Page 1 04 05.18 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Overview of instruments and controls Instrument panel overview ........Instrument cluster overview .
Page 2: Instrument Panel Overview
04 05.18 Instrument panel overview 1. Side vents 2. Instrument cluster 3. Center vents 4. Personal lights 5. Rear view mirror remote control levers 6. Auxiliary box 7. Glove box 8. Automatic transmission selector lever or manual transmission gear shift lever 9.
Page 3 04 05.18 1. Headlight and turn signal switches 2. Wiper and washer switches 3. Rear window defogger switch 4. Emergency flasher switch 5. Air conditioning controls 6. Front passenger’s seat belt reminder light 7. Cigarette lighter 8. Ashtray 9. Ignition switch SU11012c 10.
Page 4: Instrument Cluster Overview
04 05.18 Instrument cluster overview SU11016 1. Service reminder indicators and 4. Odometer and two trip meters 6. Trip meter reset button indicator lights 5. Fuel gauge 7. Tachometer 2. Speedometer 3. Extinction canceling button 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 5: Indicator Symbols On Instrument Panel
04 05.18 Indicator symbols on the instrument panel ∗ 1 ∗ 1 Brake system warning light Low fuel level indicator light ∗ 1 windshield washer fluid level warning Driver’s seat belt reminder light ∗ 1 light ∗ 1 Turn signal indicator lights Front passenger’s seat belt reminder light ∗...
Page 6 04 05.18 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 7: Table Of Contents
04 04.06 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys ............Side doors .
Page 8: Keys
To unlock: Turn the key backward. need additional keys, duplicates can be 5−door models—All the side doors and made by a Toyota dealer using the key back door lock and unlock simultaneously number. with either front door. In the driver’s door...
Page 9 04 04.06 SY12009 SY12011 SZ12028 LOCKING UNLOCKING WITH LOCKING UNLOCKING WITH REAR DOOR CHILD−PROTECTORS INSIDE LOCK BUTTON POWER DOOR LOCK SWITCH (5−door models only) (5−door models only) Move the lock button. Move the lock lever to the “LOCK” Push the switch. position as shown on the label.
Page 10: Back Door
04 04.06 Back door CAUTION Before driving, be sure that the doors closed locked, especially when small children are in the ve- SY12017 SU12071 hicle. Along with the proper use of seat belts, locking the doors helps prevent the driver and passengers from being thrown out from the ve- hicle during an accident.
Page 11: Hood
04 04.06 Hood SU12066c SU12067a SU12068 To open the hood: 2. In front of the vehicle, pull up the 3. Hold the hood open by inserting the auxiliary catch lever and lift support rod into the slot. 1. Pull the hood lock release lever. The hood.
Page 12: Fuel Tank Cap
04 04.06 Fuel tank cap CAUTION After inserting the support rod into the slot, make sure the rod supports the hood security from falling down SF12004 SU12069a on to your head or body. NOTICE Be sure to return the support rod to its clip before closing the hood.
Page 13 Make sure the cap is tightened securely. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 14 04 04.06 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 15 04 05.28 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Occupant restraint systems Seats ............Front seats .
Page 16: Seats
04 05.28 Front seats— Seats —Front seat precautions While the vehicle is being driven, all ve- Driver seat Slightly recline the back of hicle occupants should have the seatback seat. Although vehicle designs vary, upright, sit well back in the seat and prop- CAUTION many drivers can achieve the 250 erly wear the seat belts provided.
Page 17 04 05.28 —Seat adjustment precautions Front passenger seat CAUTION While adjusting the seat, do not put your hands under the seat or near CAUTION Do not adjust the seat while the the moving parts. Otherwise, your vehicle is moving as the seat may hands or fingers may be caught and The SRS front passenger airbag also unexpectedly move and cause the...
Page 18 04 05.28 —Tilting driver’s seatback for rear seat entry (3−door models) —Adjusting front seats 1. SEAT POSITION ADJUSTING LEVER Hold the center of the lever and pull it up. Then slide the seat to the desired position with slight body pressure and release the lever.
Page 19: Fold−Down Rear Seat
04 05.28 —Moving passenger’s seat for rear seat entry (3−door models) Fold−down rear seat CAUTION After putting back the seat, pushing the seat forward and rear- ward to make sure it is secured in SU13117 SU13248a place. Never allow anyone to rest their foot on the release pedal while the vehicle is moving.
Page 20: Head Restraints
04 05.28 Head restraints CAUTION When returning the seatback to the upright position, observe the follow- ing precautions in order to prevent SU13210c SY13011 personal injury in a collision or sud- den stop: Make sure the seatback is securely locked by pushing forward and rear- ward on the top of the seatback.
Page 21: Seat Belts
04 05.28 Seat belts— —Seat belt precautions For your safety and comfort, adjust the Toyota strongly urges that the driver and Do not allow any children to stand up or head restraint before driving. passengers in the vehicle be properly re- kneel on either rear or front seats.
Page 22 04 05.28 —Fastening front and rear seat belts CAUTION Be careful not to damage the belt webbing or hardware. Take care that Persons should ride in their seats they do not get caught or pinched properly wearing their seat belts in the seat or doors.
Page 23 If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed, because it cannot protect an adult occupant or your child from injury.
Page 24 04 05.28 CAUTION Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be SZ13014 SY13017 kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause serious injures in a collision.
Page 25 Toyota dealer free of extender. charge. Do not use the seat belt extender Please contact your local Toyota dealer so SU13015a when installing child restraint that the dealer can order the proper re- system on the front or rear passen- quired length for the extender.
Page 26 The driver and front passenger seat The seat belt pretensioner system con- Toyota dealer. Do not use the seat belt pretensioners are designed to be sists mainly of the following components until the seat belt is fixed, because...
Page 27 Attachment of a grille guard (bull result in death or serious injury. Con- airbag sensor assembly, front airbag sen- bar, kangaroo bar, etc.), snowplow, sult your Toyota dealer about any re- sors, seat belt pretensioner assemblies, winches or any other equipment to pair and modification.
Page 28: Srs Driver And Front Passenger Airbags
The seat belt pretensioner assembly or surrounding area has been damaged. In the following cases, contact your Toyota The SRS (Supplemental Restraint Sys- dealer as soon as possible: tem) airbags are designed to provide...
Page 29 Toyota killed or seriously injured by the strongly recommends that all in- inflating airbags if they do not wear fants and children be placed in the rear seat of the vehicle and proper- the available seat belts properly.
Page 30 04 05.28 The SRS airbags are designed to deploy in severe (usually frontal) collisions where the magnitude and duration of the forward deceleration of the vehicle Hitting a curb, Falling into or exceeds the designed threshold level. edge of pavement jumping over a Collision from the rear or hard surface...
