10.19
DIV1
Division
Format
Summary of Operation
DIV1 Rm,Rn
1-step division
(Rn ÷ Rm)
Description
This instruction performs 1-digit division (1-step division) of the 32-bit contents of general
register Rn (dividend) by the contents of Rm (divisor). The quotient is obtained by repeated
execution of this instruction alone or in combination with other instructions. The specified
registers and the M, Q, and T bits must not be modified during these repeated executions.
In 1-step division, the dividend is shifted 1 bit to the left, the divisor is subtracted from this, and
the quotient bit is reflected in the Q bit according to whether the result is positive or negative.
The remainder can be found as follows after first finding the quotient using the DIV1 instruction:
(Remainder) = (dividend) – (divisor) × (quotient)
Detection of division by zero or overflow is not provided. Check for division by zero and overflow
division before executing the division. A remainder operation is not provided. Find the remainder
by finding the product of the divisor and the obtained quotient, and subtracting this value from the
dividend.
Initial settings should first be made with the DIV0S or DIV0U instruction. DIV1 is executed once
for each bit of the divisor. If a quotient of more than 17 bits is required, place an ROTCL
instruction before the DIV1 instruction. See the examples for details of the division sequence.
Operation
DIV1(long m, long n)
{
unsigned long tmp0, tmp2;
unsigned char old_q, tmp1;
old_q=Q;
Q=(unsigned char)((0x80000000 & R[n])!=0);
tmp2= R[m];
R[n]<<=1;
R[n]|=(unsigned long)T;
DIVide 1 step
/* DIV1 Rm,Rn */
Arithmetic Instruction
Instruction Code
0011nnnnmmmm0100 1
Rev. 2.0, 03/99, page 231 of 396
Execution
States
T Bit
Result of
calculation
