LG CED-8120B User Manual

Cd-r/rw drive
Hide thumbs Also See for CED-8120B:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
D E C L A R ATION OF CONFORMITY
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions : (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Trade Name/Model : LG or GoldStar/CED-8120B
Responsible Party :
Address:
Contact Person :
Equipment Classification : FCC Class B Peripheral Device(JBP)
Type of Product (EUT) : CD-R/RW Drive
Manufacturer : LG Electronics Inc.
W e hereby declare that the equipment bearing the trade and model
number specified above was tested conforming to the applicable FCC
Rules under the most accurate measurement standards possible, and
that all the necessary steps have been taken and are in force to assure
that production units of the same equipment will continue to comply
with the Commission s requirements.
LG Electronics U.S.A. Inc.
6133 N. River Road, Suite 1100
(Riverway Plaza) Rosemont, IL 60018
Mr. P. H. Byun, General Manager
Tel. No. (847) 993-4529
Address : 19-1, Cheongho-Ri, Jinwuy-Myon
Pyungtaek-Shi, kyunggi-Do, 451-713 Korea
Attention : Mr. T.K.Lee - General Manager
Multimedia Standards Team
i

Advertisement

Table of Contents
loading

Related Manuals for LG CED-8120B

Summary of Contents for LG CED-8120B

  • Page 1 : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Trade Name/Model : LG or GoldStar/CED-8120B Responsible Party : LG Electronics U.S.A. Inc. Address: 6133 N.
  • Page 2 CAUTION : The laser used in the CD-R/RW drive can damage your eyes. Do not attempt to open the cover. To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel. Use of controls or performance of procedures other than those specified here in may result in hazardous radiation exposure.
  • Page 3 Industry Canada requirement This class B digital apparatus meets all requirements of the Canadian Interference- Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. FCC COMPLIANCE STATEMENT Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4 CAUTION - INVISIBLE LASER RADIATION WHEN OPEN AVOID EXPOSURE TO BEAM. VARNING-OSYNLIG LASERSTRÄLNING NÄR DENNA DEL ÄR ÖPPNAD STRÄLEN ÄR FARLIG. CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT...

  • Page 5: Table Of Contents

    DirectCD v2.5b(s) Contents Introduction Features ........2 Important Precautions .

  • Page 6: Introduction

    DirectCD v2.5b(s) Introduction Thank you for Features purchasing this • Running OPC* gives a flatter writing signal that improves relia- CD-R/RW Drive. bility. • Easy-to-use tray model. • Enhanced-IDE (ATAPI) model. • Power tray loading and ejection of disc.(The disc can also be ejected manually.) •...

  • Page 7: Important Precautions

    DirectCD v2.5b(s) Important Precautions Follow these precautions when handling the drive or discs. Precautions • Please take notice that the manufacturer of this equipment does not offer any warranty against data loss due to inappropriate installation or handling, or direct or indirect damages. •...

  • Page 8: System Environment

    DirectCD v2.5b(s) System Environment Computer This unit can be operated in the system environment explained here. 233MHz (or faster) Pentium (for 12x speed, System 350MHz or faster recommended) requirements Memory Windows 98/95 : 32MB or greater. Windows NT Workstation Ver. 4.0: 32MB or greater (64MB or over recommended) Windows 2000:64MB or greater(128MB or over recommended)

  • Page 9: Location And Function Of Controls

    DirectCD v2.5b(s) Location and Function of Controls Front Panel Emergency Eject Hole Disc Tray Stop/Eject Button Play/Skip Button Headphone Jack Volume Drive Activity Indicators Control 1. Disc tray This is the tray for the disc. Place the disc on the ejected disc tray, then lightly push the tray (or push the eject button) and the CD will be loaded.
  • Page 10 DirectCD v2.5b(s) Analog Audio Output Rear Panel IDE Interface Connector Connector Power Jumper Connector Digital Audio Connector Output Connector 1. Power Connector Connects to the power supply (5-and 12-V DC) of the host computer. NOTE : Be careful to connect with the proper polarity. Connecting the wrong way may damage the system (and is not guaranteed).