Page 31 04 05.28 The front airbag sensors constantly moni- Deployment of the airbags happens in a tor the forward deceleration of the vehicle. fraction of a second, so the airbags must If an impact results in a forward decelera- inflate with considerable force. While the tion beyond the designed threshold level, system is designed to reduce serious inju- the system triggers the airbag inflators.
Page 32 All vehicle occupants be properly Do not sit on the edge of the seat Toyota strongly recommends that all restrained using the available seat or lean against the dashboard when infants and children be placed in belts.
Page 33 Failure to follow these instructions your body on or in front of the can result in death or serious injury. dashboard or steering wheel pad Consult your Toyota dealer about any that houses the airbag system. They repair and modification. might...
Page 34 69 in Section 1−6.) If any of the following conditions occurs, this indicates a malfunction of the airbags or seat belt pretensioners. Contact your Toyota dealer as soon as possible. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 35: Child Restraint
04 05.28 Child restraint— —Child restraint precautions Toyota strongly urges the use of ap- NOTICE propriate child restraint systems for children. Do not disconnect the battery cables before contacting your Toyota dealer. The laws of all 50 states in the U.S.A.
Page 36 04 05.28 —Child restraint system A child restraint system for a small Toyota strongly urges use of Do not use the seat belt extender child or baby must itself be properly proper child restraint system which when installing child restraint...
Page 37 04 05.28 —Types of child restraint system Child restraint systems are classified into the following 3 types depending on the child’s age and size. (A) Infant seat (B) Convertible seat SU13214d SU13218b (C) Booster seat Install the child restraint system following the instructions provided by its manufac- turer.
Page 38 04 05.28 —Installation with 3−point type seat belt SU13223c SU13120 SU13224d (A) INFANT SEAT INSTALLATION CAUTION Do not put a child restraint system An infant seat must be used in rear− on the rear seat if it interferes with facing position only. Never put a rear−facing child re- the lock mechanism of the front straint system on the front passen-...
Page 39 1. Run the lap and shoulder belt through 2. Fully extend the shoulder belt to put it Contact your Toyota dealer immedi- or around the infant seat following the in the lock mode. When the belt is ately.
Page 40 04 05.28 SU13236a SU13237a SU13231a 3. While pressing the infant seat firmly 4. To remove the infant seat, press the CAUTION against the seat cushion and seatback, buckle release button and allow the let the shoulder belt retract as far as belt to retract completely.
Page 41 04 05.28 SU13225e SU12121 SX13010 Move seat fully back (B) CONVERTIBLE SEAT INSTALLATION CAUTION A forward−facing child restraint sys- A convertible seat must be used in for- should allowed ward−facing or rear−facing position de- Never put a rear−facing child re- installed on front passenger pending on the age and size of the...
Page 42 1. Run the lap and shoulder belt through Contact your Toyota dealer immedi- Do not put a child restraint system or around the convertible seat following ately. Do not install the child re-...
Page 43 04 05.28 SU13220b SU13221b SU13222b 2. Fully extend the shoulder belt to put it 3. While pressing convertible seat CAUTION in the lock mode. When the belt is firmly against the seat cushion and then retracted even slightly, it cannot seatback, let the shoulder belt retract Push and pull the child restraint sys- be extended.
Page 44 04 05.28 SU13232a SU13227e SU13052 Move seat fully back 4. To remove the convertible seat, press (C) BOOSTER SEAT INSTALLATION CAUTION the buckle release button and allow the A booster seat must be used in for- belt to retract completely. The belt will ward−facing position only.
Page 45 Always make sure the shoulder belt child from death or serious injury. is positioned across the center of Contact your Toyota dealer immedi- child’s shoulder. The belt should be ately. Do not install the child re- SU13233c kept away from child’s neck, but...
Page 46 04 05.28 —Using a top strap Symbol Anchor brackets SU13232 SU13242a SU13246a 2. To remove the child restraint system, Follow the procedure below for a child Use the anchor bracket behind the rear press the buckle release button and restraint system that use of a top strap seat to attach the top strap.
Page 47 04 05.28 SU13245 SU13247a SU13243a TO USE THE ANCHOR BRACKET: 2. Open the anchor bracket cover with 3. Securely fasten the child restraint the symbol mark shown in the il- system with the seat belt. 1. Remove the head restraint. lustration.
Page 48 04 05.28 —Installation with child restraint lower anchorages CAUTION Make sure the top strap is securely latched, and check that the child restraint system is secure by push- SU13244a SU13228c ing and pulling it in different direc- tions. Follow all the installation instructions provided by its manufacturer.
Page 49 04 05.28 SU13250 SU13229c SU13251 Type A (anchor position indicated by Type A (anchor position indicated by Type B (anchor position indicated by buttons) tags) buttons) 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 50 04 05.28 The symbol on a child restraint system For installation details, refer to the instruc- indicates the presence of a lower connec- tion manual equipped with each product. tor system. CAUTION CHILD RESTRAINT SYSTEM INSTALLATION When using the lower anchorages Type A—...
Page 51 04 04.06 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Steering wheel and Mirrors Tilt steering wheel ......... . . Outside rear view mirrors .
Page 52: Tilt Steering Wheel
04 04.06 Tilt steering wheel Outside rear view mirrors— CAUTION Do not adjust the steering wheel while the vehicle is moving. Doing so may cause the driver to mishan- SU13058 SU13111a dle the vehicle and an accident may occur resulting in death or serious injuries.
Page 53 04 04.06 —Rear view mirror remote control —Folding rear view mirrors CAUTION Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the ve- SY13077a SY13078 hicle and an accident may occur re- sulting in death or serious injuries.
Page 54: Anti−Glare Inside Rear View Mirror
04 04.06 Anti−glare inside rear view mirror NOTICE CAUTION Do not push backward more than the Do not adjust the mirror while the click. It may damage the mirror or vehicle is moving. Doing so may vehicle. cause the driver to mishandle the ve- SU13241 hicle and an accident may occur re- sulting in personal death or serious...
Page 55: Vanity Mirrors
04 04.06 Vanity mirrors SU13061 To use the vanity mirrors, swing down the sun visor and open the cover. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 56 04 04.06 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 57 04 05.18 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Lights, Wipers and Defogger Headlights and turn signals ........Emergency flashers .
Page 58: Headlights And Turn Signals
04 05.18 Headlights and turn signals NOTICE To prevent the battery from being dis- charged, do not leave the lights on for a long period when the engine is not running. SU14021 SU14020 Daytime running light system The headlights turn on at reduced intensi- ty when the parking brake is released with the engine started, even with the light switch in the “OFF”...
Page 59: Emergency Flashers
