Page 1 Owner’s Manual For your safety and comfort, read carefully and keep in the vehicle.
Page 2 (drain and refill) Without oil filter 5.7 Litres Engine oil type Toyota Genuine Motor Oil or equivalent Refer to “Checking engine oil level” on page 260. Oil grade: 5W-30 and 10W-30: API grade SL, SM, SN or ILSAC multigrade engine oil...
Page 3 Quick Reference Table of contents Table of contents (iii), Pictorial Index (vi), For your information (xiv) Before driving Operating and adjusting features such as door locks, steering column and mirrors. When driving Starting, stopping and driving related information. Interior features Air conditioning, audio system and other useful features. Maintenance and care 247 Cleaning, maintenance requirements and do-it-yourself maintenance. When trouble arises 299 What to do if the vehicle needs to be towed, has a flat tyre or is involved in an accident. Vehicle specifications Detailed vehicle information. Alphabetical index Alphabetical listing of information contained in this manual. What to do if... / Service Station Information 348...
Page 5: Table Of Contents
CHILD RESTRAINT SYSTEM .... 6 4 TOYOTA AND PRIVACY .... x viii FLOOR MAT .
Page 6 INTERIOR LIGHTS ..... . 2 32 TOYOTA PARKING ASSIST-SENSOR .. 1 27 PERSONAL LIGHTS ..... 2 33 BLIND SPOT MONITOR (BSM) .
Page 7 Table of contents Do-it-yourself maintenance . . . . . . . . . . . .255 IF YOUR VEHICLE HAS TO BE STOPPED IN AN EMERGENCY ... 3 21 DO-IT-YOURSELF SERVICE STARTING A FLOODED ENGINE .
Page 8: Pictorial Index - Exterior
Pictorial Index - Exterior CONTENTS Pictorial Index - Exterior Maintenance Moon roof and care page 42 page 248 Windscreen wipers Outside rear & washers view mirrors page 115 page 38 Bonnet page 257 Turn signals page 82 Headlights (high beam) Parking lights page 108 page 108 Fog lights page 115 Parking Headlights...
Page 9 CONTENTS Pictorial Index - Exterior Rear window Power windows defogger page 162 page 40 Doors Rear view monitor system page 17 page 122 Blind spot monitor (BSM) Boot page 131 page 20 Fuel filler door page 45 Wheels License plate page 271 lights page 108 Tyres: Rotation Tail lights page 270 page 108 Replacement...
Page 10: Pictorial Index - Interior
Pictorial Index - Interior CONTENTS Pictorial Index - Interior Front head Rear console box restraints page 237 page 26 SRS driver airbag Seatbelts page 50 page 31 SRS knee airbag Power window switches page 50 page 40 SRS front passenger airbag page 50 vents page 161 Glove box Armrest page 236 page 30...
Page 11 CONTENTS Pictorial Index - Interior Vehicles Without Moon Roof Sun visors Personal lights page 242 page 232 Vanity mirrors Interior light page 243 page 232 Coat hooks page 246 Assist grips page 245 Anti-glare inside rear SRS curtain view mirror shield airbags page 37 page 50 Auxiliary box Microphone page 236 page 205...
Page 12 CONTENTS Pictorial Index - Interior Driving position Inside lock memory switches button page 28 page 18 Outside rear view mirror switches page 38 Window lock switch page 41 Power window Door lock switches switch page 18 page 40 Cup holders page 238 Power outlet page 240 Automatic transmission shift lever page 76, 79 Shift lock...
Page 13 CONTENTS Pictorial Index - Interior Gauges and Windscreen wiper meters and washer switch Multi-infomation page 115 display page 84 Clock Headlight switch page 240 page 108 Turn signal Touch-screen lever audio system page 82 page 163 Fog light switch Navigation page 115 system* Bonnet lock release lever page 257 Parking brake pedal...
Page 14 CONTENTS Pictorial Index - Interior Vehicles Without Paddle Shift Telephone Display switches switch page 204 page 103 Audio remote Talk switch* control switches page 202 Ignition switch (vehicles with standard Cruise control type ignition switch) switch page 120 page 69 Vehicles With Paddle Shift Paddle shift switches Display switch page 79...
Page 15 CONTENTS Pictorial Index - Interior Rear electric sunshade switch page 243 Cigarette Ashtray lighter page 241 page 242 Headlight AFS OFF cleaner switch switch page 114 page 119 Parking Blind spot assist-sensor monitor (BSM) switch main switch page 127 page 131 xiii...
Page 16 CONTENTS Pictorial Index - Interior Security Emergency indicator flasher page 47 page 300 Rear window defogger switch Automatic air conditioning system page 155 INSTRUMENT PANEL INDICATOR SYMBOLS Brake system warning light* Charging system warning light* Low engine oil pressure warning light* Malfunction indicator lamp* SRS warning light* Anti-lock brake system (ABS) warning light* Turn signal indicators (refer to page 82) Electric power steering (EPS) system warning light * Cruise control indicator light (refer to page 120) Cruise control set indicator (refer to page 120) Automatic high beam indicator light*...
Page 17 CONTENTS Pictorial Index - Interior Headlight high beam indicator (refer to page 108) Tail light indicator (refer to page 108) AFS OFF indicator* Front fog light indicator (refer to page 115) Open door warning light* Low fuel level warning light* Slip indicator light* Driver’s and front passenger’s seatbelt reminder lights (centre panel)* Rear passenger seatbelt reminder lights* Master warning light* High coolant temperature warning light (the right most segment of the light flashes) Eco driving indicator light (refer to page 138) Security indicator (centre panel - refer to page 91) For details refer to “Indicators and warning lights” on page 88. If this light comes on, refer to “Driving assist systems” on page 135. The light comes on in yellow to indicate a malfunction.
Page 18: Symbols
Cautions & Notices CAUTION This is a warning against anything which may result in serious injury or death to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others. NOTICE This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment. SAFETY SYMBOL Throughout this manual, you will also see the symbol of a circle with a slash through it. This indicates a serious warning, e.g. “Do not”, “Do not do this”, or “Do not let this happen”. ARROWS INDICATING OPERATIONS Indicates the action (pushing, turning, etc.) used to operate switches and other devices. Indicates the outcome of an operation (e.g. a lid opens). OWNER’S MANUAL Please note that this manual covers all models and all equipment, including options. Therefore, you may find information for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, due to Toyota’s product improvement policy, we reserve the right to make changes at any time without notice. For the latest vehicle specifications, please refer to www .toyota .com .au Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.
Page 19: Abbreviations
For your information ABBREVIATIONS Abbreviations Meaning Air Conditioning Anti-lock Brake System Accessory Adaptive Front-lighting System AI-SHIFT Artificial Intelligence Shift control Automatic Locking Retractor Blind Spot Monitor Child Restraint System DISP Display Economy/Ecology Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Light Emitting Diode Object Push Profile PBAP Phone Book Access Profile Supplemental Restraint System Traction Control Vehicle Identification Number Vehicle Stability Control ACCESSORIES, SPARE PARTS AND MODIFICATION OF YOUR TOYOTA A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. Using non-genuine products may adversely affect the safety of your vehicle, even though these parts may be approved by certain authorities in Australia. Toyota therefore cannot accept any liability or guarantee spare parts and accessories which are not genuine Toyota products, nor does Toyota accept responsibility for replacement or installation involving non-genuine parts. This vehicle should not be modified with non-genuine Toyota products. Modification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty. xvii...
Page 20: Way Radio System
For your information INSTALLATION OF A MOBILE TWO-WAY RADIO SYSTEM The installation of a mobile two-way radio system in your vehicle may affect electronic systems such as the multi-port fuel injection system / sequential multi-port fuel injection system, cruise control system, anti-lock brake system, SRS airbag system or seatbelt pretensioner system. Ensure to check with your Toyota dealer for precautionary measures or special instructions regarding installation. DISPOSING OF YOUR TOYOTA The SRS airbag and seatbelt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is disposed of with the airbags and seatbelt pretensioners left as they are, this may cause an accident such as fire. Ensure to have the systems of the SRS airbag and seatbelt pretensioner removed and disposed of by a qualified service centre or by your Toyota dealer before you dispose of your vehicle. SMART ENTRY AND START SYSTEM CAUTION Users of any electrical medical devices such as implanted pacemakers should consult the manufacturer of the device for information about its operation under the influence of radio waves. Radio waves could have unexpected effects on the operation of such medical devices. For details, refer to “Smart entry and start system” on page 7. TOYOTA AND PRIVACY Toyota is committed to protecting your privacy and is required to comply with the National Privacy Principles in the Privacy Act 1988 (Cth) when it collects and handles your personal information. This includes providing you with the right to access and correct your personal information (subject to some exceptions allowed by law). For further information about Toyota and privacy, please see the Toyota Privacy Policy (available at www.toyota.com.au). You can also contact us by calling 1800 252 097, or by sending your query to the Toyota Privacy Contact, PO Box 187 Caringbah, NSW, 2229, Australia. VEHICLE CONTROL AND OPERATION DATA RECORDING Your Toyota is equipped with sophisticated computers that record certain information about your vehicle’s operation, such as: • Engine speed • Accelerator status • Brake status • Vehicle speed • Shift position...
Page 21 The EDR in this vehicle is designed to record such data as: • How various systems in your vehicle were operating • How far (if at all) the driver was depressing the accelerator and / or brake pedal • How fast the vehicle was travelling. This data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: The EDR will not record data in all crash situations; no data is recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) is recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR. Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a government agency • For use by Toyota in a law suit. However, if necessary, Toyota may: • Use the data for research on vehicle safety performance • Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner.
Page 22 For your information CAUTION General precautions while driving • Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs (including prescription medications and over-the-counter preparations) that have impaired your ability to operate your vehicle. Please consult a medical practitioner to confirm whether medications may affect your ability to drive safely. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others. • Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. • Driver distraction: Always give your full attention to driving. Anything that distracts the driver, such as adjusting controls, talking on a mobile phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others. These activities may also be illegal. General precaution regarding children’s safety • Never leave children unattended in the vehicle, and never allow children to have or use the key. • Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. • Never leave children unattended in a vehicle as heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
Page 23: Before Driving
BEFORE DRIVING Key Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 KEYS (STANDARD TYPE IGNITION SWITCH) .
Page 24: Key Information
BEFORE DRIVING Key Information Key Information KEYS (STANDARD TYPE IGNITION SWITCH) Your vehicle is supplied with two kinds of keys. 1. Master keys– These keys work in every lock and include switches for the wireless remote control. 2. Sub key (grey)– This key will not work in the glove box or boot. To protect items locked in the boot or glove box when using valet parking, leave the sub key with the attendant. 3. Key number plate The master and sub keys contain a transponder chip for the engine immobiliser system. The chip is used to enable the system to function correctly, so be careful not to lose these keys. If you make your own duplicate key, you will not be able to cancel the immobiliser system or start the engine. NOTICE To prevent key damage • Do not drop the keys, subject them to strong shocks or bend them. • Do not expose the keys to high temperatures for long periods of time. • Do not get the keys wet or wash them in an ultrasonic washer, etc. • Do not attach metallic or magnetic materials to the keys or place the keys close to such materials. • Do not disassemble the keys. • Do not attach a sticker or anything else to the surface of the key.
Page 25: Smart Entry And Start System
BEFORE DRIVING Key Information Key Number Plate Your key number is shown on the plate. If you lose your keys or if you need additional keys, duplicates can be made by a Toyota dealer using the key number. NOTICE Keep the plate in a safe place and not in the vehicle. Write down the key number and store it in a safe place. KEYS (SMART ENTRY AND START SYSTEM) By carrying the key you can lock or unlock the doors, start the engine or open the boot lid. 1. Electronic keys– These keys operate the smart entry and start system and include switches for the wireless remote control. 2. Mechanical keys– These keys can lock or unlock the doors, but cannot start the engine. To protect items locked in the glove box when using valet parking, remove the mechanical key and leave the electronic key with the attendant. 3. Key number plate. The electronic keys contain a transponder chip for the engine immobiliser system. The chip is used to enable the system to function correctly, so be careful not to lose these keys. NOTICE Keys must not be left inside the vehicle as they will continue to communicate with the smart entry and start system. Using the mechanical key To remove the mechanical key, push the release button and slide the key out. • The mechanical key cannot start the engine.
Page 26 Carrying the electronic key on your person Carry the electronic key 10 cm or more away from electric appliances that are turned on. Radio waves emitted from electric appliances within 10 cm of the electronic key may interfere with the key, causing the key to not function correctly. In case of a smart entry and start system malfunction or other key-related problems Take your vehicle with all the electronic keys to your Toyota dealer. When a vehicle key is lost If a key is lost, the risk of vehicle theft increases significantly. Take your vehicle with all the electronic keys to your Toyota dealer. When travelling in an aircraft When bringing a key with wireless remote control function onto an aircraft, make sure you do not press any buttons on the key while inside the aircraft cabin. If you are carrying the key in your bag, etc., ensure the buttons are not likely to be pressed...
Page 27: Opening, Closing And Locking The Doors
BEFORE DRIVING Opening, closing and locking the doors Opening, closing and locking the doors WIRELESS REMOTE CONTROL The wireless remote control is used to lock or unlock the doors, open the boot lid, or sound the alarm system from a distance. Pressing a switch on the remote control performs the following operations. icles with standard type ignition switch 1. Locks all the doors. 2. Sounds the alarm (press and hold). 3. Unlocks all the doors. 4. Opens the driver’s window and moon roof (press and hold). (This is a customisable feature, refer to “Power windows and moon roof*” on page 337). 5. Opens the boot lid (press and hold). Vehicles with smart entry and start system 1. Locks all the doors.
Page 28 BEFORE DRIVING Opening, closing and locking the doors Panic mode Vehicles with standard type ignition switch When is pressed for longer than one second, an alarm will sound intermittently and the turn signal lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, press any button on the wireless remote control. Vehicles with smart entry and start system When is pressed for longer than one second, an alarm will sound intermittently and the turn signal lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, press any button on the wireless remote control. Security feature If a door is not opened within approximately 30 seconds after the vehicle has been unlocked, the security feature will automatically lock the vehicle again.
Page 29: Smart Entry And Start System
BEFORE DRIVING Opening, closing and locking the doors Key battery depletion If the wireless remote control function does not operate, the battery may be discharged. This is usually indicated by the range of the wireless remote control becoming shorter and / or the LED on the key not illuminating when a switch is pressed. Replace the battery when required, refer to “Replacing the remote control transmitter battery” on page 296. Customisable features that can be modified For further information refer to “Customisable features” on page 333. SMART ENTRY AND START SYSTEM The following operations can be performed simply by carrying the electronic key in your pocket, for example. It is recommended the driver always carry the electronic key. Electronic key Electronic key Electronic key CTY12AV203 1. Locks and unlocks all the doors. 2. Opens the boot lid. 3. Unlock the steering wheel and start the engine. For further information, refer to “Ignition switch (smart entry and start system)” on page 70 and “Starting the engine (smart entry and start system)” on page 72.
Page 30 BEFORE DRIVING Opening, closing and locking the doors CAUTION • People with implanted pacemakers or cardiac defibrillators should keep away from smart entry and start system antennas. This is because the radio waves may affect the operation of such devices. Refer to “Antenna location” on page 9. • Users of any electrical medical device other than implanted pacemakers and cardiac defibrillators should consult the manufacturer of the device for information about its operation under the influence of radio waves. This is because the radio waves could have unexpected affects on the operation of such medical devices. • If necessary, the entry function can be disabled. Refer to “Customisable features” on page 333. Unlocking and locking the doors Grip the driver’s or front passenger’s door handle to unlock all doors. • Make sure the sensor on the back of the handle is touched. • After the doors have been locked, they cannot be unlocked for 3 seconds. Touch the lock sensor (the indentation on the side of the door handle) to lock all doors. Opening the boot lid Press the button to open the boot lid.
Page 31 BEFORE DRIVING Opening, closing and locking the doors Antenna location The following antennas are used to detect the electronic key and allow operation of the smart entry and start system. 1. Antennas outside the cabin. 2. Antenna outside the boot lid. 3. Antenna inside the boot lid. 4. Antennas inside the cabin. Effective range The smart entry and start system will detect the electronic key within the following areas. When locking or unlocking the doors. The system can be operated when the electronic key is within about 0.7 m of either front outside door handle. (Only the door detecting the key can be operated.) When unlocking the boot lid. The system can be operated when the electronic key is within about 0.7 m of the boot lid release button. When starting the engine or changing ENGINE START STOP switch modes. The system can be operated when the electronic key is inside the vehicle. Operation signals Doors: A buzzer sounds and the turn signal lights flash to indicate the doors have been locked or unlocked. (Locked: once; Unlocked: twice) Boot lid: A buzzer sounds to indicate the boot lid has been opened.
Page 32 BEFORE DRIVING Opening, closing and locking the doors When the door cannot be locked by the lock sensor Use your palm to touch the lock sensor. NOTICE Consult your Toyota dealer if the smart entry and start system does not operate correctly because of a system malfunction. Bring all of the keys as they may be required to repair the system. Security feature If a door is not opened within approximately 30 seconds after the vehicle has been unlocked, the security feature automatically locks the vehicle again. However, depending on the location of the electronic key, the key may be detected as being in the vehicle. In this case, the vehicle may be unlocked. When the vehicle is not driven for extended periods To prevent theft of the vehicle, do not leave the electronic key within 2 metres of the vehicle. When the key is within this range the door locks can be operated by anyone. The smart entry and start system has a battery-saving function, refer to “Battery-saving function” on page 12, or it can be deactivated through customisation, refer to “Customisable...
Page 33 BEFORE DRIVING Opening, closing and locking the doors The following table describes circumstances and correction procedures when exterior or interior alarms are sounded. Alarm Situation Correction An attempt was made to lock Interior alarm pings the doors using the smart Retrieve the electronic key once and the exterior entry and start system while from the vehicle and lock the alarm sounds the electronic key was still doors again continuously inside the vehicle The boot lid was closed while Retrieve the electronic key the electronic key was still from the boot and close the inside the boot and all the boot lid Exterior alarm sounds doors were locked once for 5 seconds An attempt was made to lock Close all doors and lock the the vehicle while a door was doors again open An attempt was made to lock either front door by opening a door and pushing Interior alarm pings the inside lock button to the...
Page 34 BEFORE DRIVING Opening, closing and locking the doors Electronic key battery depletion The standard life of the electronic key battery is one to two years. If the battery becomes discharged, an alarm will sound in the cabin when the engine is stopped. As the electronic key is always receiving radio waves, the battery will become discharged even if the electronic key is not used. The following symptoms indicate the electronic key battery may be discharged. Replace the battery when necessary. • The smart entry and start system or the wireless remote control does not operate. • The detection area becomes smaller. • The LED indicator on the key does not illuminate. To avoid serious deterioration, do not leave the electronic key within 1 metre of the following electrical appliances that produce a magnetic field: • TVs • Personal computers • Mobile phones, cordless phones and battery chargers • Glass top stoves • Table lamps When the electronic key battery is fully discharged replace the battery. Refer to “Replacing the remote control transmitter battery” on page 296. Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time.
Page 35 BEFORE DRIVING Opening, closing and locking the doors Electronic key battery-saving function When battery-saving mode is set, battery depletion is minimised by stopping the electronic key from receiving radio waves. 1. Press twice while pressing and holding . 2. Confirm the electronic key indicator flashes four times. While the battery-saving mode is set, the smart entry and start system cannot be used. To cancel the function, press any of the electronic key switches. Function to prevent the electronic key being locked in the boot When all doors are locked, closing the boot lid while the electronic key is inside the boot will sound an alarm. In this case, the boot lid can be reopened using the entry function. NOTICE • If a spare electronic key is in the boot and all the doors are then locked, the boot lid can still be opened using the entry function.
Page 36 BEFORE DRIVING Opening, closing and locking the doors NOTICE Conditions that can affect operation The smart entry and start system uses weak radio waves. In the following situations, communication between the electronic key and the vehicle may be affected, preventing the smart entry and start system, wireless remote control and engine immobiliser system from operating normally. • When the electronic key battery is discharged. • Near a TV tower, electric power plant, petrol station, radio station, large display, airport or other facility that generates strong radio waves or electrical noise. • When the electronic key is in contact with, or is covered by the following metallic objects: – Cards to which aluminium foil is attached – Cigarette boxes that have aluminium foil inside – Metallic wallets or bags – Coins – Hand warmers made of metal – Media such as CDs and DVDs • When another wireless key (that emits radio waves) is being used nearby. • When carrying the electronic key together with the following devices that emit radio waves: –...
Page 37 BEFORE DRIVING Opening, closing and locking the doors NOTICE Notes for the entry function • Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: – The electronic key is too close to a window or an outside door handle, near the ground, or too high when the doors are locked or unlocked – The electronic key is near the ground or too high, or too close to the centre of the rear bumper when the boot lid is unlocked – The electronic key is on the instrument panel, rear package tray or floor, or in the door pockets or glove box when the engine is started or ENGINE START STOP switch modes are changed • Do not leave the electronic key on top of the instrument panel or near the door pockets when exiting the vehicle. Depending on the radio wave reception conditions, it may be detected by the antenna outside the cabin and the door will become lockable from the outside, possibly trapping the electronic key inside the vehicle. • As long as the electronic key is within the effective range, the doors may be locked or unlocked by anyone. • Even if the electronic key is not inside the vehicle, it may be possible to start the engine if the electronic key is near the window. • The doors may unlock if a large amount of water splashes on the door handle, such as in the rain or in a car wash when the electronic key is within the effective range.
Page 38 BEFORE DRIVING Opening, closing and locking the doors NOTICE When locking the doors • Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. • When the lock operation is performed using the lock sensor, recognition signals will be shown up to two consecutive times. After this, no recognition signals will be given. • When washing the vehicle, for example, if a front door handle is sprayed with a strong jet of water while the electronic key is within the effective range outside the vehicle, the door may lock and unlock repeatedly. In that case: – Place the electronic key in a safe location 2 metres or more from the vehicle – Set the electronic key to battery-saving mode to disable the smart entry and start system • If the electronic key is inside the vehicle and a front door handle is sprayed with a strong jet of water during a car wash, a buzzer may sound outside the vehicle. To turn off the alarm, lock all the doors. • The lock sensor may not work properly if it comes into contact with ice, snow or mud, etc. Clean the lock sensor and attempt to operate it again. When unlocking the doors • A sudden approach to the effective range outside the vehicle or front door handle may prevent the doors from being unlocked. In this case, return the door handle to the original position and check the doors unlock before pulling the door handle again.
Page 39: Doors
BEFORE DRIVING Opening, closing and locking the doors DOORS The doors can be locked and unlocked in the following ways. Locking and unlocking with wireless door control Pressing a switch on the key performs a wireless remote control operation such as locking or unlocking the doors, opening the boot lid, or sounding the alarm. For further details refer to “Wireless remote control” on page 5. Locking and unlocking with smart entry and start system When you carry the electronic key into the activation area, you can lock and unlock the doors by grasping or touching a front door handle. For further information, refer to “Smart entry and start system” on page 7. Locking and unlocking with the key Vehicles with standard type ignition switch– Insert the key into the driver’s door handle keyhole and turn it.
Page 40 BEFORE DRIVING Opening, closing and locking the doors Locking and unlocking with the door lock switch All the doors lock or unlock simultaneously. 1. To lock: Press the switch down on the right side. 2. To unlock: Press the switch down on the left side. Locking and unlocking with the inside lock button Each door can be locked or unlocked. 1. To unlock: Pull the button backward. 2. To lock: Push the button forward. The driver’s door can be opened by pulling the inside door handle even if the lock button is in the lock position.
Page 41 BEFORE DRIVING Opening, closing and locking the doors Rear door child-protector lock When the child-protector switch is in the Lock position, the rear door cannot be opened by the inside door handle. The door can be opened normally from outside the vehicle. 1. Unlock. 2. Lock. NOTICE To avoid an accident, Toyota recommends the rear door child- protector lock feature is used whenever small children are in the vehicle. CAUTION Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. • Always wear a seatbelt and ensure it is correctly adjusted. • Ensure all doors are properly closed. • Always lock all the doors. • Do not pull the inside handle of the doors while driving. The door may open and an occupant fall out resulting in serious injury or death. • Be especially careful for the driver’s door, as the door can be opened even if the inside lock button is in the Lock position.
Page 42: Boot Lid
BEFORE DRIVING Opening, closing and locking the doors BOOT LID CAUTION Boot lid precautions • Ensure the boot lid is closed before driving. If the boot lid is left open, it may hit nearby objects while driving or luggage in the boot may be unexpectedly thrown out and cause an accident. Keeping the boot lid closed also prevents exhaust gases from entering the vehicle. • Before driving the vehicle, make sure the boot lid is fully closed. If the boot lid is not fully closed, it may open unexpectedly while driving, causing an accident. • Never let anyone sit in the boot. In the event of sudden braking or a collision, they are susceptible to death or serious injury. • When children are in the vehicle, observe the following precautions. Failure to do so may result in death or serious injury: – Do not allow children to enter the boot. If a child is accidentally locked in the boot, they could overheat or suffocate – Do not allow a child to open or close the boot lid. Doing so may cause the boot lid to operate unexpectedly, or cause the child’s hands, head, or neck to be caught by the closing boot lid...
Page 43 CAUTION When using the boot, observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in serious injury. • Remove any heavy loads, such as snow and ice, from the boot lid before opening it. Failure to do so may cause the boot lid to fall closed again after it is opened. • When opening or closing the boot lid, thoroughly check to make sure the surrounding area is safe. • If anyone is in the vicinity, make sure they are safe and let them know the boot is about to open or close. • Use caution when opening or closing the boot lid in windy weather as it may move abruptly in strong wind. • The boot lid may fall if it is not opened fully. It is more difficult to open or close the boot lid on an incline than on a level surface, so beware of the boot lid unexpectedly opening or closing by itself. Make sure the boot lid is fully open and secure before using the boot. • When closing the boot lid, take extra care to prevent your fingers etc. from being caught. • When closing the boot lid, press it lightly on its outer surface. If the handle is used to fully close the boot lid, it may result in hands or arms being caught. • Do not attach any accessories other than genuine Toyota parts to the boot lid. Such additional weight on the boot lid may cause the lid to fall closed again after it is opened.
Page 44 BEFORE DRIVING Opening, closing and locking the doors Opening the boot lid The boot lid can be opened in the following ways. With wireless door control– Pressing the switch on the key for more than 1 second performs a wireless remote control operation to open the boot lid. For further details refer to “Wireless remote control” on page 5. With smart entry and start system– When you carry the electronic key into the activation area, you can open the boot lid. For further information, refer to “Smart entry and start system” on page 7. From inside the vehicle– Lift the lever to open the boot lid. To close the boot lid Lower the boot firmly in the one action. Once it is closed, try pulling it up to make sure it is securely closed. Boot illumination The boot light turns on automatically when the boot lid is opened.
Page 45: Adjustable Components
BEFORE DRIVING Adjustable components Adjustable components SEATS While the vehicle is being driven, all vehicle occupants should have the seatback upright, sit well back in the seat and correctly wear the seatbelts provided. CAUTION • Persons not correctly seated and/or not correctly restrained by seatbelts can be killed or severely injured in the event of emergency braking or a collision. • Do not drive the vehicle unless the occupants are correctly seated. • Do not allow any passenger to sit on top of a folded-down seatback, or in the luggage compartment or cargo area. FRONT SEATS CAUTION Driver’s seat precautions • The SRS driver airbag deploys with considerable force and can cause death or serious injury, especially if the driver is very close to the airbag. • The driver airbag risk zone is the first 50-75 mm of inflation. Therefore, remaining 250 mm from your driver airbag will minimise your risk of sustaining injuries when the airbag inflates. This distance is measured from the centre of the steering wheel to your breastbone. If you sit less than 250 mm away from the driver airbag, consider changing your driving position in the following ways: – Move your seat backwards as far as you can while still reaching the pedals comfortably – Slightly recline the back of your seat. If reclining the back of the seat impedes your view of the road, raise your seat if your vehicle has that feature – Adjust your steering wheel downwards slightly. This will point the airbag toward your chest instead of at your head and neck –...
Page 46 BEFORE DRIVING Adjustable components CAUTION Front seats with SRS side airbags SRS side airbags are installed in the driver’s and front passenger’s seats. Observe the following precautions. • Do not lean against the front doors when the vehicle is in use. The side airbags inflate with considerable speed and force and you may be killed or seriously injured if your body is in contact with them during inflation. • Do not use seat accessories which cover the area where the side airbags inflate. Such accessories may prevent the side airbags from activating correctly, causing death or serious injury. • Do not modify or replace the seats or upholstery of the seats equipped with side airbags. Such change may prevent the side airbag system from activating correctly, disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury. CAUTION Seat adjustment precautions • Do not adjust the seat while the vehicle is moving as the seat may unexpectedly move and cause the driver to lose control of the vehicle. • Be careful the seat does not hit a passenger or luggage. • After adjusting the seat position, release the lever and try sliding the seat forward and backward to make sure it is locked in position. • After adjusting the seatback, push your body back against the seat to make sure the seat is locked in position. • Do not put objects under the seats. Objects placed under seats may interfere with the seat-lock mechanism or unexpectedly operate the seat position adjusting lever and the seat may suddenly move, causing the driver to lose control of the vehicle.
Page 47 BEFORE DRIVING Adjustable components Adjusting front seats (power seat) For driver’s and front passenger’s seat– 1. Seat position adjustment switch: Move the switch in the direction of the arrow to move the seat forwards or backwards. 2. Seatback angle adjusting switch: Move the switch in the direction of the arrows to adjust the seatback angle. For driver’s seat only– 3. Seat height adjustment switch, front: Move the switch in the direction of the arrow to raise or lower the front of the seat cushion. 4. Seat height adjustment switch, rear: Move the switch in the direction of the arrow to raise or lower the rear of the seat cushion. 5. Seat lumbar support adjusting switch: Push the front of the switch to increase the amount of support, or push the rear of the switch to decrease the amount of support. The amount of lumbar support will change while the switch is pushed.
Page 48: Front Head Restraints
BEFORE DRIVING Adjustable components Adjusting front passenger seats (manual seat) 1. Seat position adjusting lever: Hold the centre of the lever and pull it up. Then slide the seat to the desired position with slight body pressure and release the lever. 2. Seatback angle adjusting lever: Lean forward and pull the lever up. Then lean back to the desired angle and release the lever. CAUTION • Do not recline the seatback any more than needed. In a frontal collision, the more the seat is reclined, the greater the risk of death or serious injury. • Seatbelts provide maximum protection in a frontal or rear collision when the driver and passengers are sitting up straight and well back in their seats. If you are reclined, the lap belt may slide past your hips and apply forces directly to the abdomen or your neck may contact the shoulder belt increasing the risk of death or serious injury. • Refer to “Front seats” on page 23 regarding the recommended distance between the driver and front passengers seats and the SRS airbag. FRONT HEAD RESTRAINTS For your safety and comfort, adjust the head restraints before driving. 1. To raise– Pull the head restraint up. 2. To lower– Press the lock release button and Push the head restraint down.
Page 49 BEFORE DRIVING Adjustable components • Adjust the head restraint so the centre of the head restraint is closest to the top of your ears. • To remove the front head restraint, pull it up while pushing the lock release button. CAUTION Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. • Use the head restraints designed for each respective seat. • Adjust the head restraints to the correct position at all times. • After adjusting a head restraint, push it down to ensure it is locked in position. • Do not drive with the head restraints removed.
Page 50: Driving Position Memory System
BEFORE DRIVING Adjustable components DRIVING POSITION MEMORY SYSTEM This system can memorise the preferred position of the driver’s seat and outside rear view mirrors, and recall them at the touch of a button. Two different driving positions can be entered. Setting the driving position 1. Press the ENGINE START STOP switch to IGNITION ON mode. 2. Move the shift lever to the P position. 3. Adjust the driver’s seat and outside rear view mirrors to the desired position. 4. While pressing the SET button, press memory button 1 or 2 until a beep is heard. A second position can be memorised by repeating the above steps and using the alternate memory button. If step 4 is performed when both memory buttons contain a memorised position, the previous position will be overwritten. To make only slight changes to an already memorised position, the easiest way is to first activate the memorised position, then make the desired changes and perform step 4 above. Recalling the memorised position The memorised position can be recalled under the following conditions: 1. Press the ENGINE START STOP switch to IGNITION ON mode. 2. Move the shift lever to the P position. 3. Press memory button 1 or 2.
Page 51 BEFORE DRIVING Adjustable components CAUTION • Do not start the vehicle while the adjustments are being made. • Take care not to select the wrong button, or the seat could strike the rear passenger or force your body against the steering wheel. • If this happens, you can stop the movement by pressing any driving position memory button. Driving position memory system using the electronic key The memorised positions can be linked to the electronic key when an unlock operation is performed using the wireless remote control or the entry function of the smart entry and start system. Linking the driving position to the electronic key– 1. Set the driving position to memory buttons 1 or 2 as previously described. 2. Carry the key to which you want to link the driving position. NOTE: If another key is in the vehicle the linking operation cannot be performed. 3. Press the ENGINE START STOP switch to OFF. 4. Close the driver’s door. 5. While pressing the desired memory button (1 or 2), press the driver’s door lock or unlock switch until a beep is heard. Cancelling driving position linking– 1. Press the ENGINE START STOP switch to OFF. 2. Close the driver’s door.
Page 52: Rear Seats
BEFORE DRIVING Adjustable components REAR SEATS Armrest To use the armrest, pull it down as shown. NOTICE To prevent damage to the armrest, do not apply too much load. Fold-down rear seat 1. To unlock the seatback, pull the lever in the boot. 2. Fold down the seatback. • Each seatback can be folded separately. • This will enlarge the boot as far as the front seatbacks. CTY13AV070a...
Page 53: Seatbelts
After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. • Make sure the seatback is securely locked by pushing forward and rearward on the top of the seat. • Check the seatbelts are not twisted or caught in the seatback. • Ensure the seatbelt is passing through its guide. SEATBELTS Seatbelt precautions The seatbelts provided for your vehicle are designed for people of adult size, large enough to correctly wear them. CAUTION General • Toyota recommends that the driver and all passengers must wear seatbelts whenever the vehicle is moving. Otherwise, they are much more likely to suffer serious bodily injury or death during sudden braking or a collision. • When wearing a seatbelt, always observe the following: – Each person must wear a separate seatbelt – Do not recline the seatback any more than needed. In a frontal collision, the more the seat is reclined, the greater the risk of death or serious injury – Seatbelts provide maximum protection in a frontal or rear collision when the driver and passengers are sitting up straight and well back in their seats. If you are reclined, the lap belt may slide past your hips and apply forces directly to the abdomen, or your neck may contact the shoulder belt...
