Page 1 Pictorial Index Search by illustration For safety and Make sure to read through them security Instrument clus- How to read the gauges and meters, the variety of warning lights and indicators, etc. Operation Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information .......6 Operation of each compo- Reading this manual.......8 nent How to search ........9 Pictorial index .......10 3-1. Key information Keys ........102 For safety and security 3-2. Opening, closing and locking the doors Side doors ......114 1-1.
Page 3 4-5. Using the driving support sys- Driving tems Cruise control ....220 Speed limiter ..... 224 4-1. Before driving Stop & start system ... 228 Driving the vehicle .....160 Driving assist systems..235 Cargo and luggage ....171 Diesel particulate filter sys- Trailer towing .....173 tem........240...
Page 4 TABLE OF CONTENTS Interior features Maintenance and care 6-1. Using the air conditioning sys- 7-1. Maintenance and care tem and defogger Cleaning and protecting the Manual air conditioning sys- vehicle exterior....316 tem........280 Cleaning and protecting the Automatic air conditioning sys- vehicle interior....
Page 5 If you run out of fuel and the When trouble arises engine stalls (diesel engine only) ........ 462 vehicle becomes 8-1. Essential information stuck.........464 Emergency flashers ...394 If your vehicle has to be stopped Vehicle specifications in an emergency ....395 8-2.
Page 6: For Your Information
Accessories, spare parts and modification of your Toyota Both genuine Toyota and a wide variety of other spare parts and accessories for Toyota vehicles are currently available in the market. Should it be deter-...
Page 7 Scrapping of your Toyota The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be...
Page 8: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 9: How To Search
How to search  Searching by name • Alphabetical index ..P. 500  Searching installation position • Pictorial index ....P. 10  Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 496  Searching by title •...
Page 10: Pictorial Index
Pictorial index Pictorial index  Exterior The illustration represents the 5-door models and may differ from the body shape of the 3-door models. Side doors ........P. 114 Locking/unlocking .
Page 11 Pictorial index Wipers........P. 210, 214 Precautions against winter season .
Page 12 Pictorial index  Instrument panel (Left-hand drive vehicles) Engine switch ....... . P. 182, 185 Starting the engine.
Page 13 Pictorial index Multi-information display ......P. 90 Parking brake........P. 201 Applying/releasing .
Page 14 Pictorial index  Switches (Left-hand drive vehicles) Outside rear view mirror switches ....P. 151 Manual headlight leveling dial ..... . . P. 204 Power heater switch .
Page 15 Pictorial index Audio remote control switches ....P. 248 Paddle shift switches ......P. 193 Telephone switch Speed limiter switch .
Page 16 Pictorial index  Interior (Left-hand drive vehicles) SRS airbags ........P. 37 Floor mats .
Page 17 Pictorial index Inside rear view mirror ......P. 148 Sun visors ........P. 309 Vanity mirrors .
Page 18 Pictorial index  Instrument panel (Right-hand drive vehicles) Engine switch ....... . P. 182, 185 Starting the engine.
Page 19 Pictorial index Multi-information display ......P. 90 Parking brake........P. 201 Applying/releasing .
Page 20 Pictorial index  Switches (Right-hand drive vehicles) Outside rear view mirror switches ....P. 151 Manual headlight leveling dial ..... . . P. 204 Tire pressure warning reset switch .
Page 21 Pictorial index Audio remote control switches ....P. 248 Paddle shift switches ......P. 193 Telephone switch Speed limiter switch .
Page 22 Pictorial index  Interior (Right-hand drive vehicles) SRS airbags ........P. 37 Floor mats .
Page 23 Pictorial index Inside rear view mirror ......P. 148 Sun visors ........P. 309 Vanity mirrors .
Page 24 Pictorial index...
Page 25: For Safety And Security
For safety and security 1-1. For safe use Before driving.......26 For safety drive ....28 Seat belts......30 SRS airbags......37 Airbag manual on-off system .......49 Safety information for children......52 Child restraint systems ..53 Installing child restraints ..63 Exhaust gas precautions ..73 1-2. Theft deterrent system Engine immobilizer system .......74 Double locking system..79...
Page 26: For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat  Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats.  Only use floor mats designed for the driver’s seat. ...
Page 28: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use Adjusting the mirrors Make sure that you can see the rear of the vehicle clearly, by adjust- ing the inside and outside rear view mirrors properly. (P. 148, 151) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts  Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Fastening the rear center seat belt Take out the plate, and then pull the seat belt. Push the plate into the buckle in Plate “B” Plate “A” the order of plate “A” and plate “B” until a clicking sound is heard.
Page 32 1-1. For safe use Releasing and stowing the rear center seat belt To release the hooked plate “B”, push the buckle release button. To release the hooked plate “A”, insert the plate “B” or the key or the mechanical key (P. 104) into the hole on the buckle.
Page 33  Seat belt regulations If seat belt regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for seat belt replacement or installation.
Page 34 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children.  Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ...
Page 35 Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 36 1-1. For safe use WARNING  When using the rear center seat belt  Do not use the rear center seat belt with either buckle released. Fastening only one of the buckles may result in death or serious injury in case of sudden braking or a collision.
Page 37: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ...
Page 38 1-1. For safe use SRS airbag system components Seat belt pretensioners and SRS warning light force limiters Driver knee airbag Side impact sensors (front) Airbag sensor assembly Side airbags Front impact sensor Curtain shield airbags Airbag manual on-off switch Side impact sensors (rear) Front passenger airbag Side impact sensors “PASSENGER AIR BAG”...
Page 39 1-1. For safe use The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 41 1-1. For safe use WARNING  SRS airbag precautions  Vehicles without SRS curtain shield air- bags: Do not lean against the front door.  Vehicles with SRS curtain shield air- bags: Do not lean against the door, the roof side rail or the front, side and rear pillars.
Page 42 1-1. For safe use WARNING  SRS airbag precautions  Vehicles without SRS curtain shield air- bags: Do not attach anything to areas such as a door, windshield glass and side door glass.  Vehicles with SRS curtain shield air- bags: Do not attach anything to areas such as a door, windshield glass, side door glass, front or rear pillar, roof side...
Page 43 Vehicles with SRS curtain shield airbags: If the areas where the SRS air- bags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 44 1-1. For safe use  If the SRS airbags deploy (inflate)  Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag.  A loud noise and white powder will be emitted.  Vehicles without SRS curtain shield airbags: Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats may be hot for several minutes.
Page 45 1-1. For safe use  Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ...
Page 46 1-1. For safe use  Types of collisions that may not deploy the SRS airbags (SRS side airbags and SRS curtain shield airbags [if equipped]) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 47 When to contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional In the following cases, the vehicle will require inspection and/or repair. Con- tact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. ...
Page 48 1-1. For safe use  The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged.  Vehicles with SRS curtain shield air- bags: The portion of the front pillars, rear pillars or roof side rail garnishes (pad- ding) containing the curtain shield air- bags is inside scratched, cracked, or otherwise damaged.
Page 49: Airbag Manual On-Off System49
1-1. For safe use Airbag manual on-off system This system deactivates the front passenger airbag. Only deactivate the airbags when using a child restraint system on the front passenger seat. “PASSENGER AIR BAG” indi- cator  Vehicles without a smart entry &...
Page 50 “PASSENGER AIR BAG” indicator information If any of the following problems occur, it is possible that there is a malfunction in the system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 51 1-1. For safe use WARNING  When installing a child restraint system For safety reasons, always install a child restraint system in a rear seat. In the event that the rear seat cannot be used, the front seat be used as long as the airbag manual on-off system is set to “OFF”.
Page 52: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 53: Child Restraint Systems
 If child restraint system regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installation.  Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44.
Page 54 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44: Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0 : Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II:...
Page 55 Front passenger seat Seating Front passenger seat positions Recommended child Airbag manual on-off switch restraint systems Mass groups “TOYOTA G 0+, BABYSAFE” “TOYOTA G 0+, Up to 10 kg BABYSAFE PLUS” (22 lb.) Never put “TOYOTA G 0+, (0 - 9 months)
Page 56 1-1. For safe use  Rear outer seats Seating positions Recommended child Right-hand Left-hand restraint systems Mass groups “TOYOTA G 0+, BABYSAFE” “TOYOTA G 0+, BABYSAFE PLUS” Up to 10 kg (22 lb.) “TOYOTA G 0+, (0 - 9 months) BABYSAFE PLUS with SEAT BELT FIXATION, BASE PLATFORM”...
Page 57 Center systems Mass groups “TOYOTA G 0+, BABYSAFE” Up to 10 kg (22 lb.) “TOYOTA G 0+, BABYSAFE PLUS” (0 - 9 months) “TOYOTA G 0+, BABYSAFE” Up to 13 kg (28 lb.) “TOYOTA G 0+, BABYSAFE PLUS” (0 - 2 years) 9 to 18 kg (20 to 39 lb.)
Page 58 Right- Left- hand hand ISO/L1 — Carrycot ISO/L2 — — “TOYOTA G 0+, BABYSAFE PLUS with Group 0 ISO/R1 ISO-FIX FIXATION, Up to 10 kg BASE PLATFORM” (22 lb.) — “TOYOTA G 0+, BABYSAFE PLUS with ISO/R1...
Page 59 1-1. For safe use (1) For the CRS which do not carry the ISO/XX size class identifica- tion (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraint systems of uni- versal category approved for the use in this mass group.
Page 60  Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 61 1-1. For safe use WARNING  Child restraint precautions  Never use a rear-facing child restraint system on the front passenger seat when the airbag manual on-off switch is on. (P. 49) In the event of an accident, the force of the rapid inflation of the front pas- senger airbag can cause death or serious injury to the child.
Page 62 1-1. For safe use WARNING  When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 63: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts (An ELR belt requires a locking clip) ISOFIX rigid anchors (ISOFIX child restraint system) (vehicles...
Page 64 1-1. For safe use Installing child restraints using a seat belt Rear-facing  Baby seat/child seat  Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 65 1-1. For safe use Forward-facing  Child seat  Remove the head restraint. (P. 144) Place the child restraint sys- tem on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 66 1-1. For safe use  Junior seat Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 67 1-1. For safe use Installation with ISOFIX rigid anchors (ISOFIX child restraint sys- tem) (vehicles with rear seats) Remove the head restraint. (P. 144) Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the anchors. If the child restraint has a top strap, the top strap should be latched onto the anchor bracket.
Page 68 Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from any authorized Toyota dealer or repairer, or another duly qualified and equipped professional: Locking clip for child restraint system (Part No.
Page 69 1-1. For safe use WARNING  When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of a sudden braking, sudden swerving or an accident.
Page 70 1-1. For safe use WARNING  When installing a child restraint system  Never use a rear-facing child restraint system on the front passenger seat when the airbag manual on-off switch is on. (P. 49) The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 71 When installing a child restraint system  If child restraint system regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installa- tion.