04 05.18 Emergency flashers NOTICE To prevent the battery from being dis- charged, do not leave the switch on longer than necessary when the en- gine is not running. SU14022 SU14014 TURN SIGNALS To turn on the emergency flashers, push the switch. To signal a turn, push the headlight/ turn signal lever up or down to position All the turn signal lights will flash.
Page 60: Instrument Panel Light Control
04 05.18 Instrument panel light control Interior light Personal lights SU14018 SU14007 SZ14010 To adjust the brightness of the instru- To turn on the interior light, slide the To turn on the personal light, push the ment panel lights, turn the knob. switch.
Page 61: Luggage Compartment Light
04 05.18 Windshield wipers and washer Luggage compartment light To squirt washer fluid, pull the lever toward you. The low washer fluid warning light in the instrument cluster comes on when the fluid level in the tank becomes nearly empty. For instructions on adding washer SU14019a SH14008 fluid, see “Adding washer fluid”...
Page 62: Rear Window Wiper And Washer
04 05.18 Rear window wiper and washer Rear window defogger NOTICE Do not operate the rear wiper if the rear window is dry. It may scratch the glass. SZ14013 SU14013 To turn on the rear window wiper, twist To defog or defrost the rear window, the lever knob upward.
Page 63 04 05.18 Make sure you turn the defogger off when the window is clear. Leaving the defogger on for a long time could cause the battery to discharge, especially during stop−and− go driving. The defogger is not designed for drying rain water or for melting snow. NOTICE z To prevent the battery from being discharged,...
Page 64 04 05.18 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 65 04 05.18 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Gauges, Meters and Service reminder indicators Fuel gauge ..........Engine coolant temperature indicator and warning light .
Page 66: Fuel Gauge
If the indicator lamp does ing light (red) will come on when the igni- 1/4 full. not go off, contact your Toyota dealer as tion key is turned to the “ON” position. soon as possible. After a few seconds, the light will go off.
Page 67: Tachometer
04 05.18 Tachometer Odometer and two trip meters If the high engine coolant temperature warning light (red) flashes, your engine is too hot. If your vehicle overheats, stop your vehicle and allow the engine to cool. Your vehicle may overheat during severe operating conditions, such as: SH15003b SH15006...
Page 68 04 05.18 3. Trip meter reset button—It can reset the two trip meters to zero, and also change the meter display. To change the meter display, quickly push and release the button. The meter display changes in the order from the odometer to trip meter A to trip meter B, then back to the odometer each time you push.
Page 69: Service Reminder Indicators And Warning Buzzers
04 05.18 Service reminder indicators and warning buzzers If the indicator or buzzer comes on... Do this. If parking brake is off, stop immediately and contact Toyota dealer. Fasten driver’s seat belt. (Indicator and buzzer) Fasten front passenger’s seat belt.
Page 70 04 05.18 If the indicator or buzzer comes on... Do this. Take vehicle to Toyota dealer. Close all side doors and back door. Take vehicle to Toyota dealer immediately. Add washer fluid. Stop and check. (in red) Key reminder Remove key.
Page 71: Driver's Seat Belt Reminder Light
Turn off the air conditioning, not fastened. Unless the driver fastens the blower, radio, etc., and drive directly to belt, the light continues flashing and the the nearest Toyota dealer or repair shop. buzzer stops after about 4 to 8 seconds. (c) Front Passenger’s...
Page 72: Malfunction Indicator Lamp
Call a but the brake system still operates con- matic transmission electrical system or Toyota dealer or qualified repair shop for ventionally. warning light system itself. assistance. Contact your Toyota dealer as soon as possible to service the vehicle.
Page 73: Open Door Warning Light
(l) High Engine Coolant Temperature the warning light system. Contact your sors, seat belt pretensioner assemblies, Warning Light Toyota dealer as soon as possible to inflators, warning light, interconnecting wir- service the vehicle. The light operates to warn that the engine ing and power sources.
Page 74 The SRS warning light goes off after about 6 seconds. If any service reminder indicator or warn- ing buzzer does not function as described above, have it checked by your Toyota dealer as soon as possible. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 75 04 05.18 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Ignition switch, Transmission and Parking brake Ignition switch with steering lock ....... Automatic transmission .
Page 76: Ignition Switch With Steering Lock
04 05.18 Ignition switch with steering lock “LOCK”—Engine is off and the steering wheel is locked. The key can be re- moved only at this position. You must push in the key to turn the key from “ACC” to the “LOCK” position. On vehicles with an automatic transmission, SY16001 the selector lever must be put in the “P”...
Page 77: Automatic Transmission
04 05.18 Automatic transmission Your automatic transmission has a shift lock system to minimize the possibility of incorrect operation. This means you can Lock release button only shift out of “P” position when the To prevent misshifting Selector lever brake pedal is depressed (with the ignition switch in “ON”...
Page 78 04 05.18 (c) Normal driving 3. Release the parking brake and brake pedal. Depress the accelerator pedal 1. Start the engine as instructed in “How slowly for smooth starting. to start the engine” in Section 3. The transmission must be in “P” or “N”. (d) Using engine braking 2.
Page 79 04 05.18 (g) Parking NOTICE CAUTION 1. Bring the vehicle to a complete stop. z Be careful not to overrev the en- 2. Pull the parking brake lever up fully to Be careful when downshifting on a gine. The approximate maximum al- securely apply the parking brake.
Page 80: Manual Transmission
04 05.18 Manual transmission Low altitude CAUTION —1219 m (4000 ft.) or lower gear km/h (mph) Always keep your foot on the brake 1 to 2 or 2 to 1 24 (15) pedal while stopped with the engine 2 to 3 or 3 to 2 40 (25) running.
Page 81: Parking Brake
04 05.18 Parking brake Downshift to the appropriate gear if accel- Good driving practice eration is needed when you are cruising If it is difficult to shift into reverse, put below the above downshifting speeds. the transmission in neutral, release the Upshifting too soon or downshifting too clutch pedal momentarily, and then try late will cause lugging, and possibly ping-...
Page 82 04 05.18 CAUTION Before driving, be sure the parking brake is fully released and the park- ing brake reminder light is off. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 83 04 05.18 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Air conditioning system Controls ........... . Air flow selector settings .
Page 84: Controls
04 05.18 Controls 1. “A/C” Button (on some models) 2. Air intake selector 3. Air flow selector 4. Fan speed selector 5. Temperature selector SU18011a 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 85 04 05.18 Fan speed selector 5. Windshield—Air flows mainly from the windshield vents. Turn the knob to adjust the fan speed—to the right to increase, to the left to de- Use with the air intake selector posi- crease. tioned in FRESH. For details about air flow selector settings, Temperature selector see “Air flow selector settings”...