Page 54 BEFORE DRIVING Adjustable components CAUTION People with special needs Pregnant woman: • Toyota recommends the use of a seatbelt. Ask your doctor for specific recommendations. • The lap belt should be worn securely and as low as possible over the hips and not on the waist. Children: • An appropriate child restraint system must be used for all children until they reach a certain age or weight. The precise legal requirements are different in the various States and Territories so you should consult your local laws. Also refer to “Child restraint system” on page 64. • Some States and Territories have laws governing where a child is permitted to sit in vehicles so you should consult your local laws. • If a child is too large for a child restraint system, the child should sit in the rear seat and must be restrained using the vehicle’s seatbelt. According to accident statistics, the child is safer when correctly restrained in the rear seat than in the front seat. • If a child must sit in the front seat, the seatbelts should be worn correctly. If an accident occurs and the seatbelts are not worn correctly, the force of the rapid inflation of the airbag may cause death or serious injury to the child. • Do not allow a child to stand up or kneel on either rear or front seats. An unrestrained child could suffer serious injury or death during emergency braking or a collision. Also, do not let the child sit on your lap. Holding a child in your arms does not provide sufficient restraint.
Page 55 BEFORE DRIVING Adjustable components CAUTION Injured person: • Toyota strongly recommends the use of a seatbelt. Depending on the injury, first check with your doctor for specific recommendations. CAUTION Positioning of seatbelts • Seatbelts are designed to bear upon the bony structure of the body. Position the belt low across the front of the pelvis and over the shoulder so it does not contact the neck or slide off. • Wearing the lap section of the belt across the abdominal area must be avoided. • Seatbelts should be adjusted as firmly as possible, consistent with comfort, to provide the protection for which they have been designed. A slack belt will greatly reduce the protection afforded to the wearer. • Both high positioned lap belts and loose fitting belts could cause serious injuries due to sliding under the lap belt during a collision or other unintended event. Keep the lap belt positioned as low on hips as possible. • Do not place the shoulder belt under your arm. • Belts should not be worn with straps twisted. • WARNING: No modifications or additions should be made by the user which will either prevent the seatbelt adjusting devices from operating to remove slack, or prevent the seatbelt assembly from being adjusted to remove slack.
Page 56 • Care should be taken to avoid contamination of the webbing with polishes, oils and chemicals, and particularly battery acid. • Cleaning may safely be carried out using mild soap and water. • The belt should be replaced if webbing becomes frayed, contaminated or damaged. • Each belt assembly must only be used by one occupant; it is dangerous to put a belt around a child being carried on the occupant’s lap. Fastening and releasing the seatbelt Adjust the seat as required and sit up straight and well back in the seat. 1. To fasten the seatbelt, pull it out of the retractor smoothly and insert the tab into the buckle. You will hear a click when the tab locks into the buckle. 2. To release the seatbelt, press the Release button release button. CAUTION • To avoid serious injury or death, you must immediately contact your Toyota dealer if your seatbelt does not function normally. Do not use the seat until the seatbelt is fixed. • After inserting the tab, make sure the tab and buckle are locked and the belt is not twisted. • Do not insert coins, clips, etc. into the buckle as this may prevent you from correctly latching the tab and buckle.
Page 57 BEFORE DRIVING Adjustable components Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It also may lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around freely. Adjustable front seat shoulder anchor Adjust the shoulder anchor position to your size. 1. To lower– Push the lock release button in and slide the anchor down. 2. To raise– Slide the anchor up. After adjustment, make sure the anchor is locked in position. CAUTION Always make sure the shoulder belt is positioned across the centre of your shoulder. The belt should be kept away from your neck, but not fall off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in a collision. Rear seatbelt guide If it comes free, pass the seatbelt through the rear seatbelt guide before using. CAUTION • Always make sure the shoulder belt passes through the guide when using the seatbelt. Failure to correctly position the belt may reduce the amount of protection in an accident and could lead to serious injures in a collision or sudden stop.
Page 58: Tilt And Telescopic Steering Wheel . 3
BEFORE DRIVING Adjustable components Automatic locking retractor (ALR) The rear seatbelts have an additional locking feature used to hold a child restraint system securely. When this feature is activated, the seatbelt is locked from extending from the last retracted position. For details about this feature, refer to “Child restraint” on page 63. To unlock the seatbelt, unbuckle the belt, allow it to fully retract then pull it out again. TILT AND TELESCOPIC STEERING WHEEL To adjust the steering wheel position, hold the steering wheel and push down the lock release lever. Adjust the steering wheel to the desired angle and push or pull it to the desired steering column length. Return the lever to its original position. CAUTION Do not adjust the steering wheel while the vehicle is moving. Doing so may cause the driver to lose control of the vehicle and an accident may occur resulting in death or serious injuries. After adjusting the steering wheel, try moving it up and down or forward and rearward to make sure it is locked in position.
Page 59: Anti-Glare Inside Rear View Mirror
BEFORE DRIVING Adjustable components ANTI-GLARE INSIDE REAR VIEW MIRROR Adjust the mirror so that you can just see the rear of your vehicle in the mirror. The height of the mirror can also be adjusted up or down. CAUTION Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to lose control of the vehicle and an accident may occur resulting in death or serious injury. To reduce glare from the headlights of the vehicle behind you during night driving, operate the lever on the lower edge of the mirror. 1. Daylight driving– The reflection in the mirror has greater clarity at this position. 2. Night driving– Remember that by reducing glare you also lose some rear view clarity. AUTO ANTI-GLARE INSIDE REAR VIEW MIRROR Adjust the mirror so that you can just see the rear of your vehicle in the mirror. The height of the mirror can also be adjusted up or down. CAUTION Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to lose control of the vehicle and an accident may occur resulting in death or serious injury.
Page 60: Outside Rear View Mirrors
BEFORE DRIVING Adjustable components This mirror is equipped with an auto anti-glare function designed to automatically reduce glare from the headlights of the vehicle behind you during night driving. When the ENGINE START STOP switch is in IGNITION ON mode, the inside rear view mirror always turns on in the automatic function mode. The indicator illuminates to show you the function is on. In automatic function mode, if the mirror detects light from the headlights of the vehicle behind you, the mirror surface darkens slightly to reduce the reflected light. To turn the automatic function off or on, push the switch. When the inside air temperature is low, it may take a little longer for the mirror to darken in response to the detection of headlights. Sensors are located on both sides of the mirror. To ensure correct functioning of the anti-glare mirror, do not touch or cover the sensors. OUTSIDE REAR VIEW MIRRORS Adjust the mirror so that you can just see the side of your vehicle in the mirror. To select a mirror to adjust, press the switch. 1. Left-hand mirror. 2. Right-hand mirror. Vehicles with standard type ignition switch– Mirrors can be adjusted when the ignition switch is in the ACC or ON position. Vehicles with smart entry and start system– Mirrors can be adjusted when the ENGINE START STOP switch is in ACCESSORY or IGNITION ON mode.
Page 61 BEFORE DRIVING Adjustable components To adjust the mirror, press the switch in the desired direction. 1. Up. 2. Right. 3. Down. 4. Left. CAUTION • Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to lose control of the vehicle causing an accident resulting in death or serious injury. • If ice should jam the mirror, do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror. Folding rear view mirrors The rear view mirrors can be folded backward for parking in compact areas. To fold the rear view mirror, push backward. CAUTION Do not drive with the mirrors folded backward. Both the driver and passenger side rear view mirrors must be extended and correctly adjusted before driving. Linked mirror function when reversing (vehicles with driving position memory) The outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 62: Opening And Closing The Windows And Moon Roof
BEFORE DRIVING Opening and closing the windows and moon roof Opening and closing the windows and moon roof POWER WINDOWS The windows can be operated with the power window switch on each door. • Vehicles with standard type ignition switch– Turn the ignition switch to the ON position. • Vehicles with smart entry and start system– Press the ENGINE START STOP switch to IGNITION ON mode. Normal operation The window moves as long as you hold the switch. 1. To close the window, lightly pull the switch up.
Page 63 BEFORE DRIVING Opening and closing the windows and moon roof Window lock switch If you press the window lock switch on the driver’s door, the front and rear passenger’s windows cannot be operated. Use this switch to prevent children from accidently opening or closing a window. CAUTION To avoid death or serious personal injury, you must do the following. • Before you close the power windows, always make sure the heads, hands and other parts of the bodies of all occupants are kept completely inside the vehicle. • When small children are in the vehicle, never let them use the power window switches without supervision. Use the window lock switch to prevent them from making unexpected use of the switches. • Never leave anyone (particularly a small child) alone in your vehicle, especially with the key still inserted in the ignition switch (vehicles with standard type ignition switch) or the key left in your vehicle (vehicles with smart entry and start system). Otherwise, he / she could use the power window switch and become trapped in the window opening. Unattended children are at particular risk of injury. • The jam protection function may not work if something gets caught just before the window is fully closed. When the driver’s power window does not close normally If the jam protection function is operating abnormally and the window cannot be closed, perform the following operations using the driver’s door power window switch.
Page 64 BEFORE DRIVING Opening and closing the windows and moon roof 3. Hold the power window switch in the one-touch closing position once again. Continue holding the switch for a further 2 seconds after the window has closed. • If you release the switch while the window is moving, start again from the beginning. • If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. Customisable features that can be modified For further information refer to “Customisable features” on page 333. MOON ROOF To operate the moon roof, use the switches on the overhead console while the ENGINE START STOP switch is pressed to IGNITION ON mode. The sunshade can be opened or closed by hand. Sliding operation 1. Push the OPEN switch to open the moon roof. The moon roof will open and stop part- way from the fully opened position. Push the switch again to fully open the moon roof. 2. Push the CLOSE switch to close the moon roof.
Page 65 BEFORE DRIVING Opening and closing the windows and moon roof Key off operation The moon roof can be operated for about 45 seconds after the ENGINE START STOP switch is turned off. It stops working when either front door is opened. Moon roof open reminder function An alarm will sound when the driver’s door is opened with the moon roof not fully closed and the ENGINE START STOP switch is OFF. Jam protection function If an object is caught between the moon roof and frame during the closing operation, the moon roof stops and reopens slightly. CAUTION To avoid death or serious personal injury, you must do the following. • If any part of someone’s body is caught in the closing roof, it could result in death or serious injury. • While the vehicle is moving, always keep the heads, hands and other parts of the bodies of all occupants away from the roof opening. Otherwise, they could be killed or seriously injured if the vehicle stops suddenly or if the vehicle is involved in an accident. • Before you close the moon roof, always make sure nobody places his or her head, hands and/or other parts of the body in the roof opening. • Never leave anyone (particularly a small child) alone in your vehicle, especially with the ignition key still inserted (vehicles with standard type ignition switch) or the key left in your vehicle (vehicles with smart entry and start system). Otherwise, he/she could use the moon roof switch and get trapped in the roof opening.
Page 66 Opening and closing the windows and moon roof If the moon roof tilts down but then tilts back up– 1. Stop the vehicle. 2. Press and hold the UP switch (*1) until the moon roof moves into the tilt up position and stops. 3. Release the UP switch once and then press and hold the UP switch again (*1). The moon roof will pause for approximately 10 seconds in the tilt up position (*2). Then it will adjust slightly and pause for approximately 1 second. Finally, it will tilt down, open and close. 4. Check to make sure the moon roof is completely closed and then release the switch. *1: If the switch is released at the incorrect time, the procedure will have to be performed again from the beginning. *2: If the switch is released after the above mentioned 10 second pause, automatic operation will be disabled. In that case, press and hold the CLOSE switch or press and hold the UP switch. The moon roof will tilt up and pause for approximately 1 second. Then it will tilt down, open and close. Check to make sure the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. Customisable features that can be modified For further information refer to “Customisable features” on page 333.
Page 67: Fuel Tank Cap
• After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity. It is important to discharge static electricity before refuelling because sparks resulting from static electricity can cause fuel vapours to ignite while refuelling. • Always hold the grip on the fuel tank cap and turn it slowly to remove it. A whooshing sound may be heard when the fuel tank cap is loosened. Wait until the sound cannot be heard before fully removing the cap. In hot weather, pressurised fuel may spray out the filler neck and cause injury. • Do not allow anyone that has not discharged static electricity from their body to come close to an open fuel tank. • Do not inhale fuel vapours. Fuel contains substances that are harmful if inhaled. • Do not smoke while refuelling the vehicle. Doing so may cause the fuel to ignite and cause a fire. • Do not return to the vehicle or touch any person or object that is statically charged. This may cause static electricity to build up, resulting in a possible ignition hazard. • Securely insert the fuel nozzle into the fuel filler neck. If fuel is added with the nozzle slightly lifted away from the fuel filler neck, the automatic shut off function may not operate, resulting in fuel overflowing from the tank. • Avoid spilling fuel during refilling; doing so may damage the vehicle. Immediately pour water on any spilled fuel. Use of ethanol blended fuel Toyota allows the use of ethanol blended fuel where the ethanol content is up to 10%. For details, refer to “Fuel” on page 328. FUEL TANK CAP When refuelling, turn off the engine and close the doors and windows. To open the fuel filler door, pull the lever...
Page 68 BEFORE DRIVING Refuelling To remove the fuel tank cap, turn the cap slowly counterclockwise, then pause slightly before removing it. It is not unusual to hear a slight wooshing sound when the cap is opened. The removed cap can be stored on the back side of the fuel filler door. When installing the cap, turn the cap clockwise until you hear a click; this indicates the cap is fully closed. CAUTION When replacing the fuel cap • Make sure the cap is installed securely to prevent fuel spillage when driving. • Only use a genuine Toyota fuel tank cap designed for your vehicle. Doing otherwise may cause a fire or other incident which may result in death or serious injury. NOTICE To prevent damage to the cap, apply force only in the turning direction to the cap. Do not pull or prise it.
Page 69: Theft Deterrent System
• Vehicles with standard type ignition switch– The key is removed from the ignition switch. • Vehicles with smart entry and start system– The ENGINE START STOP switch is pressed off. The indicator will start flashing to show the system is set. NOTICE Contact your Toyota dealer if any of the following indicator conditions occurs: • The indicator stays on except when the alarm is setting or activating. Refer to “Setting the alarm system” on page 48. • The indicator does not start flashing under the following situations: – Vehicles with standard-type ignition switch– When the key is removed from the ignition switch – Vehicles with smart entry and start system– When the ENGINE START STOP switch is pressed OFF • The indicator light flashes erratically.
Page 70: Alarm
BEFORE DRIVING Theft deterrent system For your Toyota dealer to make you a new key with a built-in transponder chip, your dealer will need your key number and key (vehicles with standard-type ignition switch) or electronic key (vehicles with smart entry and start system). However, there is a limit to the number of additional keys your Toyota dealer can make for you. If you make your own duplicate key, you will not be able to cancel the engine immobiliser system or start the engine. NOTICE Do not modify, remove or disassemble the engine immobiliser system. If any unauthorised changes or modifications are made, correct operation of the system cannot be guaranteed. ALARM To deter vehicle theft, the alarm is designed to sound if any of the doors, boot or bonnet is forcibly unlocked or opened, or a battery terminal is disconnected and then reconnected when the vehicle is locked. The alarm will also sound if the PANIC switch on the key is pressed. Refer to “Panic mode” on page 6. When the alarm is triggered, the horn CTY12AV172a sounds and the turn signal lights flash. Setting the alarm system 1. Vehicles with standard type ignition switch– Remove the key from the ignition switch. Vehicles with smart entry and start system–...
Page 71 BEFORE DRIVING Theft deterrent system Triggering the alarm system The alarm will sound under the following conditions. • A locked door is unlocked or the boot lid is opened in any way other than using the wireless remote control, smart entry function or with a key. • The bonnet is forcibly opened. • A person is inside the vehicle and opens a door, the boot lid or bonnet while the alarm is set. • If the battery terminal is disconnected and reconnected while the vehicle is locked. The indicator will illuminate and all the doors will be automatically locked while the alarm is sounding. After 30 seconds, the alarm will automatically stop and the indicator light will start flashing again. Reactivating the alarm The system will automatically reset after the alarm stops sounding and will activate again under the same circumstances described in “Triggering the alarm system”. Stopping the alarm The alarm can be stopped by performing any of the following: • Vehicles with standard type ignition switch– Turn the ignition switch to the ACC or ON position or start the engine Vehicles with smart entry and start system–...
Page 72: Safety Information
BEFORE DRIVING Safety information Safety information SRS COMPONENTS The main SRS (Supplemental Restraint System) components are shown below. The SRS system is controlled by the airbag sensor assembly which together with front and side impact sensors detect a collision and may deploy the seatbelt pretensioners and airbags as determined by the force and direction of impact. Front impact sensors Curtain shield airbags Knee airbag Front passenger airbag Side impact sensors (front) Side impact sensors (rear) Seatbelt pretensioners and force SRS warning light limiters Driver airbag 11 Airbag sensor assembly Front side airbags SEATBELT PRETENSIONERS The driver and front passenger seatbelt pretensioners are designed to be activated in response to certain types of severe frontal collisions. When the impact sensor detects a severe frontal impact, the front seatbelts are quickly drawn back by the retractors so the belts snugly restrain the occupants.
Page 73 BEFORE DRIVING Safety information INFORMATION The seatbelt pretensioners do not activate in minor frontal impacts, side impacts or in a rear impact or rollover. Depending on the type of collision it is possible that only the pretensioners are activated and not the SRS airbags. While the seatbelt pretensioners are being activated, an operating noise may be heard and a small amount of non-toxic gas may be released. This does not indicate that a fire is occurring. This gas is normally harmless. CAUTION • If the seatbelt pretensioners have been activated, the SRS warning light will illuminate and the seatbelt cannot be used again and the seatbelt assemblies must be replaced. • Do not modify, remove, strike or open the seatbelt pretensioner assemblies, airbag sensor or surrounding area or wiring. Failure to follow these instructions may prevent the seatbelt pretensioners from activating correctly, cause sudden operation of the system or disable the system, which could result in death or serious injury. Consult your Toyota dealer about any repair and modification. NOTICE Do not perform any of the following changes without consulting your Toyota dealer. Such changes can interfere with correct operation of the seatbelt pretensioners in some cases. • Installation of electronic devices such as a mobile two-way radio, cassette tape player or compact disc player. • Repairs on or near the front seatbelt retractor assemblies. • Modification of the suspension system. • Modification of the front end structure. • Attachment of a grille guard (bull bar, kangaroo bar, etc.), snowplough, winches or any other equipment to the front end. • Repairs made on or near the front bumper bar, front end structure or console.
Page 74: Srs Airbags
BEFORE DRIVING Safety information SRS AIRBAGS The SRS airbags are designed to provide further protection for the driver, front passenger and rear outside passenger’s in addition to the primary safety protection provided by the seatbelts. 1. SRS driver airbag / front passenger airbag– Can help protect the head and chest of the driver and front passenger from impact with interior components 2. SRS knee airbag– Can help provide driver protection 3. SRS side airbags– Can help protect the torso of the front seat occupants 4. SRS curtain shield airbags– Can help protect primarily the head of occupants in the outer seats SRS front airbags In response to a severe frontal impact, the SRS front airbags (driver, front passenger and knee) work with the seatbelts and seatbelt pretensioners to help reduce injury by inflating. The front passenger airbag is activated even with no passenger in the front seat. The front impact sensors constantly monitor the forward deceleration of the vehicle. If an impact results in a forward deceleration beyond the designed threshold level, the system triggers the airbag inflators. At this time a chemical reaction in the inflators very quickly fills the airbags with non-toxic gas to help restrain the forward motion of the occupants.
Page 75 In a severe side impact, the side impact sensors trigger the side airbag inflators and/or the curtain shield airbag inflators on that side of the vehicle. At this time a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the lateral motion of the occupants. When the airbags inflate, they produce a loud noise and release some smoke and residue along with non-toxic gas. This does not indicate a fire. CAUTION • Always wear your seatbelt correctly. • The SRS front airbag system is designed only to supplement the primary protection of the driver and front passenger seatbelt systems. • The SRS side airbag and curtain shield airbag system is designed to supplement the seatbelt systems of the driver, front passenger and rear outside passenger. • The driver and front passenger can be killed or seriously injured by the inflating airbags or thrown out of the vehicle if they do not wear seatbelts correctly. For instructions and precautions concerning the seatbelt system refer to “Seatbelts” on page 31 and to “Front seats” on page 23. • During sudden braking, immediately before a collision, an unrestrained driver or front passenger can move forward into direct contact with, or close proximity to, the airbag which may then deploy during the collision. This can result in death or serious injury. • No-one should lean against areas from which SRS airbags deploy: the doors, the steering wheel, the rear of the driver’s and front passenger seats, rear pillar or roof side rail, as sudden inflation of the airbags could cause death or serious injury. For locations of the airbags refer to “SRS components” on page 50. • Toyota strongly recommends that all infants and children be placed in the rear seat of the vehicle and correctly restrained. • Incorrectly seated and/or incorrectly restrained infants and children can be killed or seriously injured by the deploying airbags. • An infant or child who is too small to use a seatbelt must be correctly secured using a child restraint system. For instructions concerning the installation of a child restraint system, refer to “Child restraint” on page 63.
Page 76 BEFORE DRIVING Safety information NOTICE • The smoke, residue and non-toxic gas released when airbags inflate may remain inside the vehicle for some time, causing some irritation to the eyes, skin or breathing. • Wash off any residue with soap and water as soon as possible to prevent any potential skin irritation. • If you can safely exit from the vehicle, you should do so immediately. SRS front airbag deployment conditions The SRS front airbags are designed to deploy in severe (usually frontal) collisions where the magnitude and duration of the forward deceleration of the vehicle exceeds the designed threshold level. The SRS front airbags will deploy if the severity of the impact is above the designed threshold level, comparable to an approximate 25 km/h collision when the vehicle has the impact straight into a fixed barrier that does not move or deform. However, this threshold velocity will be considerably higher if the vehicle strikes an object, such as a parked vehicle or sign post, which can move or deform on impact, or if the vehicle is involved in an under-ride collision (e.g. a collision in which the front of the vehicle under-rides, or goes under, the bed of a truck, etc.). NOTICE • It is possible that in some collisions where the forward deceleration of the vehicle is very close to the designed threshold level, the SRS front airbags and the seatbelt pretensioners may not activate together. • Always wear your seatbelts properly. NOTICE The SRS front airbags are not generally designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low- speed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle,...
Page 77 BEFORE DRIVING Safety information The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. SRS side and curtain shield airbag deployment conditions The SRS side airbags and curtain shield airbags are designed to inflate when the passenger compartment area suffers a severe impact from the side. NOTICE The SRS side airbags and curtain shield airbags are not generally designed to inflate if the vehicle is involved in a front or rear collision, if it rolls over, or if it is involved in a low-speed side collision. The SRS side airbag and curtain shield airbag system may also not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment as shown in the illustration. When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. • The SRS front airbags have been inflated.
Page 78 BEFORE DRIVING Safety information • The front of the vehicle (shaded in the illustration) is damaged or was involved in an accident that was not severe enough to cause the SRS front airbags to inflate. • The pad section of the steering wheel or instrument panel near the front passenger airbag and knee airbag (shaded in the illustration) is scratched, cracked, or otherwise damaged. • Any of the SRS side airbags and curtain shield airbags have been inflated. • The portion of the doors (shaded in the illustration) is damaged or was involved in an accident that was not severe enough to cause the SRS side airbags and curtain shield airbags to inflate. • The surface of the seats with the side airbag (shaded in the illustration) is scratched, cracked, or otherwise damaged. • Any portion of the front pillars, rear pillars or roof side rail garnishes (padding) containing the curtain shield airbags inside (shaded in the illustration) is scratched, cracked, or otherwise damaged.
Page 79: Srs Airbag Precautions
Vehicles with smart entry and start system– This warning light illuminates when the ENGINE START STOP switch is pressed to IGNITION ON mode. The warning light goes off after about 6 CTY22AV383a seconds. This means the SRS is operating correctly. The SRS warning light monitors the entire SRS including all of the airbag and impact sensors, airbags, seatbelt pretensioners, interconnecting wiring and power sources. For further information, refer to “Indicators and warning lights” on page 88 CAUTION If any of the following conditions occur, this indicates a malfunction of the airbags or seatbelt pretensioners. Contact your Toyota dealer as soon as possible. • Vehicles with standard type ignition switch– The SRS warning light does not illuminate when the ignition switch is turned to ON position, or remains on for more than 6 seconds. • Vehicles with smart entry and start system– The SRS warning light does not illuminate when the ENGINE START STOP switch is pressed to IGNITION ON mode or remains on for more than 6 seconds. • The SRS warning light illuminates or starts flashing while driving. SRS AIRBAG PRECAUTIONS Deployment of the airbags happens in a fraction of a second, so the airbags must inflate with considerable force. The airbags inflate only once. While the system is designed to reduce serious injuries, primarily to the head and chest, it may also cause other, less severe injuries which can be avoided by following the...
Page 80 • The windscreen may be damaged by absorbing some of the force of the inflating airbag. • To minimise the risk of serious injury it is important for the occupant to: – Avoid placing any object or part of the body between the occupant and the airbag module – Sit straight and well back into the seat – Wear the available seatbelt correctly – Sit as far as possible from the airbag module while still maintaining control of the vehicle • The driver or front passenger who is too close to the steering wheel or instrument panel during airbag deployment can be killed or seriously injured. Toyota strongly recommends that: – The driver sit as far back as possible from the steering wheel while still maintaining control of the vehicle – The front passenger sit as far back as possible from the instrument panel – All vehicle occupants must be correctly restrained using the available seatbelts For instructions and precautions concerning the seating position, refer to “Front seats” on page 23. • To avoid death or serious injury you need to comply with the following instructions. Failure to follow these instructions may prevent the SRS from activating correctly, causing sudden activation of the system or disabling the system: – Do not modify or remove any wiring – Do not modify, remove, strike or open any components such as the steering wheel pad, steering wheel column cover, front passenger airbag cover, front passenger airbag or airbag sensor assembly – Consult your Toyota dealer about any repair and modification...
Page 81 . A warning label on the passenger side instrument panel as shown, and on the driver’s side sun visor reminds you not to put a rearward facing child restraint system on the front passenger seat at anytime. • Do not sit on the edge of the seat or lean against the instrument panel when the vehicle is in use, since the front passenger airbag could inflate with considerable speed and force. Anyone who is up against, or very close to, an airbag when it inflates, can be killed or seriously injured. Sit up straight and well back in the seat, and always use your seatbelt correctly. • Toyota strongly recommends that all infants and children be placed in the rear seat of the vehicle and be correctly restrained. • Do not allow a child to stand up or kneel on the front passenger seat, since the front passenger airbag could inflate with considerable speed and force. Otherwise, the child may be killed or seriously injured. • Do not hold a child on your lap or in your arms. Use a child restraint system in the rear seat. For instructions concerning the installation of a child restraint system, refer to “Child restraint” on page 63.
Page 82 • The driver and front passenger should not hold objects in their arms or on their knees. • Vehicles with standard type ignition switch– Do not attach any heavy, sharp or hard objects such as other keys and accessories to the key. The objects may restrict the SRS knee airbag inflation or be thrust into the driver’s seat area by the force of the deploying airbag causing serious injury. CAUTION Side and curtain shield SRS precautions SRS side airbags and curtain shield airbags inflate with considerable force. To reduce the possibility of death or serious injury when they inflate, the driver, front passenger and rear outside passengers must: • Wear their seatbelts correctly • Remain correctly seated with their backs upright and against the seats at all times. The following pages contain more specific directions regarding precautions that should be taken in relation to the inflation of SRS airbags. Toyota recommends you consider these pages carefully.
Page 83 BEFORE DRIVING Safety information CAUTION • Do not lean against the door when the vehicle is in use or place your head close to the area where the side or curtain shield airbag could inflate. These airbags could inflate with considerable speed and force which could result in death or serious injury. • To minimise the risk of death or serious injury occurring during the inflation of airbags, sit up straight and well back in the seat. Ensure your weight is distributed evenly in the seat. Do not apply excessive weight to the outer side of the seats with a side airbag, and to the front pillar, rear pillar and roof side rail with a curtain shield airbag. • Do not kneel on the passenger seat facing the passenger’s side door. The side airbag and curtain shield airbag could inflate with considerable speed and force which may result in death or serious injury. • Do not place head or hands out of windows. Otherwise, death or serious injury may result when the curtain shield airbags inflate. • Do not attach any object on or around the door or the area where the curtain shield airbag activates, such as on the windscreen and, side door glass, front and rear pillars, roof side rail and assist...
Page 84 • Do not hook a hanger, heavy or sharp pointed objects on the coat hook. If the curtain shield airbag inflates, those items will be projected with great force or the curtain shield airbag may not activate correctly, resulting in death or serious injury. When you hang clothes, hang them on the coat hook directly. • Do not use seat accessories which cover the parts where the side airbags inflate. Such accessories may prevent the side airbags from activating correctly, causing death or serious injury. • Do not modify or replace the seats or upholstery of the seats with side airbags. Such changes may prevent the side airbag system from activating correctly, disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury. • Do not disassemble or repair the front and rear pillars and roof side rail containing the curtain shield airbags. Such changes may disable the system or cause the curtain shield airbags to inflate accidentally, resulting in death or serious injury. Failure to follow these instructions can result in death or serious injury. Consult your Toyota dealer about any repair and modification. NOTICE Do not perform any of the following changes without consulting your Toyota dealer. Such changes can interfere with correct operation of the SRS front airbag system in some cases. • Installation of electronic devices such as a mobile two-way radio, cassette tape player or compact disc player. • Modification of the suspension system. • Modification of the front end structure. • Modification of the side structure of the passenger compartment. • Attachment of a grille guard (bull bar, kangaroo bar, etc.), snowplough, winches or any other equipment to the front end. • Repairs made on or near the front bumper bar, front end structure, console, steering column, steering wheel, front seat or instrument panel near the front passenger airbag.
Page 85: Child Restraint
• If all seats, other than the front seats, are being used by children under 7 years, children aged between four and six years (inclusive) may travel in the front seat, provided they use an approved restraint or booster seat that is properly fitted. Child restraint precautions Toyota strongly recommends the use of child restraints that meet Australian Standard AS1754-2010 or later. If a child is too large for a child restraint system, the child should sit in the rear seat and must be restrained using the vehicle’s seatbelt. Refer to “Seatbelts” on page 31. CAUTION • For effective protection in automobile accidents and sudden stops, a child must be correctly restrained, using a seatbelt or child restraint system depending on the age and size of the child. Holding a child in your arms is not a substitute for a child restraint system. In an accident, the child can be crushed against the windscreen, or between you and the vehicle’s interior. • Toyota strongly recommends the use of a correct child restraint system which conforms to the size of the child, installed on the rear seat. According to accident statistics, the child is safer when correctly restrained in the rear seat than in the front seat. • Never install a rear-facing child restraint system on the front passenger seat. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat. • Australian law requires the use of an upper anchor strap on child restraint systems.
Page 86: Child Restraint System
• Do not allow children to play with the seatbelt. If the seatbelt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt. When the child restraint system is not in use • Keep the child restraint system properly secured on the seat even if it is not in use. Do not store the child restraint system unsecured in the passenger compartment. • If it is necessary to detach the child restraint system, remove it from the vehicle or store it securely in the boot. This will prevent it from injuring passengers in the event of a sudden stop, sudden swerve or accident. CHILD RESTRAINT SYSTEM A child restraint system for a small child or baby must itself be correctly restrained on the seat with the lap portion of the lap/shoulder belt. You must carefully consult the manufacturer’s instructions which accompany the child restraint system. To provide correct restraint, use a child restraint system following the manufacturer’s instructions about the appropriate age and size of the child for the child restraint system. Install the child restraint system correctly following the instructions provided by its manufacturer. General directions are also provided under the following illustrations. The child restraint system should be installed on the rear seat. According to accident statistics, the child is safer when correctly restrained in the rear seat than in the front seat. When not using the child restraint system, keep it secured with the seatbelt or place it in the boot or somewhere other than the passenger compartment. This will prevent it from injuring passengers in the event of a sudden stop or accident. Types of seatbelts Your Toyota is fitted with two types of seatbelts: • ELR (Emergency locking retractor)– This belt locks when the belt is pulled out quickly and is fitted to the front seats.
Page 87 BEFORE DRIVING Safety information • ELR / ALR (Emergency locking retractor / Automatic locking retractor)– This belt also locks when the belt is pulled out quickly. In addition, it has a fully extended lock mode. When the belt is completely extended and is then retracted even slightly, the retractor locks the belt in that position and the belt cannot be extended. The rear seatbelts in your Toyota are ELR / ALR type seatbelts. When installing a child restraint, fully extend the belt to place it in the lock mode. Fasten the belt around the child restraint according to the manufacturer’s directions and then allow the seatbelt to retract until the restraint is securely in place. The belt will be locked in position and cannot be extended. To unlock the seatbelt, unbuckle it and allow it to fully retract. Child restraint anchor fittings For easy installation of child restraints, your vehicle has three child restraint anchor fittings. When installing a child restraint, follow both the instructions here and those provided by the manufacturer of your child restraint. CAUTION Warning Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seatbelts, harnesses or for attaching other items or equipment to the vehicle. To use the child restraint anchor fitting Fix the child restraint system with the seatbelt according to the manufacturer’s directions and in “Types of seatbelts” as previously described. 1. Open the lid of the anchor fitting.
Page 88: Floor Mat
BEFORE DRIVING Safety information CAUTION Make sure the upper anchor strap is securely attached, and check the child restraint system is secure by pushing and pulling it in different directions. Follow all the installation instructions provided by its manufacturer. FLOOR MAT CAUTION Before driving the vehicle • Check the floor mat is securely fixed in the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor. • With the engine stopped and the shift lever in P position, fully depress each pedal to the floor to make sure it does not interfere with the floor mat. For details on correct floor mat installation refer to “Floor mat” on page 244...
Page 89: When Driving
REAR VIEW MONITOR SYSTEM ..... .122 TOYOTA PARKING ASSIST-SENSOR ....127 BLIND SPOT MONITOR (BSM) .
Page 90 WHEN DRIVING (CONT) Driving Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 RUNNING-IN PERIOD .
