Page 1: Dome Camera
OWNER’S MANUAL Dome Camera Please read this manual carefully before operating your set and retain it for future reference. MODELS L9322 Series 1112 (V1.0) -
Page 2: Safety Information
Safety Information 1 Safety Information CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 3 Safety Information REGULATORY INFORMATION: FCC Part 15 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Safety Information LG Electronics hereby declares that this/these product(s) is/are in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/EC and 2009/125/EC. European Standards Centre: Veluwezoom 15, 1327 AE Almere, The Netherlands (Tel : +31-(0)36-547-8888) •...
-
Page 5: Important Safety Instructions
Safety Information IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 6: Safety Precautions
Safety Information Safety Precautions • Do not attempt to disassemble the camera To prevent electric shock, do not remove screws or covers. There are no user serviceable parts inside. Ask a qualified service personnel for servicing. • Avoid the camera with direct sunlight Do not aim the camera at bright objects. -
Page 7: Camera Installation Location
Safety Information Camera Installation Location Discuss the installation location for the camera with your retailer, and select a place that is strong enough for the installation. • Install the camera on a ceiling (concrete, etc.) at a location that is sufficiently strong to support it. •... -
Page 8: Table Of Contents
Table of Contents Table of Contents DIP Switch Setup Camera ID Setup Communication Protocol Setup Safety Information Baud Rate Setup IMPORTANT SAFETY INSTRUCTIONS Terminal Resistor Setup Safety Precautions Configuration for the Manufacturer Only Camera Installation Location Mounting the camera Never install or use the camera in the following locations Surface mount About Static Electricity Removal... - Page 9 Table of Contents Color Setting Factory Reset Sharpness Setting Appendix D-Effect Setting Specifications Stabilizer Setting Pan/Tilt Setting Preset Setting Group Tour Setting Pattern Setting Auto Pan Setting Swing Setting Privacy Mask Setting Special Setting OSD Settings LANGUAGE Setting ALARM Setting Alarm In Setting Alarm Out Setting RESET Setting...
-
Page 10: Preparation
Preparation 2 Preparation Features • High Sensitivity Support The camera provides the high quality picture with 4.5 mm CCD and XDI-II ISP. • Preset Position Preset position is the function to register camera monitoring positions (preset positions). By using LKD1000 controller, you can register presets with position number. Maximum 128 Preset Positions are available. - Page 11 Preparation • Swing Swing is the function that a camera scans between 2 preset positions. Swing speed between 2 preset positions can be adjusted. There are 8 Swings. • Auto Filp When the camera is operated to tilt through the 90°, it can be watched the opposite side of the locations by Auto Flip of a 180°...
-
Page 12: Package Component
Preparation Package Component Accessories for In-ceiling mount Main Body & Surface Mount Bracket [In-ceiling Plate, In-Ceiling Wire, Machine M4x50, Nut M4] Default Accessories [Main Cable, I/O Cable, Owner’s Manual, Screws : Tapping M4x16, Machine M3x8]... -
Page 13: Main Part Description
Preparation Main Part Description Mounting Screw Hole Surface Mount Bracket Main Connector Alarm I/O Connector Dome Cover Assembly Stud Dome Cover DIP Switch Dome Cover Do not detach the protection vinyl from the dome cover before finishing all the installation process to protect the dome cover from scratches or dust. Dome Cover Assembly Stud Used to line up the stud on the main body and the stud on the dome cover when assembling the dome cover with the main body. -
Page 14: Installation
Installation 3 Installation Precautions • The following steps of installation and connection work should be done by qualified service personnel or system installers and should conform to all local codes. • Before you install and connect the camera, check and prepare the required peripheral devices and cables. -
Page 15: Port Description
Installation Port Description • Main Cable Port Pin Number Connector / Wire Color Signal Video + BNC Connector Video - RS-485 + Yellow RS-485 - Orange Power + White Power - • Alarm I/O Cable Port Pin Number Wire Color Signal Blue IN COM +... -
Page 16: Dip Switch Setup
Installation DIP Switch Setup Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol. Camera ID Setup • ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value ex) ID=5 ex) ID=10... -
Page 17: Communication Protocol Setup
Reserved • Match the camera protocol with the camera protocol in the setting of your DVR or controller to control the camera. • Adjust the DIP switch after turning off the camera. • The factory default protocol is “LG Multix”. -
Page 18: Baud Rate Setup
Installation Baud Rate Setup • Select the baud rate with the DIP switch combination. Switch Mode Baud Rate Pin 2 Pin 3 Pin 4 9600 bps 2400 bps 4800 bps 19200 bps 38400 bps OSD Set Others Reserved • Match the baud rate with the camera’s one in the setting of your DVR or controller to control the camera. •... -
Page 19: Terminal Resistor Setup
Installation Terminal Resistor Setup The terminal resistor is used for the following cases. • In case that the control cable length between a camera and a controller is relatively very long (1:1 Connection) If the communication cable length is very long, the electrical signal will bound in the terminal point. This reflected signal causes distortion of original signal. -
Page 20: Configuration For The Manufacturer Only
Installation Configuration for the Manufacturer Only • DO NOT CONFIGURE! This configuration is to upgrade its firmware by the manufacturer only. • It must be always set to ON. Mounting the camera Surface mount Remove the ceiling tile from the ceiling and cut a hole whose diameter is 30~40mm on the ceiling tile to pass the wires and cables through to the upside of the ceiling. -
Page 21: Surface Mount
Installation Prepare the surface mount bracket. Pull the wires and cables for the system as below. Attach the surface mount bracket to the mounting surface. (Tapping M4x16) - Page 22 Installation Connect the wires and cables to the ports and install the main body. (Machine M3x8)
- Page 23 Installation Align the dome cover stud with the dome cover assembly stud and slightly push the dome cover to the ceiling. Turn the dome cover clockwise and remove the protection vinyl from the dome cover.