Page 72 1-1. For safe use WARNING  When installing a child restraint system  When using the rear right seat for the child restraint system, do not sit in the rear center seat. Seat belt function may be impaired, such as being positioned overly high or loose-fitting, which may result in death or serious injury in the event of sudden braking or an accident.
Page 73: Exhaust Gas Precautions
If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible.
Page 74: Theft Deterrent System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 75 1-2. Theft deterrent system  Certifications for the engine immobilizer system (vehicles with a smart entry & start system)
Page 76 1-2. Theft deterrent system...
Page 77 1-2. Theft deterrent system  Certifications for the engine immobilizer system (vehicles without a smart entry & start system) The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/...
Page 78 1-2. Theft deterrent system NOTICE  To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 79: Double Locking System
1-2. Theft deterrent system  Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this system have labels on the window glass of both front doors.
Page 80 1-2. Theft deterrent system Canceling the double locking system Using the entry function (vehicles with a smart entry & start system): Hold either front outside door handle or push up the back door opener switch. Using the wireless remote control: Press WARNING ...
Page 81: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......82 Gauges and meters .....88 Multi-information display ..90 Fuel consumption information......96...
Page 82: Instrument Cluster Warning Lights And Indica- Tors
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 83 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Cruise control indicator light (P. 405) light (P. 407) (Yellow) Speed limiter indicator Charging system warn- (P. 407) ing light (P. 405) (Yellow) 1, 2, 5 Low engine oil pressure...
Page 84 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 85 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator “SPORT” indicator (P. 200) (P. 192) 1, 7 Headlight high beam Gear Shift Indicator indicator (P. 203) (P. 198) Tail light indicator Cruise control indicator (P.
Page 86 There may be a mal- function in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 87 Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately if this occurs.
Page 88: Gauges And Meters
2. Instrument cluster Gauges and meters Tachometer (if equipped) Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge (if equipped) Displays the quantity of fuel remaining in the tank. Display change button P. 91 Multi-information display Presents the driver with a variety of driving-related data.
Page 89 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights (when the headlight switch is on) can be adjusted. Display the instrument panel light control by pressing the display change button. (P. 91) Then, press and hold the button. Adjust the brightness to the desired level by pressing the but- ton.
Page 90: Multi-Information Display
2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data including the clock. Display contents  Type A  Type B Type C  Clock (P. 93) Outside temperature display (P. 94) Shift position and gear step position indicator (P. 191) Drive information (P.
Page 91 2. Instrument cluster Changing the display Items displayed can be switched by pressing the display change button. Drive information  Odometer Displays the total distance the vehicle has been driven.  Trip meter Displays the distance the vehicle has been driven since the meter was last reset.
Page 92 2. Instrument cluster  Average fuel consumption Displays the average rate of fuel consumption. • The function can be reset by pressing the button for longer than 1 sec- ond when the average fuel consumption is displayed. • Use the displayed average fuel consumption as a reference. ...
Page 93 2. Instrument cluster Eco Driving Indicator Light customization (if equipped) Eco Driving Indicator Light can be activated or deactivated by press- ing the display change button when the Eco Driving Indicator Light customization display is displayed. To change the Eco Driving Indicator Light customization display, display the odometer and press and hold the display change button until the display changes.
Page 94  When “” or “E” is displayed The system may be malfunctioning. Take your vehicle to any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional.  When disconnecting and reconnecting battery terminals The following information data will be reset: ...
Page 95 2. Instrument cluster WARNING  Cautions during setting up the display As the engine needs to be running during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 96: Fuel Consumption Information
2. Instrument cluster  Fuel consumption information Fuel consumption information can be displayed on the naviga- tion/multimedia system. Navigation/multimedia system Trip information (navigation/multimedia system) Press the button on the navigation/multimedia system.  : If equipped...
Page 97 2. Instrument cluster Select “Trip information”. Average vehicle speed since the engine was started. Cruising range (P. 99) Fuel consumption in the past 15 minutes Elapsed time since engine was started. Resetting the consumption data Vehicles without a smart entry & start system: Average fuel consumption for the past 15 minutes is divided by color into past averages and averages attained since the engine switch was last turned to the “ON”...
Page 98 2. Instrument cluster Past record (navigation/multimedia system) Press the button on the navigation/multimedia system. Select “Past record”. Best recorded fuel consump- tion Previous fuel consumption record Average fuel consumption Updating the average fuel consumption data Resetting the past record data The average fuel consumption history is divided by color into past averages and the average fuel consumption since the last updated.
Page 99 2. Instrument cluster  Updating the past record data Update the average fuel consumption by selecting “Update” to measure the current fuel consumption again.  Resetting the data The fuel consumption data can be deleted by selecting “Clear”.  Cruising range Displays the estimated maximum distance that can be driven with the quan- tity of fuel remaining.
Page 100 2. Instrument cluster...
Page 101: Operation Of Each Compo- Nent
Operation of each component 3-1. Key information Keys........102 3-2. Opening, closing and locking the doors Side doors......114 Back door......121 Smart entry & start system .....127 3-3. Adjusting the seats Front seats......138 Rear seats ......141 Head restraints ....144 3-4. Adjusting the steering wheel and mirrors Steering wheel ....146 Inside rear view mirror ..148...
Page 102: Key Information
3-1. Key information Keys The keys The following keys are provided with the vehicle.  Vehicles without a smart entry & start system (type A) Keys Key number plate  Vehicles without a smart entry & start system (type B) Key (with a wireless remote control function) Operating the wireless remote con-...
Page 103 3-1. Key information  Vehicles with a smart entry & start system Electronic keys • Operating the smart entry & start system (P. 127) • Operating the wireless remote control function (P. 115) Mechanical keys Key number plate Wireless remote control Vehicles without a smart entry &...
Page 104  If you lose your keys New genuine keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional using the other key and the key number stamped on your key number plate. Keep the plate in a safe...
Page 105 3-1. Key information  When riding in an aircraft When bringing a key with wireless remote control function onto an aircraft, make sure you do not press any buttons on the key while inside the aircraft cabin. If you are carrying a key in your bag etc., ensure that the buttons are not likely to be pressed accidentally.
Page 106 Confirmation of the registered key number (vehicles with a smart entry & start system) The number of keys already registered to the vehicle can be confirmed. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for details. ...
Page 107 3-1. Key information  Certification for the wireless remote control (vehicles without a smart entry & start system)
Page 108 3-1. Key information...
Page 109 3-1. Key information...
Page 110 3-1. Key information...
Page 111 3-1. Key information...
Page 112 3-1. Key information...
Page 113 If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional immediately with all remaining electronic keys that were provided with your vehicle.
Page 114: The Doors
3-2. Opening, closing and locking the doors Side doors Unlocking and locking the doors from the outside The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switches.  Entry function (vehicles with a smart entry & start system) Carry the electronic key to enable this function.
Page 115 3-2. Opening, closing and locking the doors  Wireless remote control (if equipped)  Vehicles without a smart entry & start system Locks all the doors Unlocks all the doors  Vehicles with a smart entry & start system Locks all the doors Unlocks all the doors...
Page 116 3-2. Opening, closing and locking the doors  Keys (vehicles without a smart entry & start system) Turning the key operates the doors as follows:  Driver’s door Locks all the doors Unlocks all the doors  Front passenger’s door (vehicles with a key cylinder) Locks the door Unlocks the door ...
Page 117 3-2. Opening, closing and locking the doors  Security feature  Vehicles without a smart entry & start system If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. ...
Page 118 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside  Door lock switch Unlocks all the doors Locks all the doors  Inside door lock buttons Locks the doors Unlocks the doors The front doors can be opened by pulling the inside handle even if the inside door lock but- ton is in the lock position.
Page 119 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside door lock button to the lock position. Close the door while pulling the door handle.  Vehicles without a smart entry & start system The door cannot be locked if the key is in the engine switch.
Page 120 3-2. Opening, closing and locking the doors  Impact detection door lock release system In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 121: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the fol- lowing procedures. Unlocking and locking the back door  Door lock switch P. 118  Entry function (vehicles with a smart entry & start system) Carry the electronic key to enable this function.
Page 122 3-2. Opening, closing and locking the doors  Keys From the back door (vehicles with a back door key cylinder): Unlocks all the doors Locks all the doors From the driver’s door: P. 116 Opening the back door from the outside the vehicle (vehicles with a smart entry &...
Page 123 3-2. Opening, closing and locking the doors  Operation signals (vehicles with an entry function or wireless remote control) P. 116  Security feature P. 117  Door lock buzzer (vehicles with a smart entry & start system) P. 117 ...
Page 124 3-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury.  Before driving  Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
Page 125 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended.
Page 126 Do not touch the damper stay rod with gloves or other fabric items.  Do not attach any accessories other than genuine Toyota parts to the back door.  Do not place your hand on the damper stay or apply lateral forces to it.
Page 127: Smart Entry & Start System
3-2. Opening, closing and locking the doors  Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ...
Page 128 3-2. Opening, closing and locking the doors  Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) either of the outside front door handles and back door.
Page 129 3-2. Opening, closing and locking the doors Alarm Situation/Actions An attempt was made to lock the doors other Interior alarm pings than using the smart entry & start system while once and exterior alarm the electronic key was still inside the vehicle. sounds once for 5 sec- Retrieve the electronic key from the vehicle onds (on some models)
Page 130 3-2. Opening, closing and locking the doors  Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situa- tions, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote control and engine immobilizer system from operating properly.
Page 131 3-2. Opening, closing and locking the doors  Notes for the entry function  Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 132 3-2. Opening, closing and locking the doors  Notes for the unlocking function  A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the origi- nal position and check that the doors unlock before pulling the door handle again.
Page 133 3-2. Opening, closing and locking the doors  Certification for the smart entry & start system The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/...
Page 134 3-2. Opening, closing and locking the doors...
Page 135 3-2. Opening, closing and locking the doors...
Page 136 3-2. Opening, closing and locking the doors...
Page 137 (P. 127) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 138: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (if equipped) Seatback lock release lever (3-door models only)
Page 139 3-3. Adjusting the seats Moving front passenger’s seat for rear seat entry (3-door models only)  Getting in the vehicle For easy access to the rear seat, use the seatback lock release lever. When the seatback lock release lever is used, the seat’s orig- inal slide position is memorized, so the seat may be returned to that original position.
Page 140 3-3. Adjusting the seats  After passengers have entered the vehicle (3-door models only) Slide the seat backward and then lift the seatback. The seat will be set and locked to its previous position automatically. If the seat cannot be slid back to the previous position due to the rear passenger or luggage, the seat will be locked in that position, disabling the seat position memory system.
Page 141: Rear Seats
3-3. Adjusting the seats  Rear seats The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks Stow the rear seat belt buckles as shown. Stow the seat belts. Center: P. 32 Outside: Use the seat belt hangers to prevent the belts from being tangled.
