Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
• This Blu-ray Disc Recorder is for viewing and recording free to view channels only. It does not
receive pay TV or encrypted channels.
Software (Firmware) Update
GL
Blu-ray Disc™ Recorder
Blu-ray Disc technology and broadcast services continue to add new features.
As they evolve, firmware updates may be required to support the latest
features. Panasonic strives to continually update firmware as new technology is
released. It's very important you install the latest updates to maintain proper
operation of your unit.
For details, refer to "Software (Firmware) Update" (
http://panasonic.jp/support/global/cs/ (This site is in English only.)

Operating Instructions

DMR-BWT955
Model No.
95) or
SQT0801-1