Page 86 04 05.18 “A/C” button To turn on the air conditioning, press the “A/C” button. The “A/C” button indicator will come on. To turn the air conditioning off, press the button again. SZ18009a Air intake selector Move the lever to select the air source. 1.
Page 87: Air Flow Selector Settings
04 05.18 Air flow selector settings Operating tips To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly.
Page 88 04 05.18 When driving on dusty roads, close all Heating Air conditioning windows. If dust thrown up by the ve- For best results, set controls to: For best results, set controls to: hicle is still drawn into the vehicle after closing the windows, it is recommended Fan speed—Any setting except “OFF”...
Page 89: Instrument Panel Vents
04 05.18 Instrument panel vents Defogging Defrosting —Center vents —Side vents The inside of the windshield The outside of the windshield Close Close For best results, set controls to: For best results, set controls to: Fan speed—Any setting except “OFF” Fan speed—Any setting except “OFF”...
Page 90 04 05.18 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 91 04 04.06 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Other equipment Cigarette lighter and ashtray ........Glove box .
Page 92: Cigarette Lighter And Ashtray
“ACC” position to use the light- case of an accident or a sudden stop, always keep glove door Do not hold the cigarette lighter pressed closed while driving. Use a Toyota genuine cigarette lighter or equivalent for replacement. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 93: Auxiliary Boxes
04 04.06 Auxiliary boxes NOTICE Instrument panel: During hot weather, the interior of the vehicle becomes very hot. Do not leave anything flam- mable or deformable such as a light- SU19005 SU19004a er, glasses, etc. inside. Instrument panel Passenger’s seat To use the box, pull on the handle.
Page 94: Cup Holders
04 04.06 Cup holders Grocery bag hook SZ19005 SU19014a SU19017a Type A Type C This hook is designed to hang thing like grocery bag. The cup holder is designed for holding To use the hook, pull it down. cups drink−cans securely holes.
Page 95: Luggage Cover
04 04.06 Luggage cover Floor mat SU19013 SX19001 SP19003 When you open the back door, the lug- Use a floor mat of the correct size. CAUTION gage cover tilts up for easy access to If the floor carpet and floor mat have two the luggage area.
Page 96 04 04.06 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 97 ....... Your Toyota’s identification ........
Page 98: Break−In Period
To help prevent gas station mix−ups, your to the future economy and long life of steady speed on level roads, consult your Toyota has a smaller fuel tank opening. your vehicle: Toyota dealer. The special nozzle on pumps with un-...
Page 99 Toyota, be sure that it has an octane try changing gasoline brands. If this does The WWFC consists of three categories rating no lower than 87.
Page 100: Operation In Foreign Countries
04 05.18 Operation in foreign countries Three−way catalytic converter If you plan to drive your Toyota in CAUTION another country... First, comply with the vehicle registration Keep people and combustible mate- laws. rials away from the exhaust pipe Second, confirm the availability of the cor- while the engine is running.
Page 101: Engine Exhaust Cautions
Remember, your Toyota time to time. If you hit something, cause the engine to misfire, creat- dealer knows your vehicle and its or notice a change in the sound of ing an excessive load on the three−...
Page 102: Facts About Engine Oil Consumption
04 05.18 Facts about engine oil consumption FUNCTIONS OF ENGINE OIL Oil is also used to lubricate the stems Keep the back door closed while of the intake valves. Some of this oil Engine oil has the primary functions of driving.
Page 103: Brake System
Therefore, it pedal pressure. There is enough reserved is essential that the oil level be checked vacuum for one or two stops but no more! regularly. Toyota recommends that the oil level be checked every time you refuel the vehicle. NOTICE...
Page 104 04 05.18 When the anti−lock brake system is ac- Effective way to press the ABS brake CAUTION tivated, the following conditions may pedal: occur. They do not indicate a malfunc- When the anti−lock brake system func- Do not pump the brake pedal if the tion of the system: tion is in action, you may feel the brake engine stalls.
Page 105 04 05.18 CAUTION Anti−lock brake system is not de- signed to shorten the stopping dis- overestimate anti−lock tance: Always drive at a moderate brake system: Although the anti−lock speed and maintain a safe distance brake system assists in providing ve- from the vehicle in front of you.
Page 106: Brake Pad Wear Limit Indicators
This is the primary identification number checked and replaced by your Toyota for your Toyota. It is used in registering dealer as soon as possible. Expensive ro- the ownership of your vehicle. tor damage can result if the pads are not replaced when necessary.
Page 107: Suspension And Chassis
04 05.18 —Engine number Suspension and chassis CAUTION Do not modify the suspension/chassis with lift kits, spacers, springs, etc. It can cause dangerous vehicle handling SU21006a SU21007a characteristics, resulting in loss of control. The vehicle identification number (VIN) is The engine number is stamped on the also on the Certification Label.
Page 108: Tire Information
04 05.18 Tire information— —Tire symbols (Standard tire) This illustration indicates typical tire symbols. 1. Tire size—For details, see “Tire size” on page 112. 2. DOT and Tire Identification Number (TIN)—For details, see “DOT and Tire Identification Num- ber (TIN)” on page 111. 3.
Page 109 04 05.18 6. “TUBELESS” “TUBE TYPE”—A tubeless tire does not have a tube inside the tire and air is directly filled in the tire. A tube type tire has a tube inside the tire and the tube maintains the air pressure.
Page 110 04 05.18 —Tire symbols (Compact spare tire) This illustration indicates typical tire symbols. 1. “TEMPORARY USE ONLY”—A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded into its sidewall. This tire is designed for temporary emergency use only. For details, see “Compact spare tire”...
Page 111 04 05.18 —DOT and Tire Identification Number (TIN) 6. Maximum cold tire inflation The “DOT” symbol certifies that the pressure—This means the pres- tire conforms to applicable Federal sure to which a tire may be in- Motor Vehicle Safety Standards. flated.
Page 112 04 05.18 —Tire size —Name of each section of tire SU21014a SU21026a This illustration indicates typical tire 1. Section width 1. Bead size. 2. Tire height 2. Sidewall 1. Tire (P=Passenger car, 3. Wheel diameter 3. Shoulder T=Temporary use) 4. Tread 2.
Page 113 150 would wear conditions on specified government purchasers of Toyota vehicles with in- one and a half (1−1/2) times as well test surfaces of asphalt and concrete. formation on uniform tire quality grad-...
Page 114 04 05.18 Temperature A, B, C—The tempera- ture grades are A (the highest), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 115 04 05.18 —Glossary of tire terminology Tire related term Meaning tire inflation pressure when the vehicle has been parked for at least 3 hours Cold tire inflation pressure or more, or it has not been driven more than 1.5 km or 1 mile under that condition the maximum cold inflation pressure to which a tire may be inflated and it is Maximum inflation pressure...