Page 91: Driving Procedures
WHEN DRIVING Driving procedures Driving procedures IGNITION SWITCH (STANDARD TYPE IGNITION SWITCH) The ignition switch has four positions. 1. LOCK – Engine is off and the steering wheel is locked. The key can be removed only at this position. 2. ACC – Accessories such as the radio operate, but the engine is off. 3. ON – Engine on and all accessories on. This is the normal driving position. 4. START – Starter motor on. The key will return to the ON position when released. For starting tips, refer to “Starting the engine (standard type ignition switch)” on page 71. You must push the key in to turn the key from ACC to the LOCK position. The shift lever must be in the P position before pushing the key. Once you remove the key, the engine immobiliser system is automatically set. Refer to “Engine immobiliser system” on page 47. When starting the engine, the key may seem stuck at the LOCK position. To free it, first ensure the key is pushed all the way in, and then rock the steering wheel slightly while turning the key gently. NOTICE Do not leave the key in the ACC or ON position if the engine is not running. The battery will discharge and the ignition could be damaged.
Page 92: And Start System)
WHEN DRIVING Driving procedures IGNITION SWITCH (SMART ENTRY AND START SYSTEM) When the electronic key is inside the vehicle, pressing the ENGINE START STOP switch allows you to: • Start or stop the engine (with the brake pedal depressed) • Select the ACCESSORY mode • Select IGNITION ON mode • Turn all modes OFF. If the brake pedal is depressed and the shift lever is in P position, will be displayed on the multi-information display, regardless of which mode is selected. Pressing the ENGINE START STOP switch once starts the engine. For starting tips, refer to “Starting the engine (smart entry and start system)” on page 72. Without depressing the brake pedal, each time the ENGINE START STOP switch is pressed changes the ignition modes as follows: Button Pressed Mode Multi-information Display Operation Accessories such as the First time ACCESSORY radio Second time IGNITION ON All electrical components Third time * Emergency flashers...
Page 93: Before Starting The Engine
WHEN DRIVING Driving procedures BEFORE STARTING THE ENGINE 1. Check the area around the vehicle before entering it. 2. Check the seat position, seatback angle, seat cushion height, head restraint height, steering wheel angle and steering column length are all adjusted correctly. 3. Check the inside and outside rear view mirrors are adjusted correctly. 4. Fasten the seatbelts. STARTING THE ENGINE (STANDARD TYPE IGNITION SWITCH) Before starting the engine, ensure to follow the instructions in “Before starting the engine”. 1. Apply the parking brake firmly. 2. Turn off unnecessary lights and accessories. 3. Check the shift lever is in P position. If you need to restart the engine while the vehicle is moving, move the shift lever to N position. A starter safety device will prevent the starter from operating if the shift lever is in any drive position. 4. Depress and hold the brake pedal until driving off. 5. With your foot off the accelerator pedal, crank the engine by turning the key to START. Release it when the engine starts. INFORMATION If the engine will not start, refer to “If your engine will not start” on page 313. To warm up the engine, drive while accelerating smoothly until the engine coolant temperature is within normal range. If the engine stalls, simply restart it, using the correct procedure as above. CAUTION When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances.
Page 94: Starting The Engine
WHEN DRIVING Driving procedures NOTICE Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring systems. Do not over-rev a cold engine. If the engine becomes difficult to start or stalls frequently, have the engine checked immediately. STARTING THE ENGINE (SMART ENTRY AND START SYSTEM) To start the engine Before starting the engine, ensure to follow the instructions in “Before starting the engine” on page 71. 1. Ensure the electronic key is in the vehicle (on your person). 2. Apply the parking brake firmly. 3. Turn off unnecessary lights and accessories. 4. Check the shift lever is in P position. 5. Depress the brake pedal firmly. will be displayed on the multi- information display. If it is not displayed, the engine cannot be started. 6. Press the ENGINE START STOP switch slowly and firmly. While starting the engine, continue depressing the brake pedal until the engine is started. Cranking hold function– Once you press ENGINE START STOP switch and release it, the cranking hold function continues to crank the engine until it starts, or for up to 30...
Page 95: Entry And Start System)
WHEN DRIVING Driving procedures To stop the engine 1. Stop the vehicle in a safe place. 2. Move the shift lever to P position. 3. Set the parking brake. 4. Press the ENGINE START STOP switch once. 5. Check on the multi-information display is off. When stopping the engine with the shift lever in a position other than P If the engine is stopped with the shift lever in a position other than P , the ENGINE START STOP switch will not be turned off but instead be turned to ACCESSORY mode. Perform the following procedure to turn the switch off. 1. Set the parking brake. 2. Move the shift lever to P position. 3. Check is displayed on the multi-information display and then press the ENGINE START STOP switch once.
Page 96 WHEN DRIVING Driving procedures Steering lock After pressing the ENGINE START STOP switch off and opening and closing the doors, the steering wheel will be locked by the steering lock function. Pressing the ENGINE START STOP switch again automatically cancels the steering lock. If the steering lock cannot be released, STEERING LOCK ACTIVE will be displayed on the multi-information display. 1. Check the shift lever is set in P position. 2. Press the ENGINE START STOP switch while turning the steering wheel left and right. To prevent the steering lock motor from overheating, the motor may be suspended if the engine is turned on and off repeatedly in a short period of time. In this case, refrain from operating the engine. After about 10 seconds, the steering lock motor will resume functioning. CAUTION When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Caution when driving If engine failure occurs while the vehicle is moving, do not lock or open the doors until the vehicle reaches a safe and complete stop. Activation of the steering lock in this circumstance may lead to an accident, resulting in death or serious injury. Stopping the engine in an emergency If you need to stop the engine in an emergency while driving the vehicle, press and hold the ENGINE START STOP switch for more than 3 seconds, or press it briefly three times or more in succession.
Page 97: Driving And Parking Using Smart Entry And Start System
When starting the engine • Do not over-rev a cold engine. • If the engine becomes difficult to start or stalls frequently, have the engine checked immediately. Symptoms indicating a malfunction with the ENGINE START STOP switch If the ENGINE START STOP seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Contact your Toyota dealer immediately. DRIVING AND PARKING USING SMART ENTRY AND START SYSTEM Tips for using smart entry and start system When using the smart entry and start system, it is possible to start or stop the engine as long as the key is on your person. For this reason, it is possible that a passenger may remove the key from the vehicle without the driver being aware of the fact. In such a case, it is not possible to restart the engine after having turned it off. In addition, it is possible that a person may get out of the vehicle without being aware the ENGINE START STOP switch has not been turned off completely. These situations will result in a warning message being displayed on the...
Page 98: Automatic Transmission (Without Paddle Shift Switches)
WHEN DRIVING Driving procedures AUTOMATIC TRANSMISSION (WITHOUT PADDLE SHIFT SWITCHES) Your automatic transmission has a shift lock system to minimise the possibility of incorrect operation. This means you can only shift out of P position when the brake pedal is depressed (with the ignition switch [vehicles with standard type ignition switch] is in the ON position or the ENGINE START STOP switch [vehicles with smart entry and start system] is in IGNITION ON mode). Shift lever The shift position is also displayed on the instrument cluster. P: Parking, engine starting and key removal R: Reverse N: Neutral D: Normal driving To improve fuel efficiency and reduce noise, set the shift lever in the D position for normal driving. S: S mode driving Selecting shift ranges using S mode restricts the upper limit of the possible gear ranges and controls engine braking forces. NOTICE When moving the shift lever between P and D positions, ensure the vehicle is completely stopped.
Page 99 WHEN DRIVING Driving procedures Shift Position Meter Display Function Purpose Gears between 1 and 6 Normal D position are automatically selected driving according to driving conditions Shift range Allows the driver to select selection gears for sporty driving Changing shift ranges in S mode When the shift lever is in the S position, the shift lever can be operated as follows: 1. Upshifting. 2. Downshifting. The initial shift range in S mode is set automatically to [5] or [4] according to vehicle speed. However, the initial shift range may be set to [3] if AI-SHIFT has operated while the shift lever was in the D position. Shift ranges and their functions You can choose from 6 levels of engine braking force. A lower shift range will provide greater engine braking force than a higher shift range, and the engine speed will also increase. INFORMATION When the shift range is [4] or lower, holding the shift lever toward [+] sets the shift range to [6].
Page 100 If the shift lever cannot be moved from P position If you cannot move the shift lever from P position even though the brake pedal is depressed, use the shift lock override button. For instructions, refer to “If the shift lever cannot be moved from P position” on page 314. If the S indicator does not come on or the D indicator is displayed even after shifting the shift lever to S position This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D position.) Downshift restriction warning buzzer (S mode) To help ensure safety and driving performance, a downshifting operation may sometimes be restricted. In some circumstances, downshifting may not be possible even when the shift lever is operated. (A buzzer will sound twice.) CAUTION Do not accelerate or shift gears suddenly.
Page 101: Automatic Transmission (With Paddle Shift Switches)
WHEN DRIVING Driving procedures AUTOMATIC TRANSMISSION (WITH PADDLE SHIFT SWITCHES) Your automatic transmission has a shift lock system to minimise the possibility of incorrect operation. This means you can only shift out of P position when the brake pedal is depressed (with the ignition switch [vehicles with standard type ignition switch] is in the ON position or the ENGINE START STOP switch [vehicles with smart entry and start system] is in IGNITION ON mode). Shift lever The shift position is also displayed on the instrument cluster. P: Parking, engine starting and key removal R: Reverse N: Neutral D: Normal driving To improve fuel efficiency and reduce noise, set the shift lever in the D position for normal driving. S: S mode driving Selecting shift ranges using S mode restricts the upper limit of the possible gear ranges and controls engine braking forces. NOTICE When moving the shift lever between P and D positions, ensure the vehicle is completely stopped.
Page 102 WHEN DRIVING Driving procedures Shift Position Meter Display Function Purpose Gears between 1 and 6 Normal D position are automatically selected driving according to driving conditions Shift range Allows optimum use of selection engine braking (with paddle shift switches activated) Shift range Allows the driver to select selection gears for sporty driving Changing shift ranges in S mode When the shift lever is in the S position, the shift lever or paddle shift switches can be operated as follows: 1. Upshifting [+] 2. Downshifting [–] The initial shift range in S mode is set automatically to [5] or [4] according to vehicle speed. However, the initial shift range may be set to [3] if AI-SHIFT has operated while the shift lever was in the D position.
Page 103 WHEN DRIVING Driving procedures Selecting shift ranges in D position To drive using temporary shift range selection, operate the [–] paddle shift switch. The shift range can then be selected by operating the [–] and [+] paddle shift switches. Changing the shift range allows restriction of the highest gear, preventing unnecessary upshifting and enabling the level of engine braking force to be selected. 1. Upshifting [+]. 2. Downshifting [–].]. The selected shift range, from [1] to [5], or D will be displayed in the instrument cluster. To return to normal D position driving, the [+] paddle shift switch must be held down for a period of time. When a shift range higher than [5] is selected, the shift range will return to the normal D position. Shift ranges and their functions You can choose from 6 levels of engine braking force. A lower shift range will provide greater engine braking force than a higher shift range, and the engine speed will also increase. INFORMATION When the shift range is [4] or lower, holding the shift lever toward [+] sets the shift range to [6]. To prevent the engine from over-revving, upshifting may automatically occur. To protect the automatic transmission, a function is adopted that automatically shifts to the top range when the temperature is too hot.
Page 104: Turn Signal Lever
If the shift lever cannot be moved from P position If you cannot move the shift lever from P position even though the brake pedal is depressed, use the shift lock override button. For instructions, refer to “If the shift lever cannot be moved from P position” on page 314. If the S indicator does not come on or the D indicator is displayed even after shifting the shift lever to S position This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D position.) Downshift restriction warning buzzer To help ensure safety and driving performance, a downshifting operation may sometimes be restricted. In some circumstances, downshifting may not be possible even when the shift lever or paddle shift switches are operated. (A buzzer will sound twice.) CAUTION Do not accelerate or shift gears suddenly.
Page 105: Parking Brake
WHEN DRIVING Driving procedures PARKING BRAKE When parking, firmly apply the parking brake to avoid inadvertent creeping. To set: While depressing the brake pedal with your right foot, depress the parking brake pedal with your left foot. To release: Depress the parking brake pedal again. To remind you the parking brake is set, the parking brake reminder light in the instrument cluster remains on until you fully release the parking brake pedal. If the vehicle speed rises above 5 km/h (with the parking brake remaining set) a buzzer will sound, the brake system warning light remains on, the master warning light flashes and a warning message is displayed on the multi-information display. Stop the vehicle and release the parking brake fully. CAUTION Before driving, ensure the parking brake is fully released and the parking brake reminder light is off. HORN To sound the horn, press on or close to the horn symbol on the steering wheel pad.
Page 106: Instrument Cluster
WHEN DRIVING Instrument cluster Instrument cluster GAUGES AND METERS CTY22AV276 Displays the engine speed in revolutions 1 Tachometer per minute 2 Speedometer Displays the vehicle speed Displays the quantity of fuel remaining in 3 Fuel gauge the fuel tank Displays the average fuel consumption 4 Average fuel consumption meter since the function was reset Displays the current rate of fuel 5 Current fuel consumption gauge consumption Changes the odometer / trip meter display. 6 Display change button Refer to page 85. Displays the odometer or trip meters. 7 Odometer / trip meter display Refer to page 85. Displays a variety of driving related data. 8 Multi-information display Refer to page 93. Engine coolant temperature Displays the engine coolant temperature display / instrument cluster lights and instrument cluster lights control.
Page 107 WHEN DRIVING Instrument cluster Odometer / trip meter display Pressing the button changes the display as follows. • Odometer Displays the total distance the vehicle has been driven. • Trip meters A and B Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently. Press and hold the button to reset. Instrument cluster light control button The brightness of the instrument cluster lights can be adjusted by pressing the button.
Page 108 WHEN DRIVING Instrument cluster Fuel gauge and odometer/trip meter display remain on mode Vehicles with standard type ignition switch– After the engine switch has been turned off, the fuel gauge and odometer/trip meter display remain on for 10 minutes, enabling the fuel gauge and odometer/trip meter values to be checked again without having to turn the engine switch to the ON position. When confirming the gauges and meters, turn the headlight switch to the position. Press the display change button to change between the odometer and trip meter displays. Vehicles with smart entry and start system– After the ENGINE START STOP switch has been turned off, the fuel gauge and odometer/ trip meter display remain on for 10 minutes, enabling the fuel gauge and odometer/trip meter values to be checked again without having to press the ENGINE START STOP switch to IGNITION ON mode. When confirming the gauges and meters, turn the headlight switch to the position. Press the display change button to change between the odometer and trip meter displays. INFORMATION The instrument cluster lights illuminate when: •...
Page 109 WHEN DRIVING Instrument cluster Outside temperature display The temperature display shows temperatures within the range of −40°C and 50°C. The outside temperature is displayed when: Vehicles with standard type ignition switch– The ignition switch is in the ON position Vehicles with smart entry and start system– The ENGINE START STOP switch is in IGNITION ON mode In the following situations, the correct outside temperature may not be displayed, or the display may take longer than normal to change: • When the vehicle is stopped, or moving at low speeds (less than 25 km/h.) • When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) When E is displayed the system may be malfunctioning. Take your vehicle to your Toyota dealer.
Page 110: Indicators And Warning Lights
WHEN DRIVING Instrument cluster INDICATORS AND WARNING LIGHTS The indicators and warning lights on the instrument cluster, centre panel and outside rear view mirrors inform the driver of the status of the vehicle’s various systems. Instrument cluster Indicators– • The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Shift position and shift range (page 82) indicators (page 76, 79) Headlight high beam indicator Cruise control indicator (page 108) (page 120) Automatic high beam indicator Cruise control set indicator (page 110) * (page 120) Tail light indicator Eco Driving Indicator (page 108) (page 86) * Front fog light indicator Slip indicator (page 115) (page 135) * AFS OFF indicator (page 114) *: These indicator lights illuminate when the ignition switch is turned to the ON position (vehicles with standard type ignition switch) or the ENGINE START STOP switch is pressed to IGNITION ON mode (vehicles with smart entry and start system) to indicate a system check is being performed. They turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 111 • Warning lights inform the driver of malfunctions in any of the vehicle’s systems. Warning Light Details Brake system warning light and buzzer* • Illuminates when the parking brake is engaged, if the brake fluid level is low or there is a malfunction in the brake system. • The light also illuminates and the buzzer sounds if the park brake is engaged and the vehicle speed exceeds 5 km/h. If the parking brake is off, stop immediately and contact your Toyota dealer. Charging system warning light* • Indicates a malfunction in the vehicle’s charging system. Stop immediately and contact your Toyota dealer. Low engine oil pressure warning light* • Indicates the engine oil pressure is too low. Stop immediately and check High engine coolant temperature warning light...
Page 112 WHEN DRIVING Instrument cluster Warning Light Details ABS warning light* • Indicates a malfunction in: The ABS; or The brake assist system. Stop immediately and contact your Toyota dealer Electric power steering warning light and buzzer* • Indicates a malfunction in the EPS system. Stop immediately and contact your Toyota dealer Slip indicator warning light* • Indicates a malfunction in: VSC system; or TRC system. • The indicator flashes to indicate the system is operating. Stop immediately and contact your Toyota dealer Cruise control warning light (illuminates yellow) • Indicates a malfunction in the cruise control system.
Page 113 Low fuel warning light • Indicates remaining fuel is approximately 10.5 L or less. Refuel the vehicle Master warning light A buzzer sounds and the warning light comes on and flashes to indicate that the master warning system has detected a malfunction. “Warning messages” on page 93. *1: These warning lights illuminate when the ignition switch is turned to the ON position (vehicles with standard type ignition switch) or the ENGINE START STOP switch is pressed to IGNITION ON mode (vehicles with smart entry and start system) to indicate a system check is being performed. They turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. *2: When the battery charge becomes insufficient or the voltage temporarily drops, the electric power steering system warning light may come on and the warning buzzer may sound. Centre panel Indicator– Security indicator (page 47) Warning light– Warning Light Details Rear passenger seatbelt warning light • Warns the rear passengers their seatbelt is not fastened. • The buzzer sounds for 30 seconds if a rear seat passenger has not fastened their seatbelt and the vehicle speed exceeds 20 km/h.
Page 114 In order to confirm operation, the BSM outside rear view mirror indicators illuminate in the following situations. • When the ENGINE START STOP switch is pressed to IGNITION ON mode with the BSM main switch set to • When the BSM main switch is set to ON while the ENGINE START STOP switch is in IGNITION ON mode. If the system is functioning correctly, the BSM outside rear view mirror indicators will turn off after a few seconds. CAUTION If a safety system warning light does not illuminate Should a safety system warning light such as the ABS or SRS warning light not illuminate when you start the engine, this could mean these systems are not available to help protect you in an accident, which could result in death or serious injury. Have the vehicle inspected by your Toyota dealer immediately should this occur. CAUTION When the electric power steering system warning light comes on The steering wheel may become extremely heavy. If the steering wheel becomes heavier than usual when operating, hold firmly and operate using more force than usual.
Page 115: Multi-Information Display
WHEN DRIVING Instrument cluster MULTI-INFORMATION DISPLAY The multi-information display presents the driver with a variety of driving-related data. • Warning messages (refer to below). Automatically displayed when a malfunction occurs in one of the vehicle’s systems. • Trip information (refer to “Multi- information display driving related data” on page 103). Displays cruising range, fuel consumption and other cruising- related information. • Toyota parking assist-sensor display (refer to “Toyota parking assist- sensor” on page 127). Warning messages 1. Master warning light. The master warning light also comes on or flashes in order to indicate that a message is currently being displayed on the multi-information display. Refer to the following pages. 2. Multi-information display. If a warning is shown on the multi-information display, stay calm and perform the following actions. If any of the warning lights comes on again after the following actions have been performed, contact your Toyota dealer.
Page 116 • Indicates a malfunction in the smart entry and start system . A buzzer also sounds. (Flashes) Indicates a malfunction in the Toyota parking assist-sensor . The malfunctioning assist-sensor is flashing. Indicates a malfunction in the cruise control system . Indicates a malfunction in the Blind Spot Monitor .
Page 117 WHEN DRIVING Instrument cluster Follow the correction procedures− A buzzer sounds and a warning message is shown on the multi-information display. After taking the specified steps to correct the suspected problem, check that the warning message goes off. Warning message Details Correction procedure Indicates that one or more of the doors is not fully closed . The system also indicates which doors are not fully closed. Make sure that all the doors are closed. If the vehicle reaches a speed of 5 km/h, flashes and a buzzer sounds to indicate that the door(s) are not yet fully closed. Indicates that the bonnet is not fully closed .
Page 118 Indicates, if the vehicle reaches a speed of 5 km/h, that the parking brake is Release the parking brake. still engaged . A buzzer also sounds. (Flashes) Indicates that Toyota parking assist-sensor is Clean the sensor dirty or covered with ice . Indicates that the Blind Spot Monitor sensors or Clean the sensor and its...
Page 119 WHEN DRIVING Instrument cluster Rectify the malfunction immediately– After taking the specified steps to correct the suspected problem, check that the warning message and light go off. Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic key is not detected Start the engine Once — when an attempt is with the electronic made to start the key present. engine. (Flashes) The electronic key was carried outside the vehicle and a door other than the driver's Bring the door was opened electronic key back and closed while into the vehicle. the ENGINE START STOP switch was in a mode other than off. Once 3 times The electronic...
Page 120 WHEN DRIVING Instrument cluster Interior Exterior Correction Warning message Details buzzer buzzer procedure An attempt was made to exit the vehicle with the Press the ENGINE electronic key Contin- START STOP Once and lock the uous switch off and lock doors without the doors again. first turning the ENGINE START STOP switch off. (Displayed alternatively) (Flashes) An attempt was made to start the engine without the electronic key being present, or the electronic Confirm that the key was not 9 times — electronic key is functioning inside the vehicle.
Page 121 WHEN DRIVING Instrument cluster Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic key was carried outside the vehicle • Change the and the driver’s shift lever to P door was opened position. Contin- Contin- and closed while • Bring the uous uous any shift lever electronic key position other than back into the P was selected vehicle. without turning off the ENGINE START (Displayed alternatively) STOP switch. (Flashes) An attempt was made to lock the Retrieve the doors using the electronic key Contin-...
Page 122 WHEN DRIVING Instrument cluster Interior Exterior Correction Warning message Details buzzer buzzer procedure • When the doors were unlocked with the mechanical key and then the ENGINE START STOP switch was pressed, the electronic Touch the key could not be electronic key to detected in the the ENGINE START Once — vehicle. STOP switch while depressing the • The electronic brake pedal. key could not (Flashes) be detected in the vehicle even after the ENGINE START STOP switch was pressed two consecutive times.
Page 123 WHEN DRIVING Instrument cluster Interior Exterior Correction Warning message Details buzzer buzzer procedure Replace the electronic key battery. Refer to The electronic key Once — “Replacing the has a low battery. remote control transmitter battery” o n p age 2 96. The driver's door was opened and closed with the ENGINE START STOP switch Press the ENGINE turned off and START STOP then the ENGINE switch while START STOP depressing the switch was put brake pedal.
Page 124 WHEN DRIVING Instrument cluster Interior Exterior Correction Warning message Details buzzer buzzer procedure Press the ENGINE The steering START STOP lock could not be switch while released within depressing the Once — 3 seconds of the brake pedal ENGINE START and moving the STOP switch being steering wheel left (Flashes) pressed. and right. The ENGINE START STOP switch has been Change the shift Once — turned off with lever to P position. the shift lever in a position other than (Flashes) P or N.
Page 125 WHEN DRIVING Instrument cluster Multi-information display driving related data Press the DISP button to scroll through the trip information contents. Without Paddle shift With Paddle shift CTY22AV479a Trip information contents Trip information contents Cruising range/average fuel Customisation consumption Average vehicle speed / elapsed time – (Off) Eco drive level...
Page 126 WHEN DRIVING Instrument cluster Trip information Cruising range / average fuel consumption− • Cruising range Displays the estimated maximum distance that can be driven with the quantity of fuel remaining. – This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed. – When only a small amount of fuel is added to the tank, the display may not be updated. Vehicles with standard type ignition switch− When refuelling, turn the engine switch off. If the vehicle is refuelled without turning the engine switch off, the display may not be updated. Vehicles with a smart entry and start system− When refuelling, turn the ENGINE START STOP switch off. If the vehicle is refuelled without turning the ENGINE START STOP switch off, the display may not be updated. • Average fuel consumption Displays the average fuel consumption since the function was reset. – The function can be reset by pressing the DISP button for longer than 1 second when the average fuel consumption is displayed. The average fuel consumption meter will also be reset, returning the needle to the 0 position.
Page 127 WHEN DRIVING Instrument cluster Customising vehicle features It is possible to customise the language and Eco Driving Indicator light settings using the DISP button. When customising vehicle features, ensure that the vehicle is parked in a safe place with the shift lever in P position and the parking brake set. Language− Without Paddle shift 1. While the vehicle is stopped press the DISP button to display the setting screen then press and hold the DISP button to display the customise mode screen. With Paddle shift CTY22AV480a 2. Press the DISP button to select the item to be set, then press and hold the DISP button.
Page 128 WHEN DRIVING Instrument cluster 3. Press the DISP button to select the desired setting, and then press and hold the DISP button. To go back to the previous screen or exit the customise mode, press the DISP button to select EXIT, and then press and hold the DISP button. Eco Driving Indicator Light and the current Without Paddle shift fuel consumption screen− 1. While the vehicle is stopped press the DISP button to display the setting screen then press and hold the DISP button to display the customise mode screen. With Paddle shift CTY22AV480a 2. Press the DISP button to select the item to be set, then press and hold the DISP button.
Page 129 WHEN DRIVING Instrument cluster 3. Press the DISP button to select the desired setting, and then press and hold the DISP button. When the ECO INDICATOR is set to OFF, the current fuel consumption gauge will not be displayed. To go back to the previous screen or exit the customise mode, press the DISP button to select EXIT, and then press and hold the DISP button. NOTICE The multi-information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed.
Page 130: Operating The Lights And Wipers
WHEN DRIVING Operating the lights and wipers Operating the lights and wipers HEADLIGHT SWITCH Turning the end of the lever will turn the lights on as follows. Vehicles with standard type ignition switch– The headlights and parking lights, etc. turn on and off automatically (when the ignition switch is in the ON position). Vehicles with smart entry and start system– The headlights and parking lights, etc. turn on and off automatically (when the ENGINE START STOP switch is in IGNITION ON mode). The parking, tail, licence plate and instrument panel lights turn on. The headlights and all the lights listed above turn on. If a headlight, parking light, stop or tail light bulb requires replacing, refer to “Light bulbs” on page 284.
Page 131 WHEN DRIVING Operating the lights and wipers Headlight control sensor The automatic light control sensor is located on the top of the instrument panel. The sensor may not function correctly if an object is placed on the sensor, or anything that blocks the sensor is affixed to the windscreen. Doing so interferes with the sensor detecting the level of ambient light and may cause the automatic headlight system to malfunction. Automatic light cut off system Vehicles with standard type ignition switch– • The lights automatically turn off when the driver’s door is opened with the ignition switch turned to ACC or off. • To turn on the lights again, turn the ignition switch to ON position or turn the headlight switch off and then back to or Vehicles with smart entry and start system– • The lights automatically turn off when the driver’s door is opened with the ENGINE START STOP switch pressed to ACCESSORY mode or off.
Page 132: Automatic High Beam
WHEN DRIVING Operating the lights and wipers Customisable features that can be modified For further information refer to “Customisable features” on page 333. AUTOMATIC HIGH BEAM The Automatic High Beam system uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc. and automatically turns high beam on or off as required. Activating the automatic high beam system 1. Press the ENGINE START STOP switch to IGNITION ON mode. 2. Turn the Headlight switch to AUTO position. 3. Push the lever away from you. The Automatic High Beam indicator will illuminate when the headlights are turned on automatically to indicate the system is active.
Page 133 WHEN DRIVING Operating the lights and wipers Automatic high beam operating conditions When all the following conditions are fulfilled, high beam will automatically turn on after approximately 1 second. • The vehicle speed is above approximately 32 km/h. • The area ahead of the vehicle is dark. • There are no oncoming or preceding vehicles with headlights or tail lights turned on. If any of the following conditions are fulfilled, high beam will be automatically turned off. • Vehicle speed drops below approximately 32 km/h. • The area ahead of the vehicle is not dark. • Oncoming or preceding vehicles have headlights or tail lights turned on. CAUTION Automatic high beam system limitations Do not rely on the automatic high beam system. Always drive safely, taking care to observe your surroundings and turning high beam on or off manually if necessary. Turning the high beam on/off manually Switching to low beam • Pull the lever to centre position.
Page 134 WHEN DRIVING Operating the lights and wipers INFORMATION Camera sensor detection information High beam may not be turned off automatically in the following situations. • When oncoming vehicles suddenly appear from a curve. • When the vehicle is cut in front of by another vehicle. High beam may be turned off if an oncoming vehicle that is using fog lights without using the headlights is detected. House lights, street lights, red traffic signals and illuminated billboards or signs may cause the high beam to turn off. The following factors may affect the amount of time taken to turn high beam on or off. • The brightness of oncoming and preceding vehicles headlights, fog and tail lights. • Road conditions (wetness, ice, snow, etc.). • The number of passengers and amount of baggage in the vehicle. High beam may be turned on or off when unexpected by the driver. In the situations below, the system may not be able to correctly detect the surrounding brightness levels and may flash or expose nearby pedestrians to the high beam. Therefore, you should consider turning the high beams on or off manually rather than relying on the automatic high beam system. • In bad weather (rain, snow, fog, sandstorms, etc.). • The windscreen is obscured by fog, mist, ice, dirt, etc. • The windscreen is cracked or damaged. • The inside rear view mirror or camera sensor is deformed or dirty. • Surrounding brightness levels are equal to those of the headlights, tail or fog lights.
Page 135 • Do not apply window tinting or stickers to the camera sensor or the area of windscreen near the camera sensor. • Do not place items on the dashboard. There is a possibility the camera sensor will mistake items reflected in the windscreen for streetlights or the headlights of other vehicles, etc. • Do not install a parking tag or any other accessories near or around the inside rear view mirror and the camera sensor. • Do not overload the vehicle. • Do not modify the vehicle. • Do not replace the windscreen with a non-genuine windscreen. Contact your Toyota dealer should you need to replace your windscreen. If the automatic high beam indicator illuminates in yellow This may indicate a malfunction in the automatic high beam system. Contact your Toyota dealer. Temporary lowering sensor sensitivity The sensitivity of the sensor can be temporarily lowered by pushing and holding the AUTO button on the inside rear view mirror for 15 to 20 seconds. The indicator light on the inside rear view mirror will flash to indicate the sensitivity has been lowered. When the ENGINE START STOP switch is pressed off, the sensitivity will be returned to its normal level.
Page 136: Adaptive Front-Lighting System
Operating the lights and wipers ADAPTIVE FRONT-LIGHTING SYSTEM (AFS) AFS (Adaptive Front-lighting System) secures excellent visibility at intersections and on curves by automatically adjusting the direction of the light axis of the headlights according to vehicle speed and the degree of the tyre’s angle as controlled by steering input. AFS operates at speeds of 10 km/h or higher. Deactivating AFS Pressing the AFS switch turns the AFS on / off. The indicator illuminates when the AFS is deactivated. INFORMATION • Automatic headlight levelling system (vehicles with discharge headlights) The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. • If the AFS OFF indicator flashes (vehicles with discharge headlights) It may indicate a malfunction in the system. Contact your Toyota dealer.
Page 137: Front Fog Lights
WHEN DRIVING Operating the lights and wipers FRONT FOG LIGHTS The fog lights provide improved visibility in difficult driving conditions such as fog or rain. 1. To turn on the front fog lights, while the parking lights or headlights are turned on, twist the band of the headlight and turn signal switch lever. 2. To turn the front fog lights off, twist the band to the off position. The front fog light indicator light on the instrument cluster illuminates when the front fog lights are on. If a fog light bulb requires replacing, refer to “Light bulbs” on page 284. WINDSCREEN WIPERS AND WASHERS Intermittent operation type The wipers and washers can be operated when the ignition switch is turned to the ON position (vehicles with standard type ignition switch) or when the ENGINE START STOP switch is pressed to IGNITION ON mode (vehicles with smart entry and start system). To turn on the windscreen wipers, move the lever to the desired setting. 1. Intermittent operation. 2. Low speed operation. 3. High speed operation.
Page 138 Operating the lights and wipers To adjust the wiper time interval when the wiper lever is in the intermittent position. 1. Twist the band upward to increase the intermittent windscreen wiper frequency. 2. Twist the band downward to decrease the intermittent windscreen wiper frequency. To spray washer fluid. 1. Pull the lever toward you. The wipers will automatically operate a couple of times after the washer sprays. • In freezing weather, warm the windscreen with the defroster before using the washer. This will help prevent the washer fluid from freezing on your windscreen, which can block your vision. For instructions on adding washer fluid, refer to “Washer fluid” on page 266. NOTICE Do not operate the wipers if the windscreen is dry. It may scratch the glass. If the washer fluid tank is empty, do not operate the washer switch continually as the washer fluid pump may overheat. If a nozzle becomes blocked, do not try to clear it with a pin or other object. The nozzle will be damaged. Contact your Toyota dealer. Raindrop detection type When AUTO position is selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. The wipers and washers can be operated when the ENGINE START STOP switch is pressed to IGNITION ON mode.
Page 139 WHEN DRIVING Operating the lights and wipers To operate the windscreen wipers, move the lever to the desired setting. 1. Rain-sensing wiper operation (AUTO). 2. Low speed wiper operation. 3. High speed wiper operation. 4. Single sweep operation. When AUTO is selected, the sensor sensitivity can be adjusted as follows by turning the switch ring: 1. Twist the band upward to increase the sensitivity. 2. Twist the band downward to decrease the sensitivity. To spray washer fluid. 1. Pull the lever toward you. The wipers will automatically operate a couple of times after the washer sprays. Then, after a short delay, they will operate once more to remove any drips. If the headlights are on, the headlight cleaners will operate once (if fitted).
Page 140 • In freezing weather, warm the windscreen with the defroster before using the washer. This will help prevent the washer fluid from freezing on your windscreen, which can block your vision. For instructions on adding washer fluid, refer to “Washer fluid” on page 266. The wiper frequency is determined by the amount of raindrops detected by the raindrop sensor. An optical sensor is used which may not operate correctly when sunlight from the rising or setting of the sun intermittently strikes the windscreen, or if bugs, etc. are present on the windscreen. • If the wiper switch is turned to the AUTO position while the ENGINE START STOP switch is in IGNITION ON mode, the wiper will operate once to show that AUTO mode is activated. • If the temperature of the raindrop sensor is 90°C or higher, or −15°C or lower, automatic operation may not occur. In this case, operate the wipers in any mode other than AUTO. CAUTION Using the windscreen wipers in AUTO mode The windscreen wipers may operate unexpectedly if the sensor is touched or the windscreen is subject to vibration while in AUTO mode. Take care that your fingers, etc. do not become caught in the windscreen wipers. NOTICE When using an automatic car wash, set the wiper lever to the OFF position. Do not operate the wipers if the windscreen is dry. It may scratch the glass. If the washer fluid tank is empty, do not operate the washer switch continually as the washer fluid pump may overheat. If a nozzle becomes blocked, do not try to clear it with a pin or other object. The nozzle will be damaged. Contact your Toyota dealer.