-
Page 24: In-Ceiling Mount
Installation In-ceiling mount Remove the ceiling tile from the ceiling and cut a hole whose diameter is 113 mm. Cut three holes for M4 screws, and install the main body with the In-Ceiling Plate, the three screws (M4x50) and the three nuts (M4). Then install the ceiling tile to the ceiling and connect the main cable to the main port. - Page 25 Installation Align the dome cover stud with the dome cover assembly stud and slightly push the dome cover to the ceiling tile. Then remove the protection vinyl from the dome cover.
-
Page 26: Operation
4 Operation Menu navigation We use the LKD1000 controller in this manual to explain the features of the LG Dome camera because of the LKD1000’s ability to control all of the LG Dome camera’s advanced features. (For detailed controller instructions,... -
Page 27: Setup Menu Overview
Operation Setup Menu Overview The following table shows the list of menu items and options. You can adapt the camera to your requirements by setting up the respective items in these menus. 1st level 2nd level 3rd level Contents CAMERA SET FOCUS FOCUS MODE AUTO/MANUAL/ONE PUSH/ZOOM TRIG... - Page 28 Operation 3D-DNR OFF/LOW/ MIDDLE/HIGH COLOR LEVEL -20 to 20 RETURN SHARPNESS 0~68 D-EFFECT OFF/V-FLIP/ MIRROR/ROTATE STABILIZER OFF/ON RETURN PAN/TILT SET PRESET SET PRESET NAME ON/OFF SPEED 1/SEC,10/SEC, …, 360/SEC, …, 500/SEC DWELL TIME 1 SEC to 255 SEC IRIS AUTO/20/40/60/80/100% WDR/BLC/HSBLC OFF/LOW WDR/ MID.
- Page 29 Operation GROUP TOUR SET GROUP 1 to 9 1 to 9 CLEAR 1 to 9 RETURN PATTERN RECORD 1 to 4 1 to 4 RETURN AUTO PAN SET AUTO PAN 1 to 8 CLEAR RETURN SWING SET SWING(1 to 8) POSITION 1 PRESET 1 to PRESET128 POSITION 2 PRESET 1 to PRESET128...
- Page 30 AUTO FLIP OFF/ON MOTION DET SENSITIVITY 0 to 100 WIDTH 2 to 8 HEIGHT 2 to 6 MOVE X 1 to 7 MOVE Y 1 to 5 RETURN COMMUNICATION PROTOCOL LG-Multix/Pelco-D/Pelco-P/ Pelco-C BAUD RATE 2400/4800/9600/19200/38400 SAVE & EXIT RETURN RETURN...
- Page 31 Operation RETURN OSD SET USER TITLE OFF/ON ZOOM MAG OFF/ON FUNCTION OFF/ON OFF/ON RETURN LANGUAGE ENG/ 한국어/ 中文/日本語 ALARM SET ALARM IN NORMAL OPEN/CLOSE (1~3) ALARM IN(1 to 3) PRESET 1 to PRESET128 DWELL TIME 3SEC to 255 SEC RETURN ALARM OUT ALARM OUT ALARM IN 1 to 3/MOTION DET...
