Specifications

Model
Input Rating
Power Input Connections & Wiring
Standby Power
Output Rating
Power Output
Cold-Load Pickup
Internal Residual
Current Detection
Upstream Breaker
Protection
Output Protection
Electrical Protection
Status Indicators
User Interface &
Control
Buttons/Switches
Operating
Temperature
Environmental
Humidity
Charging Cable Length 12 ft, straight cable
Ingress Protection
Mounting Type
Mechanical
Dimension (W x H x D)
Net Weight
Certificate
Regulation
Charging Interface
569217 | REV. A | 05.22.2013
EL-51245
208-240 Vac, 16 A 208-240 Vac, 30 A
L1, L2, and Ground, hardwired w/ terminal block
< 5 W
208-240 Vac, 16 A 208-240 Vac, 30 A
Randomized delay before charge resume after power failure
20 mA CCID per UL 2231
2-pole 20 A breaker
2-pole 40 A breaker on dedicated circuit,
on dedicated circuit,
non-GFCI type
non-GFCI type
Power output is terminated upon detection of charging connector
plug-out
Over current, short circuit, over voltage, under voltage, ground
fault, surge protection, over temperature
Standby (solid green), charging (flashing green), fault (solid red),
warning (flashing red)
ON/OFF switch, stop button
-22 o F to +122 o F (-30 o C to +50
95% relative humidity, non-condensing
18 ft, straight cable
Type 3R
Wall-Mount
13.8 x 15.7 x 5.0 inch (350 x 400 x 126 mm), excluding charging
cable and support bracket
15.4 lb (7 kg)
UL, cUL
SAE J1772 compliant charging plug
EL-51253 EL-51254
208-240 Vac, 30 A
208-240 Vac, 30 A
o C)
25 ft, straight cable
