Blu-ray Disc™ Player / HDD Recorder
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Please keep this manual for future reference.
• This Blu-ray Disc Player / HDD Recorder is for viewing and recording free to view channels
only. It does not receive pay TV or encrypted channels.
Region management information
BD-Video:
This unit can play BD-Video discs
supporting the region code "B".
e.g.,
GL

Operating Instructions

DMR-PWT520
Model No.
DVD-Video: This unit can play DVD-Video discs
supporting the region number "4"
or "ALL".
e.g.,
VQT4C70
