2.5 Accessories

The transceiver can be used with one or more of the accessories listed in
Table 1. Contact the factory for ordering details.
Accessory Description
AC Power
Adapter
2-Pin DC Power
Plug
Fuse (Internal)
Omnidirectional
Antennas
900 MHz
Yagi Antennas
2400 MHz
Antennas
900 MHz
Bandpass Filter
TNC-to-N
Adapter Cable
(3 ft./1 meter)
TNC-to-N
Adapter Cable
(6 ft./1.8 meter)
TNC-to-N RF
Adaptor Plug
RS/EIA-232
Cable
RJ-11 to DB-9
Adapter Cable
Flat-Surface
Mounting
Brackets
Mounting
Bracket Screws
19-Inch Rail
Mounting
Brackets
DIN Rail Mtg.
Brackets
MDS 05-2708A01, Rev. F
Table 1. Accessories
Small power supply module designed for con-
tinuous service. UL approved.
Input: 120/220 Vac
Output: 12 Vdc @ 500 mA (20 Watts)
Mates with power connector on the transceiver.
Screw terminals are provided for wires.
Fuse, 2A SMF Slo-Blo
Rugged antennas suited for use at Master
stations. Consult the factory for details.
Rugged directional antennas suited for use at
Remote stations. Consult the factory for details.
Rugged directional antennas suited for use at
Remote stations.
Antenna system filter to aid in eliminating inter-
ference from paging system transmissions.
Coaxial cable used to connect the radio's TNC
antenna connector to a Type-N style commonly
used on large-diameter coaxial cables.
Coaxial cable used to connect the radio's TNC
antenna connector to a Type-N style commonly
used on large-diameter coaxial cables.
Adapts radio's antenna connector to Type-N
style commonly used on large-diameter coaxial
cables.
Shielded data cable fitted with DB-9 male and
DB-9 female, 6 ft./1.8 meter.
For connecting a PC terminal to the transceiver
via the radio's DIAG(nostics) connector. Used
for programming and diagnostics.
Brackets: 2˝ x 3˝ plates designed to be screwed
onto the bottom of the transceiver for sur-
face-mounting the radio.
Screws: 6-32/1/4˝ with locking adhesive.
(Industry Standard MS 51957-26)
Adaptor for mounting the radio in a standard
19-inch equipment rack.
Adaptor for mounting the radio in a standard
19-inch equipment rack.
MDS TransNET Ref. Manual
Part No.
01-3682A02
73-1194A39
29-1784A03
Various;
Consult factory
Various;
Consult factory
Various;
Consult factory
20-2822A02
97-1677A159
97-1677A160
97-1677A161
97-1971A03
03-3246A01
82-1753-A01
70-2620-A01
Consult Factory
03-4022A01
5