Page 142 3-3. Adjusting the seats Pull the seatback lock release knob and fold the seatback down. Each seatback may be folded sep- arately. WARNING  When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury.
Page 143 3-3. Adjusting the seats WARNING  After returning the rear seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury.  Make sure that the seatback is securely locked in position by lightly pushing it back and forth.
Page 144: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Adjusting the head restraints Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button  Removing the front seats and rear center seat head restraints Pull the head restraint up while pressing the lock release button.
Page 145 3-3. Adjusting the seats Pull the head restraint up while pushing the lock release button. Lock release button  Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 146: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 147 3-4. Adjusting the steering wheel and mirrors WARNING  Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ...
Page 148: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror (vehicles with an auto anti-glare inside rear view mirror) The height of the rear view mirror can be adjusted to suit your driving posture.
Page 149 3-4. Adjusting the steering wheel and mirrors Anti-glare function  Vehicles with a manual anti-glare inside rear view mirror Reflected light from the headlights of vehicles behind can be reduced by operating the lever. Normal position Anti-glare position  Vehicles with an auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced.
Page 150 3-4. Adjusting the steering wheel and mirrors  To prevent sensor error (vehicles with an auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. WARNING  Caution while driving Do not adjust the position of the mirror while driving.
Page 151: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure Manually-adjustable type  Adjust the mirror up, down, in or out by pushing the mirror surface. Power-adjustable type  To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the...
Page 152 3-4. Adjusting the steering wheel and mirrors Folding the mirrors  Manual type Push the mirror back in the direc- tion of the vehicle’s rear.  Power type Press the button to fold back the mirrors Push once more to return to the original position.
Page 153 3-4. Adjusting the steering wheel and mirrors WARNING  Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ...
Page 154: Power Windows
3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (driver’s win- dow only) Opening One-touch opening (driver’s window only) : To stop the window partway, oper-...
Page 155 3-5. Opening and closing the windows  The power windows can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 156 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 157 3-5. Opening and closing the windows WARNING Observe the following precautions. Failure to do so may result in death or serious injury.  Closing the windows  The driver is responsible for all the power window operations, including the operation for the passengers. In order to prevent accidental operation, especially by a child, do not let a child operate the power windows.
Page 158 3-5. Opening and closing the windows...
Page 159: Driving
Driving 4-1. Before driving 4-4. Refueling Driving the vehicle .....160 Opening the fuel tank cap........216 Cargo and luggage ....171 4-5. Using the driving support Trailer towing .....173 systems 4-2. Driving procedures Cruise control.....220 Engine (ignition) switch Speed limiter......224 (vehicles without a smart entry &...
Page 160: Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 182, 185 Driving  Vehicles with a Multidrive With the brake pedal depressed, shift the shift lever to D. (P. 191) Release the parking brake.
Page 161 4-1. Before driving Stopping  Vehicles with a Multidrive With the shift lever in D, depress the brake pedal. Vehicles with a Stop & Start system: If the Stop & Start system is enabled, depressing the brake pedal will stop the engine. (P. 228) If necessary, set the parking brake.
Page 162 4-1. Before driving  Vehicles with a manual transmission While depressing the clutch pedal, depress the brake pedal. Set the parking brake. (P. 201) Shift the shift lever to N. (P. 196) If parking on a hill, shift the shift lever to 1 or R and block the wheels as needed.
Page 163 When the accelerator pedal is released  When the brake pedal is depressed while sport mode is selected  Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended:  For the first 300 km (186 miles): Avoid sudden stops.
Page 164 4-1. Before driving  Idling time before stopping the diesel engine To prevent damage to the turbocharger, allow the engine to idle immediately after high-speed driving or driving up a hill. Driving condition Idling time Normal city driving Not necessary Constant speed of approximately Approximately 80 km/h (50 mph)
Page 165 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury.  When starting the vehicle On vehicles with a Multidrive, always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping.
Page 166 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury.  When driving on slippery road surfaces  Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ...
Page 167 WARNING  If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 168 4-1. Before driving WARNING  Do not attach adhesive discs to the windshield or windows. Do not place containers such as air fresheners on the instrument panel or dashboard. Adhesive discs or containers may act as lenses, causing a fire in the vehi- cle.
Page 169 4-1. Before driving NOTICE  When driving the vehicle  Vehicles with a Multidrive  Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output.  Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 170 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have any authorized Toyota dealer or repairer or another duly quali- fied and equipped professional check the following: ...
Page 171: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: WARNING  Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ...
Page 172 4-1. Before driving WARNING  Load and distribution  Do not overload your vehicle.  Do not apply loads unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 173: Trailer Towing
Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Ask your local authorized Toyota dealer or repairer, or another duly qualified and equipped professional, for further details before towing, as there are additional legal requirements in some countries.
Page 174 4-1. Before driving Important points regarding trailer loads  Total trailer weight and permissible drawbar load Total trailer weight Weight of the trailer itself plus the trailer load should be within the maximum towing capacity. Exceeding this weight is dangerous. (P.
Page 175 4-1. Before driving  Information tag (manufacturer’s label) Type A  Gross vehicle mass Maximum permissible rear axle capacity Type B  Gross vehicle mass Maximum permissible rear axle capacity  Gross vehicle mass Vehicle category M1 models  The combined weight of the driver, passengers, luggage, towing hitch, total curb mass and drawbar load should not exceed the gross vehicle mass by more than 100 kg (220.5 lb.).
Page 176 Do not exceed the established speed limit for towing a trailer in built-up areas or 100 km/h (62 mph), whichever is lower. : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 177 468 mm (18.4 in.) 313 mm (12.3 in.) 397 mm (15.6 in.) 26.2 mm (1.0 in.) : Gross vehicle mass and standard tire size To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 178  Break-in schedule Toyota recommends that vehicles fitted with new power train components should not be used for towing trailers for the first 800 km (500 miles).  Safety checks before towing ...
Page 179 4-1. Before driving NOTICE  When the rear bumper strengthening material is aluminum Ensure the steel bracket part does not come directly in contact with that area. When steel and aluminum come into contact, there is a reaction similar to corrosion, which will weaken the section concerned and may result in dam- age.
Page 180 4-1. Before driving  Sudden acceleration/steering input/cornering Executing sharp turns when towing may result in the trailer colliding with your vehicle. Decelerate well in advance when approaching turns and take them slowly and carefully to avoid sudden braking.  Important points regarding turning The wheels of the trailer will travel closer to the inside of the curve than the wheels of the vehicle.
Page 181 4-1. Before driving  If the engine overheats Towing a loaded trailer up a long, steep incline in temperatures exceeding 30C (85F) may result in the engine overheating. If the high engine coolant temperature warning light flashes or comes on, turn the air conditioning off immediately, leave the road and stop the vehicle in a safe place.
Page 182: Engine (Ignition) Switch (Vehicles Without A
4-2. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) Starting the engine  Gasoline engine Check that the parking brake is set. Check that the shift lever is set in P (Multidrive) or N (manual trans- mission).
Page 183 Push in the key and turn it to the “LOCK” position.  If the engine does not start The engine immobilizer system may not have been deactivated. (P. 74) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 184  Do not race a cold engine.  If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
Page 185: Engine (Ignition) Switch (Vehicles With A Smart Entry & Start System)
4-2. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch mode. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P (Multidrive) or N (manual trans- mission).
Page 186 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to P (Multidrive) or N (manual transmission). Set the parking brake. (P. 201) Press the engine switch. Release the brake pedal (Multidrive) or clutch pedal (manual trans- mission) and check that the smart entry &...
Page 187 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P (Multidrive) If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
Page 188 If the engine does not start  The engine immobilizer system may not have been deactivated. (P. 74) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  On vehicles with a Multidrive, check that the shift lever is securely set in P.
Page 189 4-2. Driving procedures  Operation of the engine switch When operating the engine switch, one short, firm press is enough. If the switch is pressed improperly, the engine may not start or the engine switch mode may not change. It is not necessary to press and hold the switch. ...
Page 190 Do not race a cold engine.  If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.  Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 191: Multidrive
4-2. Driving procedures  Multidrive Shifting the shift lever  Vehicles without a smart entry & start system While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 192 4-2. Driving procedures Shift position purpose Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving or temporary gear step selection driving 7-speed sport sequential shiftmatic mode driving (P. 193) : To improve fuel consumption and reduce noises, set the shift lever in the D position for normal driving.
Page 193 4-2. Driving procedures Changing gear steps in 7-speed sport sequential shiftmatic mode Shift the shift lever to the M position and operate the shift lever or pad- dle shift switch. Upshifting Downshifting The gear step changes once every time the shift lever or paddle shift switch is operated.
Page 194 4-2. Driving procedures Temporally gear steps selection mode in the D position To drive in temporary gear steps selection mode, operate the “-” and “+” paddle shift switch. The gear steps can then be selected by oper- ating the “-” and “+” paddle shift switches. By selecting gear step using paddle shift switches, you can control engine braking forces.
Page 195 M This may indicate a malfunction in the Multidrive system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 196: Manual Transmission
4-2. Driving procedures  Manual transmission Shifting the shift lever 5-speed transmission  Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 197 4-2. Driving procedures  6-speed transmission Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Shifting the shift lever to R (6-speed transmission) Shift the shift lever to R while lift- ing up the ring section.
Page 198 4-2. Driving procedures Gear Shift Indicator The Gear Shift Indicator is a guide to help the driver achieve improved fuel economy and reduced exhaust emissions within limits of engine performance. Upshifting Downshifting  Gear Shift Indicator display The Gear Shift Indicator may not be displayed when your foot is placed on the clutch pedal.
Page 199 4-2. Driving procedures WARNING  Gear Shift Indicator display For safety, the driver should not look only at the display. Refer to the display when it is safe to do so while considering actual traffic and road conditions. Failure to do so may lead to an accident. NOTICE ...
Page 200: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operation instructions Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever. Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.
Page 201: Parking Brake
4-2. Driving procedures Parking brake Operation instructions To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. To release the parking brake, slightly raise the lever and lower it completely while press- ing the button. ...
Page 202: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operation instructions Turning the end of the lever turns on the lights as follows: The front position, tail, license plate and instru- ment panel lights turn on. The headlights and all the lights listed above turn on.
Page 203 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 204 4-3. Operating the lights and wipers Manual headlight leveling dial The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle.  Left-hand drive vehicles  Right-hand drive vehicles Raises the level of the head- Raises the level of the head- lights lights...
Page 205 Control switch position Driver only Driver + full luggage loading to the lug- gage room : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Daytime running light system...
Page 206 4-3. Operating the lights and wipers  Automatic light off system (if equipped)  Vehicles without a smart entry & start system  When the light switch is in : The headlights and front fog lights turn off automatically when the engine switch is turned to the “LOCK” position.
Page 207 4-3. Operating the lights and wipers  Battery-saving function In all conditions following below, the headlights and the other remaining lights will go off automatically after 20 minutes in order to prevent the vehicle bat- tery from being discharged:  The headlights and/or tail lights are on.
