Summary of Contents for Toyota YARIS SEDAN
- Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Yaris.
-
Page 3: Table Of Contents
Windshield wipers & washers Door locks-Power SAFETY AND Doors-Child safety locks EMERGENCY FEATURES Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Trunk-Internal release Tire Pressure Monitoring (warning) System Visit your Toyota dealer for information on this and other customizable options. - Page 4 OVERVIEW Instrument panel Instrument panel light control Power rearview mirror controls* Headlight, turn signal and front fog light* controls Cruise control Engine switch Wiper and washer controls Emergency flasher button Front passenger seat belt reminder light Clock adjust button Trip meter reset button...
- Page 5 “AIR BAG ON” and “AIR BAG OFF” indicator Audio system* Air Conditioning controls AUX adapter* Rear window defogger switch* Tilt steering lock release lever Hood release * If equipped...
-
Page 6: Instrument Cluster
Charging system warning If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. For details, refer to “If your vehicle overheats,” Section 5-2, 2009 Owner’s Manual... - Page 7 Malfunction/Check Engine indicator Low engine oil pressure warning Open door warning Airbag SRS warning Low windshield washer fluid level warning Electric power steering system warning Low fuel level warning Engine oil replacement reminder AIR BAG ON indicator AIR BAG OFF indicator Headlight low beam indicator Headlight high beam indicator Front fog light indicator...
-
Page 8: Fuel Tank Door Release And Cap
OVERVIEW Fuel tank door release and cap Driver seat Hang Pull up Turn NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Keyless entry (if equipped) Locking operation Unlocking operation Push ONCE: Driver door TWICE: All doors... -
Page 9: Hood Release
Hood release Pull Pull up latch and raise hood Engine maintenance Windshield washer fluid tank Engine oil filler cap Engine oil level dipstick Engine coolant reservoir Note: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Owner’s Warranty Information Booklet,”... -
Page 10: Automatic Transmission
FEATURES/OPERATIONS Automatic Transmission (if equipped) Park* Reverse Neutral Drive Third gear Second gear First gear * The engine switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill. -
Page 11: Parking Brake
Parking brake Release (2) Push (1) Pull slightly Pull (3) Lower Windows-Power (if equipped) Driver side Window lock switch Down Window operation Automatic down operation (driver side only) Push the switch completely down and release to fully open. To stop window at any point, lightly pull the switch up. -
Page 12: Seat Adjustments-Rear
FEATURES/OPERATIONS Seat adjustments-Rear (fold-down type) To fold down the rear seatback (1) Slide the seatback security lock to the right unlock position from the trunk room. (2) Lower the seat head restraints. (3) Pull the lock release knob up. (4) Fold the seatback down. Refer to the Owner’s Manual for more details. -
Page 13: Lights & Turn Signals
Lights & turn signals Headlights Headlights Parking lights Low beam High beam flasher High beam Turn signals Right turn Lane change Lane change Left turn Front fog lights (if equipped) Turn Front fog lights turn on only when the headlights are on low beam. - Page 14 FEATURES/OPERATIONS Audio Type 1 Push to turn Push to adjust tone & balance ON/OFF Eject CD Push to skip up Seek station/ /down folder CD track select Mode Mode Station/CD track scan Preset buttons - functions in other View CD text modes indicated above number.
-
Page 15: Power Outlet
AUX audio jack (if equipped) By inserting a mini plug of a commercially available component into the AUX audio jack, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. ® NOTE: An iPod -dedicated port is standard on all S model sedans. -
Page 16: Clock
FEATURES/OPERATIONS Cruise control (if equipped) Turning system ON/OFF System ON/OFF Functions Cancel Resume /Increase speed Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal. Unless vehicle speed drops below 10 mph, the set speed may be resumed once vehicle exceeds 25 mph. -
Page 17: Bottle Holders-Rear Seat
Cup holders Front Rear Rear seat armrest (if equipped) Rear console box Bottle holders-Rear seat... -
Page 18: Tire Pressure Monitoring (Warning) System
Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details. -
Page 19: Seat Belts-Shoulder Belt Anchor
Seat belts-Shoulder belt anchor Lock release knob Pull the lock release knob out to lower Spare tire & tools Tool location Jack handle Spare tire Jack Tool bag Removing the spare tire Loosen and remove the bolt. Refer to the Owner’s Manual for tire changing and jack positioning procedures. - Page 20 MN 00505-QRG09-YARS Printed in the USA 7/08...