-
Page 32: Menu Settings
Operation Menu settings Camera menu settings Focus setting The camera adjusts the focus automatically by sensing the center of the picture. Focus mode Select [FOCUS MODE] option on the [FOCUS] menu and then select the following mode. • AUTO: Auto-focus is activated automatically. •... - Page 33 Operation IRIS setting Select the desired lens iris value for camera exposure. Select [IRIS] option on the [EXPOSURE] menu, then select a value. • AUTO: The lens iris is set automatically. • MANUAL: Use [Near] or [Far] button to select the DC Iris level. DC Iris level are set by one parameter unit.
- Page 34 Operation HSBLC LEVEL: Select the HSBLC level. (0~5) COLOR: Use [Near] or [Far] button to select a color. • OFF: Not used. Brightness Setting You can increase the brightness of the darkened video. If you set the brightness to lower value, the image is darkened.
-
Page 35: White Balance Setting
Operation White Balance Setting Select the method by which the camera shifts its output colors to compensate for the color of a light source Select [WHITE BALANCE] option on the [CAMERA SET] menu. Use [Near] or [Far] button to select a mode then press [Open] or [Close]. •... -
Page 36: Day/Night Setting
Operation • MANUAL: You can set the white balance options manually. COLOR TEMP: Use [Near] or [Far] button to select a function. > INDOOR: The color temperature range for the proper white balance is approximately 3600K. > OUTDOOR: The color temperature range for the proper white balance is approximately 6500K. -
Page 37: 3D-Dnr Setting
Operation • AUTO: You will be able to change the Day/Night mode automatically. D/N LEVEL: Use [Near] or [Far] button to select a level. DWELL TIME: Use [Near] or [Far] button to select a dwell time. • DAY: Color mode enabled. •... - Page 38 Operation Use [Near] or [Far] button to select an option. Note • If you set the AGC to [OFF] on the [EXPOSURE] menu, the [3D-DNR] function is not available. • When you use this function, the afterimage may occur. Color Setting You can switch the displayed picture to grayscale or color.
-
Page 39: Sharpness Setting
Operation Sharpness Setting Sharpens the image outline. Select [SHARPNESS] option on the [CAMERA SET] menu. Use [Near] or [Far] button to adjust the option. If you set the sharpness value to higher, the image outline becomes sharp. If you set to lower value, the image outline becomes dim. D-Effect Setting Configures a digital effect to be used in video images. -
Page 40: Stabilizer Setting
Operation Stabilizer Setting Select [STABILIZER] option on the [CAMERA SET] menu. Use [Near] or [Far] button to set up the [ON] or [OFF]. Pan/Tilt Setting Preset Setting Preset position is the function to register camera monitoring positions (preset positions) associated with position numbers. - Page 41 Operation To register preset positions Select the [SET PRESET] option on the [PRESET] menu Use the [Near] or [Far] button to select the preset number you wish to register and press the [Open] or [Close] button. Set the preset name. How to set the preset name Set the NAME option to [ON] and press [Open] or [Close] button.
- Page 42 Operation 10. Move the camera to a point you wish by using the joystick and then press [Open] or [Close] button to save it. 11. Select [SAVE] option and press [Open] or [Close] button to confirm the settings. The position and its number are memorized.
-
Page 43: Group Tour Setting
Operation Group Tour Setting You can create a group using preset positions that are registered already. A maximum of 9 groups is available. To set the group Select [SET GROUP] option on the [GROUP TOUR] menu. Select the group number and press [Open] or [Close] button. Set the group item. -
Page 44: Pattern Setting
Operation To tour the group You can tour the group that is registered already. Select [RUN] option on the [GROUP TOUR] menu. Select the group number and press [Open] or [Close] button. The camera moves to the preset position in the group and the picture of the camera in that position appears on the monitor. To delete a group You can delete a memorized group. -
Page 45: Auto Pan Setting
Operation To play the pattern Select [RUN] option on the [PATTERN] menu. Select the recording number and then press [Open] or [Close] button to play the programmed pattern. The tour will play indefinitely until you stop it by moving the joystick or pressing any button. -
Page 46: Swing Setting
Operation Select the [SET POSITION] option and press [Open] or [Close] button. Move the camera to the desired position by using the joystick and then press [Open] or [Close] button. Select the [SAVE] option and press [Open] or [Close] button. Select the [RETURN] option and press [Open] or [Close] button. - Page 47 Operation To set the Swing Select a Swing to be configured in [Swing] menu with [Near] and [Far] button. Then press [Open] button or [Close] button to configure the Swing Select a preset in [POSITION 1]. Select another preset in [POSITION 2]. Configure a speed between the 2 selected presets in [SPEED].