Page 208: Fog Light Switch
4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Operation instructions  Rear fog light switch Turns the rear fog lights off Turns the rear fog lights on Releasing the switch ring returns it to Operating the switch ring...
Page 209 4-3. Operating the lights and wipers  Front and rear fog light switch (if equipped) Turns the front and rear fog lights off Turns the front fog lights Turns both front and rear fog lights on Releasing the switch ring returns it to Operating the switch ring again turns only the rear fog...
Page 210: Windshield Wiper And Washer
4-3. Operating the lights and wipers Windshield wiper and washer Operating the wiper lever Operate the lever as follows to operate the wiper.  Intermittent windshield wiper Intermittent windshield wiper operation speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer/wiper dual operation The wiper will automatically oper-...
Page 211 4-3. Operating the lights and wipers  Rain-sensing windshield wiper When is selected, the wiper will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. When is selected, the sensor sensitivity can be adjusted as fol- lows by turning the switch ring: Rain-sensing windshield...
Page 212 4-3. Operating the lights and wipers Washer/wiper dual operation The wiper will automatically operate a couple of times after the washer squirts. (After operating several times, the wiper operate one more time after a short delay to pre- vent dripping.) ...
Page 213  When a nozzle becomes blocked In this case, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 214: Rear Window Wiper And Washer
4-3. Operating the lights and wipers  Rear window wiper and washer Operation instructions Turning the end of the lever turns on the rear window wiper and washer. Intermittent window wiper operation Normal window wiper operation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The wiper will automatically...
Page 215  When a nozzle becomes blocked In this case, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 216: Refueling
“B30” or “B100” and fuel containing a large amount of FAME should not be used. The use of these fuels will damage the vehicle’s fuel system. In case of any doubt, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 217 4-4. Refueling WARNING  When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury.  After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 218: Opening The Fuel Tank
4-4. Refueling NOTICE  Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally, damage fuel system components, or the vehicle’s painted surface. Opening the fuel tank cap Pull up the opener to open the fuel filler door.
Page 219 WARNING  When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 220: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator (green) will come on.
Page 221 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 222 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 223 4-5. Using the driving support systems WARNING  To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use.  Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 224: Speed Limiter
4-5. Using the driving support systems  Speed limiter  Summary of function The desired maximum speed can be set using the cruise control switch. The speed limiter prevents vehicle speed from exceeding the set speed. Display Indicator (green) Speed limiter switch Setting the vehicle speed Press the speed limiter switch to activate the speed limiter.
Page 225 4-5. Using the driving support systems Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set the speed. The vehicle speed at the moment the lever is released becomes the set speed. Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained.
Page 226 4-5. Using the driving support systems Canceling and resuming the speed limiter Pulling the lever toward you cancels the speed limiter. Pushing the lever up resumes the speed limiter.  Speed limiter can be set when The speed limiter can be set at any vehicle speed. However, if the speed lim- iter is set while the vehicle speed is below 30 km/h (18 mph), the speed lim- iter will be set to 30 km/h (18 mph).
Page 227 4-5. Using the driving support systems WARNING  To avoid operating the speed limiter by mistake Switch the speed limiter off using the speed limiter switch when not in use.  Situations unsuitable for the speed limiter Do not use the speed limiter in either of the following situations. Doing so may result in loss of control and could cause a serious or fatal accident.
Page 228: Stop & Start System
4-5. Using the driving support systems  Stop & start system The stop & start system stops and restarts the engine according to the brake pedal and shift lever operation (Multidrive) or clutch pedal operation (manual transmission) for stopping and starting the vehicle.
Page 229 4-5. Using the driving support systems Restarting the engine  Vehicles with a Multidrive Release the brake pedal. When the shift lever is in N or P, depress brake pedal and shift the shift lever to D or M. The engine will restart. The Stop & Start indicator will go off. ...
Page 230 4-5. Using the driving support systems  If the Stop & Start cancel switch is pressed while the vehicle is stopped  When the engine is stopped by the Stop & Start system, pressing the Stop & Start cancel switch will restart the engine. From the next time the vehicle is stopped (after Stop &...
Page 231 4-5. Using the driving support systems • The driver’s seat belt is unfastened. • The driver’s door is opened. • The hood is opened. • The vehicle is stopped on a steep hill. • The brake booster vacuum is low. •...
Page 232 4-5. Using the driving support systems  The Stop & Start system protection feature  Vehicles without a smart entry & start system When an excessively loud sound is being projected by the audio system, the audio system may be automatically cut off in order to maintain power for the Stop &...
Page 233 The installed battery is specific to the Stop & Start system. It should only be replaced with a battery of identical type and rating. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details.
Page 234 If any one of the following situations occurs, the Stop & Start system may not operate correctly, thus, please have your vehicle checked by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 235: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 236 4-5. Using the driving support systems When the TRC/VSC systems are operating The slip indicator light will flash while the TRC/VSC systems are operating. Disabling the TRC systems If the vehicle gets stuck in mud, dirt or snow, the TRC system may reduce power from the engine to the wheels.
Page 237  When the “TRC OFF” indicator light comes on even if the VSC OFF switch has not been pressed TRC cannot be operated. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Sounds and vibrations caused by the ABS, brake assist, TRC and VSC systems ...
Page 238 4-5. Using the driving support systems  Operating conditions of emergency brake signal When the following three conditions are met, the emergency brake signal will operate:  The emergency flashers are off.  Actual vehicle speed is over 55 km/h (35 mph). ...
Page 239 The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further information when replacing tires or wheels.
Page 240: Diesel Particulate Filter System
4-5. Using the driving support systems  Diesel particulate filter system When the deposit collected by the filter reaches a predetermined amount, it is automatically cleaned. Cleaning the DPF catalytic converter Cleaning the DPF catalytic converter is performed as necessary in accordance with driving conditions.
Page 241 4-5. Using the driving support systems WARNING  Exhaust pipe Do not touch the exhaust pipe during cleaning, as the exhaust pipe and exhaust gases will become particularly hot. Also, make sure that there are no people or flammable materials near the exhaust pipe while the vehicle is stopped.
Page 242: Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter  Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 243 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and move the shift lever to P (Multidrive) 1 or R (man- ual transmission) without setting the parking brake.
Page 244 4-6. Driving tips  Tire chain installation Observe the following precautions when installing and removing chains:  Install and remove tire chains in a safe location.  Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 245: Audio System
Audio system 5-1. Basic Operations Audio system types....246 Steering wheel audio switches......248 USB port ......249 5-2. Using the audio system Optimal use of the audio system ......250 5-3. Using the radio Radio operation ....252 5-4. Playing audio CDs and MP3/WMA discs CD player operation...257 5-5.
Page 246: Audio System Types
5-1. Basic Operations  Audio system types  Vehicles with a Navigation/Multimedia system Owners of models equipped with a Navigation/Multimedia system should refer to the “Navigation and multimedia system Owner’s Man- ual”.  : If equipped...
Page 247 5-1. Basic Operations  Vehicles without a Navigation/Multimedia system CD player and AM/FM radio The illustration below is for left-hand drive vehicles. Some button posi- tions are reversed for right-hand drive vehicles.  Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 248: Steering Wheel Audio Switches
5-1. Basic Operations  Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 249: Usb Port
5-1. Basic Operations  USB port Connect an iPod, USB memory device or portable audio player to the USB port as indicated below. Press to select “iPod” or “USB”. Connecting using the USB port  iPod Open the cover and connect an iPod using an iPod cable.
Page 250: Using The Audio System
5-2. Using the audio system  Optimal use of the audio system Sound quality (treble/bass) and volume balance can be adjusted. Displays the current mode Changes the following set- ting • Sound quality and volume balance (P. 251) The sound quality and balance setting can be changed to pro- duce the best sound.
Page 251 5-2. Using the audio system  Adjusting sound quality Turning adjusts the level. Sound Mode Turn to the Turn to the Level quality mode displayed left right Bass “BASS” -5 to 5 High Treble “TREBLE” -5 to 5 Front/rear volume “FADER”...
Page 252: Using The Radio
5-3. Using the radio  Radio operation Select “AM” or “FM” to begin listening to the radio. Power Back button Volume AM/FM mode button Station selector Displays station list AF/region code/ Seeking the frequency TA mode setup Adjusting the frequency or selecting items ...
Page 253 5-3. Using the radio Setting station presets Search for a desired station by turning or pressing “” or “” Press and hold the button (from [1] to [6]) the station is to be set to until you hear a beep. Using the station list ...
Page 254 5-3. Using the radio RDS (Radio Data System) This feature allows your radio to receive station.  Listening to stations of the same network Press Turn to “RADIO” and press Turn as corresponds to the desired mode: “FM AF” or “Region code”.
Page 255 5-3. Using the radio  Traffic information Press Turn to “RADIO” and press Turn to “FM TA” mode. Press to select “ON” or “OFF”. TP mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received.
Page 256 5-3. Using the radio  EON (Enhanced Other Network) system (for traffic announcement func- tion) If the RDS station (with EON data) you are listening to is not broadcasting a traffic information program and the audio system is in the TA (traffic announcement) mode, the radio will be switched automatically to a station broadcasting a traffic information program in the EON AF list when traffic information begins.
Page 257: Cd Player Operation
5-4. Playing audio CDs and MP3/WMA discs  CD player operation Insert a disc or press to beginning to a disc. Power Selecting a folder Volume Back button Disc eject Playback Repeat play Displays track/folder list Random playback Selecting a track, fast-forward- ing or reversing Selecting a track/file or dis- plays text message...
Page 258 5-4. Playing audio CDs and MP3/WMA discs Ejecting CDs or MP3 and WMA discs Press and remove the disc. Using the CD player  Selecting a track Turn or press “” to move up or “” to move down using until the desired track number is displayed.
Page 259 5-4. Playing audio CDs and MP3/WMA discs Playing back MP3 and WMA discs  Selecting a folders one at a time Press “” or “” on to select the desired folder.  Selecting a folder and file from folder list Press The folder list will be displayed.
Page 260 If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Message...
Page 261 5-4. Playing audio CDs and MP3/WMA discs  Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used.
Page 262 5-4. Playing audio CDs and MP3/WMA discs  WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
Page 263 5-4. Playing audio CDs and MP3/WMA discs  ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 264 5-4. Playing audio CDs and MP3/WMA discs WARNING  Certification for the CD player This product is a class I laser product.  Do not open the cover of the player or attempt to repair the unit yourself. Refer servicing to qualified personnel. ...
Page 265 5-4. Playing audio CDs and MP3/WMA discs NOTICE  Discs and adapters that cannot be used Do not use the following types of discs. Also, do not use 8 cm (3 in.) disc adapters, Dual Discs or printable discs. Doing so may damage the player and/or the disc insert/eject function. ...
Page 266: Using An External Device
5-5. Using an external device  Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Press until “iPod” is displayed. Connecting an iPod P. 249 Control panel Power Selecting an iPod menu/song or displays text message Volume Back button iPod menu mode...