Page 141: Headlight Cleaner Switch
WHEN DRIVING Operating the lights and wipers HEADLIGHT CLEANER SWITCH Washer fluid can be sprayed on the headlights. The headlight cleaners can be operated when The ENGINE START STOP switch is in IGNITION ON mode and the headlight switch is turned on. Press the switch to clean the headlights. Windscreen washer linked operation When the windscreen washer is operated with the ENGINE START STOP switch in IGNITION ON mode and the headlights on, the headlight cleaners will operate once. Refer to “Windscreen wipers and washers” on page 115. NOTICE When the washer fluid tank is empty Do not press the switch continually as the washer fluid pump may overheat.
Page 142: Using Other Driving Systems
WHEN DRIVING Using other driving systems Using other driving systems CRUISE CONTROL The cruise control system is designed to maintain a set cruising speed without requiring the driver to operate the accelerator. Within the limits of the engine’s capabilities, cruising speed can be set and maintained above 40 km/h up or down grades. However, changes in vehicle speed may occur on steeper grades. 1. Instrument cluster indicators 2. Cruise control switch CAUTION To help maintain maximum control of your vehicle, do not use the cruise control when driving in heavy or varying traffic, on slippery (rainy, icy or snow-covered) or winding roads, on roads with sharp bends, while towing a trailer or during emergency towing. Avoid vehicle speed increases when driving downhill. If the vehicle speed is too fast in relation to the cruise control set speed, cancel the cruise control and then downshift the transmission to use engine braking to slow down. Turning the system on and off Press the cruise control ON–OFF button to turn the cruise control system on. The cruise control indicator on the instrument cluster will illuminate to indicate the cruise control is operational. Pressing the ON–OFF button again turns the system off.
Page 143 WHEN DRIVING Using other driving systems Setting the cruising speed Set the transmission in D position, or in range 4 or higher if S mode is selected. Bring your vehicle to the desired speed above 40 km/h. Push the lever down in the –SET direction and release it. • The SET indicator on the instrument cluster will illuminate and the vehicle speed will be set. You can now take your foot off the accelerator pedal. If the speed is not satisfactory, operate the lever until the desired speed is obtained. Fine adjustment: 1. Tap the lever up to increase speed, or 2. Tap the lever down to decrease speed. • Each tap changes the speed by 1.6 km/h. Large adjustment: 1. Hold the lever up to increase speed, or 2. Hold the lever down to decrease speed. • Release the lever when the desired speed is obtained. • If you need acceleration – for example, when overtaking – depress the accelerator pedal enough for the vehicle to exceed the set speed. When you release the accelerator pedal, the vehicle will return to the speed set prior to the acceleration.
Page 144: Rear View Monitor System
Automatic cruise control cancellation The cruise control system will stop maintaining the vehicle speed in any of the following situations. • The actual vehicle speed falls more than approximately 16 km/h below the preset vehicle speed. At this time, the memorised set speed is not retained. • THe actual vehicle speed is below approximately 40 km/h. • The VSC system is activated. If CHECK CRUISE CONTROL is displayed on the multi-information display Press the ON-OFF button once to deactivate the system, and then press the button again to reactivate the system. • If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. REAR VIEW MONITOR SYSTEM The rear view monitor system assists the driver by displaying an image of the view behind the vehicle while backing up. The image is displayed in reverse on the audio / navigation screen which allows the image to appear in the same manner as that of the rear view mirror. To display the rear view image on the screen, place the shift lever in the R position when the ignition switch is in the ON position (vehicles with standard...
Page 145 • Use caution, just as you would when reversing any vehicle. • The guide lines are ancillary lines and do not change even if the steering wheel is turned. • Never reverse while looking only at the screen. The image on the screen is different from actual conditions. Depicted distances between objects and flat surfaces will differ from actual distance. If you reverse while looking only at the screen, you may hit a vehicle, a person or an object. When reversing, always check behind and all around the vehicle visually and with mirrors before proceeding. The image on the screen may be inaccurate in the following ways: – The distances depicted between objects and flat surfaces will differ from actual distances – If the temperature changes rapidly, such as when hot water is poured on the vehicle in cold weather, the system may not operate normally – If the camera lens becomes dirty, it cannot transmit a clear image. If water droplets, snow, or mud adhere to the lens, rinse with water and wipe with a soft cloth. If the lens is extremely dirty, wash it with a mild cleanser and rinse – When the outside temperature is low or the system is cold, the displayed image may become faint or dark, and moving images will be distorted, or not entirely visible – If the back of the vehicle is damaged, the position and mounting angle of the camera may change. Have the camera’s position and mounting angle checked at your Toyota dealer – If the boot lid is not completely closed – As the camera has a water proof construction, do not detach, disassemble or modify it. This may cause incorrect operation – Do not allow organic solvent, car wax, window cleaner or glass coat to adhere to the camera. If this happens, wipe off as soon as possible When replacing the tyres, please consult your Toyota dealer. If you replace the tyres, the area displayed on the screen may change.
Page 146 WHEN DRIVING Using other driving systems Rear view monitor guide lines Guide lines are displayed on the monitor. 1. Vehicle width extension guide lines. These lines indicate the estimated vehicle width extension. 2. Distance guide line. This line indicates a position on the ground about 1 m behind the rear bumper of your vehicle. 3. Distance guide line (red). This line indicates a position on the ground about 0.5 m behind the rear bumper of your vehicle. 4. Vehicle centre guide lines. These lines indicate the estimated vehicle centre on the ground. Displayed area The area detected by the camera is limited. Objects which are close to either corner of the bumper or are under the bumper may not be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions. The camera uses a special lens. The distance of the image that appears on the screen differs from the actual distance.
Page 147 WHEN DRIVING Using other driving systems Driving precautions When the grade behind the vehicle slopes up sharply, objects appear to be farther away than they actually are. When the grade behind the vehicle slopes down sharply, objects appear to be closer than they actually are.
Page 148 WHEN DRIVING Using other driving systems The distance between three-dimensional Approx. 1 m objects (such as another vehicle) and flat surfaces (such as the road) appears different on the screen as follows. In reality, A and C are the same distance from the vehicle, while B is farther away. However, on the screen, the situation appears to be A is closer than B which appears closer than C. On the screen, it appears that a truck is parked approximately 1 m away. In reality if you back up to point A, you will hit the truck. Rear view monitor system camera The rear view monitor system camera is located on the boot lid as shown in the illustration. In the following cases, it may become difficult to see the images on the screen, even when the system is functioning. • In the dark, such as at night. • When the temperature near the lens is high or low. • When water droplets are adhering to the camera, or when humidity is high, such as when it rains.
Page 149: Toyota Parking Assist-Sensor
WHEN DRIVING Using other driving systems TOYOTA PARKING ASSIST-SENSOR The Toyota parking assist-sensor is a warning system to aid parking the vehicle at low speed (e.g. into a garage). It uses an ultrasonic sensor, which checks the approximate distance to an obstacle. It will inform you of the approximate distance to an obstacle by displaying information on the multi-information display and with beeping sounds. 1. Front corner sensors. 2. Rear corner sensors. CAUTION The Toyota parking assist-sensor is designed to be of assistance only when parking and does not replace the need to visually check the area around the vehicle when parking to avoid injury or other danger. Parking assist-sensor switch With the ENGINE START STOP switch in IGNITION ON mode, push the parking assist-sensor switch. The indicator light on the switch comes on indicating the parking assist-sensor is on. Pushing the switch again will turn the parking assist-sensor off.
Page 150 WHEN DRIVING Using other driving systems Display When the sensors detect an obstacle, a graphic is shown on the multi-information display depending on the position and distance to the obstacle. 1. Front corner sensor operation. 2. Rear corner sensor operation. Distance display and buzzer When a sensor detects an obstacle, the direction of and the approximate distance to the obstacle are displayed and the buzzer sounds. Front corner sensors− Approximate distance to Multi-information display Buzzer obstacle 50 to 40 cm Medium 40 to 30 cm Fast Less than 30 cm Continuous Rear corner sensors− Approximate distance to Multi-information display Buzzer obstacle 60 to 45 cm Medium 45 to 30 cm Fast Less than 30 cm Continuous...
Page 151 WHEN DRIVING Using other driving systems Detection range of sensors 1. Approximately 50 cm. 2. Approximately 60 cm. The diagram shows the detection range of the sensors. Note that the sensors cannot detect obstacles that are extremely close to the vehicle. The range of the sensors may change depending on the shape of the object etc. CAUTION The Toyota parking assist-sensor may not detect the following: • Thin objects such as wire or rope • Sound wave absorbing objects such as cotton or snow • Objects with a sharp edge • Tall objects with the upper part projected • Shorter objects Always visually check the area around the vehicle when parking. CAUTION To avoid an accident or injury, observe the following instructions, and then drive slowly using the brakes while visually confirming a safe distance around your vehicle. • Do not use the sensors at speeds in excess of 10 km/h. • The sensor detection range is limited around the bumper. Always visually confirm safety outside the sensor detection.
Page 152 WHEN DRIVING Using other driving systems CAUTION The Toyota parking assist-sensor may not work correctly in the following cases: • When the bumper is damaged. Contact your Toyota dealer • When the part near the sensors is subjected to a strong impact • When an accessory is installed within the sensor detection range • Towing eyelet is installed • When snowflakes or mud gets on the sensors. (If removed, the parking assist-sensor will work correctly) • A sensor is frozen • When water is splashed from a high pressure car wash or there is steam on the sensors • When a sensor is covered in any way • When the vehicle is tilted • In extreme hot or cold weather (In extreme cold weather, the error display appears and the parking assist-sensor becomes inoperative) • In harsh sunlight • When driving on bumpy roads, slopes, gravelled roads or grass • When devices issuing ultrasonic waves are operated around your vehicle, such as the horns from other vehicles, motorcycle engines, the air braking sound from heavy vehicles, etc • When another vehicle equipped with ultrasonic sensors gets close to your vehicle • When heavy rain or water is splashed over the vehicle.
Page 153: Blind Spot Monitor (Bsm)
The system uses radar sensors to detect vehicles that are travelling in an adjacent lane within the area not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicle’s existence via an outside rear view mirror indicator. 1. BSM main switch: Pressing the switch turns the system on or off. When the switch is set to on, the switch’s indicator illuminates. 2. Outside rear view mirror indicator: When a vehicle is detected in the blind spot, the outside rear view mirror indicator on that side illuminates. If the turn signal lever is operated when a vehicle is in the blind spot, the outside rear view mirror indicator flashes. INFORMATION The blind spot monitor is operational when: • The BSM main switch is set to on and vehicle speed is greater than about 40 km/h. The blind spot monitor will detect a vehicle when: • A vehicle in an adjacent lane overtakes your vehicle • Another vehicle enters the vehicle’s detection area when it changes lanes. Towing When towing, Toyota recommends that the Blind Spot Monitor System is turned OFF to prevent unnecessary warning activation.
Page 154 WHEN DRIVING Using other driving systems Blind spot monitor detection areas The range of the blind spot area where other vehicles can be detected in extends 1. Approximately 3.5 metres from the side of your vehicle. The first 0.5 metres from the side of your vehicle is not in the detection area. 2. Approximately 3 metres from your rear bumper. 3. Approximately 1 metre forward of your rear bumper. CAUTION Cautions regarding the use of the system The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Use the blind spot monitor in conjunction with the drivers own visual confirmation of safety. The blind spot monitor is a supplementary system which alerts the driver that a vehicle is present in the blind spot. The system cannot judge if it is safe to change lanes, therefore over-reliance could cause an accident resulting in death or serious injury. According to conditions, the system may not function correctly. For information on conditions under which the blind spot monitor may not function correctly refer below.
Page 155 WHEN DRIVING Using other driving systems Conditions under which the blind spot monitor may not function correctly The blind spot monitor may not detect vehicles correctly in the following situations: • During bad weather such as heavy rain, fog or snow, etc. • When ice or mud, etc. is attached to the rear bumper • When driving on a road surface that is wet due to rain or standing water, etc. • When there is a significant difference in speed between your vehicle and the vehicle that enters the detection area • When a vehicle is in the detection area from a stop and remains in the detection area as your vehicle accelerates • When driving up or down consecutive steep inclines, such as hills or a dip in the road, etc. • When multiple vehicles approach with only a small gap between each vehicle • When vehicle lanes are wide and the vehicle in the next lane is too far away from your vehicle • When the vehicle that enters the detection area is travelling at about the same speed as your vehicle • When there is a significant difference in height between your vehicle and the vehicle that enters the detection area • Directly after the BSM switch is set to on...
Page 156 WHEN DRIVING Using other driving systems NOTICE Handling the radar sensor One blind spot monitor is installed inside the left-hand and right-hand side of the vehicle rear bumper respectively. Observe the following to ensure the blind spot monitor can function correctly. • Keep the sensor and its surrounding area on the bumper clean at all times. • Do not subject the sensor or surrounding area on the bumper to a strong impact. If the sensor moves even slightly off position, the system may malfunction and vehicles that enter the detection area may not be detected. If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Toyota dealer. • Do not disassemble the sensor. • Do not attach accessories or stickers to the sensor or surrounding area on the bumper bar. • Do not modify the sensor or surrounding area on the bumper bar. • Do not paint the sensor or surrounding area on the bumper.
Page 157: Driving Assist Systems
Be aware, however, these systems should be used as a supplementary aid and the driver should not rely on these systems in place of the driver’s own judgement and observations. • Anti-lock Brake System (ABS) Helps to prevent wheel lock when the brakes are applied suddenly, or if the brakes are applied while driving on a slippery road surface. • Brake Assist Generates an increased level of braking force after the brake pedal is depressed when the system detects a panic stop situation. • Vehicle Stability Control (VSC) Helps the driver to control skidding when swerving suddenly or turning on slippery road surfaces. • Traction Control (TRC) Helps to maintain drive power and prevent the drive wheels from spinning when starting the vehicle or accelerating on slippery roads. • Electric Power Steering (EPS) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel. When the VSC and/or TRC systems are operating If the vehicle is in danger of slipping or if any of the drive wheels spins, the slip indicator flashes to indicate the VSC / TRC systems are operating. The slip indicator along with an ABS warning light and EPS warning light illuminate for a few seconds when the ignition key is turned to ON (vehicles with standard type ignition switch) or the ENGINE START STOP switch is pressed to IGNITION ON mode (vehicles with smart start and entry system). If the indicator and warning lights do not illuminate when the ignition is turned on, or if they remain illuminated and do not go off, contact your Toyota dealer.
Page 158 EPS operation sound. • When the steering wheel is operated, a motor sound (whirring sound) may be heard. This does not indicate a malfunction. Reduced effectiveness of the EPS system. • The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the engine off. The EPS system should return to normal within 10 minutes. If it does not, contact your Toyota dealer. CAUTION The ABS does not operate effectively when Tyres with inadequate gripping ability are used (such as excessively worn tyres on a snow covered road). The vehicle hydroplanes while driving at high speed on wet or slick roads. Stopping distance when the ABS is operating may exceed that of normal conditions The ABS is not designed to shorten the vehicle’s stopping distance. Always maintain a safe distance from the vehicle in front of you in the following situations: • When driving on dirt, gravel or snow-covered roads • When driving with tyre chains...
Page 159 WHEN DRIVING Using other driving systems CAUTION TRC may not operate effectively when Directional control and power may not be achievable while driving on slippery road surfaces, even if the TRC system is operating. Do not drive the vehicle in conditions where stability and power may be lost. When the VSC is activated The slip indicator flashes. Always drive carefully. Reckless driving may cause an accident. Exercise particular care when the indicator flashes. Replacing tyres Make sure that all tyres are of the specified size, brand, tread pattern and total load capacity. In addition, make sure the tyres are inflated to the recommended tyre inflation pressure level. The ABS, TRC and VSC systems will not function correctly if different tyres are installed on the vehicle. Contact your Toyota dealer for further information when replacing tyres or wheels. Handling of tyres and the suspension Using tyres with any kind of problem or modifying the suspension will affect the driving assist systems and may cause the system to malfunction.
Page 160: Driving Information
• For the first 1000 km: – Avoid full throttle acceleration when starting and driving – Avoid over-revving the engine – Do not drive for a long time at any single speed, either fast or slow PRE-TRIP SAFETY CHECK It is a good idea to do a safety check before starting out on a trip. A few minutes of checking can help ensure safe and pleasant driving. Just a basic familiarity with your vehicle is required and a careful eye! Items to check include, but are not limited to: • Tyre condition and pressure (including the spare wheel). • Fluid levels. If the vehicle has been parked for a while check for fluid leaking underneath the vehicle. (Water dripping from the air conditioner after use is normal). • All lights operate normally. • No indicators or warning lights remain illuminated once the vehicle has been started. • Any other items or noises that appear abnormal. If you would like, your Toyota dealer will be pleased to make this check for you at a nominal cost. ECO FRIENDLY DRIVING Your Toyota is fitted with an Eco Driving indicator to help you maximise fuel economy / minimise fuel consumption and your impact on the environment. During eco-friendly acceleration (eco driving) the indicator will illuminate. If the acceleration exceeds the zone of eco driving, and when the vehicle is stopped, the indicator turns off. Eco Driving Indicator Light will not operate in the following conditions: • The shift lever is in anything other than D position.
Page 161: Information When Driving In
– Accidentally depressing the accelerator pedal instead of the brake pedal will result in sudden acceleration that may lead to an accident that could result in death or serious injury – When reversing, you may twist your body around, leading to difficulty operating the pedals – Maintain the correct driving posture even when moving the vehicle only slightly. This allows you to depress the brake and accelerator pedals correctly – Depress the brake pedal using your right foot. Depressing the brake pedal using your left foot may delay response in an emergency, resulting in an accident • Do not drive the vehicle over, or stop the vehicle near, flammable materials such as long grass, etc. The exhaust system and exhaust gases can be extremely hot. These hot parts may cause a fire if there is any flammable material nearby. • Do not let the vehicle roll backward while the shift lever is in a driving position, or roll forward while the shift lever is in R position. Doing so may cause the engine to stall or lead to poor brake and steering performance, resulting in an accident or damage to the vehicle. • If the smell of exhaust is noticed inside the vehicle, open the windows and check the boot lid is closed. Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. • Do not move the shift lever to P position while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. • Do not move the shift lever to R position while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control. • Do not move the shift lever to D position while the vehicle is moving backward. Doing so can damage the transmission and may result in a loss of vehicle control. • Moving the shift lever to N position while the vehicle is moving will disengage the engine from the transmission. Engine braking is not available when N position is selected.
Page 162 When shifting the shift lever • Be careful not to shift the shift lever with the accelerator pedal depressed. Shifting the shift lever to a gear other than P or N may lead to unexpected rapid acceleration of the vehicle that may cause an accident and result in death or serious injury. If you hear a squealing or scraping noise (brake pad wear indicators) • Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed. It is dangerous to drive the vehicle when the wear limits of the brake pads and/or those of the brake discs are exceeded. When the vehicle is stopped • Do not over-rev the engine. If the vehicle is in any gear other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident. • Do not leave the vehicle with the engine running for a long time. If such a situation cannot be avoided, park the vehicle in an open space and check that exhaust fumes...
Page 163 WHEN DRIVING Driving Information CAUTION • In order to prevent accidents due to the vehicle rolling away, always keep depressing the brake pedal while the engine is running, and apply the parking brake as necessary. • If the vehicle is stopped on an incline, in order to prevent accidents caused by the vehicle rolling forward or backward, always depress the brake pedal and securely apply the parking brake as needed. • Avoid revving or racing the engine. Running the engine at high speed while the vehicle is stopped may cause the exhaust system to overheat, which could result in a fire if combustible material is nearby. When the vehicle is parked • Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: – Gas may leak from a cigarette lighter or spray can, and may lead to a fire – The temperature inside the vehicle may cause the plastic lenses and plastic material of glasses to deform or crack – Soft drink cans may fracture, causing the contents to spray over the interior of the vehicle, and may also cause a short circuit in the vehicle’s electrical components • Do not leave cigarette lighters in the vehicle. If a cigarette lighter is in a place such as the glove box or on the floor, it may be lit accidentally when luggage is loaded or the seat is adjusted, causing a fire. • Do not attach adhesive discs to the windscreen or windows. Do not place containers such as air fresheners on the instrument panel or dashboard. Adhesive discs or containers may act as lenses, causing a fire in the vehicle.
Page 164 WHEN DRIVING Driving Information CAUTION Exhaust gases • Exhaust gases include harmful carbon monoxide (CO), which is colourless and odourless. Inhaling exhaust gases may lead to death or a serious health hazard. • If the vehicle is in a poorly ventilated area, stop the engine. In a closed area, such as a garage, exhaust gases may collect and enter the vehicle. This may lead to death or a serious health hazard. • The exhaust system should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard. When taking a nap in the vehicle • Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard. When braking • When the brakes are wet, drive more cautiously. Braking distance increases when the brakes are wet, and this may cause one side of the vehicle to brake differently than the other side. Also, the parking brake may not securely hold the vehicle. • If the power brake assist function does not operate, do not follow other vehicles closely and avoid hills or sharp turns that require braking. In this case, braking is still possible, but the brake pedal should be depressed more firmly than usual. Also, the braking distance will increase.
Page 165 If you get a flat tyre while driving • A flat or damaged tyre may cause the following situations. Hold the steering wheel firmly and gradually depress the brake pedal to slow down the vehicle. – It may be difficult to control your vehicle – The vehicle will make abnormal sounds or vibrations – The vehicle will lean abnormally • For information on how to change a flat tyre refer to page 306. When encountering flooded roads • Do not drive on a road that has flooded after heavy rain, etc. Doing so may cause the following serious damage to the vehicle: – Engine stalling – A short circuit in electrical components – Engine damage caused by water immersion • In the event that you drive on a flooded road and the vehicle is flooded, have your Toyota dealer check the following: – Brake function – Changes in quantity and quality of engine oil, and transaxle fluid, etc. – Lubricant condition of the bearings and suspension joints (where possible) and the function of all joints and bearings, etc.
Page 166: Winter Driving Tips
Always drive the vehicle in a manner appropriate to the prevailing weather conditions. Driving in the rain Drive carefully when it is raining as visibility will be reduced and the windows may become fogged-up. Drive carefully when it starts to rain, because the road surface will be especially slippery. Refrain from high speeds when driving on an expressway in the rain, because there may be a layer of water between the tyres and the road surface that could cause the vehicle to hydra-plane, preventing the steering and brakes from operating properly. Pre-winter preparations Use the following fluids that are appropriate to the prevailing outside temperatures: • Engine oil • Engine coolant • Washer fluid Have your Toyota dealer check the engine coolant and inspect the level and specific gravity of battery electrolyte. If required, have the vehicle fitted with four snow tyres, or purchase a set of tyre chains for the front tyres. • Ensure that all tyres are the same size and brand, and the chains match the size of the tyres. Before driving the vehicle Perform the following according to the driving conditions. • Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. • Wipe away the water immediately to prevent it from freezing. • To ensure correct operation of the climate control system fan, remove any snow that has accumulated on the air inlet vents in front of the windscreen.
Page 167: Installing Snow Tyres And Chains . 1
WHEN DRIVING Driving Information INSTALLING SNOW TYRES AND CHAINS When to use snow tyres or chains Snow tyres or chains are recommended when driving on snow or ice. On wet or dry roads, conventional tyres provide better traction than snow tyres. Snow tyre selection If you need snow tyres, select tyres of the same size, construction and load capacity as the originally installed tyres. Do not use tyres other than those mentioned above. Do not install studded tyres without first checking local regulations for possible restrictions. CAUTION Do not use snow tyres other than the manufacturer’s recommended size, as this may cause dangerous handling characteristics resulting in loss of control. Otherwise, an accident may occur resulting in death or serious injuries. Snow tyre installation Installing snow tyres on the front wheels only can lead to an excessive difference in road grip capability between the front and rear tyres, which could cause loss of vehicle control. When storing removed tyres, you should store them in a cool dry place. Mark the direction of rotation and ensure to install them in the same direction when replacing. CAUTION • Snow tyres should be installed on all wheels of the vehicle. • Do not drive with the snow tyres incorrectly inflated. • Observe permissible maximum speed for your snow tyres and the legal speed limit (whichever is lower). Tyre chain selection Use the tyre chains of the correct type and size.
Page 168: Trailer Towing
Driving Information NOTICE If the wrong combination of tyre and chain is used, the chains could damage the vehicle body and/or not achieve their intended outcome. Chain installation Install the chains on the front tyres as tightly as possible. Do not use tyre chains on the rear tyres. Retighten chains after driving 0.5 – 1.0 km. When installing chains on your tyres, carefully follow the instructions of the chain manufacturer. If wheel covers are used, they will be scratched by the chain band, so remove the covers before putting on the chains. CAUTION Do not use tyre chains on the rear tyres. When using tyre chains: • Do not exceed 50 km/h or the chain manufacturer’s recommended speed limit, whichever is lower • Drive carefully avoiding bumps, holes, and sharp turns, which may cause the vehicle to bounce. • Avoid sharp turns or locked-wheel braking as use of chains may adversely affect vehicle handling • Slow down before entering curves to avoid losing control of the vehicle, otherwise an accident may occur TRAILER TOWING Your vehicle is designed primarily as a passenger-carrying vehicle. Towing a trailer will have an adverse effect on handling, performance, braking, durability and driving economy (fuel consumption, etc.). Your safety and satisfaction depend on the correct use of equipment and cautious driving habits. NOTICE For your safety and the safety of others, you must not overload your vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Ask your local Toyota dealer for further details before towing, as there are additional legal requirements in some countries.
Page 169 Rear: ........1075 kg INFORMATION Blind spot monitor When towing, Toyota recommends that the Blind Spot Monitor System is turned OFF to prevent unnecessary warning activation.
Page 170 • Vertical tow ball load / total trailer weight x 100 = 9 to 11% Never load the trailer with more weight in the back than in the front. About 60% of the trailer load should be in the front half of the trailer and the remaining 40% in the rear. 1. Total trailer weight. 2. Vertical tow ball load. Tow bars Use only a tow bar which is recommended by the tow bar manufacturer and conforms to the total trailer weight requirement. Follow the directions supplied by the tow bar manufacturer, and bolt the tow bar securely to the vehicle. Lubricate the tow ball with a light coat of grease. If removing the tow bar assembly, seal any mounting holes in the vehicle body to prevent entry of pollutants such as exhaust fumes, dirt or water. Brakes and safety chains Toyota recommends trailers with brakes conform to applicable Federal and State regulations. Safety chains must always be used between the towing vehicle and the trailer. Leave sufficient slack in the chains for turns. The chains should cross under the trailer coupling to prevent the trailer coupling from dropping to the ground in case it becomes damaged or the trailer separates from the vehicle. For correct safety chains procedures, follow the tow bar or trailer manufacturer’s recommendations. CAUTION • If the total trailer weight exceeds 500 kg, trailer brakes are required. • Never tap into your vehicle’s hydraulic system as it would lower its braking effectiveness. • Never tow a trailer without using safety chains securely attached to both the trailer and the vehicle.
Page 171 WHEN DRIVING Driving Information Tyres Ensure your vehicle’s tyres are correctly inflated. Refer to “Checking tyre inflation pressure” on page 267. The trailer tyres should be inflated to the pressure recommended by the trailer manufacturer in respect to the total trailer weight. Trailer lights Trailer lights must comply with federal and state regulations. See your Toyota dealer for the correct type of wiring and relays for your trailer. Check for correct operation of the turn signals and stop lights each time you attach the trailer. Direct splicing may damage your vehicle’s electrical system and cause a malfunction of your lights. Running-in schedule Toyota recommends that you do not tow a trailer with a new vehicle or a vehicle with any new powertrain component (engine, transmission, differential, wheel bearing, etc.) for the first 800 km of driving. Maintenance If you tow a trailer, your vehicle will require more frequent maintenance due to the additional load. For this information, please refer to the scheduled maintenance information in the Warranty and Service Book. Retighten all fixing bolts of the tow ball and tow bar after approximately 1000 km of trailer driving. Pre-towing safety check Check your vehicle remains level when a loaded or unloaded trailer is attached. Do not drive if the vehicle has an abnormal nose-up or nose-down condition, and check for incorrect vertical tow ball load, overload, load distribution of the vehicle or trailer, worn suspension or other possible causes. Make sure the trailer cargo is securely loaded so that it cannot shift. Check your rear view mirrors conform to any applicable federal and state regulations. If not, install the rear view mirrors required for the towing purposes. Trailer towing tips CAUTION • When towing a trailer, your vehicle will handle differently than when not towing.
Page 172 WHEN DRIVING Driving Information • Backing with a trailer is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to the right. (This procedure is generally opposite to that when backing without a trailer.) Also, just turn the steering wheel a little at a time, avoiding sharp or prolonged turning. Have someone guide you when backing to reduce the risk of an accident. • Because stopping distance may be increased, vehicle-to-vehicle distance should be increased when towing a trailer. For each 10 km/h of speed, allow at least one vehicle and trailer length between you and the vehicle ahead. Avoid sudden braking as you may skid, resulting in jack-knifing and loss of control. This is especially true on wet or slippery surfaces. • Avoid jerky starts or sudden acceleration. • Avoid jerky steering and sharp turns. The trailer could hit your vehicle in a tight turn. Slow down before making a turn to avoid the necessity of sudden braking. • Remember that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Therefore, compensate for this by making a larger than normal turning radius with your vehicle. • Crosswinds and rough roads will adversely affect the handling of your vehicle and trailer, causing sway. Pay attention to the rear from time to time to prepare yourself for being passed by large trucks or buses, which may cause your vehicle and trailer to sway. If swaying happens, firmly grip the steering wheel and reduce speed immediately but gradually. Never increase speed. If it is necessary to reduce speed, brake slowly. Steer straight ahead following the road. If you make no extreme correction with the steering or brakes, the vehicle and trailer will stabilise. • Be careful when passing other vehicles. Passing requires considerable distance. After passing a vehicle, do not forget the length of your trailer and ensure you have plenty of room before changing lanes. • In order to maintain engine braking efficiency, do not use overdrive. The transmission shift range position must be in 5 or 4 in S mode. • Because of the added load of the trailer, your vehicle’s engine may overheat on hot days (at temperatures over 30˚C) when going up a long or steep grade with a trailer. If the engine coolant temperature gauge indicates overheating, immediately turn off the...
Page 173: Cargo And Luggage
WHEN DRIVING Driving Information 3. When the wheel blocks are in place, release your brakes slowly until the blocks absorb the load. 4. Apply the parking brake firmly. 5. Shift into P position and turn off the engine. • When restarting out after parking on a slope: 1. With the transmission in P position, start the engine. Ensure to keep the brake pedal depressed. 2. Shift into gear. 3. Release the parking brake and foot brake, and slowly pull or back away from the wheel chocks. Stop and apply your brakes. 4. Have someone retrieve the wheel chocks. CAUTION Observe the legal maximum speeds for trailer towing. Slow down and downshift before descending steep or long downhill grades. Do not make sudden downshifts. Avoid holding the brake pedal down too long or too frequently. This could cause the brakes to overheat and result in reduced braking efficiency. CARGO AND LUGGAGE When stowing cargo or luggage in the vehicle, observe the following. • Put cargo or luggage in the boot when at all possible. Ensure all items are secured in place. • Be careful to keep the vehicle balanced. Locating the weight as far forward as possible helps maintain balance. • For better fuel economy, do not carry unnecessary weight. CAUTION Never allow anyone to ride in the enlarged boot (when the rear seat is folded down). It is not designed for passengers. They should ride in their seats with their seatbelts correctly fastened. Otherwise, they are much more likely to suffer death or serious injury in the event of sudden braking or a collision.
Page 174 WHEN DRIVING Driving Information CAUTION Do not drive with objects left on top of the instrument panel. They may interfere with the driver’s field of view. Or they may move during sharp vehicle acceleration or turning, and impair the driver’s control of the vehicle. In an accident they may injure the vehicle occupants. Items that must not be carried in the boot The following items may cause a fire if loaded in the boot: • Receptacles containing petrol • Aerosol cans Storage precautions Observe the following precautions. Failure to do so may result in death or serious injury. • Stow cargo and luggage in the boot whenever possible. • Fold-down type rear seat: To prevent cargo and luggage from sliding forward during braking, do not stack anything in the enlarged boot. Keep cargo and luggage low, as close to the floor as possible. • Fold-down type rear seat: When you fold down the rear seats, long items should not be placed directly behind the front seats. • Fold-down type rear seat: Never allow anyone to ride in the enlarged boot. It is not designed for passengers. They should ride in their seats with their seatbelts properly fastened. Otherwise, they are much more likely to suffer death or serious bodily injury, in the event of sudden braking, sudden swerving or an accident. • Do not place cargo or luggage in or on the following locations as the item may get under the clutch, brake or accelerator pedal and prevent the pedals from being depressed properly, block the driver’s vision, or hit the driver or passengers, causing an accident:...
Page 175: Interior Features
INTERIOR FEATURES Using the air conditioning system and defogger . . . 155 AUTOMATIC AIR CONDITIONING SYSTEM ... .155 FRONT, SIDE AND REAR VENTS ..... .161 REAR WINDOW DEFOGGER .
Page 176 INTERIOR FEATURES (CONT) Other interior features . . . . . . . . . . . . . . . . . . . . . . . . . . . 240 CLOCK .
Page 177: Using The Air Conditioning System And Defogger
INTERIOR FEATURES Using the air conditioning system and defogger Using the air conditioning system and defogger AUTOMATIC AIR CONDITIONING SYSTEM Front passenger’s side Air outlet Fan speed Driver’s side temperature control display display temperature control Front passenger’s Driver’s side side temperature temperature setting display setting display Automatic DUAL...
