T3 user manual Please read the manual carefully before using this product .The powerful T3 using LCD projection technology, the latest generation (bridgelux)LED light with low power consumption, fast response,vivid color reduction processingmakes the color bright and clear, long life (fifty thousand hours long life), high contrast (up to 1000: 1), resolution 800 * 480 .Fully enclosed dust and copper pipe cooling design, Make...
dozens of layers of reflective material professional optical reflector, multi-slice mufti-specialty group of the projector lens, etc.,to make the short-focus wide-screen precision optical systems. 1. Product Specifications: Projection Type Home Theater Projector Display technology type LCD technology The type of light source LED light source technology Nominal Brightness...
2.product appearance Power key: Press to open or close the projector, and as same as the power button on the remote control. Volume plus,minus key: press these two buttons can increase or decrease the volume, but also for the left and right of eachmenu under the Project menu and move the selection parameter adjustment.
Page 5
(1) Audio output headphone port seat, connect an external audio signal amplifying device or headphones.(2) AV (video) input port. (3) TF Card port, insert the TF card ,TF card can play audio, video and picture files. (4) HDMI port HD video signal, the computer connection, HDMI output signal terminal of the DVD.
Page 6
Two.Installation Projector 1.Installation method Place the projector on a solid, stable surface or hanger, surrounding ventilation, do not block the vents or shelter, and no shelter vents objects within 10CM. So that theprojector and screen to maintain an appropriate distance from the projector and screen determines the size of the projected image.
Page 7
Recommended use of Ceilingwith stentwhen Installed correctly, the image ispositive square. 2. The distance between the projector and screen Screen size Lens center Warning: Please do not stare or look directly at the light cause it is of high brightness. Especially children who are vulnerable to injury..
Page 8
Trapezoidal gear Picture3 Please refer to the following illustration Projector Ceiling Note: Do not place the projector near a heat source air conditioners and heaters, otherwise the machine may overheat and shut down automatically.When installing the projector, please choose those adequate strength and hanger screws, so as to avoid quality time or screw screwed into enough depth and occurs in the projector falling accident.
Page 9
computer equipment, connect the power cord or power adapter, turn on the projector, press the "Source" button on the projector panel or remote control, select the "PC (VGA)", press "OK" key to enter the computer model, and then the computer's resolution setting and the physical resolution of the projector consistent with the refresh rate of 60Hz.
Page 10
Refer to the follwering table parameters to adjust the output signal from a computer Field VESA Type Resolution Horizontal frequency standard Frequenc (Hz) y(KHz) 31.5 √ 640×480 34.7 37.9 √ 37.5 √ 31.4 35.1 √ SVGA 800×600 37.9 √ 46.6 48.1 √...
Page 11
panel or remote control, select "(HDMI)" press "OK" button to enter the HDMI mode. HDMI connection line Video player 6.Connect the U disk Plug U disk into the "USB" port, or insert the TF card into the TF card slot, press the "Source"...
saturation, audio volume and image clarity and sharpness.Press the "Power" button on the front panel or the remote control again to close the light path and display systems, cooling fan automatically stops, the projector into standby mode again.After shutdown, must wait until the projector fan delay automatic stop, the total power can be cut off, so as to avoid the machine stored in excess heat and affect the normal life of the projector.
(3)Input Source Select Press "SOURCE" button to enter the source selection interface Press "▲""▼" button to select your desired input signal from PC, AV HDMI, SD, USB Press “ ”“ ” button to confirm the type of input signal。 PC:PC signal inputHDMI:HD signal input AV:Video signal inputUSB:Multimedia signal input SD:Multimedia signal input...
3.menu setting picture menu Menu picture Picture display Picture Mode standard mode adjustment. Image mode standard Picture display Color temperature standard Color Zoom mode 16:9 color temperature Temperature Image Noise reduction middle adjustment. Computer settings Image 4: 3, 16: 9, HDMI mode DVD Aspect Ratio Zoom adjustments.
Menu setup Menu setup Adjust the display of Language menu language menu language Restore factory settings Restore Restore factory Menu transparency low Factory settings. Menu display time close Setting Default Image rollovers Zoom 0 Blending Blending setting Osd Duration OsdDuration setting Image flip image flip mode adjustment...
Page 16
Six.Safety Instructions WARNING: To avoid the risk of fire or electric shock. Do not place the projector to rain or moisture gas. Warning: This is a Class A product in a domestic environment, this product may cause radio interference. In this case, the user may be required to take adequate measures.
Page 17
Projector side and the rear plate was slit projector vents ,protect the normal use of the projector, to prevent overheating. Prior to use should check the ventilation parts, to ensure its smooth, in the vicinity of the projector, do not place flammable objects.Do not insert anything into the slit of the projector, or it may produce a short circuit or an electric shock to your device and cause damage.
Page 19
Deutsche Anleitung für T3 Power-Taste: Drücken Sie, um den Projektor zu einschalten oder ausschalten , und genauso wie die Power-Taste auf der Fernbedienung schließen. Volume Plus, Minus-Taste: Drücken Sie diese beiden Tasten, um die Lautstärke zu erhöhen oder zu verringern, sondern auch für die links und rechts von jedem Menü...