Page 116 04 05.18 Tire related term Meaning the combined weight of those installed regular production options weighing over 2.3 kg (5 lb.) in excess of those standard items which they replace, not pre- Production options weight viously considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim Vehicle capacity weight the rated cargo and luggage load plus 68 kg (150 lb.) times the vehicle’s desig-...
Page 117 04 05.18 Tire related term Meaning the load on an individual tire that is determined by distributing to each axle its share of the curb weight, accessory weight, and normal occupant weight Vehicle normal load on the tire (distributed in accordance with Table 1 that follows) and dividing by two Weather side the surface area of the rim not covered by the inflated tire 2005 ECHO HATCHBACK from Jul.
Page 118 04 05.18 Table 1–Occupant loading and distribution for vehicle normal load for various designated seating capacities Designated seating capacity, Vehicle normal load, Occupant distribution in a normally Number of occupants Number of occupants loaded vehicle 2 through 4 2 in front 5 through 10 2 in front, 1 in second seat 2005 ECHO HATCHBACK from Jul.
Page 119: Vehicle Load Limits
04 05.18 Vehicle load limits Vehicle load limits include total load Towing capacity: CAUTION capacity, seating capacity, towing ca- 318 kg (700 lb.) pacity and cargo capacity. Follow the Towing capacity means the maximum Do not apply the load more than load limits shown below.
Page 120: Cargo And Luggage
04 05.18 Cargo and luggage— —Stowage precautions When stowing cargo and luggage in NOTICE D Never allow anyone to ride in the vehicle, observe the following: the luggage compartment. It is Do not load the vehicle beyond D Put cargo and luggage in the lug- not designed for passengers.
Page 121 04 05.18 —Capacity and distribution Cargo capacity depends on the to- 4. The resulting figure equals the tal weight of the occupants. available amount of cargo and lug- gage load capacity. For example, (Cargo capacity) = (Total load capac- if the “XXX” amount equals 1400 ity) –...
Page 122: Types Of Tires
04 05.18 Types of tires 114 kg – 100 kg = 14 kg. Determine what kind of tires your CAUTION (251 lb. – 221 lb. = 30 lb.) vehicle is originally equipped with. As shown in the above example, if the 1.
Page 123 04 05.18 All season tires, however, do not have adequate traction performance compared with snow tires in heavy or loose snow. Also, all season tires fall short in acceleration and handling performance compared with summer tires in highway driving. The details about how to distinguish summer tires from all season tires are described on page 108.
Page 124 04 05.18 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 125 04 04.06 SECTION STARTING AND DRIVING Before starting the engine ........How to start the engine .
Page 126: Before Starting The Engine
04 04.06 How to start the engine— (a) Before cranking Before starting the engine (b) Starting the engine 1. Check the area around the vehicle be- 1. Apply the parking brake firmly. Before starting the engine, be sure to fore entering it. follow instructions “(a)
Page 127: Tips For Driving In Various Conditions
Other- work safely, pull to the side of the road wise, the impact could cause severe and call a Toyota dealer for assistance. damage to the tires and/or wheels. When parking on a hill, turn the front...
Page 128: Winter Driving Tips
If you are not sure about Do not drive in excess of the speed brid organic acid technology. (Coolant with which oil to use, call your Toyota deal- limit. Even if the legal speed limit long−life hybrid organic acid technology is er—they will be pleased to help.
Page 129: Dinghy Towing
04 04.06 Dinghy towing Dinghy towing (with automatic transmission) (with manual transmission) Do not use your parking brake when there is a possibility it could freeze. When parking, put the transmission into “P” (automatic) or into first or reverse (manual) and block the rear wheels. Do not use the parking brake, or snow or SU31006a SU31007a...
Page 130: Trailer Towing
Toyota warranties do not apply to damage or NOTICE malfunction caused by towing a trailer for commercial purposes.
Page 131 04 04.06 WEIGHT LIMITS Trailer hitch assemblies have differ- Before towing, make sure the total trailer ent weight capacities established by weight, gross vehicle weight, gross axle the hitch manufacturer. Even though weight and trailer tongue load are all with- the vehicle may be physically capa- in the limits.
Page 132 04 04.06 HITCHES The load on either the front or rear Use only a hitch (Toyota genuine hitch Total trailer weight Tongue load axle resulting from distribution of or equivalent) which is recommended the gross vehicle weight on both by the hitch manufacturer and conforms axles must not exceed the Gross to the total trailer weight requirement.
Page 133 BREAK−IN SCHEDULE loaded so that it can not shift. trailer wandering over into another Toyota recommends that you do not Check that your rear view mirrors con- lane. tow a trailer with a new vehicle or a...
Page 134 04 04.06 TRAILER TOWING TIPS Because stopping distance may be in- Crosswinds and rough roads will ad- creased, vehicle−to−vehicle distance versely affect handling of your vehicle When towing a trailer, your vehicle will should be increased when towing a and trailer, causing sway. Pay attention handle differently than when not tow- trailer.
Page 135 04 04.06 Because of the added load of the trail- When restarting out after parking on a CAUTION er, your vehicle’s engine may overheat slope: on hot days temperatures over 1. With the transmission in “P” position Do not exceed 72 km/h (45 mph) or 30°C [85°F]) when going up a long or (automatic) or the clutch pedal de- posted...
Page 136: How To Save Fuel And Make Your Vehicle Last Longer, Too
04 04.06 How to save fuel and make your vehicle last longer, too Improving fuel economy is easy–just take Avoid long engine idling. If you have Maintain a moderate speed on high- it easy. It will help make your vehicle last a long wait and you are not in traffic, ways.
Page 137 04 04.06 Keep your vehicle tuned−up and in shape. dirty cleaner, improper valve clearance, dirty plugs, dirty grease,brakes adjusted, etc. lower engine performance and contribute to poor fuel economy. For longer life of all parts and lower operating costs, keep all maintenance work on schedule, and if often drive...
Page 138 04 04.06 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 139: In Case Of An Emergency
04 05.18 SECTION IN CASE OF AN EMERGENCY If your vehicle will not start ........If your engine stalls while driving .
Page 140: If Your Vehicle Will Not Start
If the engine still will not start, it needs goes when starter adjustment or repair. Call a Toyota dealer cranked, the battery is discharged. You or qualified repair shop for assistance. may try jump starting. See “(c) Jump starting” for further instructions.
Page 141 04 05.18 (c) Jump starting To avoid serious personal injury and JUMP STARTING PROCEDURE The gas normally produced by a damage to your vehicle which might re- 1. If the booster battery is installed in battery will explode if a flame or sult from battery explosion, acid burns, another vehicle, make sure the vehicles spark is brought near.
Page 142 04 05.18 Jumper cable Negative terminal (“–” mark) Discharged battery SY41001 SY41002 SF41001 Positive terminal Positive (“+” mark) terminal Jumper cable Discharged (“ ” mark) Booster battery Booster battery battery Connecting point 4. Make the cable connections in the or- c.