Page 267 5-5. Using an external device Selecting a play mode Press (MENU) to select iPod menu mode. Turning clockwise changes the play mode in the following order: “Playlists”  “Artists” “Albums” “Songs” “Podcasts”  “Genres” “Composers” “Audiobooks” Press to select the desired play mode. ...
Page 268 5-5. Using an external device  Selecting a list Turn to display the first selection list. Press to select the desired item. Pressing the knob changes to the second selection list. Repeat the same procedure to select the desired item. To return to the previous selection list, press Selecting songs Turn...
Page 269 5-5. Using an external device Shuffle playback Pressing (RDM) changes modes in the following order: Track shuffle  Album shuffle  Off. Switching the display Press Track title, Artist name and Album title are shown on the display. To return to the previous display, press Adjusting sound quality and volume balance Press to enter iPod menu mode.
Page 270 If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Message...
Page 271 5-5. Using an external device  Compatible models Model Generation Software version iPod 5th generation Ver. 1.3.0 or higher 1st generation Ver. 1.3.1 or higher 2nd generation Ver. 1.1.3 or higher iPod nano 3rd generation Ver. 1.1.3 or higher 4th generation Ver.
Page 272 5-5. Using an external device WARNING  Caution while driving Do not connect iPod or operate the controls. NOTICE  To prevent damage to iPod  Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod. ...
Page 273: Listening To A Usb Memory Device
5-5. Using an external device  Listening to a USB memory device Connecting a USB memory device enables you to enjoy music from the vehicle speakers. Press until “USB” is dis- played. Connecting a USB memory P. 249 Control panel Power Selecting a folder Volume...
Page 274 5-5. Using an external device Selecting a folder  Selecting a folders one at a time Press “” or “” on to select the desired folder.  Selecting a folder and file from folder list Press The folder list will be displayed. Turn and press to select a folder and a file.
Page 275 If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Message...
Page 276 5-5. Using an external device  USB memory  Compatible devices USB memory that can be used for MP3 and WMA playback  Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12 Mbps) •...
Page 277 5-5. Using an external device  WMA file compatibility • Compatible standards WMA Ver. 9 • Compatible sampling frequencies HIGH PROFILE 32, 44.1, 48 (kHz) • Compatible bit rates HIGH PROFILE 32-320 (kbps, VBR)  File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma.
Page 278 5-5. Using an external device  Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of playback may result.
Page 279: Using The Air Conditioning Sys
Interior features 6-1. Using the air conditioning 6-3. Using the storage features system and defogger List of storage features ..301 Manual air conditioning • Glove box ......302 system ......280 • Cup holders ....303 • Bottle holders ....304 Automatic air conditioning •...
Page 280: Manual Air Conditioning Sys
6-1. Using the air conditioning system and defogger  Manual air conditioning system The illustration below is for left-hand drive vehicles. Some dial and button positions are reversed for right-hand drive vehicles. Air conditioning controls Air outlet selector dial Fan speed control dial Outside/recirculated air mode Cooling and dehumidification dial...
Page 281 6-1. Using the air conditioning system and defogger  Adjusting the temperature setting Vehicles without the button  Turn the temperature control dial clockwise to increase the tem- perature.  Vehicles with the button To adjust the temperature setting, turn the temperature control dial clockwise (warm) or counterclockwise (cool).
Page 282 6-1. Using the air conditioning system and defogger  Other functions  Switching between outside air and recirculated air modes (P. 282)  Defogging the windshield (P. 282)  Defogging the rear window and outside rear view mirrors (P. 283) Other functions ...
Page 283 6-1. Using the air conditioning system and defogger  Defogging the rear window and outside rear view mirrors Vehicles with a rear window defogger  Defoggers are used to defog the rear window. Press The defoggers will automatically turn off after a period of time. ...
Page 284 6-1. Using the air conditioning system and defogger  Front side outlets Direct air flow to the left or right, up or down. Open the vent. Close the vent.  Fogging up of the windows  Vehicles with the button: The windows will easily fog up when the humidity in the vehicle is high.
Page 285 Turn the air conditioning system off and have it inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 286 6-1. Using the air conditioning system and defogger WARNING  To prevent the windshield from fogging up Do not set the air outlet selector dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 287: Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger  Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls  : If equipped...
Page 288 6-1. Using the air conditioning system and defogger Cooling and dehumidification Windshield defogger button function on/off button Rear window defogger switch/ Left-hand side temperature rear window defogger and out- control dial side rear view mirror defog- gers switch (if equipped) Left-hand side temperature display Air outlet selector button...
Page 289 6-1. Using the air conditioning system and defogger  Fan speed setting Press “” on to increase the fan speed. Press “” on to decrease the fan speed. Press to turn the fan off.  Change the airflow mode To change the air outlets, press outlets used switched each time the button is...
Page 290 6-1. Using the air conditioning system and defogger Using automatic mode Press Air outlets and fan speed are automatically adjusted according to the temperature setting. Adjust the temperature setting. To stop the operation, press Air outlets  Location of air outlets The air outlets and air volume changes according...
Page 291 6-1. Using the air conditioning system and defogger  Defogging the windshield Defoggers are used to defog the windshield and front side win- dows. Press The dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to outside mode if recircu- lated air mode is used.
Page 292 6-1. Using the air conditioning system and defogger  Adjusting the position, opening and closing the air outlets Front center outlets  Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Front side outlets ...
Page 293 There may be a problem in the air conditioning system if the indicator light goes off again. Turn the air conditioning system off and have it inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 294 6-1. Using the air conditioning system and defogger  Ventilation and air conditioning odors  To let fresh air in, set the air conditioning system to the outside air mode.  During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 295: Power Heater
6-1. Using the air conditioning system and defogger  Power heater This feature is used to keep the cabin warm in cold conditions. Power heater Turns the power heater on/off The power heater turns on about 25 seconds after the switch is pressed, and takes about another 85 seconds to warm up.
Page 296  Do not modify or open the heater without consulting any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, as this may cause a heater malfunction or a fire.
Page 297: Seat Heaters
6-1. Using the air conditioning system and defogger  Seat heaters Operating instructions Turns on the front left seat heater Turns on the front right seat heater The indicator light comes on.  The seat heaters can be used when Vehicles without a smart entry &...
Page 298 6-1. Using the air conditioning system and defogger WARNING  Burns  Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 299: Using The Interior Lights
6-2. Using the interior lights Interior lights list Interior light (P. 299) Personal lights (P. 300) Footwell lights (if equipped) Engine switch light (vehicles with a smart entry & start system) Interior light Door position...
Page 300: Personal Lights
6-2. Using the interior lights Personal lights  Illuminated entry system  Vehicles without a smart entry & start system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are opened/ closed.
Page 301: Using The Storage Features
6-3. Using the storage features List of storage features Glove box (P. 302) Bottle holders (P. 304) Cup holders (P. 303) Auxiliary box (P. 305) WARNING  Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may result in the following when cabin temperature becomes high: ...
Page 302: Glove Box
6-3. Using the storage features Glove box Pull up the lever to open the glove box.  Using the glove box vent (if equipped) Air from the air conditioning system can be distributed into the glove box by open- ing and closing the vent. Open Close The air is conditioned the same as the air...
Page 303: Cup Holders
6-3. Using the storage features Cup holders  Front  Rear WARNING  Items unsuitable for the cup holders  Do not place anything other than cups or aluminum cans in the cup hold- ers. Other items may be thrown out of the holders in the event of an acci- dent or sudden braking, causing injury.
Page 304: Bottle Holders
6-3. Using the storage features Bottle holders  When using the bottle holders  When storing a bottle, close the cap.  The bottle may not be stored depending on its size or shape. WARNING  Items unsuitable for the bottle holders Do not place anything other than a bottle in the bottle holders.
Page 305: Auxiliary Box
6-3. Using the storage features Auxiliary box  Type A  Type B Open the cover. Type C  WARNING  Caution while driving (Type B) Keep the auxiliary boxes closed. In the event of sudden braking, an acci- dent may occur due to an occupant being struck by an open auxiliary box or the items stored inside.
Page 306: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Luggage cover (if equipped) The luggage cover can be removed by the following procedure: Unhook the cords and return the luggage cover to horizontal position. Lift the luggage cover and pull it toward you to remove it.
Page 307 6-3. Using the storage features Deck board (if equipped)  Deck board height adjustment Upper position Lower position The lower position can be used when the deck board is placed on the luggage floor cover.  Removing the deck board Lift the deck board and pull it toward you to remove it.
Page 308 6-3. Using the storage features Auxiliary box (if equipped) Lift the deck board and the lug- gage floor cover.
Page 309: Other Interior Features
6-4. Other interior features Other interior feature Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirrors Open the cover.
Page 310: Portable Ashtray
6-4. Other interior features  Vanity lights can be used when  Vehicles without a smart entry & start system The engine switch is in the “ACC” or “ON” position.  Vehicles with a smart entry & start system The engine switch is ACCESSORY or IGNITION ON mode. NOTICE ...
Page 311: Cigarette Lighter
6-4. Other interior features Cigarette lighter (if equipped) Push the cigarette lighter. The cigarette lighter will pop up when it is ready for use.  The cigarette lighter can be used when  Vehicles without a smart entry & start system The engine switch is in the “ACC”...
Page 312: Power Outlet
6-4. Other interior features Power outlet (if equipped) Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). Open the lid.  The power outlets can be used when ...
Page 313: Armrest
6-4. Other interior features Armrest (if equipped) Fold down the armrest for use. NOTICE  To prevent damage to the armrest Do not apply too much load on the armrest. Panoramic roof shade (if equipped) The panoramic roof shade can be opened and closed manually. ...
Page 314: Assist Grips
6-4. Other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING  Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 315 Maintenance and care 7-1. Maintenance and care 7-3. Do-it-yourself maintenance Cleaning and protecting Do-it-yourself service the vehicle exterior ..316 precautions ......325 Cleaning and protecting Hood ........328 the vehicle interior ...319 Positioning a floor jack..330 7-2. Maintenance Engine compartment..332 Maintenance Tires........347 requirements....322 Tire inflation pressure ..360 Wheels.......362...
Page 316: Vehicle Exterior
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition:  Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 317: Maintenance And Care
7-1. Maintenance and care  Aluminum wheels (if equipped)  Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical clean- ers. Use the same mild detergent and wax as used on the paint. ...
Page 318 7-1. Maintenance and care NOTICE  To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.)  Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 319: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 320 7-1. Maintenance and care  Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior.  Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 321 7-1. Maintenance and care NOTICE  Cleaning detergents  Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 322: Maintenance
Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule. For full details of your maintenance schedule, refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”. Do-it-yourself maintenance What about do-it-yourself maintenance? Many of the maintenance items are easy to do yourself if you have a little mechanical ability and a few basic automotive tools.