Page 20
(1) Audio-Ausgang Kop öreranschluss Sitz, schließen Sie ein externes Audiosignal Verstärkungseinrichtung oder Kop örer. (2) AV (Video) Eingangsport. (3) TF-Kartenhafen , legen Sie die TF-Karte ein, dann kann Audio, V ideo- und Bilddateien von TF-Karte wiedergeben. (4) HDMI-Anschluss HD-Videosignal , der Computer-Anschluss, HDMI-Ausgangssignalanschluss der DVD.
Page 21
Installationsprojektor Installationsmethode Stellen Sie den Projektor auf eine feste, stabile Ober äche oder Au änger, umgebende Belü ung, nicht blockieren Sie die Lü ungsschlitze oder Obdach und keine Zu ucht Entlü ungen Objekte innerhalb 10CM. Damit der Projektor und der Bildschirm einen entsprechenden Abstand zwischen Projektor und Leinwand bestimmt die Größe des projizierten Bildes zu erhalten.
Page 22
Stellen Sie den Projektor-Bildschirm ist auf der Symmetrieachse über die Installation, um das Bild nach links und rechts Trapezverzerrung zu vermeiden. Während der Installation Leben nicht Betrieb, um die Gefahr eines elektrischen Schlags zu vermeiden, oder die Maschine zu brennen. Nur verpackt Projektoren kann das erste Boot-Image angezeigt wurde später eine Trapez auf der unteren Verzerrung und Unschärfe, nden Sie in der "Keystone-Korrektur und Bildschärfeeinstellung "...
Page 23
Keystone Korrektur Taste Bitte beachten Sie die folgende Abbildung Projektor Decken Hinweis: Stellen Sie den Projektor nicht in der Nähe einer Wärmequelle Klimaanlagen und Heizungen, da sonst das System überhitzen und schaltet sich automatisch aus. Bei der Installation des Projektors bitte diese eine ausreichende Festigkeit und Au änger Schrauben wählen, um Qualitätszeit zu vermeiden oder Schraube in ausreichende Tiefe eingeschraubt und tritt in den Projektor fallen Unfall.
Page 24
1, Netzbuchse : Bei Verwendung bitte das Netzteil der Maschinenzubehör in den DC-Ausgangsklemme einlegen, und das andere Ende des Netzteils in die Steckdose eingesteckt. 2, VGA-Eingangsbuchse : mit dieser Port kann mit einem Computer oder einem anderen Ausgangsbuchse mit VGA-Videosignal angeschlossen werden. Wenn der Projektor mit dem Computer verbunden ist, können Sie ein VGA-Kabel- Verbindung verwenden.
Page 25
Toshiba(Fn+F5) IBM(Fn+F7) HP(Fn+F4) Founder(Fn+F3) samsung(Fn+F3) Panasonic (Fn+F3) NEC(Fn+F4) apple(Fn+F8) sharp(Fn+F5) Hitachi(Fn+F7) Dell(Fn+F8) Acer(Fn+F5) Lenovo(Fn+F3) BenQ(Fn+F7) ASUS(Fn+F9) Win7 / Win8 System: Bitte benutzen Sie das Original-VGA Kabel, um den Projektor und Notebook anschließen, dann wird der Projektor eingeschaltet ist, drücken Sie die Maschine Taste "Source"...
Audio-Signalleitung 5. HDMI-Signaleingang : Diese Schnittstelle kann mit dem Ausgangsende eines HDMI HD-Ausgang-Player angeschlossen werden. Wenn der Projektor an HD-Player, HD-Set-Top-Boxen, Videospiele , HD (HDMI) Signalverbindung verwendet werden kann, zu verbinden. Nach Projektoren und High-De nition-Geräte mit High-De nition-Kabel (HDMI-Kabel) anschließen möchten, schließen Sie das Netzkabel oder das Netzteil , schalten Sie den Projektor, drücken Sie die Taste "Source"...
Page 27
Nach einigen Sekunden wird das System vollständig aktiviert werden, wird das Projektionsbild erscheint. Drücken Sie die "SOURCE" -Taste auf der Fernbedienung, um die Signalkanal zu wählen zugegri en werden soll. Neu installierte Projektoren, kann erstmals Bild unscharf oder eine Trapez Zustand erscheinen. Wenn das Bild unscharf erscheint, können Sie das Gerät vor der Linse einzustellen, wenn die P artikel Bild klarste (vorbehaltlich der Zwischenbereich ), so ist das beste Objektiv Fokusposition .
Page 28
Schalten Sie das Gerät aus: Drücken Sie nochmal die die Power-Taste auf der Beamer oder der Fernbedienung. Menü-Grundoperationen 1 Drücken Sie die Menü-Taste auf der Fernbedienung oder "MENU" auf dem Projektor um das Menü- Bildschirm anzuzeigen. 2 Drücken Sie die -Taste auf der Fernbedienung oder am Projektor Ihren Bedarf zu wählen einzustellen oder einen Menüpunkt gesetzt, dann wird das Menü...