Page 143: If Your Engine Stalls While Driving
(for example, lights left on), will not work so steering and braking Wait until the steam subsides before you should have it checked at your Toyota will be much harder than usual. opening the hood. If there is no coolant dealer.
Page 144: If You Have A Flat Tire
You should have it checked as a highway. Park on a level spot soon as possible at your Toyota dealer. CAUTION with firm ground. 2. Stop the engine and turn on your When the engine is running, keep emergency flashers.
Page 145 04 05.18 D Do not put any part of your D Use the jack only for lifting body under the vehicle sup- your vehicle during wheel ported by the jack. Personal in- changing. jury may occur. D Do not raise the vehicle with D Do not start or run the engine someone in the vehicle.
Page 146 04 05.18 The compact spare tire saves space NOTICE CAUTION in your luggage compartment, and its lighter weight helps to improve fuel Your ground clearance is re- D The compact spare tire was de- economy and permits easier installa- duced when the compact spare signed especially for your To- tion in case of a flat tire.
Page 147 04 05.18 —Required tools and spare tire SU41111b SU41114b SU41121a 1. Get the required tools and Tool tray Glove box spare tire. 1. Jack handle Tie−down belt 1. Tool tray 2. Wheel nut wrench To prepare yourself for an emergency, 2.
Page 148 04 05.18 SM41002 SU41112b SU41115b To remove the jack, move the driver To remove the spare tire: seat to the front−most position and re- 1. Remove the spacer. move the cover. 2. Remove the spare tire cover. To remove: Turn the joint in direction 3.
Page 149 04 05.18 —Blocking the wheel —Loosening wheel nuts When storing the spare tire, put it in place with the outer side of the wheel facing up. Then secure the tire by re- peating the above removal steps in reverse order to prevent it from flying forward during a collision or sudden SY41007 SY41012...
Page 150 04 05.18 —Positioning the jack —Raising your vehicle CAUTION Never use oil or grease on the bolts or nuts. The nuts may loos- en and the wheels may fall off, SU41125 SU41126 which could cause a serious ac- cident. 4. Position the jack at the correct 5.
Page 151 04 05.18 —Changing wheels CAUTION Never get under the vehicle when the vehicle is supported by the jack alone. SY41016 SY41015 6. Remove the wheel nuts and Before putting on wheels, remove any change tires. corrosion on the mounting surfaces with a wire brush or such.
Page 152 04 05.18 —Reinstalling wheel nuts —Lowering your vehicle CAUTION Never use oil or grease on the bolts or nuts. Doing so may lead to overtightening the nuts and SU41131a SU41127 damaging the bolts. The nuts may loosen and the wheels may fall off, which could cause a seri- ous accident.
Page 153 04 05.18 —Stowing flat tire 9. Restow all the tools and jack se- CAUTION curely. Then secure the flat tire and the spare tire cover with the D When lowering the vehicle, tire tie−down belts and the ISO- make sure all portions of your FIX bar in the luggage compart- body and all other persons ment as follows.
Page 154 04 05.18 SU41116c SU41117a SU41118b Put the belt on the ISOFIX bar. Place a flat tire against the seatback Put the spare tire cover against the with the tire in an upright position. flat tire, and then pass the rest of the belt hooks thorough the hole in the Pass one of the belt hooks through cover.
Page 155 04 05.18 —After changing wheels 10.Check the air pressure of the re- placed tire. Adjust the air pressure to the specifi- cation designated on page 217 in Section 8. If the pressure is lower, SU41119d SU41120a drive slowly to the nearest service station and fill to the correct pressure.
Page 156: If Your Vehicle Becomes Stuck
04 05.18 If your vehicle needs to be If your vehicle becomes stuck towed— If your vehicle becomes stuck in snow, NOTICE (a) Towing with wheel lift type truck— mud, sand, etc., then you may attempt to rock the vehicle free by moving it —From front If you rock your vehicle, observe the forward and backward.
Page 157 If towing is necessary, we recommend (a) Towing with wheel lift type truck Automatic transmission: you to have it done by your Toyota From front—Release the parking brake. Use a towing dolly under the front dealer or a commercial tow truck ser- wheels.
Page 158 04 05.18 —Emergency towing If towing is necessary, we recommend (c) Towing with sliding type you to have it done by your Toyota truck dealer or a commercial tow truck ser- vice. If a towing service is not available in...
Page 159 04 05.18 —Installing front towing eyelet A driver must be in the vehicle to steer NOTICE it and operate the brakes. z Use only a cable or chain specifi- Towing in this manner may be done only cally intended for use in towing ve- on hard−surfaced roads for a short dis- hicles.
Page 160 04 05.18 SH41013a SU41124 SZ41022 2. Remove the front towing eyelet cover 3. Secure the front towing eyelet to the 4. Tighten the front towing eyelet securely on the front bumper, using a flat− hole on the bumper by turning clock- by a wheel nut wrench.
Page 161: If You Cannot Shift Automatic Transmission Selector Lever
If you cannot shift automatic transmission selector lever If you lose your keys You can purchase a new key at your Toyota dealer if you can give them the key number. See the suggestion given in “Keys” in Section 1−2.
Page 162 04 05.18 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 163: Corrosion Prevention And Appearance Care
CORROSION PREVENTION AND APPEARANCE CARE Protecting your Toyota from corrosion ......Washing and waxing your Toyota .
Page 164 Now, it is up to be dry. to see all the mud and dirt. It will do you. Proper care of your Toyota can help more harm than good to simply wet the High temperatures will cause corrosion ensure long−term corrosion prevention.
Page 165 04 05.18 Washing and waxing your Toyota Check the interior of your vehicle. Wa- Washing your Toyota 1. Rinse off loose dirt with a hose. Re- ter and dirt can accumulate under the move any mud or road salt from the...
Page 166 To prevent damage to the antenna, damage. low the manufacturer’s instructions and make sure to remove it before driving precautions. Be sure to polish and wax your Toyota through an automatic car the chrome trim as well as the paint. 3. Rinse thoroughly—dried soap wash.
Page 167 04 05.18 Cleaning the interior Vinyl interior Carpets CAUTION The vinyl upholstery may be easily Use a good foam−type shampoo to cleaned with a mild soap or detergent clean the carpets. Do not wash the vehicle floor with and water. Begin by vacuuming thoroughly to remove water, or allow water to get onto the First vacuum over the upholstery to re-...
Page 168 04 05.18 Windows Leather Interior NOTICE The leather upholstery may be cleaned The windows may be cleaned with any z Do not use organic substances (sol- with neutral detergent for wool. household window cleaner. vents, kerosene, alcohol, gasoline, Remove dirt using a soft cloth dampened NOTICE etc.) or alkaline or acidic solutions.
Page 169 Improper cleaning of the leather up- holstery could result in discolor- ation or staining. If you have any questions about the cleaning of your Toyota, your local Toyota dealer will be pleased to answer them. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 170 04 05.18 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 171 04 05.18 SECTION VEHICLE MAINTENANCE AND CARE Maintenance requirements ........General maintenance .