Page 323 There can also be advantages in utilizing authorized Toyota dealers or repairers for non-warranty repairs and services, as members of the Toyota network will be able to expertly assist you with any difficulties you may encounter.
Page 324 7-2. Maintenance WARNING  If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury.  Handling of the battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 325: Tions
Battery condition • Conventional wrench (for terminal clamp bolts) (P. 342) • Distilled water • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology level (P.
Page 326 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions.  When working on the engine compartment  Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 327 7-3. Do-it-yourself maintenance NOTICE  If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air.  If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 328: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 329 7-3. Do-it-yourself maintenance WARNING  Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ...
Page 330: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 331 7-3. Do-it-yourself maintenance NOTICE  When raising your vehicle Do not jack the vehicle at the suspen- sion. The suspension may be damaged. Suspension Front...
Page 332: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment  1KR-FE engine Fuse boxes (P. 370) Engine coolant reservoir (P. 340) Engine oil level dipstick (P. 335) Electric cooling fan Engine oil filler cap Condenser (P. 341) (P. 337) Radiator (P. 341) Battery (P. 342) Washer fluid tank (P.
Page 333 7-3. Do-it-yourself maintenance  1NR-FE engine Fuse boxes (P. 370) Engine coolant reservoir (P. 340) Engine oil filler cap (P. 337) Electric cooling fan Engine oil level dipstick Condenser (P. 341) (P. 335) Radiator (P. 341) Battery (P. 342) Washer fluid tank (P. 345)
Page 334 7-3. Do-it-yourself maintenance  1ND-TV engine Fuse boxes (P. 370) Intercooler (P. 341) Engine oil filler cap Electric cooling fan (P. 337) Condenser (P. 341) Engine oil level dipstick Radiator (P. 341) (P. 335) Engine coolant reservoir Fuel filter (P. 346) (P.
Page 335 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick.  Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 336 7-3. Do-it-yourself maintenance Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive  Flat dipstick  Non-flat dipstick The shape of the dipstick may differ depending on the type of vehicle or engine. Wipe the dipstick and reinsert it fully.
Page 337 7-3. Do-it-yourself maintenance  Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine.  1KR-FE engine  1NR-FE engine  1ND-TV engine Make sure to check the oil type and prepare the items needed before adding oil.
Page 338 7-3. Do-it-yourself maintenance  Engine oil consumption A certain amount of engine oil will be consumed while driving. In the following situations, oil consumption may increase, and engine oil may need to be refilled in between oil maintenance intervals.  When the engine is new, for example directly after purchasing the vehicle or after replacing the engine ...
Page 339 Call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, service station or auto parts store for information concerning recycling or disposal.
Page 340 “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion- ized water. (Minimum temperature: -35C [-31F]) For more details about coolant, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 341 Check the radiator, condenser and intercooler and clear away any for- eign objects. If any of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional.
Page 342 7-3. Do-it-yourself maintenance Battery Check the battery as follows.  Caution symbols The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid flames, no sparks Note operating instruc- Shield eyes tions Keep away from children Explosive gas...
Page 343 Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. WARNING ...
Page 344 7-3. Do-it-yourself maintenance WARNING  Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is insufficient ventilation.  How to recharge the battery Only perform a slow charge (5 A or less).
Page 345 7-3. Do-it-yourself maintenance Washer fluid If the washer fluid level is less than “FULL” line, add washer fluid to “FULL” line. WARNING  When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 346 Even if you decide to drain it yourself, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. The water in the fuel filter needs to be drained if the fuel filter warning ...
Page 347: Tires
7-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires New tread Treadwear indicator Worn tread The location of treadwear indica- tors is shown by the “TWI” or “” marks, etc., molded on the sidewall of each tire.
Page 348 7-3. Do-it-yourself maintenance To equalize tire wear and help extend tire life, Toyota recommends that tire rotation is carried out approximately every 10000 km (6000 miles). Tire pressure warning system (if equipped) Your vehicle is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire infla- tion pressure before serious problems arise.
Page 349 7-3. Do-it-yourself maintenance  How to initialize the tire pressure warning system (vehicles with a tire pressure warning system) Park the vehicle in a safe place and turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry &...
Page 350 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 351 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 352 7-3. Do-it-yourself maintenance  Certification for the tire pressure warning system The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing address: http://www.globaldenso.com/en/products/oem/index.html...
Page 353 7-3. Do-it-yourself maintenance...
Page 354 7-3. Do-it-yourself maintenance...
Page 355 7-3. Do-it-yourself maintenance The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: DoC address: http://www.pacific-ind.co.jp/eng/products/car/tpms/doc/...
Page 356 7-3. Do-it-yourself maintenance...
Page 357 7-3. Do-it-yourself maintenance...
Page 358 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear.  Do not use tire sizes other than those recommended by Toyota.  Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 359 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
Page 360: Tire Inflation Pressure
 Reduced safety  Damage to the drive train If a tire needs frequent inflating, have it checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ...
Page 361 7-3. Do-it-yourself maintenance WARNING  Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury:  Excessive wear  Uneven wear ...
Page 362: Wheels
 Used wheels  Bent wheels that have been straightened Aluminum wheel precautions (if equipped)  Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels.  When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 363 7-3. Do-it-yourself maintenance  When removing the wheel ornament (vehicles with steel wheels and emergency tire puncture repair kit) Remove the wheel ornament using the wheel cap clip.  When replacing wheels (vehicles with a tire pressure warning system) The wheels of your vehicle are equipped with tire pressure warning valves and transmitters (except for spare tire [include compact spare tire]) that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure.
Page 364 Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional or other qualified service shop. In addition, make sure to...
Page 365: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry & start system).
Page 366 Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”.)  If air flow from the vents decreases dramatically The filter may be clogged.
Page 367: Wireless Remote Control/Elec- Tronic Key Battery
7-3. Do-it-yourself maintenance Wireless remote control/electronic key bat-  tery Replace the battery with a new one if it is depleted. You will need the following items:  Flathead screwdriver  Lithium battery CR2016 (vehicles without a smart entry & start sys- tem), or CR2032 (vehicles with a smart entry &...
Page 368 7-3. Do-it-yourself maintenance Remove the depleted battery. Insert a new battery with the “+” terminal facing up.  Vehicles with a smart entry & start system Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a tape.
Page 369 Use a CR2016 (vehicles without a smart entry & start system) or CR2032 (vehicles with a smart entry & start system) lithium battery  Batteries can be purchased at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, local electrical appliance shops or camera stores.
Page 370: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch to the “LOCK” position (vehicles without a smart entry &...
Page 371 7-3. Do-it-yourself maintenance  Engine compartment: type C fuse box (left-hand drive vehicles) Pull the rubber strip on the edge to unhook it from the cover, and then push the tabs in and lift the cover off. Remove the battery terminal cover and then the fuse box cover.
Page 372 7-3. Do-it-yourself maintenance  Instrument panel (left-hand drive vehicles) Remove the lid.  Instrument panel (right-hand drive vehicles) Remove the cover. Do not pull off the cover using excessive force as it is attached to the footwell light. Remove the lid. Remove the fuse with the pull- out tool.
Page 373 Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type G: Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Type A Type B ...
Page 374 (P. 376)  If the replaced fuse blows again, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.  If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 375 Do not modify the fuses or fuse boxes. NOTICE  Before replacing fuses Have the cause of electrical overload determined and repaired by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible.
Page 376: Light Bulbs
As there is a danger that components may be damaged, we recommend that replacement is carried out by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. For more information about replacing other light bulbs, contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional.
Page 377 7-3. Do-it-yourself maintenance  Rear Rear fog light Rear turn signal lights Stop/tail lights (bulb type) back-up light License plate lights Back-up light rear fog light : Left-hand drive vehicles : Right-hand drive vehicles...
Page 378 7-3. Do-it-yourself maintenance Replacing light bulbs  Halogen headlights Reflector type  Unplug the connector. Remove the rubber cover. Release the bulb retaining spring. Remove the bulb. To install a new bulb, align tabs of the bulb with the cutouts of the mounting hole.
Page 379 7-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting and insert. Install bulb retaining spring. Install the rubber cover. Ensure the rubber cover is securely attached. Fit the rubber cover outer circumference in firmly.
Page 380 7-3. Do-it-yourself maintenance  Projector type Turn the bulb base counter- clockwise. Pull the bulb out while press- ing the lock release of the connector. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting and insert.
Page 381 7-3. Do-it-yourself maintenance  Front fog lights (if equipped) Turn the steering wheel in the opposite direction of the light to be replaced. Turn the steering wheel to a point that allows your hand to easily fit between the tire and fender liner.
Page 382 7-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb. Install the connector. Shake the bulb base gently to check that it is not loose, turn the front fog light, on once and visually confirm that no light is...
Page 383 7-3. Do-it-yourself maintenance Reinstall the fender liner. Attach the end of the fender liner to the inside of the front bumper. Install the screw.  Front position lights/daytime running lights (bulb type) Turn the bulb base counterclockwise. Type A Type B ...
Page 384 7-3. Do-it-yourself maintenance Remove the light bulb.  Type A  Type B When installing, reverse the steps listed.  Front turn signal lights Turn the bulb base counterclockwise.  Type A  Type B Remove the light bulb  Type A ...
Page 385 7-3. Do-it-yourself maintenance  Side turn signal lights Depress the mirror. Remove the mirror. To prevent damaging the vehi- cle, wrap the screwdriver with a tape. Remove the bulb base. Remove the light bulb.
Page 386 7-3. Do-it-yourself maintenance After installing the new bulb, secure the bulb base to the mirror body. Align the tabs, and secure the mirror by pushing in each diagonally-opposite pair of tabs in order. Make sure to insert the tabs in order as shown in the illustra- tion, and push them in until a click is heard.
Page 387 7-3. Do-it-yourself maintenance Remove the light bulb. Stop/tail light Rear turn signal light Install the new bulb. Stop/tail light Rear turn signal light Turn and secure the bulb base. Stop/tail light Rear turn signal light Install the cover. Align the cover claws with the notches.
Page 388 7-3. Do-it-yourself maintenance  License plate light Remove the cover. Insert a properly sized screw- driver into the hole of the cover, and ply off the cover as shown in the illustration. To prevent damaging the vehi- cle, wrap the screwdriver with a tape.
Page 389 7-3. Do-it-yourself maintenance Make sure that the cover is secured by pressing on the entire cover.  Back-up light/rear fog light Remove the clip and partly remove the cover. Pull the center section of the clip and the remove and pull out the lock.
Page 390 (LED type) and high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional to have the light replaced.
Page 391 7-3. Do-it-yourself maintenance WARNING  Replacing light bulbs  Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns.  Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 392 7-3. Do-it-yourself maintenance...
Page 393: When Trouble Arises
When trouble arises 8-1. Essential information If the engine will not start ...448 Emergency flashers...394 If the shift lever cannot be shifted from P (vehicles If your vehicle has to with a Multidrive)....450 be stopped in an emergency....395 If the electronic key does not operate properly 8-2.