Sprachauswahl Siehe "Menü Grundbedienung " Abschnitt rechts des Menübildschirms zu wechseln, und wählen Sie eine Menüsprache . Drücken Sie die Taste "OK", um Sprachoptionen Bildschirm eingeben. Drücken Sie "▲""▼" oder , wählen Sie die gewünschte Sprache, und drücken Sie dann die Taste "MENU" um die Einstellungen zu übernehmen und beenden Bilddrehung Siehe "Menü...
Page 31
Projecteur Mini LED Mode d'emploi T3 L'apparence du produit Bouton Power: Appuyez sur pour ouvrir ou fermer le projecteur, et que même que le bouton d'alimentation de la télécommande. Bouton volume plus/moins: appuyez sur ces deux boutons peuvent augmenter ou diminuer le volume, mais aussi pour la gauche et à...
Page 32
1. Port audio du siège de sortie casque pour connecter un périphérique externe d'ampli cation de signal audio ou un casque. 2. AV (vidéo) port d'entrée. 3. Port carte TF, insérez la carte TF carte de TF peut lire des chiers audio, vidéo et image.
Page 33
Projecteur d'installation Méthode d'installation Placez le projecteur sur une surface ou suspension solide et stable, ventilation environnante, ne pas obstruer les ori ces de ventilation ou un abri, et aucun objet évents de logement au sein de 10CM. De sorte que le projecteur et l'écran a n de maintenir une distance appropriée entre le projecteur et l'écran détermine la taille de l'image projetée.
Page 34
Utilisation recommandée de stents plafond La distance entre le projecteur et l'écran Screen size Lens center Focus adjustment Rotation à droite de la lentille, la lentille tout dans la machine, puis tourner lentement la lentille dans le sens antihoraire, et soigneusement observer les pixels sur l'écran, les particules dans l'image la plus claire quand Hou (sous réserve du centre de la zone d'image), Il est également la meilleure position de la lentille de mise au point.
Page 35
Engrenage keystone Fig.3 S'il vous plaît se référer à l'illustration du projecteur au plafond suivant Note: Ne pas placer le projecteur près d'une source de chaleur des climatiseurs et des appareils de chau age, sinon la machine peut surchau er et arrêter automatiquement Lors de l'installation du projecteur, s'il vous plaît choisir les vis adéquates de résistance et de suspension, a n d'éviter le temps de qualité...
Page 36
Connection des câbles de signal Prise d'entrée d'alimentation: lors de l'utilisation, s'il vous plaît insérez l'adaptateur d'alimentation des accessoires de la machine dans la borne de sortie DC, et l'autre extrémité de l'adaptateur d'alimentation est inséré dans la prise de courant. Prise d'entrée du VGA: ce port peut être relié...
Page 37
similaire à l'icône de la télévision. Appuyez une fois sur l'écran de l'ordinateur, tandis que le secondaire est pressé double a chage, appuyez trois fois le moniteur externe (ordinateur non représenté). Étant donné que chaque marque de touche de fonction de l'ordinateur pour basculer entre les di érentes positions situées, vous contrôlez les éléments suivants selon les instructions de votre ordinateur portable pour basculer Toshiba(Fn+F5) IBM(Fn+F7) HP(Fn+F4) Founder(Fn+F3)
Page 38
Prise d'entrée vidéo: Ce port peut être connecté aux joueurs OLD, lecteurs de DVD, des caméras et un autre lecteur vidéo vidéo (VIDEO), la prise de sortie audio. Sortie audio: Le signal audio à partir du port de sortie du projecteur, comme une puissance élevée à...
Page 39
sélectionnez une vidéo ou des chiers d'image dans le mode de prévisualisation vidéo, appuyez sur la télécommande "/ play pause" pour plein écran. Fonctionnement et utilisation du projecteur Utilisation du menu Alummer/Éteindre Mettez la machine Appuyez sur la touche d'alimentation sur la couverture ou de la télécommande, la couleur du clignotant, la machine en état de fonctionnement normal.
Input Source Select Appuyez sur "SOURCE" pour entrer dans l'interface de sélection de la source. Appuyez sur "▲""▼"pour sélectionner le signal d'entrée souhaitée à partir du PC, AV HDMI, SD, USB Appuyez sur pour con rmer le type de signal d'entrée. PC: Entrée de signal PC HDMI:Entrée de signal HD AV: Entrée de signal vidéo USB: Multimedia entrée de signal...
Réglage du menu Photo Menu standard Mode d'image Réglage du mode d'affichage de l'image. Température de Affichage de l'image couleur de réglage de la température de couleur. Image 4: 3, 16: 9, Ratio d'aspect Zoom ajustements. Réduction de Affichage de l'image bruit de réglage de réduction du bruit.
Menu Horloge Horloge Réglez l'heure actuelle de l'horloge Le temps d’ Off réglage de l'heure éteindre Le temps Le réglage de l'heure d’allumer Mise en Réglage de la minuterie de veille mise en veille Auto Aucun signal automatique sommeil COMPENSATION Con guration du menu Langue OSD Réglez l'affichage de la...