Page 172: Maintenance Requirements
Simple instructions for how to per- or if you prefer, your Toyota dealer will be without invalidating this warranty. See form them are presented in Section 7. pleased to do them at a nominal cost. “Owner’s Warranty Information Booklet”...
Page 173: General Maintenance
Radiator, condenser and hoses Supplement” for the details. vehicle to your Toyota dealer or a quali- Check that the front of the radiator and fied service shop immediately. It is recom- condenser are clean and not blocked with mended that any problem you notice be leaves, dirt or insects.
Page 174 04 05.18 Exhaust system Seats Parking brake If you notice any change in the sound of Check that all front seat controls such as Check that the lever has the proper travel and that, on a safe incline, your vehicle the exhaust or smell exhaust fumes, have seat adjusters, seatback recliner, etc.
Page 175: Does Your Vehicle Need Repairing
Be on the alert for changes in perfor- If you notice any of these clues, take your mance, sounds, and visual tip−offs that vehicle to your Toyota dealer as soon as Check the pressure with a gauge ev- indicate service is needed. Some impor- possible.
Page 176: Emissions Inspection And Maintenance (I/M) Programs
Toyota dealer comes on. In this case, your vehicle may to prepare the vehicle for re−testing. not pass the I/M test and need to be repaired.
Page 177 04 04.06 SECTION − DO−IT−YOURSELF MAINTENANCE Introduction Engine compartment overview ....... Fuse locations .
Page 178: Engine Compartment Overview
04 04.06 Engine compartment overview 1. Windshield washer fluid tank 2. Engine oil filler cap 3. Power steering fluid reservoir 4. Brake fluid reservoir 5. Battery 6. Fuse blocks 7. Engine coolant reservoir 8. Radiator 9. Condenser SU71008 10. Electric cooling fan 11.
Page 179: Fuse Locations
Read separate Toyota Warranty statement for details and suggestions. This section gives instructions only for those items that are relatively easy for an SU71009c owner to perform. As explained in Section...
Page 180 04 04.06 CAUTION Do not get under your vehicle with Dispose of used oil and filter only just the body jack supporting it. Al- in a safe and acceptable manner. When the engine is running, keep ways use automotive jack stands or Do not dispose of used oil and fil- hands, clothing,...
Page 181: Parts And Tools
Do not drive with the air cleaner need to perform do−it−yourself mainte- filter removed, or excessive engine nance. Remember all Toyota parts are de- z Remember that battery and ignition wear could result. Also backfiring signed in metric sizes, so your tools must...
Page 182: Positioning The Jack
04 04.06 Positioning the jack CHECKING BRAKE FLUID ADDING WASHER FLUID Do not jack up Do not jack up Parts (if level is low): Parts: SAE J1703 or FMVSS No.116 DOT 3 Water brake fluid Washer fluid containing antifreeze (for winter use) Tools: SH71009...
Page 183 04 04.06 CAUTION Do not raise the vehicle with some- one in the vehicle. When jacking, be sure to observe the When raising the vehicle, do not following to reduce the possibility of place any objects on top of or un- personal injury: derneath the jack.
Page 184 04 04.06 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 185 04 04.06 SECTION − DO−IT−YOURSELF MAINTENANCE Engine and Chassis Checking the engine oil level ....... . . Checking the engine coolant level .
Page 186: Checking The Engine Oil Level
Engine oil selection full If the oil level is below or only slightly “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved above the low level, add engine oil of the same type as already in the engine.
Page 187 04 04.06 Recommended viscosity: Oil identification marks SAE 5W−30 Either or both API registered marks are added to some oil containers to help you select the oil you should use. The API Service Symbol is located any- SOIL13 where on the outside of the container. The top portion of the label shows the oil quality by API (American Petroleum Insti- OIL008...
Page 188: Checking The Engine Coolant Level
Please contact your Toyota dealer for fur- “Toyota Super Long Life Coolant” is a mix- If you can find no leak, have your Toyota ther details about “Toyota Genuine Motor ture of 55% coolant and 45% deionized dealer test the cap pressure and check Oil”.
Page 189: Checking The Radiator And Condenser
Checking the radiator and condenser Checking brake fluid If any of the above parts are extremely dirty or you are not sure of their condi- tion, take your vehicle to a Toyota dealer. CAUTION Z72109 SU72002 To prevent burning yourself, be care- ful not to touch the radiator or con- denser when the engine is hot.
Page 190: Checking Power Steering Fluid
04 04.06 Checking power steering fluid Remove and replace the reservoir cap by Check the fluid level through the reser- hand. Fill the brake fluid to the dotted voir. If necessary, add automatic trans- line. This brings the fluid to the correct mission fluid DEXRONrII or III.
Page 191: Checking Tire Inflation Pressure
04 04.06 Checking tire inflation pressure f. After replacing the reservoir cap and rubber cap, visually check the steering If cold add box case, vane pump and hose con- If cold O.K. nections for leaks or damage. CAUTION SU72010 The reservoir tank may be hot so be careful not to burn yourself.
Page 192 04 04.06 Keep your tire inflation pressures D Always use a tire pressure Tire pressure gauge at the proper level. gauge. The appearance of a tire can be misleading. Besides, tire The recommended cold tire inflation inflation pressures that are even pressures, tire sizes and the com- just a few pounds off can degrade bined weight of occupants and cargo...
Page 193 If a tire frequently needs refilling, have it checked by your Toyota deal- 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 194: Checking And Replacing Tires
04 04.06 Checking and replacing tires The tires on your Toyota have built−in If air loss occurs while driving, do not Tread wear indicator tread wear indicators to help you continue driving. Driving even a short know when the tires need replace- distance can damage a tire beyond ment.
Page 195 Toyota recommends all four tires, or at least both of the front or rear tires be replaced at a time as a set. See “If you have a flat tire” in Section 4 for tire change procedure.
Page 196: Rotating Tires
Do not install studded tires without first checking local regulations for To equalize the wear and help ex- possible restrictions. tend tire life, Toyota recommends that you rotate your tires accord- CAUTION ing to the maintenance schedule. (For scheduled maintenance infor-...
Page 197 04 04.06 SNOW TIRE INSTALLATION TIRE CHAIN SELECTION CAUTION Snow tires should be installed on all Use the tire chains of correct size and wheels. type. Do not exceed 50 km/h (30 mph) or Installing snow tires on the front wheels Use SAE Class “S”...
Page 198: Replacing Wheels
When balancing your wheels, use only tires, too. Do not use wheels other than the Toyota balance weights or equivalent Correct replacement wheels are available and a plastic or rubber hammer. manufacturer’s recommended size, as at your Toyota dealer.
Page 199 04 04.06 SECTION − DO−IT−YOURSELF MAINTENANCE Electrical components Checking battery condition ........Battery recharging precautions .
Page 200: Checking Battery Condition
