1.0 ABOUT THIS MANUAL

This manual presents installation and operating instructions of the
MDS TransNET 900™ and MDS TransNET 2400™ transceivers for use by
a professional installer. This person is expected to install, operate, and
perform basic system maintenance on the described radio. Following instal-
lation, we suggest keeping this manual near the equipment for future refer-
ence.
NOTE: If you have a board-only version of this product, the operating instructions in this
manual still apply, but refer also to the supplemental data at the back of this
manual (see

2.0 PRODUCT DESCRIPTION

The transceiver, shown in
license-free operation. These units employ Digital Signal Processing (DSP)
technology to provide highly-reliable long-distance communications, even in
the presence of weak signals or interference.
DSP technology also makes it possible to obtain information about radio
operation and troubleshoot problems, without going to the Remote radio site.
Using appropriate software at the Master station, diagnostic data can be
obtained on any DSP radio in the system, even while payload data is being
transmitted. (See
Page 49.)
The transceiver is housed in a compact and rugged die-cast enclosure that
need only be protected from direct exposure to the weather. It contains a
single printed circuit board with all necessary components for radio opera-
tion. No jumper settings or manual adjustments are required to configure the
radio for operation.

2.1 Transceiver Features

Listed below are several key features of the transceiver. These are designed
to ease the installation and configuration of the radio, while retaining the
ability to make changes in the future.
• 902–928 MHz operation using the TransNET 900
MDS 05-2708A01, Rev. F
Page 72).
Figure 1, is a spread spectrum radio designed for
"Performing Network-Wide Remote Diagnostics" on
MDS TransNET Ref. Manual
Figure 1.
MDS TransNET
Series Transceiver