Page 178 INTERIOR FEATURES Using the air conditioning system and defogger 2. To adjust the fan speed, press [>] on to increase the fan speed and [<] to decrease the fan speed. Press to turn the fan off. 3. To adjust the temperature setting, turn clockwise to increase the temperature and turn counterclockwise to decrease the temperature. When is pressed (the indicator is on) or the passenger’s side temperature control dial is turned, the temperature for the driver and passenger seats can be adjusted separately. 4. To change the air outlets, press [<] or [>] on The air outlets used are switched each time either side of the button is pressed. Air outlets and air flow Panel− Air flows to the upper body. Bi-level− Air flows to the upper body and feet. Floor− Air flows mainly to the feet.
Page 179 1. Press The dehumidification function operates and the fan speed increases. Set the outside / recirculated air mode button to the outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windscreen and the side windows quickly, increase the air flow and temperature settings. To return to the previous mode, press again when the windscreen is defogged. Switching between outside air and recirculated air modes Press The mode switches between outside air mode (the indicator is off) and recirculated air mode (the indicator is on) each time the button is pressed. NOTE: Recirculated air mode or outside air mode may automatically switch depending on the temperature setting, outside temperature, pressure, engine coolant temperature or the inside temperature. Operating tips • To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly. • Make sure the air intake grilles in front of the windscreen are not blocked (by leaves or snow, for example). • On humid days, do not blow cold air on the windscreen. The windscreen could fog up because of the difference in air temperature on the inside and outside of the windscreen.
Page 180 INTERIOR FEATURES Using the air conditioning system and defogger • The windows will easily fog up when the humidity in the vehicle is high. Turning on will dehumidify the air from the outlets and defog the windscreen effectively. If you turn off, the windows may fog up more easily. The windows may fog up more easily if the recirculated air mode is used. • Keep the area under the front seats clear to allow air to circulate throughout the vehicle. • On cold days, set the fan speed to high for a minute to help clear the intake ducts of snow or moisture. This can reduce the amount of fogging on the windows. • When driving on dusty roads, close all windows. If dust thrown up by the vehicle is still drawn into the vehicle after closing the windows, it is recommended the air intake selector be set to FRESH and the fan speed selector to any setting except OFF. • If following another vehicle on a dusty road, or driving in windy and dusty conditions, it is recommended the air intake selector be temporarily set to RECIRCULATE, which will close off the outside passage and prevent outside air and dust from entering the vehicle interior. • When the outside temperature falls to nearly 0˚C the dehumidification function may not operate even when is pressed. CAUTION To prevent the windscreen from fogging up do not use with the air conditioning on in extremely humid weather. The difference in temperature between the outside air and the windscreen can cause the outer surface of the windscreen to fog up, blocking your vision. NOTICE To prevent battery discharge do not leave the air conditioning system on longer than necessary when the engine is stopped.
Page 181 INTERIOR FEATURES Using the air conditioning system and defogger for manual operation– Fan speed – To the desired fan speed Temperature – Towards WARM Air intake – FRESH (outside air) Air flow – FLOOR Air conditioning – OFF • For quick heating, select recirculated air for a few minutes. To keep the windows from fogging, select fresh after the vehicle interior has been warmed. • Press the A/C button on for dehumidified heating. • Choose floor / windscreen air flow to heat the vehicle interior while defrosting or defogging the windscreen. Air conditioning For best results, set controls as follows: for automatic operation– Press in the AUTO button Temperature – To the desired temperature...
Page 182 INTERIOR FEATURES Using the air conditioning system and defogger for manual operation– Fan speed – To the desired fan speed Temperature – Towards COLD Air intake – FRESH (outside air) Air flow – PANEL Air conditioning – OFF Defogging and defrosting the inside of the windscreen For best results, set controls as follows: for automatic operation– Temperature – Towards high temperature to heat;...
Page 183: Front, Side And Rear Vents
INTERIOR FEATURES Using the air conditioning system and defogger for manual operation– Fan speed – To the desired fan speed Temperature – Towards high temperature Air intake – FRESH (outside air) Air flow – WINDSCREEN • Pressing the windscreen button turns on the defroster linked air conditioning. At this time, the A/C button indicator comes on regardless of whether or not the A/C button is pressed in. This is to clean up the front view more quickly. • To turn off the air conditioning alone, press the A/C button once again. • When the A/C button is not pressed in, pressing another air flow button turns off the air conditioning. • To heat the vehicle interior while defrosting the windscreen, choose floor / windscreen air flow. Customisable features that can be modified For further information refer to “Customisable features” on page 333.
Page 184: Rear Window Defogger
INTERIOR FEATURES Using the air conditioning system and defogger Rear vents 1. Direct air flow to the left or right, up or down. 2. Turn the knob to open or close the vent. Air conditioning odours During use, various odours from inside and outside the vehicle may enter into and accumulate in the air conditioning system. This may then cause odours to be emitted from the vents. To reduce potential odours from occurring: • It is recommended that the air conditioning system be set to outside air mode prior to turning the vehicle off. • The start timing of the blower may be delayed for a short period of time immediately after the air conditioning system is started in automatic mode. Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Refer to “Air conditioning filter” on page 272. REAR WINDOW DEFOGGER To defog or defrost the rear window, press the switch. The system will automatically shut off when the operation time has been completed. The operation time is between 15 minutes and 1 hour depending on the ambient temperature and vehicle speed.
Page 185: Touch-Screen Audio System
INTERIOR FEATURES Touch-screen audio system Touch-screen audio system HINT: For vehicles with Navigation system refer to the separate owners manual. By touching the screen with your finger, you can control the audio system and hands-free system, etc. QUICK REFERENCE Button Function AUDIO Audio system, refer to page 169 Hands-free system, refer to page 204 SETUP Setup menu, refer to page 164 Vehicle information, refer to page 167 INFORMATION To avoid damaging the touch screen • Touch the screen lightly with your finger. If there is no response, remove your finger from the screen and try again. • Remove any dirt on the screen by wiping with a soft cloth. Do not use detergent. When using the touch screen • If the screen is cold, the display may be dark, or the system may seem to be operating slightly slower than normal. • The screen may seem dark and hard to see when viewed through sunglasses. Change your angle of viewing, adjust the display on the DISPLAY SETTINGS screen, refer to page 166, or remove your sunglasses.
Page 186: Setup Menu
INTERIOR FEATURES Touch-screen audio system SETUP MENU You can change the Touch-screen audio system to your desired setting. Press to display the SETUP screen. Touch the desired screen button to proceed to the following screens. Switch Reference GENERAL Refer to page 165 DISPLAY Refer to page 166 BLUETOOTH Refer to page 227 TELEPHONE Refer to page 218 VEHICLE* Refer to page 167 Bluetooth is a registered trademark of Bluetooth SIG, Inc. ® *Displayed only when the ignition switch is in the ON position (vehicles with standard type ignition switch) or the ENGINE START STOP switch is in the IGNITION ON position (vehicles with smart entry and start system).
Page 187 INTERIOR FEATURES Touch-screen audio system General settings This screen is used for various settings. 1. Press 2. Touch GENERAL on the SETUP screen. a. Touch BEEP to set ON / OFF. b. Touch DISPLAY CAPTURED IMAGE to set ON / OFF. ON or OFF can be selected to display captured image / iPod ® cover art in the screen. STNDA00001Ea c. Touch ANIMATION to set ON / OFF. The animation effect for audio source selection screen can be set to ON or OFF. d. Personal data can be deleted, refer below. 3. When you complete settings, touch OK. Delete personal data− 1. Touch DELETE PERSONAL DATA on the GENERAL SETTINGS screen. 2. Touch DELETE. Check carefully beforehand, as data cannot be retrieved once deleted. 3. A confirmation screen will be displayed. Touch YES.
Page 188 INTERIOR FEATURES Touch-screen audio system Display settings 1. Press SETUP . 2. Touch DISPLAY on the SETUP screen. a. Turn off screen. The screen is turned off. To turn it on, press any button such as AUDIO or SETUP . b. Changes to day mode, refer below. Displays only when the headlights are set to ON or AUTO. c. Adjust screen contrast / STNDA00109Ea brightness, refer below. d. Adjust screen contrast / brightness of the rear view monitor camera, refer below. Changing between day mode and night mode− When the headlights are turned on, the screen dims. However, the screen can be switched to day mode by touching DAY MODE. The screen will stay in day mode when the headlights are turned on until DAY MODE is touched again. Adjusting the screen contrast / brightness− 1. Touch GENERAL or CAMERA on the DISPLAY SETTINGS screen. 2. Adjust the display as desired using [+] or [−]. Select CONTRAST or BRIGHTNESS using the [<<] or [>>].
Page 189: Vehicle Information
INTERIOR FEATURES Touch-screen audio system Vehicle settings 1. Press SETUP . 2. Touch VEHICLE* on the SETUP screen. Various settings can be changed. For details refer to “Customisable features” on page 333. 3. When you complete the settings, touch OK. *Displayed only when the ignition switch is in the ON position (vehicles with standard type ignition switch) or the ENGINE START STOP switch is in the IGNITION ON position (vehicles with smart entry and start system). VEHICLE INFORMATION This screen can be used to display the fuel consumption. Press CAR to display the TRIP INFORMATION or PAST RECORD screen.
Page 190 INTERIOR FEATURES Touch-screen audio system Fuel consumption Trip information− If the TRIP INFORMATION screen does not appear, touch TRIP INFORMATION. 1. Average vehicle speed. 2. Elapsed time. 3. Cruising range. 4. Previous fuel consumption per minute. 5. Current fuel consumption. 6. Reset the trip information data. 7. PAST RECORD screen appears. NOTE: These images are examples only, and may vary slightly from actual conditions. Past record− If the PAST RECORD screen does not appear, touch PAST RECORD. 1. Previous fuel economy record. 2. Current fuel economy. 3. Best recorded fuel economy. 4. Update the Past record data. 5. Reset the Past record data. 6. TRIP INFORMATION screen appears. NOTE: These images are examples only, and may vary slightly from actual conditions. INFORMATION Resetting the data Selecting CLEAR on the TRIP INFORMATION screen will reset the consumption data.
Page 191: Audio System
INTERIOR FEATURES Touch-screen audio system AUDIO SYSTEM Press AUDIO to display the audio control screen. Title Page Using the radio Refer to page 172 Using the CD player Refer to page 174 Playing an audio CD and MP3/WMA discs Refer to page 174 Listening to an iPod Refer to page 182 Listening to a USB memory Refer to page 187 Using the AUX port Refer to page 193 Listening to Bluetooth audio Refer to page 194 ® Optimal use of the audio system Refer to page 201 Using the steering wheel audio switches Refer to page 202...
Page 192 INTERIOR FEATURES Touch-screen audio system Switching the audio source 1. Touch SOURCE or press AUDIO to display the audio source selection screen. 2. Touch the desired audio source. : To scroll the screen. : C hange to the list style screen as shown below. List style screen.
Page 193 INTERIOR FEATURES Touch-screen audio system List screen operation When a list is displayed, use the appropriate button to scroll through the list. : T o scroll to the next or previous page. : I f appears to the right of titles, the complete titles are too long for the display. Touch this button to scroll to the title. Turn TUNE / SCROLL to move the cursor box to select a desired item from the list, and press TUNE / SCROLL to play it. The track that is being played is highlighted. INFORMATION Using mobile phones Interference may be heard through the audio system’s speakers if a mobile phone is being used inside or close to the vehicle while the audio system is operating. CAUTION Laser product This product is a class 1 laser product. • A laser beam leak may result in hazardous radiation exposure. • Do not open the cover of the player or attempt to repair the unit yourself. Refer servicing to qualified personnel. NOTICE To prevent battery discharge Do not leave the audio system on longer than necessary when the engine is off.
Page 194: Using The Radio
INTERIOR FEATURES Touch-screen audio system USING THE RADIO Touch AM or FM on the audio source selection screen. Power Volume Adjusting the frequency Selecting a frequency Muting the sound Displaying the source selection or audio control screen CTY33AV192 Audio control screen Pressing AUDIO displays the audio control screen from any screens of the selected source. 1. Audio source selection screen appears. 2. Scanning for receivable station. 3. Setting the sound, refer to page 201. 4. Preset stations. Selecting a station Seek tuning−...
Page 195 INTERIOR FEATURES Touch-screen audio system Setting station presets 1. Search for desired stations by turning TUNE / SCROLL or pressing [b] or [d] on SEEK / TRACK. 2. Touch and hold one of the preset stations [1 to 12] until you hear a beep. Scanning radio stations Scanning the preset radio stations− 1. Touch SCAN on the screen until P .SCAN appears. Preset stations will be played for a few seconds each. 2. Touch SCAN once again when the desired station is reached. Scanning all radio stations within range− 1. Touch SCAN on the screen. SCAN appears on the screen and all stations within range will be played for a few seconds each. 2. Touch SCAN once again when the desired station is reached. INFORMATION Reception sensitivity • Maintaining perfect radio reception at all times is difficult due to the continually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc. • The radio antenna is mounted inside the rear window. To maintain clear radio reception, do not attach metallic window tinting or other metallic objects to the antenna wire mounted inside the rear window.
Page 196: Using The Cd Player
INTERIOR FEATURES Touch-screen audio system USING THE CD PLAYER Power Volume Ejecting Selecting a a disc track and file Disc slot Selecting a track and file / fast-forwarding Playback / pause and reversing Displaying the source selection or audio control screen Loading a disc Insert a disc into the disc slot with the label facing up.
Page 197 INTERIOR FEATURES Touch-screen audio system MP3 / WMA disc 1. Audio source selection screen appears. 2. Displaying the track / file list. 3. Pause. (Touch to play.) 4. Repeat play. 5. Random playback. 6. Displaying the folder list. 7. Setting the sound, refer to page 201. Selecting, fast-forwarding and reversing tracks (Audio CD) Selecting a track− Press [b] or [d] on SEEK / TRACK or turn TUNE / SCROLL to select the desired track number. To fast-forward or reverse, press and hold [b] or [d] on SEEK / TRACK. Selecting a track from the track list− 1. Touch TRACKS on the audio control screen. 2. Touch the desired track number.
Page 198 INTERIOR FEATURES Touch-screen audio system Selecting a folder (MP3/WMA disc) 1. Touch FOLDERS on the audio control screen. 2. Touch the desired folder number. 3. Touch the desired file number. Random playback Each time is touched, the mode changes in the following order: Audio CD− MP3/WMA disc− Repeat play Each time is touched, the mode changes in the following order: Audio CD− MP3/WMA disc−...
Page 199 INTERIOR FEATURES Touch-screen audio system INFORMATION Displaying the title and artist name If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. Error messages Refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures • The disc is dirty or Clean the disc. damaged. • The disc is inserted upside Insert the disc correctly. CHECK DISC down. • The disc is not playable Confirm the disc is playable with the player. with the player. There is a malfunction within DISC ERROR Eject the disc. the system. NO MUSIC This indicates that no playable Eject the disc.
Page 200 INTERIOR FEATURES Touch-screen audio system INFORMATION MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format. There is a limit to the MP3 and WMA file standards that can be used and to the media / formats on which the files are recorded. MP3 file compatibility− • Compatible standards MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3). • Compatible sampling frequencies MPEG1 LAYER3: 32, 44.1, 48 (kHz) MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz). • Compatible bit rates MPEG1 LAYER3: 32—320 (kbps) MPEG2 LSF LAYER3: 8—160 (kbps). • Compatible channel modes: stereo, joint stereo, dual channel and monaural. WMA file compatibility− • Compatible standards WMA Ver. 7, 8, 9. • Compatible sampling frequencies 32, 44.1, 48 (kHz). • Compatible bit rates (only compatible with 3-channel playback) Ver. 7, 8: CBR 48—192 (kbps) Ver. 9: CBR 48—320 (kbps).
Page 201 INTERIOR FEATURES Touch-screen audio system INFORMATION Compatible disc formats− The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2. • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) UDF (2.01 or lower). MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly. Items related to standards and limitations are as follows: • Maximum directory hierarchy: 8 levels (including the root) • Maximum length of folder names / file names: 32 characters • Maximum number of folders: 192 (including the root) • Maximum number of files per disc: 255 File names− The only files that can be recognised as MP3 / WMA and played are those with the extension .mp3 or .wma. Discs containing multi-session recordings− As the audio system is compatible with multi-sessions, it is possible to play discs that contain MP3 and WMA files. However, only the first session can be played. ID3 and WMA tags− ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver. 1.0 and 1.1.) WMA tags can be added to WMA files, making it possible to record the track title and artist name in the same way as with ID3 tags. MP3 and WMA playback− When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend you do not write in any files other than MP3 or WMA files or create any unnecessary folders.
Page 202 INTERIOR FEATURES Touch-screen audio system INFORMATION Extensions− If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognised and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers. Playback− • To play MP3 files with steady sound quality, we recommend a fixed bit rate of 128 kbps and a sampling frequency of 44.1 kHz. • CD-R or CD-RW playback may not be possible in some instances, depending on the characteristics of the disc. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encoding and the file format, poor sound quality or noise at the start of playback may result. In some cases, playback may not be possible at all. • When files other than MP3 or WMA files are recorded on a disc, it may take more time to recognise the disc and in some cases, playback may not be possible at all. • Microsoft, Windows, and Windows Media are the registered trademarks of Microsoft Corporation in the U.S. and other countries.
Page 203 INTERIOR FEATURES Touch-screen audio system NOTICE Discs and adapters that cannot be used Do not use the following types of discs or 8 cm disc adapters or Dual Discs. Doing so may damage the player and / or the insert / eject function. • Discs that have a diameter that is not 12 cm. • Low-quality and deformed discs. • Discs with a transparent or translucent recording area. • Discs that have had tape, stickers or CD-R labels attached to them, or that have had the label peeled off.
Page 204: Listening To An Ipod
INTERIOR FEATURES Touch-screen audio system NOTICE Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. • Do not insert anything other than discs into the disc slot. • Do not apply oil to the player. • Store discs away from direct sunlight. • Never try to disassemble any part of the player. LISTENING TO AN iPod ® Connecting an iPod enables you to enjoy music from the vehicle speakers. ® Touch iPod on the audio source selection screen. ® Power Volume Selecting a song Selecting a song / fast-forwarding and reversing Playback / pause Displaying the source selection or audio control screen...
Page 205 INTERIOR FEATURES Touch-screen audio system Audio control screen Pressing AUDIO displays the audio control screen from any screens of the selected source. 1. Audio source selection screen appears. 2. Selecting the play mode. 3. Displaying the song list. 4. Pause. (Touch to playback.) 5. Repeat play. 6. Shuffle play. 7. Setting the sound, refer to page 201. Connecting an iPod ® 1. Lift the lid. 2. Open the cover and connect an iPod ® using an iPod cable. ® Turn on the power of the iPod if it is ®...
Page 206 INTERIOR FEATURES Touch-screen audio system Playing an iPod ® Play / Pause− Touch or to Play / Pause. Selecting a play mode− 1. Touch BROWSE on the audio control screen. 2. Select the desired play mode by touching the PLAYLISTS, ARTISTS, ALBUMS, SONGS, PODCASTS, AUDIO BOOKS, GENRES or COMPOSERS tabs. Selecting, fast-forwarding and reversing songs Selecting one song at a time− Press [b] or [d] on SEEK / TRACK or turn TUNE / SCROLL to select the desired song. To fast-forward or reverse, press and hold [b] or [d] on SEEK / TRACK until you hear a beep. Selecting a song from the list− 1. Touch SONGS on the audio control screen. 2. Touch the desired song. Shuffle play Each time is touched, the mode changes in the following order: When a large number of songs is stored in an iPod , shuffle selection may take time.
Page 207 INTERIOR FEATURES Touch-screen audio system INFORMATION About iPod ® • “Made for iPod ” and “Made for ® iPhone ” means that an electronic ® accessory has been designed to connect specifically to iPod , or ® iPhone , respectively, and has been ® certified by the developer to meet Apple performance standards. • Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance. ® ® • iPhone , iPod , iPod classic, iPod nano, iPod shuffle, and iPod touch are ®...
Page 208 INTERIOR FEATURES Touch-screen audio system INFORMATION Error messages CONNECTION ERROR: This indicates a problem in the iPod or its connection. ® THERE ARE NO SONGS AVAILABLE FOR PLAYBACK: This indicates there is no music data in the iPod ® NO ITEMS AVAILABLE: This indicates that some available songs are not found in a selected playlist. Compatible models The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can ® ® ® ® ® be used with this system. Made for • iPod touch (1st, 2nd, 3rd and 4th generation) • iPod classic • iPod with video • iPod nano (1st, 2nd, 3rd, 4th, 5th and 6th generation) • iPhone (iPhone, 3G, 3GS and 4) Depending on differences between models or software version etc., some models listed above might be incompatible with this system. iPod 4th generation and earlier models are not compatible with this system.
Page 209: Listening To A Usb Memory
INTERIOR FEATURES Touch-screen audio system LISTENING TO A USB MEMORY Connecting a USB memory enables you to enjoy music from the vehicle speakers. Touch USB on the audio source selection screen. Power Volume Selecting a file Selecting a file / fast-forwarding Playback / pause and reversing Displaying the source selection or audio control screen Audio control screen Pressing AUDIO displays the audio control screen from any screens of the selected source. 1. Audio source selection screen appears. 2. Displaying the folder list. 3. Displaying the file list. 4. Pause.
Page 210 INTERIOR FEATURES Touch-screen audio system Connecting a USB memory 1. Lift the lid. 2. Open the cover and connect the USB memory. Turn on the power of the USB memory if it is not turned on. Selecting, fast-forwarding and reversing files Selecting one file at time− Press [b] or [d] on SEEK / TRACK or turn TUNE / SCROLL to select the desired file. To fast-forward or reverse, press and hold [b] or [d] on SEEK / TRACK until you hear a beep. Selecting a file from the list− 1. Touch FILES on the audio control screen. 2. Touch the desired file number.
Page 211 INTERIOR FEATURES Touch-screen audio system Selecting a folder 1. Touch FOLDERS on the audio control screen. 2. Touch the desired folder number. 3. Touch the desired file number. Random playback Each time is touched, the mode changes in the following order: Repeat play Each time is touched, the mode changes in the following order:...
Page 212 INTERIOR FEATURES Touch-screen audio system INFORMATION USB memory functions • Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be available. If the device is inoperable or a function is unavailable due to a malfunction (as opposed to a system specification), disconnecting the device and reconnecting it once again may resolve the problem. • If the USB memory still does not begin operation after being disconnected and reconnected, format the memory. Error messages CONNECTION ERROR: This indicates a problem in the USB memory or its connection. THERE ARE NO FILES AVAILABLE FOR PLAYBACK: This indicates that no MP3/WMA files are included in the USB memory. USB memory Compatible devices− USB memory that can be used for MP3 and WMA playback. Compatible device formats− The following device formats can be used: • USB communication formats: USB2.0 FS (12 Mbps) • File formats: FAT16/32 (Windows) • Correspondence class: Mass storage class MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly Items related to standards and limitations are as follows: • Maximum directory hierarchy: 8 levels • Maximum number of folders in a device: 3000 (including the root) • Maximum number of files in a device: 9999 • Maximum number of files per folder: 255...
Page 213 INTERIOR FEATURES Touch-screen audio system INFORMATION MP3 and WMA files− MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format. There is a limit to the MP3 and WMA file standards that can be used and to the media / formats on which the files are recorded. MP3 file compatibility− • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5). • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz). • Compatible bit rates (compatible with VBR) MPEG1 AUDIO LAYERII, III: 32-320 (kbps) MPEG2 AUDIO LAYERII, III: 8-160 (kbps). • Compatible channel modes: stereo, joint stereo, dual channel and monaural. WMA file compatibility− • Compatible standards WMA Ver. 7, 8, 9. • Compatible sampling frequencies HIGH PROFILE 32, 44.1, 48 (kHz). • Compatible bit rates HIGH PROFILE 48-320 (kbps, VBR). File names− The only files that can be recognised as MP3/WMA and played are those with the extension .mp3 or .wma. ID3 and WMA tags−...
Page 214 INTERIOR FEATURES Touch-screen audio system INFORMATION MP3 and WMA playback− • When a device containing MP3 or WMA files is connected, all files in the USB memory are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders. • When the USB memory is connected and the audio source is changed to USB memory mode, the USB memory will start playing the first file in the first folder. If the same device is removed and reinserted (and the contents have not been changed), the USB memory will resume play from the same point in which it was last used. Extensions− If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be skipped (not played). Playback− • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encoding and the file format, poor sound quality or noise at the start of playback may result. In some cases, playback may not be possible at all. • Microsoft, Windows, and Windows Media are registered trademarks of Microsoft Corporation in the U.S.A. and other countries. CAUTION Do not connect a USB memory or operate the controls while driving. NOTICE If the auxiliary box lid cannot be fully closed Depending on the size and shape of the USB memory that is connected to the system, the auxiliary box lid may not close fully. In this case, do not forcibly close the lid as this may damage the USB memory or the terminal, etc.
Page 215: Using The Aux Port
INTERIOR FEATURES Touch-screen audio system USING THE AUX PORT This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. 1. Lift the lid. 2. Open the cover and connect the portable audio device. 3. Touch AUX on the audio source selection screen. INFORMATION Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet Noise may occur during playback. Use the power source of the portable audio device.
Page 216: Listening To Bluetooth ® Audio
INTERIOR FEATURES Touch-screen audio system LISTENING TO BLUETOOTH AUDIO ® The Bluetooth audio system enables users to enjoy music played on a portable player ® from the vehicle speaker via wireless communication. This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without ® cables. If your portable player does not support Bluetooth , the Bluetooth audio system ® ® will not function. Touch BT on the audio source selection screen. Power Volume Selecting a track Selecting a track / fast-forwarding and reversing Playback / pause Displaying the source selection or audio control screen Audio control screen Pressing AUDIO displays the audio control...
Page 217 INTERIOR FEATURES Touch-screen audio system Status display You can check such indicators as signal strength and battery charge on the screen. 1. Connection status. 2. Battery charge. Indicators Conditions Connection status Battery charge Registering a Bluetooth audio player ® To use the Bluetooth audio system, you ® need to register your portable audio player into the system. Once registered, you can enjoy your music on the vehicle’s audio system. You can register up to 5 devices in the system. 1. Touch CONNECT on the audio control screen. 2. Touch YES.
Page 218 INTERIOR FEATURES Touch-screen audio system 3. Input the passcode displayed on the screen into your portable audio player. For the operation of the portable audio player, see the manual that comes with your portable audio player. Passcodes are not required for SSP (Secure Simple Pairing) compatible Bluetooth devices. Depending on the ® device, you may need to select YES to register, or NO to cancel on your Bluetooth device. ® If you want to cancel it, select CANCEL. If a completion message is displayed, registration is complete. If an error message is displayed, follow the guidance on the screen to try again. Selecting the Bluetooth audio player ® If multiple Bluetooth devices are ® registered, follow the procedure below to select the Bluetooth device to be used. ® You may only use one device at a time. 1. Touch CONNECT on the audio control screen. 2. Touch the device to connect.
Page 219 INTERIOR FEATURES Touch-screen audio system Connecting the Bluetooth® audio player There are two connection methods available. When the connection method is set to FROM VEHICLE− Vehicles with standard type ignition switch− When the portable audio player is on standby for the connection, it will be automatically connected whenever the ignition switch is in either ACC or ON position. Vehicles with a smart entry and start system− When the portable audio player is on standby for the connection, it will be automatically connected whenever the ENGINE START STOP switch is in either ACCESSORY or IGNITION ON mode. When the connection method is set to FROM AUDIO PLAYER− Operate the portable player and connect it to the Bluetooth audio system. ® 1. Touch CONNECT on the audio control screen. 2. Touch the device to connect. A message is shown if connection has been successful.
Page 220 INTERIOR FEATURES Touch-screen audio system Some titles and controls may not be displayed depending on the type of portable audio player. Selecting a track Selecting a track− Press [b] or [d] on SEEK / TRACK or turn TUNE / SCROLL to select the desired track number. To fast-forward or rewind, press and hold [b] or [d] on SEEK / TRACK until you hear a beep. Selecting a track from the list− 1. Touch TRACKS on the audio control screen. 2. Touch the desired track. Selecting an album 1. Touch BROWSE on the audio control screen. 2. Touch the desired album.
Page 221 INTERIOR FEATURES Touch-screen audio system 3. Touch the desired track. Random playback Each time is touched, the mode changes in the following order: Repeat play Each time is touched, the mode changes in the following order: INFORMATION When using the Bluetooth audio system ® In the following conditions, the system may not function. • If the portable audio player is turned off. • If the portable audio player is not connected. • If the portable audio player’s battery is low. There may be a delay if phone connection is carried out during Bluetooth audio play. ® Depending on the type of portable audio player that is connected to the system, operation may differ slightly and certain functions may not be available. Bluetooth antenna ® The antenna is built into the display. If the portable audio player is behind the seat or in the glove box or console box, or is touching or covered by metal objects, connection status may deteriorate. Battery charge / signal status This display may not correspond exactly with the portable audio player, and this system does not have a charging function.
Page 222 INTERIOR FEATURES Touch-screen audio system INFORMATION About Bluetooth ® Bluetooth is a registered trademark of Bluetooth SIG, Inc. The Bluetooth wordmark and logo are owned by Bluetooth SIG. and permission has been granted to use the trademark of the licensee FUJITSU TEN LIMITED. Other trademarks and trade names are owned by various different owners. Compatible models Portable audio players must correspond to the specifications. • Bluetooth® specifications: Ver. 1.1, or higher (recommended: Ver. 2.1 + EDR or higher) • Profiles: – A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (recommended: Ver. 1.2 or higher). This is a profile to transmit stereo audio or high quality sounds to the headphone – AVRCP (Audio / Video Remote Control Profile) Ver. 1.0 or higher (recommended: Ver. 1.4 or higher). This is a profile to remote control the A/V equipment However, please note that some functions may be limited depending on the type of portable audio player Reconnecting the portable audio player Vehicles with standard type ignition switch− If the portable audio player is disconnected due to a poor reception when the ignition switch is in the ACC or ON position, the system automatically reconnects the portable audio player when possible.
Page 223: Optimal Use Of The Audio System
INTERIOR FEATURES Touch-screen audio system INFORMATION When transferring ownership of the vehicle Initialise the system to prevent personal data from being improperly accessed, refer to page 165. CAUTION Do not use the portable audio player or connect the Bluetooth system while driving. ® NOTICE When leaving the vehicle Do not leave your portable audio player in the vehicle. The inside of the vehicle may become hot, causing damage to the portable audio player. OPTIMAL USE OF THE AUDIO SYSTEM Touch to adjust the sound settings. SOUND tab 1, 2, 3. Touch [−] or [+] to adjust the treble, mid or bass to a level between −5 to 5. 4, 5. Touch FRONT or REAR to adjust the front / rear audio balance to a level between Front 7 and Rear 7. 6, 7. Touch L or R to adjust the left / right audio balance to a level between L7 and R7.
Page 224: Using The Steering Wheel Audio Switches
INTERIOR FEATURES Touch-screen audio system DSP tab 1. Automatic sound leveliser (ASL) Adjust the ASL level in the order of HIGH, MID, LOW or OFF. INFORMATION The sound quality level is adjusted individually The treble, mid and bass levels can be adjusted for each audio mode separately. About Automatic Sound Leveliser (ASL) ASL automatically adjusts the volume and tone quality according to the vehicle speed. USING THE STEERING WHEEL AUDIO SWITCHES Some audio features can be controlled using the switches on the steering wheel. 1. Increases / decreases volume. Without Paddle Shift 2. Returns to the previous screen. 3. Radio mode: Selects radio stations. CD mode: Selects tracks / files and folders (MP3/WMA). iPod mode: ®...
Page 225 INTERIOR FEATURES Touch-screen audio system Turning on the power Press MODE when the audio system is turned off. Changing the audio source Press MODE when the audio system is turned on. The audio source changes as follows each time MODE is pressed. If no discs are inserted in the player, or if the external device is not connected, that mode will be skipped. FM → CD player → iPod / USB memory → Bluetooth audio → AUX → AM. ® ® Adjusting the volume Press [+] to increase the volume and [−] to decrease the volume. Hold the button in that position to continue increasing or decreasing the volume. Silencing a sound Press and hold MODE. To cancel, press and hold MODE. Returning to the previous screen Press to display the previous screen.
Page 226: Hands-Free System
INTERIOR FEATURES Touch-screen audio system Operating on the list screen 1. Press [b] or [d] on to move the cursor up or down. 2. Press to select an item. When the folder or album is selected, the SELECT FILE screen is displayed. CAUTION To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. HANDS-FREE SYSTEM (FOR MOBILE PHONES) The hands-free system is a function that allows you to use your mobile phone without touching it. This system supports Bluetooth . Bluetooth is a wireless data system that allows the ® ® mobile phone to wirelessly connect to the hands-free system and make / receive calls. Telephone switch 1. Off hook switch With paddle shift switches –...
Page 227 INTERIOR FEATURES Touch-screen audio system Microphone You can use the microphone when talking on the phone. The person you are speaking to can be heard from the front speakers. To use the hands-free system, you must register your Bluetooth phone in the ® system, refer to page 209. Status display You can check indicators such as signal strength and battery charge on the TELEPHONE screen. 1. Connection status. 2. Battery charge. 3. Call area. 4. Signal strength. Indicators Conditions Connection status Battery charge Call area Rm: Roaming area Signal strength...
Page 228 INTERIOR FEATURES Touch-screen audio system INFORMATION When using the hands-free system • The audio system is muted when making a call. • If both parties speak at the same time, it may be difficult to hear. • If the received call volume is overly loud, an echo may be heard. If the Bluetooth phone is too close to the system, quality of the sound may ® deteriorate and connecting condition may go down. • In the following circumstances, it may be difficult to hear the other party. – When driving on unpaved roads. – When driving at high speeds. – If a window is open. – If the air conditioning is blowing directly on the microphone. – There is an effect from the network of the mobile phone. Conditions under which the system will not operate • If using a mobile phone that does not support Bluetooth ®...
Page 229 INTERIOR FEATURES Touch-screen audio system INFORMATION When using Bluetooth audio and hands-free system at the same time ® The following problems may occur. • The Bluetooth connection may be cut. ® • Noise may be heard on the Bluetooth audio playback. ® About the phonebook in this system The following data is stored for every registered phone. When another phone is connected, you cannot read the registered data. • Phonebook data. • All of call history. • Speed dial. When you delete the phone, the above-mentioned data is also deleted.