04 04.06 Checking battery condition— —Precautions —Checking battery exterior CAUTION If electrolyte gets on your skin, Hold−down clamp thoroughly wash the contact area. If BATTERY PRECAUTIONS you feel pain or burning, get medi- cal attention immediately. The battery produces flammable and explosive hydrogen gas.
Page 201 04 04.06 —Checking battery condition Charging necessary. Have battery DARK WHITE NOTICE Type A checked by your Toyota dealer. Clear or z Be sure the engine and all accesso- Dark Green light yellow ries are off before performing main- CLEAR tenance.
Page 202: Battery Recharging Precautions
04 04.06 Battery recharging precautions Checking and replacing fuses During recharging, the battery is pro- ducing hydrogen gas. Type A Therefore, before recharging: 1. If recharging with the battery installed on the vehicle, be sure to disconnect SU73062 the ground cable. 2.
Page 203: Adding Washer Fluid
Have your Toyota dealer correct it as light comes on, the washer tank may be soon as possible. empty. Add washer fluid.
Page 204: Replacing Light Bulbs
Side turn signal ∗ Toyota dealer. Halogen bulbs have pressurized gas lights inside and require special handling. Rear turn signal They burst shatter PY21W lights scratched or dropped. Hold a bulb only by its plastic or metal case.
Page 205 04 04.06 —Headlights ∗ : Side turn signal lights should be re- placed as an assembly. A: HB2 halogen bulbs B: Single end bulbs (amber) C: Wedge base bulbs D: Wedge base bulbs (amber) SH73015 SH73016 E: Double end bulbs 1.
Page 206 Make sure the rubber cover fits securely on the connector and the headlight body. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- SH73050 SU73064a essary, contact your Toyota dealer. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 207 04 04.06 —Front turn signal lights SU73059b SU73060a SH73022d Right side SU73065a SH73023c Left side 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 208 04 04.06 —Stop/tail and rear side marker, rear turn signal, back−up lights —Side turn signal lights Front of vehicle SU73061 SH73026 SH73028 a: Rear turn signal light b: Stop/tail and rear side marker lights c: Back−up lights SH73027 SH73029 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 209 04 04.06 —License plate lights —High mounted stoplight SU73063 SH73039 SH73034 SH73038 SH73035 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 210 04 04.06 SH73036 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 211 04 04.06 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 212 04 04.06 SECTION SPECIFICATIONS Dimensions and weights ........Engine .
Page 213: Dimensions And Weights
04 04.06 Dimensions and weights Engine Fuel Overall length mm (in.) 3735 (147.0) Model: Fuel type: Overall width mm (in.) 1660 (65.4) 1NZ−FE Unleaded gasoline, Octane Rating 87 Overall height mm (in.) 1500 (59.1) (Research Octane Number 91) or higher Type: Wheelbase mm (in.)
Page 214: Service Specifications
ILSAC multigrade engine oil Manual transmission 4.4 (4.7, 3.9) Exhaust 0.25—0.35 (0.010—0.014) Automatic transmission 4.3 (4.5, 3.8) Please contact your Toyota dealer for fur- ther details. Spark plug type: Coolant type: DENSO K16R−U Recommended oil viscosity: “Toyota Super Long Life Coolant” is...
Page 215 Pedal free play, mm (in.): MANUAL TRANSAXLE changing the automatic transmission fluid, 1—6 (0.04—0.24) use only “Toyota Genuine ATF Type T−IV” Oil capacity, L (qt., Imp. qt.): (ATF JWS3309 or NWS6500) to aid in Pad wear limit, mm (in.): 1.9 (2.0, 1.7) assuring optimum transaxle performance.
Page 216: Tires
04 04.06 Tires Fuses Tire size and cold tire inflation pressure: Tire size kPa (kgf/cm or bar, psi) Standard P175/65R14 81S 220 (2.2, 32) SU81005 SU81006 Spare T115/70D14 420 (4.2, 60) Wheel size: Standard14 x 5 1/2J, 14 x 5 1/2JJ Spare 14 x 4T Wheel nut torque, N·m (kgf·m,...
Page 217: Fuses
04 04.06 21. HAZ 10 A: Turn signal lights, emergen- 33. ALT 120 A: “ECU−B”, “TAIL”, “D/L”, cy flashers “OBD”, “A.C”, “HTR”, “POWER”, “STOP” and “DEF” fuses 22. STOP 10 A: Stop lights, high mounted stop light, anti−lock brake system, shift 34.
Page 218 When it comes to service, remember that your Toyota dealer knows your vehicle very well and is interested in your complete satisfaction. Your Toyota dealer will provide quality maintenance and any other assistance you may require. If there is not a Toyota dealer near you, or you need emergency assistance for any reason, please call the following number: CANADIAN OWNERS: Toyota Canada Customer Interaction Centre Toll−free:1−888−TOYOTA−8 (1−888−869−6828)
Page 219 04 05.19 U −6 Quick index D If a service reminder indicator or warning buzzer comes on ..D If your vehicle will not start ........D If your engine stalls while driving .
Page 220: Important Information About This Manual
04 05.18 Important information about this manual Safety and vehicle damage warnings Safety symbol Throughout this manual, you will see safety and vehicle damage warnings. You must follow these warnings carefully to avoid possible injury or damage. The types of warnings, what they look like, and how they are used in this manual are explained as follows.
Page 221: Occupant Restraint Systems
None of these systems, either indi- Toyota encourages you and your family to take the time vidually or together, can ensure that there is no injury to read Section 1−3 of this Owner’s Manual carefully.
Page 222 In order to be effective, the SRS airbags must deploy with tremendous speed. The rapid deployment of the SRS airbags makes the SRS airbags themselves poten- Your new vehicle is covered by the following Toyota tial sources of serious injury if an occupant is too close limited warranties:...
Page 223 04 04.06 Your responsibility for Important health and safety maintenance information about your Toyota It is the owner’s responsibility to make sure that the CAUTION specified maintenance is performed. Section 6 gives de- tails of these maintenance requirements. Also included WARNING: Engine exhaust, some of its constitu- in Section 6 is general maintenance.
Page 224 Toyota Toyota A wide variety of non−genuine spare parts and accessories The spark ignition system in your Toyota meets all re- quirements of the Canadian Interference−Causing Equip- for Toyota vehicles are currently available in the market. You ment Standard.
Page 225 SRS airbag and seat belt pretensioner removed and disposed of by the quali- fied service shop or by your Toyota dealer before you dispose of your vehicle. 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 226 04 04.06 viii 2005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Page 227 The Toyota authorized Repair Manual is packed with literally everything you need to know to perform your own maintenance in virtually every area of your new vehicle.
Page 228 Toyota dealer. Areas covered include such things as spark plug re- Pub. Name: 2005 ECHO Repair Manual placement, valve clearance adjustment and engine oil Pub.
Page 229 04 04.06 WE REALLY CARE ABOUT YOU PLEASE BUCKLE UP Toyota has made a special effort to encourage use of seat belts. Toyota belts are: Comfortable Easy to use Convenient We encourage you to use your belts every time you drive.

This manual is also suitable for:

2004 yaris

Toyota 2005 Yaris Owner's Manual

1 2 Section −

1 3 Section −

1 4 Section −

1 5 Section −

1 6 Section −

1 7 Section −

1 8 Section −

1 9 Section −

2 Section

3 Section

Section

6 Section

7 1 Section −

7 2 Section −

7 3 Section −

Quick Links

Chapters

Related Manuals for Toyota 2005 Yaris

Summary of Contents for Toyota 2005 Yaris

This manual is also suitable for:

Table of Contents