Page 394: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 395: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 396 8-1. Essential information Vehicles with a smart entry & start system: stop engine, press and hold the engine switch for 3 consecutive seconds or more, or press it briefly 3 times or more in suc- Press and hold for 3 seconds or cession.
Page 397: Steps To Take In An Emergency
Situations needs to contact dealers before towing The following may indicate a problem with your transmission. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional before towing.  The engine is running but the vehicle will not move.
Page 398 Release the parking brake. Use a towing dolly under the front wheels. Using a flatbed truck If your Toyota is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. After transporting, return the cov- ers that were attached to the rear side.
Page 399 8-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for 80 km (50 miles) at low speeds.
Page 400 Vehicles with a wheel nut wrench: Wheel nut wrench is installed in the lug- gage. (P. 419, 434)  Vehicles without a wheel nut wrench: Wheel nut wrench can be purchased at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 401 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury.  When towing the vehicle Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 402 8-2. Steps to take in an emergency NOTICE  To prevent damage to the vehicle when towing using a wheel-lift type truck When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
Page 403: If You Think Something Is Wrong
If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible.
Page 404: Fuel Pump Shut Off System (Gasoline Engine Only)
8-2. Steps to take in an emergency Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 405: If A Warning Light Turns On Or A Warning Buzzer Sounds
However, if this continues to occur, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Warning light and warning buzzer list...
Page 406 • The electronic Multidrive control system (if equipped); • The emission control system; or • The DPF catalytic converter (if equipped).  Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
Page 407 Slip indicator light (if equipped) Indicates a malfunction in: • The VSC system; • The TRC system.  Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. Cruise control indicator light (if equipped) Indicates a malfunction in the cruise control system.
Page 408 The light will turn off after a few minutes. In case the light does not turn off even if the tire inflation pres- sure is adjusted, have the system checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 409 (40 mph) or greater, or the DPF system warning light does not turn off even after driving for more than 30 minutes, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly quali- fied and equipped professional.
Page 410 (and the oil maintenance data has been reset).  Check and change the engine oil, and oil filter by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. After changing the engine oil, the oil change system should be reset.
Page 411 : The DPF system warning light may not turn off when the engine oil change reminder light is on. In this event, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.
Page 412 8-2. Steps to take in an emergency  If the engine oil change reminder light flashes (diesel engine with a DPF system) Repeated short trips and/or low-speed driving may cause the oil to degrade sooner than usual, regardless of the actual distance driven. If this happens, the engine oil change reminder light will flash.
Page 413 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings  If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ...
Page 414 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 415 100 to 300 km (62 to 187 miles), the malfunction indicator lamp may come on. If this happens, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. ...
Page 416 8-2. Steps to take in an emergency Interior Exterior Warning Warning light/Details/Actions buzzer buzzer light Smart entry & start system indicator light Vehicles with a Multidrive: The electronic key was carried outside the vehicle and the driver’s door was opened and closed while the shift position P was selected without turning off the engine switch.
Page 417 8-2. Steps to take in an emergency Interior Exterior Warning Warning light/Details/Actions buzzer buzzer light Smart entry & start system indicator light Indicates that the electronic key is not pres-  Once ent when attempting to start the engine.  Confirm the location of the electronic (Flashes in yellow for 15 seconds.)
Page 418: If You Have A Flat Tire (Vehicles With A Spare Tire)
8-2. Steps to take in an emergency If you have a flat tire (vehicles with a spare tire) Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 347 WARNING ...
Page 419 8-2. Steps to take in an emergency Location of the spare tire, jack and tool bag  Location Jack Luggage floor cover Spare tire Wheel nut wrench Tool bag Towing eyelet Jack handle...
Page 420 8-2. Steps to take in an emergency WARNING  Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury.  Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 421 8-2. Steps to take in an emergency Taking out the jack Move the front left seat to the front most position and remove the cover. Take out the jack. For tightening For loosening...
Page 422 8-2. Steps to take in an emergency Taking out the spare tire  Vehicles with a compact spare tire Vehicles with a deck board: Lift the deck board and pull it toward you to remove it. (P. 307) Remove luggage floor cover.
Page 423 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 424 8-2. Steps to take in an emergency Turn the tire jack portion hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indi- cate the jack point positions. Raise the vehicle until the tire is slightly raised off the ground.
Page 425 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. • When installing the wheel nuts, be sure to install them with the tapered...
Page 426 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 427 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 103 N·m (10.5 kgf·m, 76 ft·lbf) Do not use other tools or any addi- tional leverage other than your hands, such as a hammer, pipe or your foot.
Page 428 8-2. Steps to take in an emergency  The compact spare tire  The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ...
Page 429 8-2. Steps to take in an emergency  Certification for the jack...
Page 430 8-2. Steps to take in an emergency...
Page 431 8-2. Steps to take in an emergency WARNING  When using the full-size spare tire  Replace the full-size spare tire with a standard tire as soon as possible.  Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations that cause sudden engine braking. ...
Page 432 When replacing the tires (vehicles with a tire pressure warning system) When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as the tire pressure warning valve...
Page 433: If You Have A Flat Tire (Vehicles With An Emergency Tire Puncture Repair Kit)
(P. 436) After temporarily repairing the tire with the kit, have the tire repaired or replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Repairs conducted using the emergency tire puncture repair kit are only a temporary measure.
Page 434 : Use of the jack, jack handle and wheel nut wrench. (if equipped) (P. 419) A jack, jack handle and wheel nut wrench can be purchased at any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.
Page 435 8-2. Steps to take in an emergency Emergency tire puncture repair kit components Nozzle Compressor switch Power plug Air pressure gauge Hose Stickers...
Page 436  In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  When the tire is damaged due to driving without sufficient air pressure ...
Page 437 8-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Vehicles with a deck board: Lift the deck board and pull it toward you to remove it. (P. 307) Remove luggage floor cover. Take out the emergency tire puncture repair kit.
Page 438 8-2. Steps to take in an emergency Remove the cap from the bot- tle. Connect the nozzle to the valve. Screw the end of the nozzle clock- wise as far as possible. The bottle should hang vertically without contacting the ground. If the bottle does not hang vertically, move the vehicle so that the tire valve is located properly.
Page 439 Remove any dirt and moisture from the wheel before attaching the label. If it is impossible to attach the label, make sure to tell any authorized Toyota dealer repairer, or another duly qualified and equipped professional when you have them repair and replace...
Page 440 8-2. Steps to take in an emergency Connect the bottle to the com- pressor. Screw the end of the hose clock- wise as far as possible. Check the specified tire inflation pressure. Tire inflation pressure is specified on the label in the glove box. (P.
Page 441 8-2. Steps to take in an emergency Inflate the tire until the specified air pressure is reached. The sealant will be injected and the pressure will surge and then gradually decrease. The air pressure gauge will display the actual tire infla- tion pressure about 1 minute (5 minutes at low tempera- ture) after the switch is...
Page 442 Check the tire inflation pres- sure. If the tire inflation pressure is under 130 kPa (1.3 kgf/cm or bar, 19 psi): The puncture cannot be repaired. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.
Page 443 Taking precautions to avoid sudden braking, sudden acceleration and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional for tire repair or replacement.
Page 444 The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire. If the sealant has been used and needs to be replaced, purchase a new bottle at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. The compressor is reusable.
Page 445 8-2. Steps to take in an emergency WARNING  Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 446 8-2. Steps to take in an emergency WARNING  Connect the valve and hose securely with the tire installed on the vehicle. If the hose is not properly connected to the valve, air leakage may occur as sealant may be sprayed out. ...
Page 447 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
Page 448: If The Engine Will Not Start
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 182, 185), consider each of the fol- lowing points: The engine will not start even though the starter motor operates normally.
Page 449  There may be a malfunction in the steering lock system (vehicles with a smart entry & start system). Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, if the problem cannot be repaired, or if repair procedures are unknown.
Page 450: If The Shift Lever Cannot Be Shifted From P (Vehicles With A Multidrive)
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
Page 451: If The Electronic Key Does Not Operate Properly (Vehicles With A Smart Entry & Start System)
8-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with a smart entry & start system) If communication between the electronic key and vehicle is interrupted (P. 130) or the electronic key cannot be used because the battery is depleted, the smart entry &...
Page 452 (green) turns on. Press the engine switch. In the event that the engine still cannot be started, contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional.  Stopping the engine Shift the shift lever to P (Multidrive) or N (manual transmission) and press the engine switch as you normally do when stopping the engine.
Page 453: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 454 8-2. Steps to take in an emergency Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle. Connect a negative cable clamp to the negative (-) battery termi- nal on the second vehicle.
Page 455 8-2. Steps to take in an emergency  1ND-TV engine Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle. Connect a negative cable clamp to the negative (-) battery termi- nal on the second vehicle.
Page 456 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible. ...
Page 457 8-2. Steps to take in an emergency WARNING  Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery:  Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with anything other than the intended ter- minal.
Page 458: If Your Vehicle Overheats
8-2. Steps to take in an emergency If your vehicle overheats The following may indicate that your vehicle is overheating:  The high engine coolant temperature warning light (P. 406) comes on or flashes, or a loss of engine power is experienced. (For example, the vehicle speed does not increase.) ...
Page 459 8-2. Steps to take in an emergency The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir. Gasoline engine Diesel engine   Reservoir Reservoir “FULL” “FULL” “LOW” “LOW” Add coolant if necessary. Water can be used in an emergency if coolant is unavailable.
Page 460 Stop the engine immediately and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. If the fan is operating: Have the vehicle inspected at the nearest authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 461 8-2. Steps to take in an emergency WARNING  To prevent an accident or injury when inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns.  If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 462: If You Run Out Of Fuel And The Engine Stalls (Diesel Engine Only)
8-2. Steps to take in an emergency If you run out of fuel and the engine stalls (diesel engine only) If you run out of fuel and the engine stalls Refuel your vehicle. Pull the rubber strip on the edge to unhook it from the cover, and then push the tabs in and lift the cover off.
Page 463 If the engine does not start after the above steps have been performed, wait for 10 seconds and then try steps 3 and 5 again. If the engine still does not start, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 464: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P (Multidrive) or N (manual transmission).
Page 465 8-2. Steps to take in an emergency WARNING  When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 466 8-2. Steps to take in an emergency...
Page 467: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...468 Fuel information ....487 9-2. Customization Customizable features ..489 9-3. Items to initialize Items to initialize ....493...
Page 468: Specifications Maintenance Data
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 3950 mm (155.5 in.) Overall width 1695 mm (66.7 in.) 1510 mm (59.4 in.) Overall height 1520 mm (59.8 in.) 1530 mm (60.2 in.) Wheelbase 2510 mm (98.8 in.) 1485 mm (58.5 in.) Front 1470 mm (57.9 in.)