Page 230 INTERIOR FEATURES Touch-screen audio system INFORMATION Compatible models This system supports the following service. • Bluetooth Specification: ® Ver. 1.1 or higher (Recommended: Ver. 2.1+EDR or higher) • Profiles: – HFP (Hands Free Profile) Ver. 1.0 or higher (Recommended: Ver. 1.5 or higher) This is a profile to allow hands-free phone calls using the mobile phone or head sets. It has an outgoing and incoming call function – OPP (Object Push Profile) Ver. 1.1 or higher. This is a profile to exchange phonebook data. When the Bluetooth phone has ® PBAP and OPP , OPP cannot be used – PBAP (Phone Book Access Profile) Ver. 1.0 or higher. This is a profile to transfer phonebook data If your mobile phone does not support HFP , you cannot enter the Bluetooth phone. You ® need to take OPP or PBAP service individually. CAUTION Do not use the mobile phone or connect the Bluetooth system while driving. ® NOTICE When leaving the vehicle Do not leave your mobile phone in the vehicle. The inside of the vehicle may become hot, causing damage to the phone.
Page 231: Phones)
INTERIOR FEATURES Touch-screen audio system USING THE BLUETOOTH PHONE ® Device name Make a call Bluetooth connection status ® To display the TELEPHONE screen shown above, press on the steering wheel or Registering a Bluetooth® phone To use the hands-free system, you must register a Bluetooth phone in the system. ® You can register up to 5 phones in the system. 1. Display the TELEPHONE screen. 2. Touch YES. 3. Input the passcode displayed on the screen into your phone. For the operation of the phone, see the manual that comes with your mobile phone. Passcodes are not required for SSP (Secure Simple Pairing) compatible Bluetooth® devices. Depending on the phone, you may need to select YES to register, or NO to cancel on your mobile phone. If you want to cancel it, select CANCEL.
Page 232 INTERIOR FEATURES Touch-screen audio system Selecting the Bluetooth phone ® If multiple Bluetooth devices are registered, follow the procedure below to select the ® Bluetooth device to be used. You may only use one device at a time. ® 1. Touch CONNECT TELEPHONE on the TELEPHONE screen. 2. Touch the device to connect. ADD NEW: Registering a Bluetooth ® device, refer to page 209. The selection indicator is displayed on left side of the selected device name. The Bluetooth mark is displayed ® when you connect the device. When the system cannot get the device names, alternate names will be displayed such as DEVICE1, DEVICE2, etc. Connecting a Bluetooth phone ® There are two connecting methods available - automatic and manual. Automatic− When you register your phone, auto connection will be activated. Always set it to this mode and leave the Bluetooth phone in a place where connection can be established.
Page 233 INTERIOR FEATURES Touch-screen audio system Manual− When the auto connection has failed or BLUETOOTH POWER is turned off, you must connect Bluetooth manually. ® 1. Touch CONNECT TELEPHONE on the TELEPHONE screen. 2. Touch the device to connect. A message is shown if connection has been successful. If connection fails, a message will be displayed and connection will be re-attempted. INFORMATION Reconnecting to the Bluetooth phone ® Vehicles with standard type ignition switch− If the system cannot connect due to poor signal strength with the ignition switch in the ACC or ON position, the system will automatically attempt to reconnect. Vehicles with a smart entry and start system− If the system cannot connect due to poor signal strength with the ENGINE START STOP switch in ACCESSORY or IGNITION ON mode, the system will automatically attempt to reconnect.
Page 234 INTERIOR FEATURES Touch-screen audio system Making a call Once the Bluetooth phone is registered, you can make a call using the following ® procedure: Dialing− 1. Input the phone number on the TELEPHONE screen. To delete the inputted phone number, touch To enter + as the first digit, prolong the touch on [ * +]. 2. Press on the steering wheel or touch on the screen. Dialing from the phonebook− You can dial a number from the phonebook data imported from your mobile phone. The system has one phonebook for each telephone. Up to 1000 entries may be stored in each phonebook, refer to page 219. 1. Touch CONTACTS on the TELEPHONE screen. 2. Choose the desired data to call from the list. If the phonebook is empty, a message will be displayed, refer to page 213. 3. Choose the number and then press on the steering wheel or touch on the screen.
Page 235 INTERIOR FEATURES Touch-screen audio system When the phonebook is empty− You can transfer the phone numbers in your Bluetooth phone to the system. ® Operation methods differ between PBAP compatible and PBAP incompatible Bluetooth ® phones. If your mobile phone does not support either PBAP or OPP service, you cannot transfer contacts. 1. Touch CONTACTS on the TELEPHONE screen. 2. If the phonebook is empty, a message will be displayed. 3. For a PBAP compatible Bluetooth phone− ® Touch YES if you want to transfer new contacts from a mobile phone. Touch NO if you want to cancel transferring the contacts. For a PBAP incompatible and OPP compatible Bluetooth phone− ® Touch TRANSFER if you want to transfer new contacts from a mobile phone. Touch CANCEL if you want to cancel transferring the contacts. You need to operate your phone to transfer new contacts.
Page 236 INTERIOR FEATURES Touch-screen audio system Dialing from history− You can call using the call history which has the following 4 functions. ALL: All the calls below which were memorised. MISSED: Calls which you missed. INCOMING: Calls which you received. OUTGOING: Calls which you called. 1. Touch CALL HISTORY on the TELEPHONE screen. 2. Select the desired tab and choose the desired data from the list. 3. Press on the steering wheel or touch on the screen. INFORMATION Call history list • If you make a call to or receive a call from a number registered in the phonebook, the name is displayed in the call history. • If you make multiple calls to the same number, only the last call made is displayed in the call history. When driving The functions DIALING, DIALING FROM THE PHONEBOOK, and DIALING FROM HISTORY (except for calls using the 5 most recently called numbers shown by ALL tab) are unavailable. International calls You may not be able to make international calls, depending on the mobile phone in use.
Page 237 INTERIOR FEATURES Touch-screen audio system INFORMATION Calling by using the latest call history item 1. Press on the steering wheel to display the TELEPHONE screen. 2. Press on the steering wheel to display the CALL HISTORY screen. 3. Press on the steering wheel to select the latest history item. 4. Press on the steering wheel or touch on the screen to call the latest history item. Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone: • Press on the steering wheel or, • Touch on the screen. To refuse a call • Press on the steering wheel or, • Touch...
Page 238 INTERIOR FEATURES Touch-screen audio system To adjust the incoming call volume− Touch [−] or [+]. You can also adjust the volume using the steering switches or the volume knob. To prevent the other party from hearing your voice− Touch MUTE. Inputting tones− When using phone services such as an answering service or a bank, you can store phone numbers and code numbers in the phonebook. 1. Touch [0-9]. 2. Input the number. 3. If repeated tone symbols* are stored in the phone book, SEND and EXIT are displayed on the right side of the screen. *: Repeated tone symbols are symbols or numbers displayed as p or w, that come after the phone number. (e.g. 056133w0123p#1*) 4. Confirm the number displayed on the screen, and touch SEND. If you touch EXIT, this function will end. To transfer a call− Touch HANDSET MODE to change from hands-free call to mobile phone call. Touch HANDS-FREE MODE to change from mobile phone call to hands-free call. To hang up− Press on the steering wheel or touch on the screen.
Page 239 INTERIOR FEATURES Touch-screen audio system Call waiting When a call is interrupted by a third party while talking, the incoming call message will be displayed. To talk with the other party: • Press on the steering wheel or, • Touch on the screen. To refuse the call: • Press on the steering wheel or, • Touch on the screen. Every time you press on the steering wheel or touch on the screen during call waiting, you will be switched to the other party. INFORMATION Transferring calls • It is not possible to transfer from hands-free to the mobile phone while driving. • If you transfer from the mobile phone to hands-free, the hands-free screen will be displayed, and you can operate the system using the screen. • Transfer method and operation may vary according to the mobile phone used. • For operation of the mobile phone in use, see the phone’s manual. Call waiting operation Call waiting operation may differ depending on your phone company and mobile phone.
Page 240: Setting The Hands-Free System
INTERIOR FEATURES Touch-screen audio system SETTING THE HANDS-FREE SYSTEM You can set the hands-free system to your desired settings. 1. Setting the sound. 2. Phonebook settings. To display the TELEPHONE SETTINGS screen shown above, press SETUP , and touch TELEPHONE on the SETUP screen. Setting the sound 1. Touch SOUND SETTINGS on the TELEPHONE SETTINGS screen. a. Changes the call volume. b. Changes the ring tone volume. c. Changes the ring tone. d. Restore default settings. HINT: Refer to the following procedures for details. STNDA0057Ea Setting the volume− 1. Touch CALL VOLUME or RING TONE VOLUME on the SOUND SETTINGS screen. 2. Touch [−] or [+] to lower or raise the volume, and then OK. 3. When you complete all settings, touch...
Page 241 INTERIOR FEATURES Touch-screen audio system Setting the ring tone− 1. Touch RING TONE on the SOUND SETTINGS screen. 2. Touch TONE 1, TONE 2 or TONE 3 to change the ring tone, and then OK. 3. When you complete all settings, touch INFORMATION To return to the default volume settings Touch DEFAULT, and then YES. Phonebook settings The phonebook manages a maximum of 5 phones in total. The data for 1000 contacts (up to 3 numbers per contact) can be registered in each phonebook. STNDA00060Ea To display the screen above, follow the steps below. 1. Display the TELEPHONE SETTINGS screen, refer to page 218. 2. Touch PHONEBOOK on the TELEPHONE SETTINGS screen. a. Managing the contacts. b. Managing the speed dials. c. Deleting the call history.
Page 242 INTERIOR FEATURES Touch-screen audio system Managing the contacts− Transferring a phone number: You can transfer the phone numbers in your Bluetooth phone to the system. Operation ® methods differ between PBAP compatible and PBAP incompatible Bluetooth phones. ® If your mobile phone does not support either PBAP or OPP services, you cannot transfer contacts. 1. Touch MANAGE CONTACTS on the PHONEBOOK SETTINGS screen. 2. Touch TRANSFER CONTACTS. 3. For PBAP compatible Bluetooth ® phones− Touch required selection. a. Automatic phonebook download on / off. The phonebook data can be automatically transferred. Depending on the mobile phone, call history will be also transferred. STNDA00062Ea b. Update phonebook. The phonebook data can be updated. c. Restore default settings. For PBAP incompatible Bluetooth ®...
Page 243 INTERIOR FEATURES Touch-screen audio system Deleting the phonebook data: 1. Touch MANAGE CONTACTS on the PHONEBOOK SETTINGS screen. 2. Touch DELETE CONTACTS. If your phone supports PBAP service, AUTOMATIC PHONEBOOK DOWNLOAD setting needs to be set to OFF, refer to page 220. 3. Choose the data to delete. To delete all data, touch ALL DELETE. 4. A confirmation message will be displayed. If everything is correct, touch YES. INFORMATION Phonebook data Phonebook data is managed for every registered phone. When another phone is connecting, you cannot read the registered data. Setting the phonebook in a different way (To display the CONTACTS screen) 1. Display the TELEPHONE screen, refer to page 209. 2. Touch CONTACTS on the TELEPHONE screen.
Page 244 INTERIOR FEATURES Touch-screen audio system INFORMATION When you have selected REPLACE CONTACTS or ADD CONTACTS to transfer the phone number If your mobile phone does not support OPP service, you cannot use these functions. You can transfer the phonebook data only by operating your phone Transferring the phone number in a different way (To display the CONTACT TRANSFER METHOD screen) 1. Display the TELEPHONE screen, refer to page 209. 2. Touch CONTACTS on the TELEPHONE screen. 3. Touch TRANSFER on the CONTACTS screen.
Page 245 INTERIOR FEATURES Touch-screen audio system 3. Choose the data to register. 4. Touch the desired phone number. 5. Touch the switch you want to register the number in. 6. If you select a switch you registered before, a confirmation message will be displayed. If you want to replace it, touch YES. Registering the speed dial from call history: 1. Touch MANAGE SPEED DIALS on the PHONEBOOK SETTINGS screen. 2. Touch NEW SPEED DIAL FROM CALL HISTORY.
Page 246 INTERIOR FEATURES Touch-screen audio system 3. Choose the data to register. 4. Touch the switch you want to register the number in. 5. If you select a switch you registered before, a confirmation message will be displayed. If you want to replace it, touch YES. Deleting the speed dial: 1. Touch MANAGE SPEED DIALS on the PHONEBOOK SETTINGS screen. 2. Touch DELETE SPEED DIALS on the SPEED DIALS screen. 3. Choose the data to delete. To delete all data, touch ALL DELETE. 4. A confirmation message will be displayed. If everything is correct, touch YES. INFORMATION Setting the speed dials in a different way (From SPEED DIAL screen) 1. Display the TELEPHONE screen, refer to page 209.
Page 247 INTERIOR FEATURES Touch-screen audio system INFORMATION Setting the speed dials in a different way (From CONTACTS screen) 1. Display the TELEPHONE screen, refer to page 209. 2. Touch CONTACTS on the TELEPHONE screen. 3. Touch OPTIONS on the CONTACTS screen. 4. Touch MANAGE SPEED DIALS on the PHONEBOOK SETTINGS screen. Registering the speed dial in a different way (From SPEED DIAL screen) 1. Display the TELEPHONE screen, refer to page 209. 2. Touch SPEED DIALS on the TELEPHONE screen. 3. Touch (ADD NEW) on the SPEED DIAL screen.
Page 248 INTERIOR FEATURES Touch-screen audio system Deleting the call history− 1. Display the PHONEBOOK SETTINGS screen, refer to page 219. 2. Touch DELETE CALL HISTORY on the PHONEBOOK SETTINGS screen. If your phone supports PBAP service, the AUTOMATIC PHONEBOOK DOWNLOAD setting needs to be set to OFF, refer to page 220. 3. Choose the desired history to delete. 4. Choose the data to delete. To delete all data, touch ALL DELETE. 5. A confirmation message will be displayed. If everything is correct, touch YES. INFORMATION Deleting call history in a different way 1. Display the TELEPHONE screen, refer to page 209. 2. Touch CALL HISTORY on the TELEPHONE screen. 3. Touch DELETE on the CALL HISTORY screen. 4. Follow the steps DELETING THE CALL HISTORY above.
Page 249: Bluetooth ® Settings
INTERIOR FEATURES Touch-screen audio system BLUETOOTH SETTINGS ® You can set the Bluetooth system to your desired settings. ® Registered devices settings Connecting audio player Connecting telephone Detailed Bluetooth settings ® To display the BLUETOOTH SETTINGS screen shown above, press SETUP , and touch BLUETOOTH on the SETUP screen. Registered devices settings Registering a Bluetooth device− ® Bluetooth devices compatible with ® phones (HFP) and portable audio players (AVP) can be registered simultaneously. You can register up to 5 Bluetooth ® devices. 1. Touch REGISTERED DEVICES on the BLUETOOTH SETTINGS screen. 2. Touch ADD NEW.
Page 250 INTERIOR FEATURES Touch-screen audio system 3. When this screen is displayed, input the passcode displayed on the screen into your Bluetooth device. ® For the operation of the Bluetooth ® device, see the manual that comes with your Bluetooth device. ® Passcodes are not required for SSP (Secure Simple Pairing) compatible Bluetooth devices. Depending on the ® phone, you may need to select YES to register, or NO to cancel on your mobile phone. If you want to cancel it, touch CANCEL. If a completion message is displayed, registration is complete. If an error message is displayed, follow the guidance on the screen to try again. Removing a Bluetooth device− ® 1. Touch REGISTERED DEVICES on the BLUETOOTH SETTINGS screen. 2. Touch REMOVE. 3. Touch the device to remove. 4. A confirmation message will be displayed, touch YES to remove the device.
Page 251 INTERIOR FEATURES Touch-screen audio system Displaying a Bluetooth device details− ® You can confirm and change the device details. 1. Touch REGISTERED DEVICES on the BLUETOOTH SETTINGS screen. 2. Touch DETAILS. 3. Touch the device. 4. The following screen is displayed: a. Display device name. b. Display device address. c. Display your telephone number. The number may not be displayed depending on the phones. d. Display compatibility profile of the device. e. Change connection method, refer STNDA00077Ea to page 230. f. Restore default settings. 5. When you complete settings, touch STNDA00078Ea...
Page 252 INTERIOR FEATURES Touch-screen audio system Changing connection method: 1. Touch CONNECTION METHOD on the DEVICE DETAILS screen. 2. Touch FROM VEHICLE or FROM AUDIO PLAYER. FROM VEHICLE: Connect the audio system to the portable audio player. FROM AUDIO PLAYER: Connect the portable audio player to the audio system. Selecting the Bluetooth phone ® If multiple Bluetooth devices are registered, follow the procedure below to select the ® Bluetooth device to be used. You may only use one device at a time. ® 1. Touch CONNECT TELEPHONE on the BLUETOOTH SETTINGS screen. 2. Touch the device to connect. ADD NEW: Registering a Bluetooth ® device, refer to page 227. The selection indicator is displayed on left side of the selected device name. The Bluetooth mark is displayed ® when you connect the device.
Page 253 INTERIOR FEATURES Touch-screen audio system Detailed Bluetooth settings ® You can confirm and change the detailed Bluetooth settings. ® 1. Touch DETAILED BLUETOOTH SETTINGS on the BLUETOOTH SETTINGS screen. 2. The following screen is displayed: a. Change Bluetooth power on / off ® You can change Bluetooth ® function to ON or OFF. b. Display device name. c. Change passcode, refer to page 231. STNDA00081Ea d. Display device address. e. Display compatibility profile of the system. f. Change displaying telephone status on / off. You can set the system to show the status confirmation display when connecting a telephone.
Page 254: Using The Interior Lights
INTERIOR FEATURES Using the interior lights Using the interior lights INTERIOR LIGHTS OVERVIEW CTY34AV309 Interior / rear personal lights (vehicles with moon roof) refer to “Rear personal lights (vehicles with moon roof)” on page 233. Interior light (vehicles without moon roof) refer to “Interior lights” on page 232. Interior light (vehicles with moon roof) refer to “Interior lights” on page 232 / front personal lights refer to “Front personal lights” on page 233. Shift lever light (when the tail lights are on – vehicles with moon roof). Ignition switch light (vehicles with standard type ignition switch) / ENGINE START STOP switch light (vehicles with a smart entry and start system). INTERIOR LIGHTS Vehicles without moon roof− To turn on the interior light, slide the switch. The interior light switch has 3 positions: 1. Turns the lights on. 2. Turns the light on when the illuminated entry system operates, refer to “Illuminated entry system” on page 234. 3. Turns the lights off.
Page 255: Personal Lights
INTERIOR FEATURES Using the interior lights Vehicles with moon roof− To turn on the interior light and rear personal lights, press the switch. 1. Turns the lights on / off when the illuminated entry system operates, refer to “Illuminated entry system” on page 234. 2. Turns the lights on / off. PERSONAL LIGHTS Front personal lights Press to turn the personal lights on / off. Rear personal lights (vehicles with moon roof) Press to turn the personal lights on / off.
Page 256: Illuminated Entry System
INTERIOR FEATURES Using the interior lights ILLUMINATED ENTRY SYSTEM Vehicles with standard type ignition switch− The lights automatically turn on / off according to the ignition switch position, whether the doors are locked / unlocked, and whether the doors are open / closed. When any of the doors are unlocked, the lights will come on and remain on for about 15 seconds before fading out. After all the doors are closed, the lights remain on for about 15 seconds before fading out. If all the doors are closed and the ignition switch is turned to ACC or ON position, the lights will fade out. Vehicles with a smart entry and start system− The lights automatically turn on / off according to the ENGINE START STOP switch mode, the presence of the electronic key, whether the doors are locked / unlocked, and whether the doors are open / closed. When any of the doors are unlocked or in the presence of the electronic key, the lights will come on and remain on for about 15 seconds before fading out. After all the doors are closed, the lights remain on for about 15 seconds before fading out. If all the doors are closed and the ENGINE START STOP switch is turned to ACCESSORY or IGNITION ON mode, the lights will fade out. NOTICE Vehicles with standard type ignition switch− If the interior lights and / or personal lights are left on when the ignition switch is turned to the LOCK position, the lights will go off automatically after 20 minutes.
Page 257: Using The Storage Features
INTERIOR FEATURES Using the storage features Using the storage features STORAGE FEATURES OVERVIEW Bottle holders / door pockets Cup holders Glove box Rear console box Auxiliary boxes CAUTION • Do not leave glasses in the storage spaces as they may be deformed by heat or cracked if they come into contact with other stored items. • Do not leave lighters or spray cans in the storage spaces as they may explode. If they come into contact with other stored items, the lighter may catch fire or the spray can may release gas, causing a fire hazard.
Page 258: Glove Box
INTERIOR FEATURES Using the storage features GLOVE BOX To use the glove box The glove box can be opened by pulling the lever and can be locked and unlocked by using the master key (vehicles with standard type ignition switch) or the mechanical key (vehicles with a smart entry and start system). 1. Open. 2. Lock. 3. Unlock. With the instrument panel lights on, the glove box light (where fitted) will come on when the glove box is open. CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the glove box door closed while driving. AUXILIARY BOXES Overhead auxiliary box− Push the lid. Centre console auxiliary box− Lift the lid.
Page 259: Rear Console Box
INTERIOR FEATURES Using the storage features CAUTION Caution while driving Keep the auxiliary boxes closed. In the event of sudden braking, an injury may occur due to an occupant being struck by the items stored inside an open auxiliary box. Items unsuitable for storing (overhead auxiliary box only) Do not store items heavier than 0.2 kg. Doing so may cause the auxiliary box to open and the item inside may fall out, resulting in an accident. REAR CONSOLE BOX To open the console box, lift the lid while pulling up the lock release latch. If desired, the console box lid can be slid forward to add to comfort. Pull up the lock release latch and pull forward. The lid can also be opened from the forward most position. CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the console box closed while driving.
Page 260: Cup Holders
INTERIOR FEATURES Using the storage features CUP HOLDERS Front cup holders The cup holder is designed for holding cups or drink cans securely. Press down and release the left side of the cup holder lid. Cup holder insert– The cup holder insert can be removed. Rear cup holders The cup holder is designed for holding cups or drink cans securely. To use it, pull down the armrest. CAUTION • Do not place anything else other than cups or drink cans in the cup holders, as such items may be thrown about the vehicle interior and possibly injure people in the vehicle during sudden braking or in an accident. If possible cover hot drinks to prevent burns. • Do not lift the rear armrest upright when the cup holder is in use.
Page 261: Bottle Holders
INTERIOR FEATURES Using the storage features BOTTLE HOLDERS Front− Rear− INFORMATION • Ensure that caps are fitted securely to bottles placed in the bottle holders. • The bottle may not be able to be stored depending on its size or shape. CAUTION Do not place anything other than bottles in the bottle holder, as such items may be thrown about in the compartment and possibly injure people in the vehicle during sudden braking or in an accident.
Page 262: Other Interior Features
INTERIOR FEATURES Other interior features Other interior features CLOCK Vehicles with standard type ignition switch– The clock is displayed when the ignition switch is in the ACC or ON position. Vehicles with smart entry and start system– The clock is displayed when the ENGINE START STOP switch is in ACCESSORY or IGNITION ON mode. To set the clock 1. Adjusts the hours. 2. Adjusts the minutes. INFORMATION When disconnecting and reconnecting the battery terminals the time display will automatically be set to 1:00. POWER OUTLET The power outlet is designed for 12V car accessories that operate on less than 10 A. Vehicles with standard type ignition switch– The ignition switch must be in ACC or ON position for the power outlet to be used.
Page 263: Ashtray
INTERIOR FEATURES Other interior features NOTICE • To prevent the fuse from being blown, do not use accessories with a power rating of more than 12V / 10 A. • To prevent the battery from being discharged, do not use the power outlet longer than necessary when the engine is not running. • Close the power outlet lid when the power outlet is not in use. Inserting anything other than an appropriate plug that fits the outlet, or allowing any liquid to get into the outlet may cause electrical failure or short circuits. ASHTRAY Push the lid to open. Pull the ashtray out to remove it. CAUTION When not in use Keep the ashtray closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open ashtray or ash flying out. To prevent fire • Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed. • Do not place paper or any other type of flammable object in the ashtray.
Page 264: Cigarette Lighter
INTERIOR FEATURES Other interior features CIGARETTE LIGHTER Push the lid to open, and push the cigarette lighter in. The cigarette lighter will pop up when it is ready for use. Vehicles with standard type ignition switch– The ignition switch must be in ACC or ON position for the cigarette lighter to be used. Vehicles with smart entry and start system– The ENGINE START STOP switch must be in ACCESSORY or IGNITION ON mode for the cigarette lighter to be used. CAUTION To avoid burns or fires • Do not touch the metal part of the cigarette lighter. • Do not hold the cigarette lighter down. It could overheat and cause a fire. • Do not insert anything other than the cigarette lighter provided into the cigarette lighter outlet. Doing so may deform the outlet and make the cigarette lighter pop out of the outlet or become difficult to take out.
Page 265: Vanity Mirrors
INTERIOR FEATURES Other interior features VANITY MIRRORS To use the vanity mirror, swing down the sun visor and open the cover. The vanity light (if fitted) comes on when you open the cover. INFORMATION To prevent battery discharge, the vanity lights (if fitted) will automatically turn off after 20 minutes when the engine is not running. REAR ELECTRIC SUNSHADE To raise the rear sunshade, press the switch shown in the illustration. To lower the shade, press the switch again. The ENGINE START STOP switch must be in IGNITION ON mode. INFORMATION • The rear sunshade can be used only when the ENGINE START STOP switch is in IGNITION ON mode. • The rear sunshade can be operated for approximately 1 minute after the ENGINE START STOP switch is turned off. Reverse operation feature • To ensure adequate rear visibility, the rear sunshade automatically lowers when the shift lever is moved to R position. However, the rear sunshade is raised again if any of the following occurs: – The switch is pressed again – The shift lever is moved to P position – The shift lever is moved out of R, and the vehicle reaches a speed of 15 km/h When the reverse operation feature does not work • The reverse operation feature may not work under some conditions. In such cases, press the switch to extend / retract the rear sunshade.
Page 266: Floor Mat
INTERIOR FEATURES Other interior features CAUTION • To avoid injuring your fingers on the screws, etc., do not touch the brackets fastening the shade. • Do not put your fingers in the shade groove while the shade is operating to avoid getting them caught or injured by the runner. NOTICE • To maintain battery life, always operate the rear electric sunshade while the engine is running. • The rear electric sunshade may fail or be damaged unless the following items are considered: – Do not overload the shade motor and other parts – Do not place anything where it may hinder the lowering / raising of the shade – Do not place items on the shade – Clean the shade groove if there is any foreign matter or dust – Do not operate the rear sunshade continuously for long periods of time FLOOR MAT NOTICE Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place. Always align the marks *: Always align the Δ marks.
Page 267: Assist Grips
INTERIOR FEATURES Other interior features CAUTION Observe the following precautions, as failure to do so may cause the driver’s floor mat to slip, possibly interfering with the pedals while driving. An unexpectedly high speed may result or it may become difficult to stop the vehicle, leading to a serious accident. When installing the driver’s floor mat • Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. • Only use floor mats designed for the driver’s side. • Always install the floor mat securely using the retaining hooks (clips) provided. • Do not use two or more floor mats on top of each other. • Do not place the floor mat bottom-side up or upside-down. Before driving • Check the floor mat is securely fixed in the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor. • With the engine stopped and the shift lever in P position, fully depress each pedal to the floor to ensure it does not interfere with the floor mat.
Page 268: Coat Hooks
INTERIOR FEATURES Other interior features COAT HOOKS CAUTION Items that cannot be hung on the coat hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury. GROCERY BAG HOOKS These hooks are designed to hang items such as grocery bags. NOTICE To prevent damage to the hooks, avoid hanging heavy loads on them.
Page 269 MAINTENANCE AND CARE Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . 248 CLEANING AND PROTECTING THE EXTERIOR .
Page 270: Maintenance And Care
MAINTENANCE AND CARE Maintenance and care Maintenance and care CLEANING AND PROTECTING THE EXTERIOR CAUTION When cleaning the windscreen (vehicles with rain-sensing windscreen wiper) Set the wiper switch to off. If the wiper switch is in AUTO, the wipers may operate unexpectedly in the following situations, which may result in hands being caught or other serious injuries and cause damage to the wiper blades. • When the upper part of the windscreen (where the raindrop sensor is located) is touched by hand. • When a wet rag or similar is held close to the raindrop sensor. • If something bumps against the windscreen. • If you directly touch the raindrop sensor body or if something bumps into the raindrop sensor. Exhaust pipe precautions Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns.
Page 271 MAINTENANCE AND CARE Maintenance and care Perform the following to protect the vehicle and maintain it in prime condition. • Working from top to bottom, liberally apply water to the vehicle body, wheel-wells and underside of the vehicle to remove any dirt and dust. • Wash the vehicle body using a sponge or soft cloth, such as a chamois. • For hard-to-remove marks, use car wash soap and rinse thoroughly with water. • Wipe away any water. • Wax the vehicle when the waterproof coating deteriorates. • If water does not bead on a clean surface, apply wax when the vehicle body is cool. Automatic car washes • Fold the mirrors before washing the vehicle. Start washing from the front of the vehicle. Make sure to extend the mirrors before driving. • Brushes used in automatic car washes may scratch the vehicle surface and harm your vehicle’s paint. • Vehicles with a rear spoiler: In certain automatic car washes, the rear spoiler may interfere with machine operation. This may prevent the vehicle from being cleaned properly or result in damage to the rear spoiler. High pressure car washes • Do not allow the nozzles of the car wash to come within close proximity of the windows. • Before washing the car, check the fuel filler door on your vehicle is closed properly. NOTICE Vehicles with smart entry and start system When using a car wash, if the door handle is sprayed with a jet of water while the...
Page 272 Maintenance and care Bumpers • Do not scrub with abrasive cleaners. The bumper faces are soft. Paintwork • If the paint is chipped or scratched, have it repaired immediately. NOTICE Precaution regarding the blind spot monitor If the paint on the rear bumper is chipped or scratched, the system may malfunction. If this occurs, consult your Toyota dealer. NOTICE To prevent paint deterioration and corrosion on the body and components (aluminium wheels, etc .) • Wash the vehicle immediately in the following cases: – After driving near the sea coast – After driving on salted roads – If coal tar or tree sap is present on the paint surface –...
Page 273: Cleaning And Protecting The Interior
• Do not get any of the SRS components or wiring in the vehicle interior wet. An electrical malfunction may cause the airbags to deploy or not function properly, resulting in death or serious injury. • Do not wash the vehicle floor with water, or allow water to get onto the floor when cleaning the vehicle interior or exterior. Water may get into audio components or other electrical components above or under the floor carpet (or mat) and cause a malfunction; and it may cause vehicle body corrosion. • Do not use polish wax or polish cleaner particularly on the instrument panel as it may reflect on the windscreen, obstructing the driver’s view leading to an accident, resulting in death or serious injury. The following procedures will help protect your vehicle’s interior and keep it in top condition. If you have any questions about the cleaning of your Toyota, your local Toyota dealer will be pleased to answer them. Cleaning the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water. NOTICE Cleaning detergents Do not use the following types of detergent, as they may discolour the vehicle interior or cause streaks or damage to painted surfaces. • Non-seat portions: Organic substances such as benzene or petrol, alkaline or acidic solutions, dye and bleach. • Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol. Do not use polish wax or polish cleaner. The instrument panel or other interior part’s painted surface may be damaged. Cleaning the leather areas • Remove dirt and dust using a vacuum cleaner.
Page 274 MAINTENANCE AND CARE Maintenance and care Caring for leather areas– • Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. NOTICE Preventing damage to leather surfaces Observe the following precautions to avoid damage to and deterioration of leather surfaces. • Remove any dust or dirt from leather surfaces immediately. • Do not expose the vehicle to direct sunlight for extended periods of time. Park the vehicle in the shade, especially during summer. • Do not place items made of vinyl, plastic, or containing wax on the upholstery, as they may stick to the leather surface if the vehicle interior heats up significantly. Cleaning the synthetic leather areas • Remove loose dirt using a vacuum cleaner. • Apply a mild soap solution to the synthetic leather using a sponge or soft cloth. • Allow the solution to soak in for a few minutes. Remove the dirt and wipe off the solution with a clean, damp cloth. Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam. Rub in overlapping circles. Do not use water. Wipe dirty surfaces and let...
Page 275: Maintenance Requirements
Maintenance requirements MAINTENANCE REQUIREMENTS To ensure safe and economical driving, day-to-day care and regular maintenance are essential. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule. For full details of your maintenance schedule, refer to the “Warranty and Service Book”. Do-it-yourself maintenance Many maintenance items are easy to do yourself if you have a little mechanical ability and a few basic automotive tools. Note that some maintenance tasks require special tools and skills and are best performed by qualified technicians. Even if you are an experienced do-it-yourself mechanic, we recommend that repairs and maintenance be conducted by your Toyota dealer who will keep a record of maintenance on your vehicle. This record could be helpful should you ever require Warranty Service. Regular maintenance will also aid: • Good fuel economy • Long vehicle life • Driving enjoyment • Safety • Reliability • Compliance with government regulations Where to go for service? It makes good sense to take your vehicle to your local Toyota dealer for service. Toyota technicians are well-trained specialists. And they are receiving the latest service information through technical bulletins, service tips, and in-dealership training programs.
Page 276: Does Your Vehicle Need Repairing? . 2
• Strange engine noises. • A leak under the vehicle. (However, water dripping from the air conditioning after use is normal.) • Change in exhaust sound. (This may indicate a dangerous carbon monoxide leak. Drive with the windows open and have the exhaust system checked immediately.) • Flat-looking tyre; excessive tyre squeal when cornering; uneven tyre wear. • Vehicle pulls to one side when driving straight on a level road. • Strange noises related to suspension movement. • Loss of brake effectiveness; spongy feeling brake pedal; the pedal almost touches floor; vehicle pulls to one side when braking. • Engine coolant temperature continually higher than normal. If you notice any of these symptoms, take your vehicle to your Toyota dealer as soon as possible. It probably needs adjustment or repair. CAUTION If your vehicle is not properly maintained • Do not continue driving with the vehicle unchecked. It could result in serious vehicle damage and serious injury or death to users. • Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. Handling of the battery Battery posts, terminals and related accessories contain lead and lead compounds which are known to cause brain damage. Wash your hands after handling.
