engine output and applies the brakes to the spinning wheel. This transfers power to the wheels that still have traction to help keep you on track. -
Page 28: Floor Mat Installation
Floor mat installation There are two types of Toyota floor mats: carpeted and all-weather. Each vehicle has model-specific floor mats. Installation is easy. To keep your floor mat properly positioned, follow these steps: •... - Page 30 NOTES...
- Page 31 NOTES...