  • Page 11: Installation

    DirectCD v2.5b(s) Installation Installing the Drive Before Before installing the drive, please note the following points. You will need the following: Installation • A screw driver of a suitable size to fit the securing screws for the drive unit. • The manual for the computer, so you can find the mounting positions for the IDE controller.
  • Page 12 DirectCD v2.5b(s) ″ drive bay panel from the computer. Refer to Mounting 1. Remove the 5 the manual for the computer for details. the Drive 2. Insert the drive unit into the bay. Do not apply excessive pressure to the cables inside the computer. 3.
  • Page 13 DirectCD v2.5b(s) Connecting Connect the 40 pin IDE cable to the back of the CD-R/RW Drive, making sure the coloured (red) stripe on the IDE cable is connected to pin 1 on the CD-R/RW drive. Interface NOTE : Generally, the IDE connector is keyed and will only fit one way.
  • Page 14 DirectCD v2.5b(s) Jumper Before installation, set the jumper on the jumper connector on the rear panel. Setup The drive can be connected as the Master or Slave on an EIDE (ATAPI) interface. When several (up to four) EIDE devices are con- nected, each must be set in a unique way.
  • Page 15 DirectCD v2.5b(s) The CD-R/RW drive connects to the motherboard of the host com- puter using an IDE interface cable. You may connect the CD-R/RW Connection Drive as a Slave or Master device, depending on your computer. To Install as To install the drive as a Master, the jumper can be left as supplied from the factory.
  • Page 16 DirectCD v2.5b(s) To Install as To install the drive as a Slave, change the jumper setting on the rear panel to SL. a Slave Drive Master drive (Booting hard disk) Slave drive (CD-R/RW drive) - OR - Master drive (Booting hard disk) Master drive (Other IDE drive) Slave drive...

  • Page 17: Device Drivers

    DirectCD v2.5b(s) Device Drivers When using Windows 95/98/2000 or Window NT Workstation Ver.4.0, no special device driver is required. ″ flop- This CD-R/RW drive is supplied with MS-DOS drivers on a 3 py disk. These drivers are required to use the CD-R/RW drive in DOS or to enable the CD-ROM disk.
  • Page 18 DirectCD v2.5b(s) Running 1. Insert the diskette into the appropriate drive. 2. Go to the floppy drive by typing A: or B: at the DOS prompt, as the Install appropriate. Program 3. Type the word INSTALL and press [ENTER]. (MS-DOS 4.

  • Page 19: Operation

    DirectCD v2.5b(s) Operation How to Use the Discs When using CD-ROM discs, CD-R discs or CD-RW discs, don’t attach any stickers or labels to the discs. Using discs with them attached not only causes read and write errors, but data on the disc may be lost due to damage to the disc itself.

  • Page 20: Appendix

    DirectCD v2.5b(s) Appendix Troubleshooting Before Before calling for service, check this list. • The drive doesn’t have power. Requesting • Is the power supply cable from the host computer plugged in? Service • Is the Power Connector to the drive securely attached? •...

  • Page 21: Specifications

    DirectCD v2.5b(s) Specifications Type Internal type (bare drive) Enhanced-IDE (ATAPI) Interface Data buffer memory 12cm, 8cm Disc diameter ∗ Sustained Data Transfer Rate Read : 14 to 32x CAV: 2.1MB to 4.8MB/sec Write : 2x: 300KB/sec. 4x: 600KB/sec. 8x: 1200KB/sec. 12x: 1800KB/sec.

  • Page 22: Warranty

    Internet Address : http :// www. LGEservice.com CD-R/RW LIMITED WARRANTY LG Electronics Inc. will repair or at its option replace*, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase.