Page 277: Do-It-Yourself Maintenance
MAINTENANCE AND CARE Do-it-yourself maintenance Do-it-yourself maintenance DO-IT-YOURSELF SERVICE PRECAUTIONS If you perform maintenance by yourself, ensure to follow the correct procedures given in this section. You should be aware that incorrect or incomplete servicing may result in operating problems. This section gives instructions only for those items that are relatively easy for an owner to perform. There are still a number of items that must be done by a qualified technician with special tools, refer to “Maintenance requirements” on page 253. Utmost care should be taken when working on your vehicle to prevent accidental injury. CAUTION When working on the engine compartment The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energised. To avoid death or serious injury, observe the following precautions. • When the engine is running, keep hands, clothing, and tools away from the moving fan and engine drive belts. (Removing rings, watches, and ties is advisable.) • Immediately after driving, the engine compartment – the engine, radiator, exhaust manifold, power steering fluid reservoir and spark plug boots, etc. – will be hot. So be careful not to touch them. Oil, fluids and spark plugs may also be hot. • If the engine is hot, do not remove the radiator cap or loosen the drain plugs to prevent burning yourself. • Do not leave any combustible materials, such as paper or rags, in the engine compartment. • Do not smoke, cause sparks or allow open flames around fuel or the battery. Their fumes are flammable. • Be extremely cautious when working on the battery. It contains poisonous and corrosive sulphuric acid.
Page 278 • Do not leave used oil within the reach of children. • Dispose of used oil and filter only in a safe and acceptable manner. Do not dispose of used oil and filter in household rubbish, in sewers or onto the ground. Call your dealer, a service station or local government for information concerning recycling or disposal. When working under the vehicle • Do not get under your vehicle with just the body jack supporting it. Always use automotive jack stands or other solid supports. • Use eye protection whenever you work on or under your vehicle where you may be exposed to flying or falling material, fluid spray, etc. NOTICE • Remember that battery and ignition cables carry high currents or voltages. Be careful of accidentally causing a short circuit. • Add only “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology to fill the radiator. “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deionised water. • If you spill some of the coolant, ensure to wash it off with water to prevent it from damaging the parts or paint. • Do not allow dirt or anything else to fall through the spark plug holes. • Do not prise the outer electrode of a spark plug against the centre electrode. • Use only spark plugs of the specified type. Using other types will cause engine damage, loss of performance or radio noise. • Do not reuse iridium-tipped spark plugs by cleaning or regapping. • Do not overfill automatic transmission fluid, or the transmission could be damaged.
Page 279: Bonnet
MAINTENANCE AND CARE Do-it-yourself maintenance NOTICE • If you spill the fluid, ensure to wash it off with water to prevent it from damaging the parts or paint. • Do not drive with the air cleaner filter removed, or excessive engine wear could result. Also backfiring could cause a fire in the engine compartment. • Be careful not to scratch the glass surface with the wiper frame. • When closing the engine bonnet, check to see that you have not forgotten any tools, rags, etc. BONNET To open the bonnet: 1. Pull the bonnet lock release lever. The bonnet will spring up slightly. 2. In front of the vehicle, lift the auxiliary catch lever and raise the bonnet. • Before closing the bonnet, check to see that you have not forgotten any tools, rags, etc. • To close the bonnet, lower it to about waist height and drop it to close it fully. Make sure it locks into place, if not, open it again and drop it from a slightly higher point. NOTICE To avoid damaging the panel, avoid pushing the bonnet to close it. CAUTION Before driving, ensure the bonnet is closed and securely locked. Otherwise, the bonnet may open unexpectedly while driving and an accident may occur.
Page 280: Positioning A Floor Jack
MAINTENANCE AND CARE Do-it-yourself maintenance POSITIONING A FLOOR JACK When raising your vehicle with a trolley jack, position the jack correctly as shown. Front– Rear– CAUTION Use only a trolley jack that complies with Mandatory Standards in force in relation to trolley jacks at the time of use. Use only a trolley jack that is rated strong enough to lift the vehicle.
Page 281 MAINTENANCE AND CARE Do-it-yourself maintenance CAUTION When using a trolley jack, observe the following to reduce the possibility of death or serious injury. Follow the trolley jack instructions • Use the hydraulic trolley jack on a hard, flat level surface. • Before commencing use, ensure that the trolley jack is free to roll during lifting and lowering. • Do not put any part of your body under the vehicle supported by the jack. Personal injury may occur. • Stop the vehicle on a level firm ground, firmly set the parking brake and put the transmission in P position. • Do not start the engine while the vehicle is supported by the floor jack. • Chock the unlifted wheels. • A trolley jack should only be used to raise and lower the vehicle. The vehicle should be supported by support stands, in accordance with the manufacturer’s instructions. • Ensure the jack is correctly set in the jack point. Raising the vehicle with the jack incorrectly positioned will damage the vehicle or may allow the vehicle to fall off the jack and cause personal injury. • Do not raise the vehicle with someone in the vehicle. • Ensure the load is centrally located on the head cap. • When raising the vehicle, do not place any objects on top of or underneath the jack. NOTICE Ensure the jack is placed correctly, or your vehicle may be damaged.
Page 282: Engine Compartment Overview
MAINTENANCE AND CARE Do-it-yourself maintenance ENGINE COMPARTMENT OVERVIEW Engine oil filler cap Radiator Brake fluid reservoir Electric cooling fans Engine oil level dipstick Condenser Fuse block Engine coolant reservoir Battery 10 Windscreen washer fluid tank ENGINE OIL Importance of engine oil level check One of the most important points in correct vehicle maintenance is to keep the engine oil at the optimum level so that oil function will not be impaired. Therefore, it is essential the oil level be checked regularly. Toyota recommends the oil level be checked every time you refuel the vehicle. NOTICE Failure to check the oil level regularly could lead to serious engine damage due to insufficient oil. Checking engine oil level With the engine at operating temperature and turned off, check the oil level on the dipstick. 1. To get a correct reading, the vehicle should be parked on level ground. After turning off the engine, wait a few minutes for the oil to drain back into the engine sump.
Page 283 MAINTENANCE AND CARE Do-it-yourself maintenance 2. Pull the dipstick out while holding a rag under the end and wipe it clean. 3. Reinsert the dipstick fully. The reading will be incorrect if it is not fully reinserted. Full 4. Pull the dipstick out while holding a rag under the end and inspect the oil level. If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. CAUTION Be careful not to touch the hot exhaust manifold. Adding engine oil Remove the oil filler cap and add engine oil in small quantities at a time, checking the dipstick. We recommend that you use a funnel when adding oil. The approximate quantity of oil needed to raise the level between low and full on the dipstick is 1.5 litres. When the level is within the correct range, install the filler cap hand-tight. For the engine oil capacity refer to “Lubrication” on page 329. NOTICE • Be careful not to spill engine oil on the vehicle components. • Avoid overfilling, or the engine could be damaged. • Check the oil level on the dipstick once again after adding the oil.
Page 284 MAINTENANCE AND CARE Do-it-yourself maintenance CAUTION Used engine oil • Used engine oil contains potentially harmful contaminants which may cause skin disorders such as inflammation and skin cancer, so care should be taken to avoid prolonged and repeated contact. To remove used engine oil from your skin, wash thoroughly with soap and water. • Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household waste, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. • Do not leave used engine oil within the reach of children. Engine oil selection Toyota Genuine Motor Oil is used in your Toyota vehicle. Use Toyota approved Toyota Genuine Motor Oil or equivalent to satisfy the following grade and viscosity. Oil grade– • 5W-30 and 10W-30 API grade SL Energy-Conserving, SM Energy-Conserving, SN Resource-Conserving or ILSAC multigrade engine oil • 15W-40 and 20W-50 API grade SL, SM or SN multigrade engine oil Recommended viscosity (SAE)– If you use SAE 10W-30 or a higher viscosity engine oil in extremely low temperatures, the engine may become difficult to start, so SAE 5W-30 engine oil is recommended. Temperature range anticipated before next oil change.
Page 285 1. The API Service Symbol is located anywhere on the outside of the container. – The top portion of the label shows the oil quality designations by API (American Petroleum Institute) such as SN. – The centre portion of the label shows the SAE viscosity grade such as SAE 10W-30. – Resource-Conserving shown in the lower portion indicates the oil has fuel saving and environmental protection capabilities. 2. The ILSAC (International Lubricant Standardisation and Approval Committee) Certification Mark is displayed on the front of the container. To ensure excellent lubrication performance for your engine, Toyota Genuine Motor Oil is available which has been specifically tested and approved for all Toyota engines. Please contact your Toyota dealer for further details about Toyota Genuine Motor Oil. Facts about engine oil consumption Functions of engine oil– Engine oil has the primary functions of lubricating and cooling the inside of the engine, and plays a major role in maintaining the engine in correct working order. Engine oil consumption– It is normal that an engine should consume some engine oil during normal engine operation. The causes of oil consumption in a normal engine are as follows. • Oil is used to lubricate pistons, piston rings and cylinders. A thin film of oil is left on the cylinder wall when a piston moves downwards in the cylinder. High negative pressure generated when the vehicle is decelerating sucks some of this oil into the combustion chamber. This oil as well as some part of the oil film left on the cylinder wall is burned by the high temperature combustion gases during the combustion process.
Page 286: Engine Coolant
• Oil consumption: Max. 1.0 L per 1000 km (1.1 qt., 0.9 lmp. qt.) When judging the amount of oil consumption, note the oil may become diluted and make it difficult to judge the true level accurately. As an example, if a vehicle is used for repeated short trips, and consumes a normal amount of oil, the dipstick may not show any drop in the oil level at all, even after 1000 km or more. This is because the oil is gradually becoming diluted with fuel or moisture, making it appear the oil level has not changed. The diluting ingredients evaporate out when the vehicle is then driven at high speeds, as on an expressway, making it appear that oil is excessively consumed after driving at high speeds. Importance of engine oil level check One of the most important points in correct vehicle maintenance is to keep the engine oil at the optimum level so that oil function will not be impaired. Therefore, it is essential the oil level be checked regularly. Toyota recommends the oil level be checked every time you refuel the vehicle. NOTICE Failure to check the oil level regularly could lead to serious engine trouble due to insufficient oil. ENGINE COOLANT Checking engine coolant level Look at the see-through coolant reservoir when the engine is cold. 1. Reservoir cap 2. FULL line 3. LOW line • The coolant level is satisfactory if it is between the FULL and LOW lines on the reservoir when the engine is cold.
Page 287: Radiator And Condenser
MAINTENANCE AND CARE Do-it-yourself maintenance CAUTION When the engine is hot Do not remove the engine coolant reservoir cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing serious injuries, such as burns. Coolant type selection Use of incorrect coolants may damage your engine cooling system. Only use Toyota Super Long Life Coolant or similar high quality ethylene glycol based non- silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology. (Coolant with long-life hybrid organic acid technology is a combination of low phosphates and organic acids.) Toyota Super Long Life Coolant is a mixture of 50% coolant and 50% deionised water. This coolant provides protection down to about –35˚C. Contact your Toyota dealer for further details. NOTICE • Do not use plain water alone. • Coolant is neither plain water nor straight antifreeze. The correct mixture of water and antifreeze must be used to provide correct lubrication, corrosion protection and cooling. • If you spill the coolant, wash it off with water immediately to prevent it from damaging parts or paint. RADIATOR AND CONDENSER Check the radiator and condenser and clear away any foreign objects such as leaves, etc. If the radiator or the condenser is extremely dirty or you are not sure of their condition, take your vehicle to a Toyota dealer. CAUTION To prevent burning yourself, be careful not to touch the radiator or condenser when the engine is hot.
Page 288: Brake Fluid
MAINTENANCE AND CARE Do-it-yourself maintenance BRAKE FLUID Checking the brake fluid level To check the fluid level, simply look at the see-through reservoir. Refer to “Engine compartment overview” on page 260 for the location of the brake fluid reservoir. The level should be between the MAX and MIN lines on the reservoir. It is normal for the brake fluid level to go down slightly as the brake pads wear. So ensure to keep the reservoir filled. CTY43PAC001 If the reservoir needs frequent refilling, it may indicate a serious mechanical problem. If the level is low, add SAE J1703 or FMVSS No. 116 DOT 3 brake fluid to the brake reservoir. Remove and replace the reservoir cover by hand. Fill the brake fluid to the dotted line. This brings the fluid to the correct level when you put the cover back on. Use only newly opened brake fluid. Once opened, brake fluid absorbs moisture from the air, and excess moisture can cause a dangerous loss of braking. CAUTION Take care when filling the reservoir because brake fluid can harm your eyes and damage painted surfaces. If fluid gets in your eyes, flush your eyes with clean water, and seek medical assistance. NOTICE If fluid is spilt, wash it off with water immediately to prevent damage to parts or paint. WASHER FLUID If the windscreen washers do not operate, the windscreen washer fluid tank may be empty. Refer to “Engine compartment overview” on page 260 for tank location. Checking fluid level (without fluid gauge) Remove the washer fluid tank cap and visually check the fluid level. If washer fluid is not visible, add fluid until the washer fluid fills the tank neck.
Page 289: Tyres
MAINTENANCE AND CARE Do-it-yourself maintenance Checking fluid level (with fluid gauge) 1. Open the washer reservoir cap, pull out the fluid gauge and check the fluid level. 2. Check the fluid level by observing the liquid-covered holes on the fluid gauge. If the level is below the second hole from the end of the gauge (the LOW mark) add washer fluid. Current fluid level CTY43AV089a CAUTION Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine, etc. NOTICE Do not overfill Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking or damage the vehicle’s painted surfaces. Diluting washer fluid Dilute washer fluid with water as necessary. Refer to the freezing temperatures listed on the label of the washer fluid bottle.
Page 290 MAINTENANCE AND CARE Do-it-yourself maintenance Incorrect tyre inflation pressure may waste fuel, reduce the comfort of driving, reduce tyre life and make your vehicle less safe to drive. The following instructions for checking tyre inflation pressure should be observed. • The pressure should be checked only when the tyres are cold. If your vehicle has been parked for at least 3 hours and has not been driven for more than 1.5 km since, you will get an accurate cold tyre inflation pressure reading. • Always use a tyre pressure gauge. The appearance of a tyre can be misleading. Tyres that are only slightly over or under inflated can degrade ride and handling. • Do not bleed or reduce tyre inflation pressure after driving. It is normal for the tyre inflation pressure to be higher after driving. • Reinstall the tyre valve caps. Without the valve caps, dirt or moisture could get into the valve core and cause air leakage. If the caps have been lost, have new ones put on as soon as possible. CAUTION • Keep your tyres inflated in accordance with the vehicle’s specifications. Otherwise, death or serious injuries may result. • Under inflation can result in: – Possibility of blowouts from an overheated tyre – Poor sealing of the tyre bead – Wheel deformation and/or tyre separation – Poor handling – Increased possibility of tyre damage from road hazards – Excessive wearing of tyres – Uneven wearing of tyres. • Over inflation of tyres can result in: –...
Page 291 MAINTENANCE AND CARE Do-it-yourself maintenance NOTICE If tyre inflation pressure becomes low while driving Do not continue driving as your tyres and/or wheels may be ruined. Driving on rough roads Take particular care when driving on roads with loose surfaces or potholes. These conditions may cause losses in tyre inflation pressure, reducing the cushioning ability of the tyres. In addition, driving on rough roads may cause damage to the tyres themselves, as well as the vehicle’s wheels and body. Checking your tyres The tyres on your Toyota have built-in tread wear indicators to help you know when the tyres need replacement. The location of tread wear indicators is shown by the TWI or Δ marks, etc., moulded on the sidewall of each tyre as shown. 1. New tread. 2. Tread-wear indicator 3. Worn tread When the tread depth wears to 1.6 mm or less, the indicators will appear. If you can see the indicators in two or more adjacent grooves, the tyre should be replaced. The lower the tread, the higher the risk of skidding.
Page 292 Do-it-yourself maintenance Replacing your tyres CAUTION Observe the following instructions. Otherwise, an accident may occur resulting in death or serious injuries. • Do not mix radial, bias belted, or bias-ply tyres on your vehicle, as this may cause dangerous handling characteristics resulting in loss of control. • Do not use tyres other than the manufacturer’s recommended size, as this may cause dangerous handling characteristics resulting in loss of control. • Do not mix tyres of different makes, models or tread patterns, and do not mix tyres of remarkably different tread wear. This may cause dangerous handling characteristics resulting in loss of control. When replacing a tyre, use a tyre of the same size and construction, and the same or greater load capacity as the originally installed tyres. Using any other size or type of tyre may seriously affect handling, ride, speedometer / odometer calibration, ground clearance, and clearance between the body and tyres or snow chains. Never use second-hand tyres on your Toyota. Using tyres whose previous history is unknown is a risk. Toyota recommends all four tyres, or at least both front or rear tyres be replaced at a time as a set. Refer to “If you have a flat tyre” on page 306 for tyre change procedure. When a tyre is replaced, the wheel should always be balanced. An unbalanced wheel may affect vehicle handling and tyre life. Wheels can get out of balance with regular use and should therefore be balanced occasionally. When replacing a tubeless tyre, the air valve should also be replaced with a new one. Rotating tyres To equalise tyre wear and help extend tyre life, Toyota recommends that you rotate your tyres approximately every 10000 km. However, the most appropriate timing for tyre rotation may vary according to your driving habits and road surface conditions. Refer to “If you have a flat tyre” on page 306 for tyre change procedure. When rotating tyres, check for uneven wear and damage. Abnormal wear is usually...
Page 293: Wheels
If you fail to replace a damaged wheel, the tyre may slip off the wheel or cause loss of handling control. Refer to “If you have a flat tyre” on page 306 for tyre change procedure. Wheel selection When replacing wheels, care should be taken to ensure the wheels are replaced by ones with the same load capacity, diameter, rim width and offset. Correct replacement wheels are available at your Toyota dealer. A wheel of a different size or type may adversely affect handling, wheel and bearing life, brake cooling, speedometer / odometer calibration, stopping ability, headlight aim, bumper height, vehicle ground clearance, and tyre or snow chain clearance to the body and chassis. Replacement with used wheels is not recommended as they may have been subjected to rough treatment or high mileage and could fail without warning. Also, bent wheels which have been straightened may have structural damage and therefore should not be used. Never use an inner tube in a leaking wheel which is designed for a tubeless tyre. CAUTION Do not use wheels other than the manufacturer’s recommended size, as this may cause dangerous handling characteristics resulting in loss of control. Otherwise, an accident may occur resulting in death or serious injuries. Aluminium wheel precautions • When installing aluminium wheels, check the wheel nuts are tight after driving your vehicle the first 1600 km. • If you have rotated, repaired, or changed your tyres, check the wheel nuts are still tight after driving 1600 km. • When using tyre chains, be careful not to damage the aluminium wheels. • Use only Toyota wheel nuts and wrench designed for your aluminium wheels. • When balancing your wheels, use only Toyota balance weights or equivalent and a plastic or rubber hammer. • As with any wheel, periodically check your aluminium wheels for damage. If damaged, replace immediately.
Page 294: Air Conditioning Filter
MAINTENANCE AND CARE Do-it-yourself maintenance AIR CONDITIONING FILTER The air conditioning filter must be changed regularly to maintain air conditioning efficiency. • Inspect and replace the air conditioning filter according to the maintenance schedule. • In dusty areas or areas with heavy traffic flow, early replacement may be required. • If air flow from the vents decreases dramatically, the filter may be clogged. Check the filter and replace if necessary. Replacement 1. Vehicles with standard type ignition switch– Turn the ignition switch off. Vehicles with smart entry and start system– Press the ENGINE START STOP switch off. 2. Open the glove box and slide off the damper. 3. Push in each side of the glove box to disconnect the stops. 4. Pull out the glove box and disconnect the lower claws. 5. Remove the filter cover.
Page 295: Battery
MAINTENANCE AND CARE Do-it-yourself maintenance 6. Remove the air conditioning filter and replace it with a new one. The UP marks shown on the filter should be pointing up. NOTICE Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system. BATTERY Precautions CAUTION Battery precautions The battery produces flammable and explosive hydrogen gas. • Do not cause a spark from the battery with tools. • Do not smoke or light a match near the battery. The electrolyte contains poisonous and corrosive sulphuric acid. • Avoid contact with eyes, skin or clothes. • Never ingest electrolyte. • Wear protective safety glasses when working near the battery. • Keep children away from the battery. Emergency measures • If electrolyte gets in your eyes, flush your eyes with clean water immediately and get immediate medical attention. If possible, continue to apply water with a sponge or cloth while en-route to the medical office. • If electrolyte gets on your skin, thoroughly wash the contact area. If you feel pain or burning, get medical attention immediately. • If electrolyte gets on your clothes, there is a possibility of its soaking through to your skin, so immediately take off the exposed clothing and follow the procedure above, if necessary.
Page 296 MAINTENANCE AND CARE Do-it-yourself maintenance Checking the battery Check the battery for corroded or loose terminal connections, cracks, or a loose hold-down clamp. 1. Terminal connections– If a terminal connection is loose, tighten the clamp nut. Do not overtighten. If the battery terminals are corroded, wash it off with a solution of warm water and baking soda. Coat the terminals with grease to prevent further corrosion. 2. Hold-down clamp– Tighten the hold-down clamp to secure the battery firmly. Over-tightening may damage the battery case. NOTICE • Ensure the engine and all accessories are off before performing maintenance. • When checking the battery, remove the ground cable from the negative terminal [–] first and reinstall it last. • Be careful not to cause a short circuit with tools. • Take care no solution gets into the battery when washing it. Checking battery fluid The fluid (electrolyte) level must be maintained at a certain level for the battery to function correctly. To check the fluid level, view through the inspection window. Adding distilled water– 1. Remove each vent plug. 2. Add distilled water to cells as required.
Page 297 NOTICE Never recharge the battery while the engine is running. Also, ensure all accessories are turned off. After recharging / reconnecting the battery (vehicles with smart entry and start system) • Unlocking the doors using the smart entry and start system may not be possible immediately after reconnecting the battery. If this happens, use the wireless remote control or the mechanical key to lock or unlock the doors. • Start the engine with the ENGINE START STOP switch in ACCESSORY mode. The engine may not start with the ENGINE START STOP switch turned off. However, the engine will operate normally from the second attempt. NOTICE ENGINE START STOP switch mode The ENGINE START STOP switch mode is recorded by the vehicle. If the battery is reconnected, the vehicle will return the mode to the status it was in before the battery was disconnected. • Ensure you turn off the engine before disconnecting the battery. • Take extra care when connecting the battery if the ENGINE START STOP switch mode prior to discharge is unknown. • If the engine will not start even after multiple attempts, contact your Toyota dealer.
Page 298: Checking And Replacing Fuses
MAINTENANCE AND CARE Do-it-yourself maintenance CHECKING AND REPLACING FUSES If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. • Vehicles with standard type ignition switch– Turn the ignition switch off. Vehicles with smart entry and start system– Press the ENGINE START STOP switch off. Engine compartment fuse block • Push in the tabs and lift off the fusebox lid. Instrument panel fuse block • Disconnect the four claws of the cover located under the instrument panel. • Remove the cover by pulling it away from the instrument panel (toward the rear of the vehicle).
Page 299 MAINTENANCE AND CARE Do-it-yourself maintenance • Unplug the connector while depressing the lock release. • Remove the fusebox lid. Fuse Removal For fuse descriptions and amperages refer to “Fuse layout and amperage ratings” on page 279. The amperage rating is also inside the fuse box lid. Several types of fuses are used. Type A– • Only type A fuses can be removed using the removal tool. • Remove the fuse by pulling it straight out and check if it has blown. 1. Normal fuse. 2. Blown fuse. • Replace the blown fuse with a new fuse of the same amperage rating.
Page 300 MAINTENANCE AND CARE Do-it-yourself maintenance Type B– 1. Normal fuse. 2. Blown fuse. • Remove the fuse by pulling it straight out and check if it has blown. • Replace the blown fuse with a new fuse of the same amperage rating. Type C– 1. Normal fuse. 2. Blown fuse. • Contact your Toyota dealer. If you cannot use a fuse of the same amperage, use one that is lower, but as close to the rating as possible. If the amperage is lower than that specified, the fuse might blow out again but this does not indicate anything wrong. Obtain the correct fuse as soon as possible and return the substitute to its original clip. It is a good idea to purchase a set of spare fuses and keep them in your vehicle for emergencies. If the new fuse immediately blows out, there is a problem with the electrical system. Have your Toyota dealer correct it as soon as possible. CAUTION Never use a fuse with a higher amperage rating, or any other object, in place of a fuse. This may cause extensive damage and possibly a fire.
Page 301: Fuse Layout And Amperage Ratings
MAINTENANCE AND CARE Do-it-yourself maintenance FUSE LAYOUT AND AMPERAGE RATINGS Engine compartment Fuse block– Fuse block cover (inside)– Fuse Amperage Circuit METER-IG2 Gauge and meters 50 A Electric cooling fans H-LP CLN 30 A Headlight cleaner 50 A Air conditioning system...
Page 302 MAINTENANCE AND CARE Do-it-yourself maintenance Fuse Amperage Circuit 120 A Charging system ABS NO.2 30 A Vehicle stability control system Starter system, ECU-IG2 NO.1, A/B, ECU-IG2 ST/AM2 30 A NO.2 H-LP-MAIN 30 A H-LP LH-LO, H-LP RH-LO, headlights (low beam) ABS NO.1 50 A Vehicle stability control system 80 A Electric power steering S-HORN 7.5 A S-HORN HORN 10 A Horns Fuel injection system, electronic controlled EFI NO.2 15 A transmission EFI NO.3 10 A Fuel injection system 7.5 A Fuel injection system ECU-IG2 NO.3 7.5 A Fuel injection system 15 A Starter system...
Page 303 MAINTENANCE AND CARE Do-it-yourself maintenance Fuse Amperage Circuit RADIO-B 20 A Audio system, navigation system Clock, vanity lights, interior lights, personal DOME 7.5 A lights, trunk light, door courtesy lights Front power seats, outside rear view mirrors, multiplex communication system, smart entry & ECU-B NO.1 10 A start system, gauge and meters, steering sensor, Blind Spot Monitor, wireless remote control SPARE 25 A Spare fuse SPARE 30 A Spare fuse *1: Vehicles with halogen headlight *2: Vehicles with discharge headlight...
Page 304 MAINTENANCE AND CARE Do-it-yourself maintenance Instrument panel Fuse Amperage Circuit Headlight cleaner, outside rear view mirrors, Toyota parking assist-sensor, shift lock control system, windshield wipers and washer, rear ECU-IG1 NO.2 10 A sunshade, multiplex communication system, audio system, navigation system, moon roof, auto antiglare inside rear view mirror, clock Vehicle stability control system, electric cooling fans, Blind Spot Monitor, headlights (low beam), ECU-IG1 NO.1 10 A steering sensor, Fuel injection system, charging system, rear window defogger Switch illumination, air conditioning system, cigarette lighter, shift lever light, glove box light, PANEL 10 A interior lights, personal lights, audio system, navigation system Front position lights, tail lights, license plate TAIL 15 A lights, fog lights, trailer tail lights EPS-IG1 7.5 A Electric power steering ECU-IG1 NO.3 7.5 A Blind Spot Monitor H-LP LVL 7.5 A...
Page 305 MAINTENANCE AND CARE Do-it-yourself maintenance Fuse Amperage Circuit Back-up lights, Fuel injection system, electronic controlled transmission, audio system, BKUP LP 7.5 A navigation system, Toyota parking assist-sensor, trailer backup lights DOOR NO.1 30 A Power windows P/OUTLET RR 20 A Power outlet SFT LOCKACC Shift lock control system DOOR R/R 20 A Rear right-hand power windows DOOR R/L 20 A Rear left-hand power windows 10 A On-board diagnosis system ECU-B NO.2 10 A Rear sunshade 20 A*1 Power windows DOOR NO.2 25 A*2 Outside rear view mirrors, power windows Fuel injection system, starter system, electronic 7.5 A controlled transmission Tail lights, Fuel injection system, vehicle...
Page 306: Light Bulbs
Light bulb locations You may replace the light bulbs shown in the following illustrations. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. Vehicles with standard type ignition switch– When replacing a bulb, make sure the ignition switch and light switch are off. Vehicles with smart entry and start system– When replacing a bulb, make sure the ENGINE START STOP switch and light switch are off. CAUTION Discharge headlights • Contact your Toyota dealer before replacing discharge headlights and/or bulbs. • Do not touch the discharge headlight’s high voltage socket when the headlights are turned on. • An extremely high voltage of 30000 V will be discharged and could result in serious injury or death by electric shock. • Do not attempt to take apart or repair the low beam discharge headlight bulbs, connectors, power supply circuits, or related components. Doing so could result in electric shock and serious injury or death. • While the low beam headlights are turned on, and for a short time after they have been turned off,...
Page 307 MAINTENANCE AND CARE Do-it-yourself maintenance NOTICE • Only use a bulb of the listed type and wattage. Discharge headlights • If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or may go out temporarily. The discharge bulbs will come on when normal power is restored. The inside of the lens of exterior lights such as headlights may temporarily fog up when the lens becomes wet in the rain or in a car wash. This is not a problem because the fogging is caused by the temperature difference between the outside and inside of the lens, just like the windscreen fogs up in the rain. However, if there is a large amount of water on the inside of the lens, or if there is water pooled inside the light, contact your Toyota dealer. Front exterior lights– Headlight low beam (halogen bulb) Headlight high beam Front parking light Front turn signal light Fog light (if equipped) Bulb Wattage Bulb type Headlight low beam (halogen)
Page 308 Stop/tail light Tail light Bulb Wattage Bulb type Stop/tail light 21/5 Wedge base (clear) Rear turn signal light Wedge base (amber) Back-up light Wedge base (clear) License plate light Wedge base (clear) Other lights– If any of the following light bulbs do not operate, take your vehicle to your Toyota dealer to have the light replaced: • Headlight low beams (discharge) • Side turn signal lights • High mounted stop light The high mounted stop light consists of a number of light emitting diodes (LEDs) • Interior lights Bulb Wattage Bulb type Side turn signal light Wedge base (amber) Front interior / personal light Wedge base (clear) Interior light (*1) Double end Rear Interior / personal light (*2)
Page 309 MAINTENANCE AND CARE Do-it-yourself maintenance Headlight low beam (halogen only)* 1. Turn the steering in the opposite direction to the low beam (halogen) light bulb that you wish to replace. E.g. Turn the steering wheel left to replace the right-hand low beam (halogen) light bulb. * For discharge type bulb replacement see your Toyota dealer. 2. Remove the fender liner screws. 3. Remove the fender liner clip. Step 1: After turning the clip, pull it out slightly until it stops. Step 2: Turn the clip again and then remove it. 4. Partly remove the fender liner and turn the bulb base counterclockwise.
Page 310 MAINTENANCE AND CARE Do-it-yourself maintenance 5. Unplug the connector while depressing the lock release. 6. Reinstall the new light bulb in the reverse of removal. CAUTION Hold the halogen bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands. • Insert the fender liner clip with the slot aligned vertically. Do not rotate the clip after installation. Headlight high beam 1. Open the bonnet. 2. Turn the bulb base counterclockwise and remove the bulb base from the headlight. 3. Unplug the connector while depressing the lock release. 4. Reinstall the new light bulb in the reverse of removal. CAUTION Hold the halogen bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands.
Page 311 MAINTENANCE AND CARE Do-it-yourself maintenance Parking light 1. Open the bonnet. 2. Turn the bulb base counterclockwise and remove the bulb base from the headlight. 3. Remove the light bulb from the bulb base. 4. Reinstall the new light bulb in the reverse of removal. Front turn signal light 1. Turn the steering in the opposite direction to the front turn signal light bulb that you wish to replace. E.g. Turn the steering wheel left to replace the right-hand front turn signal light bulb. * For discharge type bulb replacement see your Toyota dealer. 2. Remove the fender liner screws.
Page 312 MAINTENANCE AND CARE Do-it-yourself maintenance 3. Remove the fender liner clip. Step 1: After turning the clip, pull it out slightly until it stops. Step 2: Turn the clip again and then remove it. 4. Partly remove the fender liner and turn the bulb base counterclockwise. 5. Remove the light bulb. 6. Reinstall the new light bulb in the reverse of removal. Fog light 1. Turn the steering in the opposite direction to the fog light bulb that you wish to replace. E.g. Turn the steering wheel left to replace the right-hand fog light bulb.
Page 313 MAINTENANCE AND CARE Do-it-yourself maintenance 2. Remove the fender liner screws. 3. Remove the fender liner clip. Step 1: After turning the clip, pull it out slightly until it stops. Step 2: Turn the clip again and then remove it. 4. Partly remove the fender liner and turn the bulb base counterclockwise.
Page 314 MAINTENANCE AND CARE Do-it-yourself maintenance 5. Unplug the connector while depressing the lock release. 6. Reinstall the new light bulb in the reverse of removal noting the following. CAUTION Hold the halogen bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands. • Insert the fender liner clip with the slot aligned vertically. Do not rotate the clip after installation. Rear turn signal and stop / tail light NOTICE It is recommended your Toyota dealer replace the rear turn signal and stop / tail light bulbs as components can be damaged if care is not taken. 1. Open the boot lid. 2. Remove the luggage floor cover, spare wheel cushion and jack / tool cushions. Refer to “Location of the spare tyre, jack and tools” on page 307. 3. Remove the luggage finish panel clips. CTY43PAC005...
Page 315 MAINTENANCE AND CARE Do-it-yourself maintenance • HINT: Removal – To remove the trim clip, insert a small screwdriver and prise the centre retainer out slightly. Then remove the clip. Installation – To install the trim clip, insert the clip and push retainer in place. 4. Remove the luggage finish panel by carefully pulling upward to disengage the four clips. CTY43PAC006 5. Remove the luggage trim clips. CTY43AV519a 6. Pull the grocery hook while depressing the button.
Page 316 MAINTENANCE AND CARE Do-it-yourself maintenance 7. Carefully pull back the luggage trim cover to gain access to the light bulbs. 8. Turn the turn signal or stop / tail light Turn signal bulb base counterclockwise and light remove the bulb base from the combination light. Stop/tail light 9. Remove the light bulb from the bulb base. 10. Reinstall the new light bulb in the reverse of removal. Turn signal Stop/tail light light Tail light and back-up light 1. Open the boot lid. 2. Remove the boot lid trim cover clips and carefully pull the trim back to gain access to the light bulbs.
Page 317 MAINTENANCE AND CARE Do-it-yourself maintenance • HINT: Removal – To remove the trim clip, insert a small screwdriver and prise the centre retainer out slightly. Then remove the clip. Installation – To install the trim clip, insert the clip and push retainer in place. 3. Turn the tail light or back-up bulb base counterclockwise and remove the bulb base from the combination light. Tail light Back-up light 4. Remove the light bulb from the bulb Back-up light base. Tail light 5. Reinstall the new light bulb in the reverse of removal. Licence plate light 1. Insert a small flat-blade screw driver into the hole and prise off the licence plate light lens. HINT: T o prevent damage to the lens, wrap tape around the screw driver blade.
