Flexible NC programming
1.25 Subprogram technique
Example 2: A cycle is to act like a command for a user
Main program:
Program code
N10 G1 X10 G90 F200
N20 X-4 Y6
N30 CYCLE1
N40 G1 X0
N50 M30
Cycle CYCLE1:
Program code
N100 PROC CYCLE1 DISPLOF SBLOF
N110 R10=3*SIN(R20)+5
N120 IF (R11 <= 0)
N130 SETAL(61000)
N140 ENDIF
N150 G1 G91 Z=R10 F=R11
N160 M17
CYCLE1 is processed for active single block execution, i.e., the Start key must be pressed
once to process CYCLE1.
182
Comments
; Suppress single block
Programming Manual, 06/2009, 6FC5398-2BP20-0BA0
Job Planning