-
Page 48: Privacy Mask Setting
Operation To play the Swing Select [RUN] in [Swing] menu to run a Swing Select a Swing to run with [Near] and [Far] button and press [Open] button or [Close] button. A camera scans the 2 pre-defined presets. To delete the Swing You can delete a memorized swing. -
Page 49: Special Setting
Operation Select the [HEIGHT] option and use [Near] or [Far] button to adjust the vertical size of the mask zone box. 10. Repeat steps 3 to 9 to add additional positions. Note If you change the color of a mask, the color of all masks will be changed. Special Setting Propotional PT This function optimizes the image by automatically adjusting the PAN/TILT (horizontal/vertical rotation) - Page 50 Operation Home position The home position is the camera’s basic position. The camera returns to this position whenever you want. Use the following procedure to make the home position. Select [HOME POSITION] option on the [SPECIAL] menu. Use [Near] or [Far] button to set it ON. Press [Open] or [Close] button.
- Page 51 Operation Note If you set the [AUTO RETURN] to [ON], the [HOME POSITION] option is set to [OFF] automatically and you can not use it. Tilt Limit To remove block area on videos, tilt angle limit can be configured. Select [TILT LIMIT] in [SPECIAL]. To turn on this function, select [ON] with [Near] button or [Far] button.
- Page 52 Operation Adjust center of detection area with [Near] button or [Far] button in [MOVE X] and [MOVE Y] option. Select [RETURN] and exit [MOTION DET] menu with [Open] button or [Close] button. Note • Even though Motion Detection function is set to [ON], Motion Detection function does not work in the following cases.
-
Page 53: Osd Settings
Operation OSD Settings User Title Setting You can use the camera identification to assign a number and character to the camera. Select [USER TITLE] option on the [OSD] menu. Use [Near] or [Far] button to set it [ON]. Press [Open] or [Close] button. The USER TITLE menu appears. Use [In], [Out], [Near] or [Far] button to select a character, number, symbol mark or option item. - Page 54 Operation ZOOM MAG Setting Displays or removes the zoom OSD on the screen. Select [ZOOM MAG] option on the [OSD] menu. Use [Near] or [Far] button to set it [ON] or [OFF]. Select [RETURN] option and press [Open] or [Close] button to exit the setting menu FUNCTION Setting Displays or removes the Function OSD on the screen.
-
Page 55: Language Setting
Operation DOME ID Setting Displays or removes the Camera ID OSD on the screen. Select [DOME ID] option on the [OSD] menu. Use [Near] or [Far] button to set it [ON] or [OFF]. Select [RETURN] option and press [Open] or [Close] button to exit the setting menu LANGUAGE Setting Select a language for the setup menu and OSD display. -
Page 56: Alarm Setting
Operation ALARM Setting This camera has a terminal that can sense the alarm signals. The camera can be programmed to go to a preset with a signal from any connected alarm device. Function status Mode While observe a specific Change the observe position to the alarmed position then return to the position position that previously observed. -
Page 57: Alarm In Setting
Operation Alarm In Setting Select one of the alarms in option on the [ALARM SET] menu. Use [Near] or [Far] button to set it [ON]. Press [Open] or [Close] button. Select [NORMAL] option and select [Open] or [Close] option. • OPEN: Activate the alarm in the close position. -
Page 58: Reset Setting
Operation Select alarm input number or motion detection on the [ALARM OUT] option. When the selected function is activated, the alarm signal is outputted. Select [DWELL TIME] option and then set the alarm dwell time. The alarm output is stopped after selected dwell time. -
Page 59: Initialization
Operation Initialization You can reboot the camera. Select [INITIALIZATION] option on the [RESET] menu. Press [Open] or [Close] button then confirmation window is displayed. Select [YES] and press [Open] or [Close] button. Factory Reset Clear certain settings and information and return to factory default settings. Select [FACTORY RESET] option on the [RESET] menu. - Page 60 Appendix 5 Appendix Specifications Camera Part Model L9322-BN L9322-BP Signal System NTSC Pick-Up Device 4.5 mm (1/4 Type) CCD Total Pixel No 520 000 Pixels 610 000 Pixels Effective Pixel No 480 000 Pixels 570 000 Pixels Horizontal Resolution 600 TV Lines Lens 12X, F1.6 (Wide), F2.7 (Tele) f=3.80 mm to 45.6 mm S/N Ratio...
- Page 61 4 pattern (920 commands/pattern) Swing 8 Swings Group Tour 9 Group (8 actions/group) Communication RS-485 Protocol LG-Multix, Pelco-D, Pelco-P, Pelco-C Motion Detection Sensitivity, Area Adjustable Alarm Input 3 channels Alarm Output 1 channel Video Output Composite Output 1 Vp-p (75 Ω Terminated) Operating Temperature -10 ˚C to 50 ˚C (Humidity 0 % to 80 %RH)