Page 318: Replacing The Remote Control Transmitter Battery
3. Reinstall the new light bulb in the reverse of removal. REPLACING THE REMOTE CONTROL TRANSMITTER BATTERY If the key battery is discharged the following symptoms may occur: • The wireless remote control and, if fitted, the smart entry and start system will not function properly • The operational range will be reduced CAUTION • Keep away from children. Swallowing the battery or any of its components may cause injury or death. • Special care should be taken to prevent anyone from swallowing the removed transmitter battery or components. NOTICE • When replacing the remote control transmitter battery, be careful not to lose the components. • Replace the battery only with the same or equivalent type recommended by a Toyota dealer. • Dispose of used batteries according to the local laws. Standard type ignition switch For replacement, you must use a CR2016 lithium battery or equivalent. 1. Cover the tip of the screwdriver with a rag or tape, etc. 2. Prise the key cover with the screwdriver and remove the cover. HINT: To prevent the buttons from being dislodged, face the button surface downward.
Page 319 MAINTENANCE AND CARE Do-it-yourself maintenance 3. Remove the module from the key. 4. Open the module cover using a coin protected with tape, etc. and remove the discharged battery. 5. Insert a new battery with the positive [+] terminal facing up. 6. Reassemble the key in the reverse order of removal. NOTICE • Take care not to damage the circuit board. • Do not bend the terminals. • Make sure the positive side [+] of the transmitter battery is facing up. • Do not replace the battery with wet hands. Water may cause corrosion. • Close the transmitter case securely. After replacing the battery, check the remote control functions operate correctly. If they do not operate correctly, contact your Toyota dealer. Smart entry and start system For replacement, you must use a CR2032 lithium battery or equivalent. 1. Remove the mechanical key.
Page 320 MAINTENANCE AND CARE Do-it-yourself maintenance 2. Cover the tip of the screwdriver with a rag or tape, etc. 3. Prise the key cover with the screwdriver and remove the cover. 4. Remove the discharged battery using a small flat-blade screw driver. 5. Insert a new battery with the positive [+] terminal facing up. 6. Reassemble the key in the reverse order of removal. NOTICE • Take care not to damage the circuit board. • Do not bend the terminals. • Make sure the positive side [+] of the transmitter battery is facing up. • Do not replace the battery with wet hands. Water may cause corrosion. • Close the transmitter case securely. After replacing the battery, check the remote control and smart entry and start functions operate correctly. If they do not operate correctly, contact your Toyota dealer.
Page 321: When Trouble Arises
WHEN TROUBLE ARISES Essential information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 EMERGENCY FLASHERS .
Page 322: Essential Information
Always pull off the road as far as possible. • To turn on the emergency flashers, press the switch. All the turn signal lights will flash. • To turn them off, press the switch once again. CTY51AV012 The turn signal light switch will not work while the emergency flashers are operating. NOTICE To prevent the battery from being discharged, do not leave the flashers on for a long period when the engine is not running. IF YOUR VEHICLE NEEDS TO BE TOWED If towing is required, we recommend you to have it done by your Toyota dealer or a commercial tow truck service using a wheel-lift type truck or flatbed truck. NOTICE • Use a safety chain system for all towing and abide by the State and local laws. • To prevent serious damage to the transmission, never tow a vehicle from the rear with four wheels or the front wheels on the ground. Before towing The following may indicate a problem with your transmission. Contact your Toyota dealer before towing. • The engine is running, but the vehicle will not move. • The vehicle makes an abnormal sound. Towing with a sling-type truck NOTICE To prevent body damage, do not tow with a sling-type truck, either from the front...
Page 323 WHEN TROUBLE ARISES Essential information Towing with a wheel-lift type truck NOTICE • To prevent serious damage to the transmission, never tow the vehicle from the rear with the front wheels on the ground. • To prevent damage to the vehicle, when raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed. From the front– • Release the parking brake. From the rear– • Use a towing dolly under the front wheels. Using a flatbed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged.
Page 324 WHEN TROUBLE ARISES Essential information Emergency towing If a towing service is not available in an emergency, your vehicle may be temporarily towed by a cable, towing strap or chain secured to the emergency towing eyelet. A driver must be in the vehicle to steer it and operate the brakes. NOTICE Use extreme caution when towing vehicles. • Only use the specified towing eyelet; otherwise your vehicle may be damaged. • Never tow the vehicle from the rear with the front wheels on the ground. This may cause serious damage to the transmission. • Emergency towing may be done only on hard-surfaced roads for a short distance and at low speeds. Also, the wheels, axles, drivetrain, steering and brakes must all be in good working condition. NOTICE • Use only a cable, strap or chain specifically intended for use in towing vehicles. • Securely fasten the cable or chain to the towing eyelet provided. • Do not allow the cable, strap or chain to contact the vehicle body when towing. Doing so may damage the vehicle. Before towing– • Release the parking brake and put the transmission in N position. • Vehicles with standard type ignition switch– The ignition switch must be in ACC or ON position.
Page 325 WHEN TROUBLE ARISES Essential information Installing the front towing eyelet CAUTION When installing the eyelet on the vehicle, tighten the front eyelet securely. If the eyelet is loose, it may come off when being towed and result in death or serious injury. 1. Remove the front towing eyelet from the underside of the spare tyre cover in the boot of the vehicle. Refer to “Location of the spare tyre, jack and tools” on page 307. 2. Remove the front towing eyelet cover on the front bumper using a flat- bladed screwdriver, wrapped with a cloth. 3. Insert the front towing eyelet into the hole on the bumper by turning clockwise. 4. Tighten the front towing eyelet securely using a wheel nut wrench.
Page 326: If You Think Something Is Wrong
WHEN TROUBLE ARISES Essential information IF YOU THINK SOMETHING IS WRONG If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms • Fluid leaks under the vehicle (water dripping from the air conditioning after use is normal). • Flat-looking tyres or uneven tyre wear. • The right-most segment of the engine coolant temperature display flashes. Audible symptoms • Changes in exhaust sound. • Excessive tyre squeal when cornering. • Strange noises related to the suspension system. • Pinging or other noises related to the engine. Operational symptoms • Engine missing, stumbling or running roughly. • Appreciable loss of power. • Vehicle pulls heavily to one side when braking. • Vehicle pulls heavily to one side when driving on a level road. • Loss of brake effectiveness, spongy feeling, pedal almost touches the floor. FUEL PUMP SHUT OFF SYSTEM The fuel pump shut off system stops supplying fuel to the engine to minimise the risk of fuel leakage when the engine stalls or an airbag inflates upon collision.
Page 327: Steps To Take In An Emergency
WHEN TROUBLE ARISES Steps to take in an emergency Steps to take in an emergency IF A WARNING LIGHT ILLUMINATES, A BUZZER SOUNDS OR A WARNING MESSAGE IS DISPLAYED If a warning light illuminates or flashes, or if a buzzer sounds or a warning message is displayed on the multi-information display, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Check the details of the warning light, buzzer or warning message; it may be simply that a door is not shut correctly, or the parking brake is not fully released, etc. For details refer to “Indicators and warning lights” on page 88 and “Warning messages” on page 93. If the reason for the warning light illumination, buzzer sounding or warning message cannot be easily rectified, contact your Toyota dealer. CAUTION In some instances it may be dangerous to continue driving the vehicle. SRS warning light The SRS warning light monitors the entire SRS system including all of the airbag assemblies and seatbelt pretensioner assemblies, etc. For details refer to “Indicators and warning lights” on page 88. CAUTION If any of the following conditions occurs, this indicates a malfunction of the airbags or seatbelt pretensioners. Contact your Toyota dealer as soon as possible. • Vehicles with standard type ignition switch–...
Page 328: If You Have A Flat Tyre
WHEN TROUBLE ARISES Steps to take in an emergency Electric power steering system warning light (warning buzzer) When the battery charge becomes insufficient or the voltage temporarily drops, the electric power steering system warning light may come on and the warning buzzer may sound. CAUTION • When the electric power steering system warning light illuminates the steering wheel may become extremely heavy. • If the steering wheel becomes heavier than usual when operating, hold firmly and operate using more force than usual. • Drive slowly and carefully and contact your Toyota dealer as soon as possible. IF YOU HAVE A FLAT TYRE CAUTION Do not get under a vehicle that is supported by a jack – use vehicle support stands. 1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place well away from the traffic. Avoid stopping on the centre divider of a highway. Park on a level spot with firm ground. 2. Stop the engine and turn on your emergency flashers. 3. Firmly set the parking brake and put the transmission in P position. 4. Have everyone get out of the vehicle on the side away from traffic. 5. Read the following instructions thoroughly.
Page 329 CAUTION • Raise the vehicle only high enough to remove and change the tyre. • Failure to follow the following precautions could cause the wheel nuts to loosen and the tyre to fall off, resulting in death or serious injury: – Have the wheel nuts tightened with a torque wrench to 103 Nm (10.5 kg/f, 76 ft/ lbf) as soon as possible after changing wheels – Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving – When installing a tyre, only use wheel nuts that have been specifically designed for that wheel – If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer NOTICE • Do not continue driving with a deflated tyre. Driving even a short distance can damage a tyre and wheel beyond repair. • Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven as these areas will be extremely hot. Touching these areas may result in burns. Location of the spare tyre, jack and tools To prepare yourself for an emergency, you should familiarise yourself with the use of the jack, each of the tools and their storage locations. Floor cover Spare tyre...
Page 330 WHEN TROUBLE ARISES Steps to take in an emergency Vehicle jack maintenance– Ensure the jack is maintained correctly and is ready for use. • Inspect the jack before use. • Always keep the jack clean and the moving parts free from dirt, rust, etc. • Make sure the screw thread is adequately lubricated. Jack removal 1. Open the boot lid and lift up the luggage floor cover. – If required, the luggage floor cover can be removed by folding the ends down and sliding it out of the boot. 2. Remove the jack. Spare tyre removal 1. Open the boot lid and lift up the luggage floor cover.
Page 331 WHEN TROUBLE ARISES Steps to take in an emergency 2. Remove the spare tyre cushion. 3. Remove the retainer and spacer securing the spare tyre. Retainer Spacer 4. Carefully remove the spare tyre. – When storing the spare tyre, put it in place with the outer side of the wheel facing up. CTY52AV813a – Secure the tyre in the boot by repeating the removal steps in reverse order to prevent it from flying forward during a collision or sudden braking. Removing a flat tyre 1. Chock the wheel diagonally opposite the flat tyre to keep the vehicle from rolling when it is jacked up.
Page 332 WHEN TROUBLE ARISES Steps to take in an emergency 2. Slightly loosen each wheel nut (up to one turn). 3. Position the jack under the vehicle’s rocker panel at the jacking point closest to the flat tyre. – Turn the jack screw, part A, by hand until the recess in the jack is in contact with the jack point. – Position the jack so it is between the notches in the rocker panel flange. 4. Insert the jack handle and raise the vehicle until the tyre is off the ground. – Remember to raise the vehicle a bit extra to allow for the deflated portion of the tyre.
Page 333 WHEN TROUBLE ARISES Steps to take in an emergency 5. Remove the wheel nuts and the wheel. – If resting the wheel on the ground, take care to avoid damaging the wheel outer surface. Installing the spare tyre 1. Remove any dirt or foreign material from the wheel contact surfaces. – If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the wheel to come off. – If resting the wheel on the ground, take care to avoid damaging the wheel outer surface. 2. Install the wheel and loosely tighten Disc wheel each wheel nut by hand approximately the same amount. – Turn the wheel nuts until the washers come into contact with the disc wheel. Washer CAUTION When installing the wheel nuts...
Page 334 WHEN TROUBLE ARISES Steps to take in an emergency 3. Lower the vehicle. 4. Firmly tighten each wheel nut two or three times in the order shown in the illustration. – As soon after changing wheels as possible, tighten the wheel nuts to the correct torque specification. Tightening torque: 103 Nm (10 .5 kg/f, 76 ft/lbf) After changing wheels • Check the air pressure of the replaced tyre. Adjust the air pressure to the specification designated, refer to “Tyres and wheels” on page 332. If the pressure is lower, drive slowly to the nearest service station and fill to the correct pressure. Do not forget to reinstall the tyre inflation valve cap as dirt and moisture could get into the valve core and possibly cause air leakage. If the cap is missing, have a new one put on as soon as possible. • Restow all the tools, jack and flat tyre securely. • Have a technician repair the flat tyre. CAUTION Before driving, make sure all the tools, jack and flat tyre are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden...
Page 335: If Your Engine Will Not Start
1. Vehicles with standard type ignition switch– Turn the ignition switch to ACC or LOCK position and try starting the engine again. Vehicles with smart entry and start system– Press the ENGINE START STOP switch to ACCESSORY mode or off and try starting the engine again. 2. Check there is sufficient fuel in the fuel tank; refill as required. 3. The engine may be flooded because of repeated cranking. Refer to “Starting a flooded engine” on page 322 for further instructions. 4. If the engine still will not start, it may need adjustment or repair. Call a Toyota dealer or qualified repair shop. If the engine does not turn over or is turning over too slowly. 1. Check the battery terminals are tight and clean. 2. If the battery terminals are OK, switch on the interior light. 3. If the light is out, dim or goes out when the starter is cranked, the battery is discharged. You may try jump starting. Refer to “Jump starting” on page 317 for further instructions. 4. With smart entry and start system–...
Page 336: Emergency Start
WHEN TROUBLE ARISES Steps to take in an emergency EMERGENCY START (SMART ENTRY AND START SYSTEM) When the engine does not start, the following procedure can be used to start the engine if the vehicle’s starting system and ENGINE START STOP switch function normally. 1. Set the parking brake and put the transmission in P position. 2. Press the ENGINE START STOP switch to ACCESSORY mode by pressing it once (while the brake pedal is not depressed). 3. Press and hold the ENGINE START STOP switch for about 15 seconds while depressing the brake pedal firmly. Even if the engine can be started using the above procedure, the system may be malfunctioning. Have the vehicle checked by your Toyota dealer. If the engine cannot be started using the above procedure, contact your Toyota dealer. IF THE SHIFT LEVER CANNOT BE MOVED FROM P POSITION If you cannot move the shift lever from P position to other positions, even though the brake pedal is depressed, use the shift lock override button as follows: 1. Vehicles with standard type ignition switch– Turn the ignition switch to the LOCK position. Make sure the parking brake is on. Vehicles with smart entry and start system–...
Page 337: If The Electronic Key Does Not Operate Properly (Smart Entry And Start System)
• If the doors cannot be locked or unlocked by the smart entry and start system, lock and unlock the doors by the mechanical key or wireless remote control. • When the electronic key does not work properly, check the smart entry and start system has not been deactivated through customisation. For further information refer to “Customisable features” on page 333. • Check if battery-saving mode is set. If it is set, cancel the function. For details refer to “Battery-saving function” on page 12. Locking and unlocking the doors Use the mechanical key to perform the following operations for the driver’s door: 1. Locks all the doors. 2. Unlocks the door. CTY52AV821a Starting the engine 1. Place the shift lever in P position and firmly depress the brake pedal. 2. Touch the Toyota emblem side of the electronic key to the ENGINE START STOP switch. The ENGINE START STOP switch will change to IGNITION ON mode. – If the smart entry and start system has been deactivated through customisation, the ENGINE START STOP switch will change to ACCESSORY mode.
Page 338: If The Battery Is Discharged
WHEN TROUBLE ARISES Steps to take in an emergency The modes can then be changed by pressing the ENGINE START STOP switch with the brake pedal released. (The mode changes each time the switch is pressed.) 3. Firmly depress the brake pedal and check that is displayed on the multi- information display. 4. Press the ENGINE START STOP switch. In the event the ENGINE START STOP switch still cannot be operated, contact your Toyota dealer. Stopping the engine Move the shift lever to P position and press the ENGINE START STOP switch as you normally do when stopping the engine. IF THE BATTERY IS DISCHARGED Starting the engine when the battery is discharged The engine cannot be started by push-starting the vehicle. If the battery is discharged, the engine can only be started by fitting a replacement battery or by jump starting. To prevent battery discharge • Turn off the headlights and the audio system while the engine is off. • Turn off any unnecessary electrical components when the vehicle is running at a low speed for an extended period, such as in heavy traffic.
Page 339: Jump Starting
WHEN TROUBLE ARISES Steps to take in an emergency JUMP STARTING To avoid serious personal injury and damage to your vehicle which might result from battery explosion, acid burns, electrical burns, or damaged electronic components, these instructions must be followed precisely. If you are unsure about how to follow this procedure, we strongly recommend that you seek the help of a competent mechanic or towing service. CAUTION Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flammable gas that may be emitted from the battery. • Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended terminal. • Do not allow the [+] (red) and [–] (black) jumper cable clamps to come into contact with each other. • Do not smoke, use matches, cigarette lighters or allow open flame near the battery. CAUTION Battery precautions The battery contains poisonous and corrosive acidic electrolyte and parts made from lead and lead compounds. Observe the following precautions when handling the battery. • Always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle. • Do not lean over the battery. • In the event that battery fluid comes into contact with the skin or eyes, immediately wash the affected area with water and seek medical attention.
Page 340 4. Connect the other clamp of the black cable to a solid, stationary, unpainted, metallic ground point on your vehicle as shown in the illustration. (b) Start the engine of the second vehicle. Increase the engine speed slightly and maintain at that level for approximately 5 minutes to recharge the battery of your vehicle. (c) Vehicles with smart entry and start system: Open and close any door of your vehicle while the ENGINE START STOP switch is off. (d) Maintain the engine speed of the second vehicle and start the engine– Vehicles with standard type ignition switch: Turn the ignition switch to the ON position, then start the engine. Vehicles with smart entry and start system: Press the ENGINE START STOP switch to IGNITION ON mode, then start the engine. (e) Once the engine has started, increase the engine speed slightly for several minutes and then carefully remove the jumper cables in the exact reverse order from which they were connected. (f) Have the vehicle checked at your Toyota dealer as soon as possible if required.
Page 341: If Your Vehicle Overheats
3. Turn off the air conditioning if it is being used. 4. Check if coolant or steam is coming out from under the bonnet. If you see steam: – Stop the engine. Wait until the steam subsides and then carefully open the bonnet. – If there is no coolant boiling over or steam, restart the engine. If you do not see steam: – Leave the engine running and carefully lift the bonnet. CAUTION To avoid personal injury, keep the bonnet closed until there is no steam. Escaping steam or coolant is a sign of very high pressure. 5. Check if the electric cooling fans are operating. If the fans are operating: – Wait until the high-temperature warning light goes off and then stop the engine If the fans are not operating: – Stop the engine and contact your Toyota dealer immediately 6. After the engine has cooled sufficiently, look for any obvious coolant leaks from the radiator, hoses, and under the vehicle. Note that water draining from the air conditioner is normal, if it has been used. CAUTION When the engine is running, keep hands and clothing away from the moving fan and engine drive belts. – If the coolant is leaking, stop the engine immediately. Call a Toyota dealer for assistance. – If there are no obvious leaks, check the coolant reservoir. If it is dry, add coolant to the reservoir while the engine is running. Fill it about half full. For the coolant type, refer to “Engine coolant” on page 264.
Page 342: If Your Vehicle Becomes Stuck
Steps to take in an emergency CAUTION Do not attempt to remove the radiator cap when the engine and radiator are hot. Serious injury could result from scalding hot fluid and steam blown out under pressure. NOTICE • Wait until the engine has cooled down before adding engine coolant. • Add the coolant slowly. Adding coolant to a hot engine too quickly can damage the engine. • As an emergency measure, water can be used if coolant is unavailable. However, have the problem checked and the coolant replaced by your Toyota dealer as soon as possible. 7. After the engine coolant temperature has cooled to normal, again check the coolant level in the reservoir. If necessary, bring it up to half full again. Serious coolant loss indicates a leak in the system. You should have it checked as soon as possible at your Toyota dealer. IF YOUR VEHICLE BECOMES STUCK Carry out the following procedures if the tyres spin or the vehicle becomes stuck in mud, dirt or snow. 1. Stop the engine. Set the parking brake and move the shift lever to P position. 2. Remove the mud, snow or sand from around the stuck tyre(s). 3. Place wood, stones or some other material under the tyres to help provide traction. 4. Restart the engine. 5. Move the shift lever to the D or R position and carefully apply the accelerator to free the vehicle.
Page 343: If Your Vehicle Has To Be Stopped In An Emergency
WHEN TROUBLE ARISES Steps to take in an emergency NOTICE To avoid damaging the transmission and other components • Avoid spinning the wheels and depressing the accelerator pedal more than necessary. • If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed. IF YOUR VEHICLE HAS TO BE STOPPED IN AN EMERGENCY Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following procedure. 1. Steadily depress the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle. 2. Move the shift lever to N position. If the shift lever can be moved to N position– (a) After slowing down, stop the vehicle in a safe place by the road. (b) Stop the engine. If the shift lever cannot be moved to N position– (a) Keep depressing the brake pedal with both feet to reduce vehicle speed as much as possible. (b) Vehicles with standard type ignition switch–...
Page 344: Starting A Flooded Engine
Never attempt to remove the key, as doing so will lock the steering wheel. STARTING A FLOODED ENGINE If the engine will not start, your engine may be flooded because of repeated cranking. Vehicles with standard type ignition switch– If this happens, turn the ignition switch to START with the accelerator pedal fully depressed. Keep the ignition switch and accelerator pedal in these positions for 15 seconds and release them. Then start the engine with your foot off the accelerator pedal. Vehicles with smart entry and start system– If this happens, press the ENGINE START STOP switch with the brake pedal and the accelerator pedal fully depressed, and hold the ENGINE START STOP switch for about 30 seconds. Then the cranking hold function stops cranking automatically, and you can try starting the engine with your foot off the accelerator pedal. If the engine still will not start, contact your Toyota dealer for assistance. NOTICE Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring systems. IF YOUR ENGINE STALLS WHILE DRIVING If your engine stalls while driving. 1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place. 2. Turn on your emergency flashers. 3. Try starting the engine again. If the engine will not start, refer to “If your engine will not start” on page 313. CAUTION • If the engine is not running, the power assistance for the brakes and steering will not work so steering and braking will be much harder than usual.
Page 345: If You Cannot Increase Engine Speed
WHEN TROUBLE ARISES Steps to take in an emergency IF YOU CANNOT INCREASE ENGINE SPEED If engine speed does not increase when the accelerator pedal is depressed, there may be a problem somewhere in the electronic throttle control system. At this time, vibration may occur. However, if you depress the accelerator pedal more firmly and slowly, you can drive your vehicle at low speeds. Have your vehicle checked by your Toyota dealer as soon as possible. Vehicles with standard type ignition switch– Even if the abnormality of the electronic throttle control system is corrected during low speed driving, the system may not be recovered until the engine is stopped and the ignition switch is turned off. Vehicles with smart entry and start system– Even if the abnormality of the electronic throttle control system is corrected during low speed driving, the system may not be recovered until the engine is stopped and the ENGINE START STOP switch is turned off. CAUTION Be especially careful to prevent erroneous pedal operation.
Page 346 WHEN TROUBLE ARISES...
Page 347: Vehicle Specifications
VEHICLE SPECIFICATIONS Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326 DIMENSIONS .
Page 348: Specifications
VEHICLE SPECIFICATIONS Specifications Specifications DIMENSIONS 4835 mm (190.4 in.) - Vehicles without front spoiler Overall length 4855 mm (191.1 in.) - Vehicles with front spoiler Overall width 1825 mm (71.9 in.) Except Papua New Guinea and Fiji: – 1470 mm (57.9 in.) Overall height (Unladen) Papua New Guinea and Fiji: – 1480 mm (58.3 in.) Wheelbase 2775 mm (109.3 in.) Front tread 1575 mm (62.0 in.) Rear tread 1565 mm (61.6 in.) ENGINE NUMBER The engine number is stamped on the engine block as shown. VEHICLE IDENTIFICATION NUMBER (VIN) The vehicle identification number (VIN) is the legal identifier for your vehicle. This number is stamped under the right front seat. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle.
Page 349: Engine
VEHICLE SPECIFICATIONS Specifications The vehicle identification number (VIN) is also on the manufacturer’s label. The manufacturer’s label adhered on the left front and rear door pillars contains VIN and other model data such as date of manufacture. Date of manufacture The date of manufacture, indicated on the vehicle as the “Built Date”, is the calendar month and year in which the body shell and powertrain sub-assemblies are joined and the vehicle is driven or moved from the production line. Use the VIN, built date and other model data to identify your Toyota for purposes such as registration, parts ordering, insurance, and communication with Toyota. CTY61PAC001 ENGINE Model 2GR-FE Type 6 cylinder V type, 4 cycle, petrol Bore and stroke 94.0 x 83.0 mm (3.70 x 3.27 in.) Displacement 3456 cm3 (210.9 cu in.) Drive belt tension Automatic adjustment Valve clearance (engine cold) Automatic adjustment...
Page 350: Fuel
VEHICLE SPECIFICATIONS Specifications FUEL Selecting the correct fuel is essential for satisfactory engine performance. Engine damage caused by use of incorrect fuels is not covered under Toyota’s new vehicle warranty. Unleaded petrol only Fuel type (Unleaded petrol containing up to 10% ethanol may be safely used) Research Octane Number (RON) 91 or higher Fuel tank capacity 70 L (18.5 gal., 15.4 Imp. gal.) To help prevent petrol station mix-ups, your vehicle has a smaller fuel tank opening. The special nozzle on pumps with unleaded fuel will fit it, but the larger standard nozzle on pumps with leaded petrol will not. NOTICE Do not use leaded petrol. Use of leaded petrol will cause the three-way catalytic converter to lose its effectiveness and the emission control system to function incorrectly. Also, this can increase maintenance costs. If your engine knocks If you detect heavy knocking even when using the recommended fuel, or if you hear steady knocking while holding a steady speed on level roads, consult your Toyota dealer. However, occasionally, you may notice light knocking for a short time while accelerating or driving up hills. This is normal and there is no need for concern.
Page 351: Lubrication
VEHICLE SPECIFICATIONS Specifications LUBRICATION Oil capacity (drain and refill*)  With filter 6.1 L (6.4 qt., 5.4 Imp. qt.)  Without filter 5.7 L (6.0 qt., 5.0 Imp. qt.) Oil grade 5W-30, 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN “Resource- Conserving” or ILSAC multigrade engine oil 15W-40 and 20W-50: API grade SL, SM or SN multigrade engine Recommended oil viscosity “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Temperature range anticipated before next oil change. *: The engine oil capacity is a reference quantity to be used when changing the engine oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level on the dipstick. Please contact your Toyota dealer for further details.
Page 352: Cooling System
VEHICLE SPECIFICATIONS Specifications COOLING SYSTEM Total capacity 9.4 L (9.9 qt., 8.3 Imp. qt.) Coolant type “Toyota Super Long Life Coolant” is used in your Toyota vehicle at factory fill. In order to avoid technical problems, only use “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non- borate coolant with long-life hybrid organic acid technology. Coolant with long-life hybrid organic acid technology is a combination of low phosphates and organic acids. Do not use plain water alone. Contact your Toyota dealer for further details. IGNITION Spark plug DENSO FK20HR11 Spark plug gap 1.1 mm (0.043 in.) NOTICE Use only iridium tipped spark plugs. Do not adjust the spark plug gap. ELECTRICAL SYSTEM Battery Specific gravity reading at 20°C (68°F): 1.250–1.270 Fully charged 1.160–1.180 Half charged 1.060–1.080 Discharged Charging rates Quick charge: 15 A max. Slow charge: 5 A max. NOTE: If the battery requires replacement, ensure the new battery meets the same standard as the original.
Page 353: Automatic Transaxle
VEHICLE SPECIFICATIONS Specifications AUTOMATIC TRANSAXLE Fluid capacity* 6.5 L (6.9 qt., 5.7 Imp. qt.) Fluid type Toyota Genuine ATF WS *: The fluid capacity is a reference quantity only. Generally, it is necessary to change automatic transmission fluid only if your vehicle is driven under one of the Additional Service Requirements listed in your “Warranty and Service Book”. When changing the automatic transmission fluid, use only “Toyota Genuine ATF WS” (ATF JWS3324 or NWS9638) to aid in assuring optimum transaxle performance. NOTICE Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmission of your vehicle. Please contact your Toyota dealer for further details. BRAKES Minimum pedal clearance –when depressed with the force of 500 N 98 mm (3.86 in.) (51 kgf, 112 lbf) with the engine running. Pedal free play 1–6 mm (0.04–0.24 in.) Parking brake pedal travel –when depressed with the force of 300 N 9–12 clicks (31 kgf, 67 lbf) Fluid type SAE J1703 or FMVSS No.116 DOT 3 STEERING Steering wheel free play Less than 30 mm (1.2 in)
Page 354: Tyres And Wheels
VEHICLE SPECIFICATIONS Specifications TYRES AND WHEELS 16-inch wheels Tyre size 215/60R16 95V Tyre inflation pressure 240 kPa (2.4 kgf/cm or bar, 35 psi) (cold tyre) Wheel size 16 x 6 1/2 J Wheel nut torque 103 Nm (10.5 kgf m, 76 lb ft∙) 17-inch wheels Tyre size 215/55R17 94V tyres Tyre inflation pressure 240 kPa (2.4 kgf/cm or bar, 35 psi) – cold tyre Wheel size 17 x 7 J Wheel nut torque 103 Nm (10.5 kgf m, 76 lb ft∙) NOTE: For complete information on tyres (e.g. replacing tyres or replacing wheels), refer to “Tyres” on page 267 through to “Wheels” on page 271.
Page 355: Customisation
VEHICLE SPECIFICATIONS Customisation Customisation CUSTOMISABLE FEATURES Introduction Your vehicle includes a variety of electronic features that can be personalised. Programming some of these settings requires specialised equipment and must be  performed by your Toyota dealer, while others you can do yourself. This is shown by a or  in the applicable column for each system. These settings can be changed using the touch-screen audio system. Touch-screen For details refer to “Vehicle settings” on page 167. These settings can be changed using the navigation system. For further Navigation details, refer to the Navigation System Owner’s Manual. These settings can be changed by your Toyota dealer using specialised Dealer equipment. On vehicles with smart entry and start system, this setting can be changed with the wireless remote control on the electronic key. For details, refer to “Customising door lock and unlock functions” on page 338. NOTE: Some settings may affect another system, this is shown where two systems are described together. Contact your Toyota dealer for further assistance. Wireless remote control and Smart entry and start system* Function Default Setting Customised setting...
Page 356 VEHICLE SPECIFICATIONS Customisation Wireless remote control* Function Default Setting Customised setting    Wireless remote control Driver’s door unlocked in one Unlock operation All doors unlocked    step, all doors (Remote 2-press unlock) in one step unlocked in two steps Press and hold Press and hold the (long)    Boot lid opening boot lid open switch (short) Press twice One short press Smart entry and start system* Function Default Setting Customised setting...
Page 357 VEHICLE SPECIFICATIONS Customisation Door lock* Function Default Setting Customised setting Speed-detecting automatic door lock function    (Speed sensitive auto locking) Opening the driver’s door    unlocks all the doors Moving the shift lever to P    position unlocks all doors (Auto unlock by shift to P) Moving the shift lever out of P    position locks all doors Auto lock by shift from P) Driver’s door unlocked in one All doors unlocked    Unlocking using a key step, all doors in one step unlocked in two...
Page 358 VEHICLE SPECIFICATIONS Customisation Interior illumination* Function Default Setting Customised setting Time before interior lights    15 seconds 7.5 seconds turn off 30 seconds Operation when the doors    are unlocked Vehicles with standard type ignition switch:    Operation after the ignition switch turned to the LOCK position Vehicles with smart entry and start system: ...
Page 359 VEHICLE SPECIFICATIONS Customisation Toyota parking assist sensor Function Default Setting Customised setting    Buzzer volume Level 3 Levels 1 to 5 Power windows and moon roof* Function Default Setting Customised setting    Key linked opening    Key linked closing Wireless remote control    linked opening Wireless remote control ...
Page 360: Functions
VEHICLE SPECIFICATIONS Customisation CUSTOMISING DOOR LOCK AND UNLOCK FUNCTIONS Vehicles with smart entry and start system It is possible to set which doors the smart entry function unlocks when using the wireless remote control on the electronic key. 1. Press the ENGINE START STOP switch off. 2. When the indicator on the key is off, press and hold either or or for about 5 seconds while also pressing and holding . 3. A confirmation beep will sound. • The setting will change (from default to customised to default, etc.) each time the above operation is performed. Setting Unlocking doors Beep • Holding the driver’s door handle unlocks only the driver’s door Exterior: Three double beeps Customised Interior: Beeps once • Holding the front passenger’s door handle unlocks all doors Holding either front door handle unlocks Exterior: Two double beeps Default...
Page 361: Alphabetical Index
ALPHABETICAL INDEX...
Page 362 ALPHABETICAL INDEX ALPHABETICAL INDEX Using the Bluetooth phone ....209 Using the CD player ......174 Using the radio ........172 Abbreviations ..........xvii Vehicle information ......167 ABS warning light ........ 90 Auto anti-glare inside rear view mirror .. 37 Adjustments: Automatic air conditioning system .. 155 Front seats ..........25 Automatic high beam ...... 110 Mirrors ............. 37 Seatbelts ..........
Page 363 ALPHABETICAL INDEX ALPHABETICAL INDEX Defogger, rear window ...... 162 CD player .......... 174 Dimensions .......... 326 Charging system warning light .... 89 Dimmer switch - headlights .... 108 Checking and replacing fuses .... 276 Does your vehicle need repairing? .. 254 Checking the brake fluid level .... 266 Do-it-yourself maintenance: Checking the engine coolant level .. 264 Service precautions ......255 Checking the engine oil level .... 260 Door lock - smart entry and start Checking the radiator and condenser . . 265 system .
Page 364 ALPHABETICAL INDEX ALPHABETICAL INDEX Emergency flasher switch ...... 300 Emergency, in case of: Facts about engine oil consumption .. 263 Battery is discharged ......316 Electronic key does not operate Flat tyre: properly (vehicles with smart entry After changing wheels ......312 and start system) ........315 If you have a flat tyre ......306 Emergency flasher switch ....
Page 365 ALPHABETICAL INDEX ALPHABETICAL INDEX Hand brake – See Parking brake: Jack: Positioning a floor jack ......258 Hands-free system Positioning the vehicle jack ....310 (for mobile phones) ......... 204 Vehicle jack ........... 307 Hazard switch .......... 300 Jump starting ........... 317 Headlights .......... 108 Automatic high beam ......110 Bulbs ............