Page 469 9-1. Specifications  1KR-FE engine 730 kg (1609 lb.)  1NR-FE engine with brake 880 kg (1940 lb.) Towing capacity  1ND-TV engine 780 kg (1719 lb.) without brake 550 kg (1212 lb.) Maximum permissible mass for tow- 19 kg (41 lb.) ing hitch/bracket : Unladen vehicles : Vehicles with rough road package (without raised vehicle height)
Page 470 9-1. Specifications Vehicle identification  Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toy- ota. It is used in registering the ownership of your vehicle. This number is stamped under the front right seat.
Page 471 9-1. Specifications  Engine number The engine number is stamped on the engine block as shown.  1KR-FE engine  1NR-FE engine 1ND-TV engine  Engine  Gasoline engine 1KR-FE engine  Model 1KR-FE Type 3-cylinder in line, 4-cycle, gasoline 71.0 ...
Page 472 The high strength drive belt is used for the generator side drive belt. When replacing the drive belt, use Toyota genuine drive belt or equivalent high strength drive belt. If the high strength drive belt is not used, durability of the belt may become less than expected.
Page 473 9-1. Specifications Fuel  Gasoline engine EU area: Unleaded gasoline conforming to European Fuel type standard EN228 only Except EU area: Unleaded gasoline only Research Octane 95 or higher Number Fuel tank capacity 42 L (11.1 gal., 9.2 Imp.gal.) (Reference) ...
Page 474 9-1. Specifications Lubrication system (gasoline engine)  Oil capacity (Drain and refill — reference  With filter 1KR-FE engine 2.8 L (3.0 qt., 2.5 Imp.qt.)  1NR-FE engine 3.4 L (3.6 qt., 3.0 Imp.qt.)  Without filter 1KR-FE engine 2.6 L (2.7 qt., 2.3 Imp.qt.) ...
Page 475 9-1. Specifications  Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
Page 476 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 477 Engine oil selection Vehicles without a DPF system  “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used. Oil grade: ACEA C2, B1, API CF-4 or CF...
Page 478 9-1. Specifications  Vehicles with a DPF system “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used. Oil grade: ACEA C2 NOTICE Using engine oil other than ACEA C2 may damage the catalytic converter.
Page 479  Manual transmission 4.6 L (4.9 qt., 4.0 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 480 Fluid capacity 6.4 L (6.8 qt., 5.6 Imp.qt.) Fluid type Toyota Genuine CVT Fluid FE : The fluid capacity is the reference quantity. If replacement is necessary, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 481 9-1. Specifications NOTICE  Multidrive fluid type Using Multidrive fluid other than “Toyota Genuine CVT Fluid FE” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. Manual transmission ...
Page 482 9-1. Specifications Brakes  Rear drum brake 83 mm (3.27 in.) Min. Gasoline engines  Rear disk brake Left- 79 mm (3.11 in.) Min. hand drive  Rear drum brake vehicles 81 mm (3.19 in.) Min. Diesel  engines Rear disk brake 78 mm (3.07 in.) Min.
Page 483 9-1. Specifications Tires and wheels  14-inch tires (Type A) Tire size 175/65R14 82T Tire inflation pressure (Recommended cold 220 kPa (2.2 kgf/cm or bar, 32 psi) tire inflation pressure) 14  5J Wheel size Wheel nut torque 103 N·m (10.5 kgf·m, 76 ft·lbf) ...
Page 484 9-1. Specifications  15-inch tires (Type B) Tire size 185/60R15 84H Front wheel Rear wheel Vehicle speed (kgf/cm kPa (kgf/cm or bar, psi) bar, psi) Tire inflation pressure 160 km/h (Recommended cold (99 mph) or 220 (2.2, 32) 220 (2.2, 32) tire inflation pressure) less More than...
Page 485 9-1. Specifications  Compact spare tires Tire size T125/70D15 95M Tire inflation pressure (Recommended cold 420 kPa (4.2 kgf/cm or bar, 60 psi) tire inflation pressure) 15  4T Wheel size Wheel nut torque 103 N·m (10.5 kgf·m, 76 ft·lbf) Tire size T125/70D16 96M Tire inflation pressure...
Page 486 9-1. Specifications Light bulbs Light Bulbs Type Halogen headlights Reflector type 60/55 Projector type Front fog lights Front position light/daytime running lights 21/5 (bulb type) Front turn signal lights Exterior Side turn signal lights Rear turn signal lights Stop/tail lights (bulb type) 21/5 Back-up light Rear fog light...
Page 487: Fuel Information
 If your engine knocks  Consult any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  You may occasionally notice light knocking for a short time while accelerat- ing or driving uphill. This is normal and there is no need for concern.
Page 488 “B30” or “B100” and fuel containing a large amount of FAME should not be used. The use of these fuels will damage the vehicle’s fuel system. In case of any doubt, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 489: Customization
(For further information on customizing settings using the Naviga- tion/Multimedia system, refer to the “Navigation and multimedia system Owner’s Manual”.) Settings that can be changed by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for fur- ther details...
Page 490 9-2. Customization  Smart entry & start system (P. 114, 127) Default Customized Function setting setting Smart entry & start system Operation signal — (Emergency flashers) Time elapsed before automatic 60 seconds door lock function is activated if 30 seconds —...
Page 491 9-2. Customization  Automatic light control system (P. 202) Default Customized Function setting setting Light sensor sensitivity Level 3 Level 1 to 5  Lights (P. 202) Default Customized Function setting setting 60 seconds Time that the low beam headlights 30 seconds 90 seconds —...
Page 492 9-2. Customization WARNING  During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 493: Items To Initialize
9-3. Items to initialize Items to initialize The following item must be initialized for normal system opera- tion in cases such as after the battery is reconnected, or mainte- nance is performed on the vehicle. Item When to initialize Reference Engine oil mainte- After changing engine oil P.
Page 494 9-3. Items to initialize...
Page 495: Index
Index What to do if... (Troubleshooting) .....496 Alphabetical index ......500 For vehicles with a Navigation/Multimedia system, refer to the “Navigation and multimedia system Owner’s Manual” for information regarding the equipment listed below. • Navigation/Multimedia system • Rear view monitor system...
Page 496: What To Do If
You lose your keys  If you lose your keys, new genuine keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. (P. 104)  If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 497 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without a smart entry & start system)  Vehicles with a Multidrive: Is the shift lever in P? (P. 182)  Vehicles with a manual transmission: Did you turn the key while firmly depressing the clutch pedal? (P.
Page 498 What to do if... (Troubleshooting) The shift lever cannot be shifted from P even if you depress the brake pedal (vehicles with a Multidrive)  Vehicles without a smart entry & start system: Is the engine switch in the “ON” position? If you cannot release the shift lever by depressing the brake pedal with the engine switch in the “ON”...
Page 499 What to do if... (Troubleshooting) A warning buzzer sounds during driving  The seat belt reminder light is flashing Is the driver wearing the seat belts? (P. 408)  The parking brake indicator is on Is the parking brake released? (P. 405) Depending on the situation, other types of warning buzzer may also sound.
Page 500: Alphabetical Index
Alphabetical index Alphabetical index Side airbag operating conditions ......44 A/C........280, 287 Side airbag precautions ..41 Air conditioning filter....365 Side and curtain shield Automatic air conditioning airbags operating system ........ 287 conditions ......44 Manual air conditioning Side and curtain shield system ........
Page 501 Alphabetical index Automatic air conditioning system ........287 Care........316, 319 Air conditioning filter....365 Aluminum wheels....317 Automatic air conditioning Exterior ......... 316 system ........ 287 Interior........319 Automatic light control Seat belts......320 system ........205 CD player........257 Auxiliary boxes ......
Page 502 Alphabetical index Child-protectors.......119 Cigarette lighter .......311 Daytime running light Cleaning......316, 319 system........205 Aluminum wheels....317 Replacing light bulbs..... 390 Exterior........316 Defogger Interior........319 Outside rear view Seat belts ......320 mirrors ......283, 291 Clock ........... 93 Rear window ....
Page 503 Alphabetical index Engine “ACC” position ...... 183 Eco Driving Indicator Light..164 Accessory mode ....186 Electric Power Steering Compartment ......332 (EPS)........235 Engine switch....182, 185 Function ........ 235 Hood ........328 Warning light ......406 How to start Electronic key ......
Page 504 Alphabetical index Engine oil maintenance Front turn signal lights ... 200 data ......... 338 Replacing light bulbs..... 384 Engine switch Turn signal lever ....200 (ignition switch)..... 182, 185 Wattage ........ 486 Engine switch light Fuel (ignition switch light) .... 299 Capacity........
Page 505 Alphabetical index Hands-free system Identification ......470 (for cellular phone) Engine........471 Hazard lights Vehicle ........470 Switch ........394 Ignition switch Head restraints......144 (engine switch) ....182, 185 Headlights ........ 202 Ignition switch light Follow me home system ..203 (engine switch light) .....
Page 506 Alphabetical index Jack Lever Positioning a floor jack ..330 Auxiliary catch lever....328 Vehicle-equipped jack... 419 Hood lock release lever ..328 Jack handle ...... 419, 434 Shift lever...... 191, 196 Jam protection function Turn signal lever ....200 Power window.......155 Wiper lever....
Page 507 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance ... 325 Maintenance data ....468 Maintenance requirements ... 322 Odometer........91 Malfunction indicator lamp ..406 Manual headlight leveling Engine oil ......474 dial .......... 204 Manual transmission oil ..481 Manual transmission ....196 Opener Oil..........
Page 508 Alphabetical index Radiator ........341 Seat belt reminder light... 408 Radio......... 252 Seat belts........30 Radio data system ....254 Child restraint system RDS ........... 254 installation ......63 Rear fog light......208 Cleaning and maintaining Replacing light bulbs..... 389 the seat belt......
Page 509 Alphabetical index Side airbags ....... 37 Sun shade Side doors ........ 114 Roof ........313 Side mirrors......151 Sun visors ........ 309 Adjusting and folding..... 151 Switches Heaters ......283, 291 Audio remote control Side turn signal lights ..... 200 switches......
Page 510 Alphabetical index Tools ......... 419, 434 Top strap ........68 Tachometer ........ 88 Towing Tail lights ........202 Emergency towing ....397 Light switch ......202 Towing eyelet......399 Replacing light bulbs..386, 390 Trailer towing ......173 Wattage......... 486 Traction control .......
Page 511 Alphabetical index Washer......210, 214 Checking....... 345 Warning buzzers Preparing and checking Brake system ......405 before winter....... 242 Electric power steering..406 Switch ......210, 214 Key reminder......184 Washing and waxing ....316 Open door ......407 Weight........468 Seat belt reminder....
Page 512 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 328 P. 218 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 328 P. 218 P. 483 Fuel tank capacity 42 L (11.1 gal., 9.2 Imp.gal.) (Reference) Fuel type P.
